Master Garden Island Bar BBI-6 User manual

1
Island Bar Manual (BBI-6, BBI-8)
Parts List:
Island Bar Front Panel. Qty. 3,
(Panel 5) Wider Panel with 3
legs
(Panel 1, 6) Narrow Panel with
2 legs
Island Bar Side Panels qty 3
(Panel 2,3,4)
Island Bar Door Panel. Qty. 1
(Panel 9)
Inside Panel 7, 8 qty 2
Inside Panel 10, qty 1 Bamboo Shelves, qty.4 (1) 86” Long (ShelfB)
(2) 51” Long (ShelfC)
(3) 67.5” Long (ShelfA)
(4) 38” Long (ShelfD)
Hardware included:
4” Bolts– 10
5” Bolts– 18
5 5/8” Bolts– 8
Tools Needed:
Phillips Screw Driver
Wrench
Continue to setup instructions on the nextpage
Master Garden Products
3223 C. ST. NE Suite #1
Auburn, WA 98002
www.mastergardenproducts.com

2
1
C
5
6
10
9
7
84
3
2
B
A
D
Bamboo
dowel
1.) First setup the outside panels numbered 1-5 usingthe bolts provided (The sizes do vary
because of inconsistencies in the bamboo, longer bolts may be required. Use as required.
2.) Insert the Bamboo Dowels where indicated for shelves A and B, there will be two lev-
els of shelves that would need to be installed in each side. After setting up the dowels, the
bamboo shelves should slide right in.
Shelves C and D can be setup without dowel installation.
3.) Setup panel 9 with the doors, this panel can slide right in and is essential for settingup
the rest ofthe Island Bar.
4.) Afterwards,panels 6-10 that compromise the inside of the Island Bar can be installed.
The base frame should then be complete.
5.) Usingcounter pieces E, F, and G, install the bamboo countertop which will complete
your Bamboo Island Bar.
E
G
F
Setup Instructions
Bamboo Shelf Setup
