Master&Dynamic MW50 User manual

1
USER MANUAL — MW50 WIRELESS ON EAR HEADPHONES
EN / FR / ES / DE / PT / IT / KO

2 3
EN
SOUND TOOLS FOR CREATIVE MINDS
At Master & Dynamic our obsession is the interaction between
sound and creativity. Our passion is building beautifully designed,
technically sophisticated sound tools for creative minds.
For our MW50 On Ear Wireless Headphone we incorporated the same
industry leading technology found in our MW60 Over Ear Wireless
Headphone while designing a more compact, lighter-weight model.
We are very proud of the result -- a smaller form factor with
Master & Dynamic’s signature sound quality and user functionality.

4 5
EN
Our intuitive controls afford an elegant, tactile experience. Weight
distribution, fit and comfort are paramount. Our patent-pending antenna
provides best-in-class signal range for Bluetooth®connectivity distance.
TECHNOLOGY MEETS SOPHISTICATION

6 7
EN
We created a rich, warm sound signature from our custom 40mm
beryllium drivers. An expansive soundscape that perfectly captures
the exceptional detail that well recorded music has to offer. Our
tuning is designed to accommodate a diversity of tastes and
musical genres.
A RICH, WARM SOUND

8 9
EN
Our headbands are constructed with premium grain cowhide on
the exterior surface and lined with a soft lambskin. The ear pads
are made of memory foam, wrapped in lambskin, providing superior
comfort and breathability. Areas subject to heavy wear, such as the
ear pads, are built to last and be easily replaced as needed.
All high strain areas utilize stainless steel components. Our
innovative all-aluminum antenna enables maximum Bluetooth®
range, while incorporating an elegant design element. All metals
are anodized or PVD coated, not painted.
DESIGNED FOR DECADES OF USE

11
EN
OVERVIEW
SPECS
6
7
8
9
10
11
Aluminum Headband Connector
Premium Grain Leather Inlay
USB-C Input
Machined Aluminum Antenna
Noise Rejecting Microphone
Array
Headphone Controls (see
pages 14 – 18 for details)
Dimensions
Bluetooth®Profile
Weight
Impedance
190mm x 175mm x 60mm
Bluetooth®4.1 with AptX®
240g
32 ohms
Drivers
40mm Beryllium
High-Performance Drivers
Premium Grain Leather
Headband with Lambskin
Interior
Removable/Replaceable
Memory Foam Ear Pads
with Lambskin Covering
Forged Aluminum Components
3.5mm Passive Audio Input
Stainless Steel Adjustment Arm
1
2
3
4
5
10
1
6
5
8
11
9
10
11
7
3
4
2

12 13
EN
Adjust earcup post
to find optimal fit.
ADJUSTABILITY | FIT | COMFORT
Rotates for comfort
around neck.

M&D M&D
MFB
vol +
vol –
vol + (≥2sec)or
double press MFB
vol – (≥2sec)
15
EN
PASSIVE AUDIO
Plug 3.5mm audio plug into
headphone audio input to
engage passive audio
Headphone powers off
when audio cable is
plugged in
•
•
•
•
Audio will work even if battery
is depleted
Microphone is disabled during
passive mode
14
ENFUNCTIONS (AUDIO + TELEPHONE)
vol+
vol-
Multi Function Button
(MFB)
Audio
Telephone
Factory
Reset
Play/Pause
Vol up
Vol down
Next track
Previous
track
Answer call
End call
Ignore call
Digital
assistant /
voice dial
MFB
MFB
MFB (≥2sec)
MFB (≥2sec)
Hold down vol+ and vol-
(≥4 seconds)

16 17
EN
Charging
Plug in the USB-C
connector and connect
to a USB port to charge.
The headphone turns off
when the USB-C is plugged
in. Avoid using the device
while it is charging
A solid orange light
indicates charging and a
solid green light indicates
a full charge when the USB
cable is connected.
• •
•
Charging Full Charge
TURN ON AND CHARGE
•
•
•
To turn on the MW50 slide the switch
to the middle position.
Each time you turn on the headphone
the battery status will be displayed. To
recall battery status, slide switch to
for less than 2 seconds.
The headphone will automatically
search for previously connected
devices. A solid light indicates you
are connected. If no connection is
made after 2 minutes, the headphone
will enter deep-sleep mode. Cycle
power switch to awaken.
Low Battery
ON
Med Battery
Full Battery
Connected
A solid orange light
indicates charging and a
solid green light indicates
a full charge when the USB
cable is connected.
••
Charging

19
EN
PAIRING TO 2 DEVICES
How to pair with two devices
Enter pairing mode
Connect to device 1
Enter pairing mode again
Device 1 will disconnect
Connect to device 2
Turn headphone off
Turn headphone on, headphone
will automatically connect to
device 1 and 2 simultaneously
Pause one device and play
from the other to swap
headphone connection
1
2
3
4
5
6
7
8
18
•
•
ENPAIRING
Hold in position for 2 seconds,
light will pulse when headphone is
in pairing mode.
Access Bluetooth®settings
on your source device. Locate
MW50 and connect. A solid light
indicates you are connected.
If no connection is made after 2 minutes,
the headphone will enter deep-sleep mode.
Cycle power switch to awaken.
Pairing
Connected
Turn headphone off

M&DM&D
M&D M&D
21
EN
Ear pads are magnetized for easy removal/replacement. Reattach
ear pads by aligning the two guide posts on the earcup with the
guide holes on the inside of the ear pad. Simply hold the outside ring
of the ear pad and remove.
CHANGING/REMOVING EAR PADS
20
EN
ACCESSORIES
Cable 01: USB-C
Cable 02: 1.25m Straight Cable
Headphone Plug
Headphone Plug
Source Plug
Source Plug
Serial Number
RIGHT EARCUP
Canvas
Headphone Case
Leather
Cable Box

22 23
EN
The headphones and device
do not pair
Make sure the headphones
are not connected to the
charger. Cycle power switch
off and on.
Turn the Bluetooth®off, then
on again on the source device.
Turn off the Bluetooth®feature
on any other device that is
paired with the headphones.
Slide switch to and hold until
white light flashes.
MAINTENANCE AND TROUBLESHOOTING
Make sure “MW50" is selected
in the Bluetooth®device list
•
•
•
No audio or poor audio
quality from a connected
Bluetooth®device
Move the device closer to
the headphones, physical
objects between the
headphone and the source
may obstruct the signal.
Try another music application
or try another track.
Try a different audio device.
1
2
3
4
5
•Factory reset
Hold down vol+ and vol- for
≥4 seconds. Red and white
light flashes four times
Clean ear pads and
headphones with soft, slightly
damp cloth. Do not soak,
submerge or allow moisture
to enter near the drivers or
cable jacks. Ear pads and
cables can be purchased if
they are worn out at:
www.masterdynamic.com
Do not drop, sit on, or allow
the headphones to be exposed
to water, moisture, or
temperature extremes.
MAINTENANCE AND TROUBLESHOOTING
It is recommended that you
return your headphones to their
storage case when not in use.
To avoid damage, do not store
other items in the canvas case
along with your headphones.
CAUTION: Incorrectly rotating
or over rotating the earcups
can damage the headphones.
Temperature Range
Operate and store this product
within the temperature range
of -4°F to 113°F (-20°C to 45°C)
only. Charge the battery where
the temperature is between 41°F
and 104°F (5°C and 40°C) only.

24 25
EN
Our ability to hear is amazing. Treat your ears like the precious tools
they are, and they will continue to provide you with exceptional data, as
well as a lifetime of incredible sonic experiences.
In general, do not listen “too loud or for too long,” and be attentive to
your own ears. Ringing, discomfort, or sensitivity to high frequencies
and treble may be a signal from your ears that you are pushing them to
their limits and causing damage.
As a general practice, find what seems to be your preferred listening
level and then adjust the volume down another 10% or more.
Surprisingly, your ears will attune to a slightly lower volume over time,
and what seems quiet at first can be perfect for longer listening periods.
If you are interested in tuning your ear to have a more refined sonic
palate, there are some apps and training programs you can find online.
HEARING HEALTH AND FITNESS

26 27
EN
NIHL is a preventable condition caused by both one-time and
extended exposure to excessive decibel (dB) levels. This harm to
sensitive inner ear structures is irreversible and people of all ages
can be affected. Damage can happen in a single event or gradually
over time. One-time exposure to sounds louder than 110 decibels
and extended exposure to sounds over 85 decibels can cause harm.
Indicators of NIHL include hearing loss and tinnitus, a condition of
sensing constant ringing, buzzing or roaring. The NIDCD (National
Institute on Deafness and Other Communication Disorders) offers
this simple rule of thumb: avoid sound exposure that is “too loud,
too close or too long.” Here are some general references to sound
levels that occur in everyday life: refrigerator humming (45 dB);
normal conversation (60 dB); city traffic (85 dB); motorcycles
(95 dB); an MP3 player at full volume (105 dB); sirens (120 dB);
firecrackers (150 dB).
PREVENTION OF NIHL (NOISE INDUCED HEARING LOSS)

28 29
EN
Master & Dynamic guarantees this product against defects in materials
or workmanship for a period of two years from the date of original
purchase from an authorized Master & Dynamic retailer or reseller.
Master & Dynamic will either repair or replace the defective product
at our discretion if the product is returned within the warranty period.
This limited warranty is in lieu of all other warranties, expressed
or implied, including, but not limited to, any implied warranty of
merchantability or fitness for a particular purpose.
Master & Dynamic shall have no liability of any kind for any direct,
indirect, incidental or consequential damages or expenses
that arise from the use of this product. Master & Dynamic does not
cover normal wear and tear, blown drivers, cut cords, bent jacks,
torn headbands, loss or theft. You will void this warranty if you
disassemble your headphones or expose them to excessive moisture.
If you believe this product is defective within the warranty period,
contact us via our support page at www.masterdynamic.com/support. Once
your warranty is verified, you will be issued a return authorization and
instructions for return shipment. Proof of purchase may be required.
Products with unreadable or removed serial numbers will not be covered.
For questions regarding your product’s warranty, contact
Master & Dynamic Support at [email protected].
WARRANTY AND CUSTOMER SERVICE

30 31
FR
Chez Master & Dynamic, notre obsession est l’interaction entre
le son et la créativité. Notre passion est l’élaboration d’une belle
conception techniquement sophistiquée d’outils de son pour les
esprits créatifs.
Pour notre oreillette sans fil MW50, nous avons incorporé la même
technologie de pointe utilisée dans notre casque d’écoute sans fil
MW60 dans un modèle plus compact e plus léger. Nous sommes
très fiers du résultat – un petit facteur de forme avec une qualité
de son et une fonctionnalité d’utilisateur d’une signature de
Master & Dynamic.
OUTILS AUDIO POUR LES ESPRITS CREATIFS

33
FR
32
La sensitivité de nos commandes permet une expérience tactile de
haute qualité. La distribution du poids, la prise en main et le confort
sont de la plus haute priorité. Notre antenne, en attente de brevet,
offre la meilleure couverture de signal Bluetooth®disponible dans
cette gamme.
LA OU TECHNOLOGIE RENCONTRE LA SOPHISTICATION

35
FR
34
Nous créons une signature de son riche, chaude à partir de nos
drivers personnalisés en béryllium de 40 mm. Une ambiance sonore
expansive qui capte parfaitement le détail exceptionnel qu’une
musique bien enregistrée doit offrir. Notre réglage est destiné à
répondre à la diversité des gouts et des genres de musique.
UN SON RICHE ET CHALEUREUX

37
FR
36
Nos bandeaux sont fabriqués avec du cuir de vachette de qualité
supérieure la surface extérieure et doublée avec une peau d’agneau
très douce Les oreillettes sont faites de mousse à mémoire,
enveloppées dans de la peau d’agneau, pour fournir un confort
supérieur et une bonne aération. Les zones soumises à une usure
plus importante, sont fabriquées pour durer et être facilement
remplacées au besoin.
Toutes les zones à haute déformation sont fabriquées avec des
composants en acier inoxydable. Notre antenne innovante en
aluminium nous permet une portée Bluetooth®maximale, tout en
intégrant un design élégant. Tous les métaux sont anodisés ou
recouverts de PVD, non peints.
CONÇU POUR UNE UTILISATION PENDANT DES DECENNIES

39
VUE D’ENSEMBLE
CARACTERISTIQUES
7
8
9
10
11
Incrustation en cuir de
qualité supérieure
Entrée USB-C
Antenne en aluminium usiné
Ensemble de microphones à
élimination du bruit
Commandes des écouteurs
( voir pages 14 à 18 pour l
es détails )
Dimensions
Profil Bluetooth®
Poids
Impedance
Bluetooth®4.1 avec AptX®
32 ohms
Transducteurs
Béryllium de 40mm
Transducteurs de haute
performance
Bandeau en cuir de première
qualité doublé de peau d’agneau
Oreillettes à mémoire amovibles/
remplaçables recouvertes de
peau d’agneau
Composants en aluminium forgé
Entrée audio passive de 3,5mm
Bras de réglage en acier
inoxydable
Connecteur de serre-tête
en aluminium
1
2
3
4
5
6
38
FR
1
6
5
8
11
9
10
11
7
3
4
2
190mm x 175mm x 60mm
240g
