MasterCraft 4707.3 User manual

headline bars
continuation tabs
notes
warnings
model no. 060-1998-6
CORDLESS
BRUSHLESS LEAF BLOWER
IMPORTANT:
Read and understand this instruction manual thoroughly
before using the product.
INSTRUCTION
MANUAL

headline bars
continuation tabs
notes
warnings

headline bars
continuation tabs
notes
warnings
3
TABLE OF CONTENTS
Technical Specifications 4
Safety Guidelines 5
Key Parts Diagram 10
Operating Instructions 11
Maintenance 13
Troubleshooting 14
Parts List 15
Warranty 17
NOTE:
If any parts are missing or damaged, or if you have any questions,
please call our toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
• This manual contains important safety and operating instructions. Read all
instructions and follow them when using this product.
TABLE OF CONTENTS

headline bars
continuation tabs
notes
warnings
model no. 060-1998-6 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rated Voltage 20 V d.c.
Maximum Air Volume 410 CFM
Maximum Air Speed 100 MPH
*Maximum battery voltage without workload; with workload nominal voltage is 18 V.
Recommend using tool with Mastercraft® 20V max* Lithium-Ion 4.0 Ah battery (054-7557-6; sold
separately) for optimal performance.
NOTICE: The blower is intended for household or commercial use.

headline bars
continuation tabs
notes
warnings
5
SAFETY GUIDELINES
WARNING!
Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do not,
by themselves, eliminate any danger, nor are they substitutes for proper accident prevention
measures.
WARNING!
This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.
KNOW YOUR TOOL
To operate this tool, carefully read this Instruction Manual and all labels affixed to the cordless blower
before using. Keep this instruction manual available for future reference.
IMPORTANT SAFETY INSTRUCTIONS
This tool should only be serviced by a qualified service technician. For more information, call the
toll-free helpline at 1-800-689-9928.
READ ALL INSTRUCTIONS BEFORE USING.
SAVE THESE INSTRUCTIONS.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
6
model no. 060-1998-6 | contact us 1-800-689-9928
ELECTRICAL SAFETY
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of an GFCI reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while operating power tools may result in
serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have the
switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
• Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe injury
within a fraction of a second.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
7
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or remove the battery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits, etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
• Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, seek additional
medical help. Liquid ejected from the battery may cause irritation or burns.
• Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause an explosion.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
8
model no. 060-1998-6 | contact us 1-800-689-9928
• Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
SERVICE
• Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service providers.
SAFETY INSTRUCTIONS FOR BLOWER
• Know your power blower. Read the instruction manual carefully. Learn the blower’s
applications and limitations, as well as the specific potential hazards related to this
blower. Following this rule will reduce the risk of electric shock, fire, or serious injury.
• Do not allow the blower to be used as a toy. Close attention is necessary when used by or
near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• If the blower is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, return it to a service centre.
• Do not handle the charger, including charger plug, or charger terminals, with wet hands.
• Do not put any object into any openings. Do not use with any opening blocked; keep
openings free of dust, lint, hair, and anything that may reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts. Loose clothes, jewellery, or long hair can be drawn into air vents.
• Secure long hair above shoulder level to prevent entanglement in moving parts.
• Use extra care when cleaning on stairs.
ADDITIONAL SAFETY GUIDELINES FOR BLOWER
• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V ..................... Volts
A ..................... Amperes
W .................... Watts
min ................. Minutes
or d.c. ... Direct current
n0................... No-load speed
............... Class II Construction
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
9
CFM ................ Cubic feet per minute
MPH ................ Miles per hour
................ WARNING – To reduce the risk of injury, user must read instruction manual.
................ WARNING – To reduce the risk of injury, always wear eye protection.
................ WARNING – To reduce the risk of injury, always wear ear protection.
......... The logo of UL certification
WARNING!
To reduce the risk of electric shock or damage to the charger and battery, use only the
Mastercraft®batteries and chargers listed.
BATTERY PACKS CHARGERS
054-3124-0, 054-7553-4, 054-7557-6 054-3126-6, 054-7559-2
• For best results, your battery and tool should be stored, charged, and used in a
location where the temperature is more than 5°C (41°F) but less than 40°C (104°F). Do
not store outside or in vehicles.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
model no. 060-1998-6 | contact us 1-800-689-9928
10
PACKAGE CONTENTS:
Cordless blower, blower tube.
KEY PARTS DIAGRAM
2
3
1
No. Description No. Description
1 Blower tube 3 Variable-speed trigger switch
2 Trigger-lock lever
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the following operating instructions carefully
before using.
KEY PARTS DIAGRAM
WARNING!
• Remove the blower from the package and examine it carefully. Do not discard the carton or any packaging material until all
parts have been examined.
• If any part of the blower is missing or damaged, do not attach the battery pack to the tool or use the tool until the part has
been repaired or replaced. Failure to heed this warning could result in serious injury.
• Do not allow familiarity with the blower to cause a lack of alertness. A fraction of a second of carelessness is enough to cause
severe injury.
FPO

headline bars
continuation tabs
notes
warnings
11
OPERATING INSTRUCTIONS
TO ATTACH BATTERY PACK (fig 1)
1. Make sure that the switch is in the OFF position.
2. Align the raised portion on the battery pack with the
grooves on the bottom of the tool, and then slide the
battery pack onto the tool as shown.
3. Ensure that the battery-release button on the
battery pack snaps into place and that battery pack
is secured to the tool before beginning operation.
TO DETACH THE BATTERY PACK (fig 1)
1. Ensure that the switch is in the OFF position.
2. Depress the battery-release button located on the front of the battery pack to release the battery pack.
3. Pull rearward on the battery pack to remove it from the tool.
ASSEMBLING THE BLOWER TUBE (fig 2)
This product requires assembly before using. To
prevent accidental starting that could cause serious
personal injury, always remove the battery pack
from the tool when assembling parts.
1. Align the flat surface on the blower tube with the
flat place on the top of blower housing, and then
insert the tube into the blower housing.
2. To remove the blower tube, just pull it straight out
from the blower.
OPERATING INSTRUCTIONS
WARNING!
• To avoid the possibility of accidental starting, always take care not to activate the variable-speed trigger
switch when you are attaching the battery pack or performing other adjustments to the tool.
FPO
NOTICE: When placing a battery pack on the tool, be sure that the raised rib on the battery pack aligns with the groove on
the cordless blower and the latches snap into place properly. Improper assembly of the battery pack can cause damage to internal
components.
fig 1 Battery-release
button
Blower
tube
fig 2

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
12
model no. 060-1998-6 | contact us 1-800-689-9928
TO TURN THE BLOWER ON (fig 3)
1. To turn the blower on, depress the variable-speed
trigger switch.
2. The variable-speed trigger switch delivers higher
speed with increased trigger pressure and lower
speed with decreased trigger pressure.
3. To lock the blower on the chosen speed, move the
trigger-lock lever toward the back of the tool.
4. The trigger-lock lever can also be pulled back to
start the blower without needing to first depress the
variable-speed trigger switch. The blower runs at
higher speeds as the lever is moved further back.
TO TURN THE BLOWER OFF (fig 3)
1. If the trigger-lock lever is not engaged, release the variable-speed trigger switch to turn off the blower.
2. If the trigger-lock lever is engaged, move the trigger-lock lever forward to the unlocked position to turn
off the blower.
HANGING HOLE (fig 4)
The blower is equipped with a hanging hole. The
blower can be hung from a screw or nail for storage.
TIPS FOR OPERATING THE BLOWER
1. Always wear eye protection with side shields
marked to comply with ANSI Z87.1, along with
hearing protection. Failure to do so could result
in objects being thrown into your eyes and other
possibly serious injuries.
2. To keep from scattering debris, blow around the
outer edges of a debris pile. Never blow directly into the centre of a pile.
3. Use rakes and brooms to loosen debris before blowing it to clear it. In dusty conditions, slightly dampen
surfaces if water is available.
4. Watch out for children, pets, open windows, or freshly washed cars and blow debris safely away.
OPERATING INSTRUCTIONS
fig 3 Trigger-lock
lever
Variable-speed
trigger switch
fig 4 Hanging hole

headline bars
continuation tabs
notes
warnings
13
headline bars
continuation tabs
notes
warnings
MAINTENANCE
The tool may be cleaned most effectively with compressed dry air. Always wear safety goggles when
cleaning tools with compressed air.
Before each use:
•
Check for damaged, missing, or worn parts.
• Check for loose screws, misalignment or binding of moving parts, or any other condition that may affect the
operation.
• If abnormal vibration or noise occurs, turn the tool off immediately and have the problem corrected before
further use.
WARNING!
• Do not allow brake fluids, gasoline, petroleum-based products, penetrating oil, etc., to come into contact with
plastic parts. These substances contain chemicals that can damage, weaken, or destroy plastic.
• When servicing, use only identical replacement parts. The use of any other parts may create a hazard or
cause damage to the product.
• Use only accessories that are recommended for this blower by the manufacturer. Accessories that may be
suitable for one tool may become hazardous when used with another tool.
• To ensure safety and reliability, all repairs should be performed by a qualified service technician.
FPO
MAINTENANCE

headline bars
continuation tabs
notes
warnings
model no. 060-1998-6 | contact us 1-800-689-9928
14
TROUBLESHOOTING
Problem Possible causes Solutions
The blower does
not work.
The battery pack is depleted. Charge the battery pack.
The battery pack or blower is too
hot.
Turn off the blower and allow the
blower and battery pack to cool.
The air velocity is noticeably
decreased. The air inlet is blocked by debris. Remove the battery pack and clear the debris.
If the problem remains unsolved after performing the checks described above, call the toll-free helpline
at 1-800-689-9928.
TROUBLESHOOTING

headline bars
continuation tabs
notes
warnings
15
EXPLODED VIEW
PARTS LIST

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
16
model no. 060-1998-6 | contact us 1-800-689-9928
No. Part No. Description No. Part No. Description
1 2830617000 Electric Assembly 11 5610021000 Tapping Screw
2 5610294000 Tapping Screw 12 2825518000 Ducted Set
3 3129093000 Tube 13 3660013000 Spring1
4 3128762000 Speed Adjusting Knob 14 5650519000 Rubber Gasket
5 5650058000 Wave Washer 15 5620176000 Screw With Washer
6 3128759000 Intermediate Wheel 16 3706390000 Clamp Washer
7 5650006000 Plain Washer 17 4970333000 Static Dissipation
Assembly
8 5650008000 Spring Washer 18 3127472000 Fan Baffle
9 3128761000 Switch Trigger 19 3127466000 Right Cover
10 3650227000 Anti-static Bar 20 3900240000 L R Housing Set
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline
at 1-800-689-9928.
PARTS LIST

headline bars
continuation tabs
notes
warnings
17
headline bars
continuation tabs
notes
warnings
This product is guaranteed for a period of 3 years from the date of original retail purchase
against defects in workmanship and materials, except for the following components:
a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years
from the date of original retail purchase against defects in workmanship and materials;
b) Component B: Accessories, which are guaranteed for a period of 1 year from the date of original
retail purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us with proof
of purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear the
cost of any repair or replacement and any costs of labour relating thereto.
These warranties are subject to the following conditions and limitations:
a) a bill of sale verifying the purchase and purchase date must be provided;
b) this warranty will not apply to any product or part thereof which is worn or broken or which has
become inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation,
operation or maintenance (as outlined in the applicable owner’s manual or operating instructions) or
which is being used for industrial, professional, commercial or rental purposes;
c) this warranty will not apply to normal wear and tear or to expendable parts or accessories that
may be supplied with the product that are expected to become inoperative or unusable after a
reasonable period of use;
d) this warranty will not apply to routine maintenance and consumable items such as, but not limited
to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids, tune-ups or adjustments;
e) this warranty will not apply where damage is caused by repairs made or attempted by others (i.e.,
persons not authorized by the manufacturer);
f) this warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless otherwise specified in writing);
g) this warranty will not apply to any product or part thereof if any part from another manufacturer
is installed therein or any repairs or alterations have been made or attempted by unauthorized
persons;
WARRANTY

headline bars
continuation tabs
notes
warnings
18
model no. 060-1998-6 | contact us 1-800-689-9928
WARRANTY
h) this warranty will not apply to normal deterioration of the exterior finish, such as, but not limited
to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical
cleaners; and
i) this warranty will not apply to component parts sold by and identified as the product of another
company, which shall be covered under the product manufacturer’s warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor
the manufacturer shall be liable for any other expense, loss or damage, including, without limitation,
any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or
inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify, take
away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or federal
legislation.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8
