MasterForce CUB401 User manual

OPERATOR’S MANUAL
80V BRUSHLESS
CULTIVATOR
270-2454
2800194ME
CUB401
To Reduce The Risk Of Injury, User Must Read
CAUTION
And Understand Operator’s Manual. Save These Instructions For
Future Reference.

TABLE OF CONTENTS
Safety Symbols........................................................................................................... Page 2
Safety Instructions ...................................................................................................... Page 3
Overview..................................................................................................................... Page 7
Assembly .................................................................................................................... Page 8
Operation.................................................................................................................. Page 10
Maintenance / Troubleshooting................................................................................. Page 11
Notes ........................................................................................................................ Page 12
Warranty ................................................................................................................... Page 14

Page 2
SAFETY SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better
and safer.
Symbol Name Designation / Explanation
VVolts Voltage
AAmperes Current
Hz Hertz Frequency (cycles per second)
Direct Current Type or a characteristic of current
Safety Alert Precautions that involve your safety.
Read The Operator’s Manual
To reduce the risk of injury user must read and
understand operator’s manual before using this
product.
Cutting Hazard Keep feet and hands away from rotating tines.
Wet Conditions Alert Do not expose the product to rain or moist
conditions.
Ricochet Thrown objects can ricochet and result in
personal injury or property damage.
Wear eye and ear protection Failure to keep loose clothing from being drawn
into air intake could result in personal injury.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.

Page 3
SAFETY INSTRUCTIONS
The purpose of safety symbols is to attract our attention to possible dangers. The safety
symbols, and the explanations with them, deserve your careful attention and understanding.
The symbol warnings do not by themselves eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures.
Failure to obey this safety warning CAN result in death or serious
injury to yourself or to others. Always follow the safety precautions to reduce the risk of
re, electric shock and personal injury.
WARNING
Failure to obey this safety warning MAY result in personal injury
to yourself or others or property damage. Always follow the safety precautions to
reduce the risk of re, electric shock and personal injury.
CAUTION
Failure to obey this warning WILL result in death or serious injury
to yourself or to others. Always follow the safety precautions to reduce the risk of fire,
electric shock and personal injury.
DANGER
Be sure to read and understand all safety instructions in this
manual, including all safety alert symbols such as “DANGER”, “WARNING” and
“CAUTION”, before using this power tool. Failure to follow all instructions listed below
may result in electric shock, re and/or serious personal injury.
WARNING
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May be used
in conjuntion with other symbols or pictographs

Page 4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
READ ALL INSTRUCTIONS
BEFORE USING (THIS POWER
TOOL)
WARNING Read all safety
warnings and all instructions. Failure to
follow the warnings and instructions
may result in electric shock, re and/or
serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the
warnings refers to your batteryoperated
(cordless) power tool.
• Use Right Appliance – Do not use
appliance for any job except that for which
it is intended.
• Read the operator’s manual carefully. Be
thoroughly familiar with the controls and
the proper use of the equipment. Know
how to stop the unit and disengage the
controls quickly.
• Do not operate the machine in explosive
atmospheres, such as in the presence
of fammable liquids, gases, or dust. The
machine creates sparks which may ignite
the dust or fumes.
• Avoid body contact with grounded surfaces
such as pipes, radiators, ranges, and
refrigerators. There is an increased risk of
electric shock if your body is grounded.
• Avoid Dangerous Environment — Don’t
expose to rain or use machine in damp or
wet locations. Water entering the machine
will increase the risk of electric shock.
• Never allow children to operate the
equipment. Never allow adults to operate
the equipment without proper instruction.
• Always wear safety glasses with side
shields that comply with ANSI Z87 .1-
Everyday glasses have only impact
resistant lenses. They are NOT safety
glasses. Following this rule will reduce
the risk of eye injury. Use a face mask if
operation is dusty.
• Dress Properly – Do not wear loose
clothing or jewelry. They can be caught in
moving parts. Use of rubber gloves and
substantial footwear is recommended
when working outdoors. Wear protective
hair covering to contain long hair.
• Do not force the machine — Use the
correct tool for your application. The
correct tool will do the job better and safer
at the rate for which it is designed.
• Do not operate the equipment while
barefoot or when wearing sandals
or similar lightweight footwear. Wear
protective footwear that will protect your
feet and improve your footing on slippery
surfaces.
• Do not operate the machine while under
the inuence of alcohol or drugs.
• Do not overreach — Keep rm footing and
balance at all times. Overreaching can
results in loss of balance.
• Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to battery pack, picking up
or carrying the appliance. Carrying the
appliance with your nge on the switch or
energizing appliance that have the switch
on invites accidents.
• Avoid Unintentional Starting – Don’t carry
cordless machine with nger on switch. Be
sure the switch is off when inserting the
battery.
• Never pick up or carry the machine
while the tines are turning or the motor is
running.
• Keep the machine in good working
condition. Check all nuts, bolts, and screws
at frequent intervals for proper tightness to
be sure the equipment is in safe working
condition.
• Keep the machine free of grass, leaves
or grease to reduce the chance of a fire
hazard.
• Do not use the machine if switch does not
turn it on or off. Any tool that cannot be
controlled with the switch is dangerous and
must be repaired.
• Disconnect the battery pack from
the appliance before making any
adjustments, changing accessories, or
storing appliance. Such preventive safety
measures reduce the risk of starting the
appliance accidentally.
• Before cleaning, repairing, or inspecting,

Page 5
remove the battery and make certain all
moving parts have stopped.
• Never spray water directly into the motor
compartment of the machine.
• Use only identical replacement parts when
servicing the machine. Use of unauthorized
parts may create a risk of serious injury to
the user, or damage to the product.
• Use only Masterforce Batteries: BAB726
and other BAB series.
• Use only Masterforce Charger: CAB809
and other CAB series.
SPECIFIC SAFETY RULES
• Cleaning, user-maintenance (such
as lubrication adjustment, and the
like), operations recommended by the
manufacturer, and a warning to the user that
any other servicing should be performed by
an authorized service representative.
• Do not use near underground electric cables,
telephone, lines, pipes, or hoses. If in doubt,
contact your utility or telephone company to
locate underground services.
• If the machine strikes a foreign object,
stop the motor, remove the battery pack,
thoroughly inspect the machine for any
damage, and repair the damage before
restarting and operating the machine.
• Maintain Appliance With Care – Keep cutting
edge sharp and clean for best performance
and to reduce the risk of injury.
• Do not overload the machine capacity by
cultivating too deep in a single pass or at too
fast a rate.
• Stay alert. Watch what you are doing. Use
common sense. Do not operate the machine
when you are tired, ill, or upset.
• Don’t use in rain.
• Be aware that the equipment may
unexpectedly bounce upward or jump forward
if the tines should strike buried obstacles such
as large stones, roots, or stumps.
• Wear hearing protection.
• Ensure that people and pets are at least 50’ (15
m) away from the machine while in use.
• Ensure that work area is free of slippery spots
or excessive quantities of stone.
• Start the machine carefully according to
instructions from a normal operating position
and with feet well away from the tines. It will
SAFETY INSTRUCTIONS
do the job better and with less likelihood of
a risk of injury at the rate for which it was
designed.
• Keep hands away from blades.
• Remove the battery pack from the machine
before unclogging the tines and when making
any repairs, adjustments, or inspections.
• Never operate the equipment on a slope.
• Use extreme caution when pulling the
machine towards you.
• When not in use, the machine should be
stored indoors in dry, and high or locked-up
place – out of reach of children.
• When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminal stogether may cause burns or a re.
• Keep Children Away — All visitors and
bystanders should be kept at a distance of at
least 50 feet from work area.
• Do not use a battery pack or appliance that is
damaged or modied. Damaged or modied
batteries may exhibit unpredictable behavior
resulting in re, explosion or risk of injury.
• Don’t grasp the exposed cutting blades or
cutting edges when picking up or holding the
machine.
• Do not expose a battery pack or appliance
to re or excessive temperature. Exposure to
fire or temperature above 130°C may cause
explosion. The temperature of 130°C can be
replaced by the temperature of 265°F.
• Follow all charging instructions and do
not charge the battery pack or appliance
outside of the temperature range specified
in the instructions. Charging improperly or at
temperatures outside of the specified range
may damage the battery and increase the risk
of re.
• Have servicing performed by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the product
is maintained.
• Do not modify or attempt to repair the
appliance or the battery pack (as applicable)
except as indicated in the instructions for use
and care.
• Check damaged parts. Before further use
of this cultivator, a guard or other part that
is damaged should be carefully checked to
determine that it will operate properly and
perform its intended function. Check for
alignment of moving parts, binding of moving

Page 6
SAFETY INSTRUCTIONS
parts, breakage of parts, mounting, and any
other condition that may affect its operation.
A guard or other part that is damaged should
be properly repaired or replaced by an
authorized service center unless otherwise
indicated elsewhere in this manual.
• Save these instructions. Refer to them
frequently and use them to instruct others who
may use this cultivator. If you loan someone
this unit, loan them these instructions also.
• Do not dispose of batteries in re, the cell may
explode, check with local codes for possible
special disposal instructions.
• Do not open, damage or otherwise tamper
with the battery. Released electrolyte is
corrosive and may cause damage to the eyes
or skin, it may be toxic if swallowed.
• Exercise care in handling batteries in order
not to short the battery with conducting
materials such as rings, bracelets and keys.
The battery or conductor may overheat and
cause burns.
PROPOSITION 65
This product contains a chemical known to
the state of California to cause cancer, birth
defects or other reproductive harm. Some dust
created by power sanding, sawing, grinding,
drilling, and other construction activities
contains chemicals known to cause cancer,
birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement
and other masonry products;
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure to these chemicals
varies depending on how often you do this
type of work. To reduce your exposure to these
chemicals, work in a well-ventilated area, and
work with approved safety equipment, such as
dust masks that are specially designed to lter
out microscopic particles.
CHILD SAFETY
Tragic accidents can occur if the operator is
not aware of the presence of children.
• Keep children out of the working
area and under the watchful care of a
responsible adult.
• Do not allow children under the age
of 14 to operate this blower. Children
who are 14 years of age and older must
read and understand the operating
instructions and safety rules in this
manual and must be trained and
supervised by a parent.
• Stay alert, and turn the blower off if a
child or any other person enters the
working area.
• Use extreme care when approaching
blind corners, doorways, shrubs, trees,
or other objects that may obscure your
view of a child who may run into the
path of the blower.
SAVE THESE INSTRUCTIONS

Page 7
OVERVIEW
SPECIFICATIONS
Motor 80V Brushless
No-load speed 170 ± 5% RPM
Cultivating Path 10'' (25 cm)
Cultivating Depth 5'' (13 cm)
Weight (Without Battery) 29.3 lb. (13.3 kg)
The recommended ambient temperature range:
Item Temperature
Cultivator storage temperature range 32°F (0°C) - 113°F (45°C)
Cultivator operation temperature range 32°F (0°C) - 113°F (45°C)
Battery charging temperature range 39°F (4°C) - 104°F (40°C)
Charger operation temperature range 39°F (4°C) - 104°F (40°C)
Battery storage temperature range 32°F (0°C) - 113°F (45°C)
Battery discharging temperature range 32°F (0°C) - 113°F (45°C)
Handle bar
Safety lock button
Tine shield
Inner tine
Outer tine
Hitch pin
Bolt
Hitch pin
Wheel
assembly

Page 8
ASSEMBLY
UNPACKING
This product requires assembly.
• Carefully remove the product and any
accessories from the box. Make sure that
all items listed in the package contents
section are included.
• Inspect the product carefully to make sure
no breakage or damage occurred during
shipping.
• Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the product.
• If any parts are damaged or missing, please
call 1-844-MSTR4CE (844-678-7423) for
assistance.
THE WHEELS
1. Remove the battery from the unit.
2. Place cultivator in a stable position as
shown in Fig. 1.
3. Insert the wheel assembly into the support
rod.
4. Align wheel assembly hole to desired
position. Slide bolt through hole and attach
hitch pin to bolt.
5. The highest tilling position is Position A
and lowest tilling position is Position B.
6. Wheels can be removed for greater tilling
depth.
THE TINES
The cultivator has four tines—two inner
tines stamped B and C and two outer tines
stamped A and D. For correct operation of the
unit, the tines must be installed in the correct
orientation.
1. Place tine (C) on the tine shaft to the left of
the gear box. The stamped side of the tine
should face away from the gear box.
2. Place tine (B) on the tine shaft to the right
of the gear box. The stamped side of the
tine should face away from the gear box.
3. Place a felt washer on each side of
the tine shaft, and slide to rest against the
inner tine.
4. Place the outer tine (D) on the left side of
the tine shaft. The stamped side should
face in toward tine (C).
5. Place the outer tine (A) on the right side
of the tine shaft. The stamped side should
face in toward tine (B).
6. To secure the tines to the tine shaft, insert
the hitch pins into the holes located on
either side of the tine shaft.
NOTE: The unit will not operate properly if
the tines are installed incorrectly. If you notice
a problem with the cultivating operation of the
unit, check for proper tine positioning.
WARNING The tines and the
machine may damage even if you move the
machine with the motor switched off. To pre-
vent the tines from touching the ground while
moving please tilt the machine.
Support rod
Position A - Highest
Wheel
assembly
Position B - Lowest
Hitch
pin
Step 1
Step 2
Bolt
FIG. 1
Hitch
pin
Hitch
pin
Flute Flute
Tine(D) Tine(C)
Gear box
Tine shaft
Tine(B) Tine(A)
Felt
Felt
FIG. 2

Page 9
ASSEMBLY
THE BATTERY PACK
WARNING Follow these instruc-
tions in order to avoid injury and to reduce the
risk of electric shock or re:
• If the battery pack or charger is damaged,
replace the battery pack or the charger.
• Stop the machine and wait until the engine
stops before you install or remove the
battery pack.
• Read, know, and follow the instructions in
the battery and charger manual.
To install the battery pack
1. Align the lift ribs on the battery pack with
the grooves in the battery compartment.
2. Push the battery pack into the battery
compartment until the battery pack locks
into place.
3. When you hear a click, the battery pack is
installed.
To remove the battery pack
1. Press and hold the battery release button.
2. Remove the battery pack from the machine.
THE HANDLE
1. Align the holes on the upper handle with
the holes on the lower handle. Insert the
bolts, and tighten them using the wing nuts
provided.
FIG. 3
FIG. 4
Wing nut
Upper handle
Battery pack
Battery release button
Lower handle
Bolt

Page 10
START / STOP THE CULTIVATOR
To start
1. Press the safety lock button.
2. Pull the bail switch toward the handle while
you hold the safety lock button.
3. Release the safety lock button.
To stop
1. Release the bail switch to stop the machine.
NARROW CULTIVATING WIDTH
The two outer tine blades can be removed
from the unit to allow a more narrow cultivat-
ing width.
1. Place tine (A) onto the shaft, and place tine
(D) onto the other side shaft.
2. Insert the hitch pin into the holes in order to
secure the tines to the tine shaft.
OPERATION TIPS
The cultivator can be used to break up gar-
den soil and prepare a seedbed for planting.
Plan ahead to leave enough room between
the seed rows to allow for machine cultivating
after the plants have grown.
• Several passes over the same path may be
required to reach the desired depth. Do not
try to dig too deeply in the rst pass.
• If the machine jumps or bucks, allow the
unit to move forward at a slightly faster rate
or install wheel assembly.
• If the cultivator stays and digs in at one
spot, try rocking it from side to side in order
to start it moving forward again.
• If the soil is very hard, water a few days
before cultivating. Avoid working the soil
when soggy or wet. Wait a day or two after
heavy rain for the ground to dry.
• Shallow cultivating less than 5cm. deep
can be used to disrupt weeds and aerate
soil, without injuring nearby plant roots. It
should be done often so that weeds do not
grow large and cause tangling in the tines
of the unit.
OPERATION
FIG. 5
FIG. 6
Battery pack
Safety lock button
Tine(D)
Tine(A)
Hitch pin
Flute
Bail switch

Page 11
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
The motor shuts
down whilst
working.
The battery pack is
not installed tightly.
Make sure that you tighlty installed
the battery pack in the machine.
The battery pack is
out of power.
Charge the battery pack.
The machine has
damage.
Do not use the machine and speak to service
center.
The machine smokes
during operation.
The machine has
damage.
1. Immediately stop the machine.
2. Remove the battery.
3. Speak to service center.
Motor runs but tines
do not move.
The machine has
damage.
Do not use the machine and
speak to service center.
The tines are blocked. Remove battery then clear blockage
from the tines.
Gear train failure. Speak to service center.
MAINTENANCE
CLEAN THE MACHINE
• Clear the unwanted material out of the air
vent with a vacuum cleaner.
• Do not spray the air vent or put the air vent
in solvents.
• Clean the housing and the plastic
components with a moist and soft cloth.
CAUTION Do not let brake
uids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can
cause damage to the plastic, and make the
plastic unserviceable.
CAUTION Do not use strong
solvents or detergents on the plastic
housing or components.
CAUTION Remove the battery
pack from the machine before maintenance.
STORE THE MACHINE
• Clean the machine before storage.
• Make sure that the motor is not hot when
you store the machine.
• Make sure that the machine does not have
loose or damaged parts. If it is necessary,
do these steps/instructions:
1. Replace the damaged parts.
2. Tighten the bolts.
3. Speak to a person of an approved
service center.
• Store the machine in a dry area.
• Make sure that children cannot come near
the machine.

Page 12
EXPLODED VIEW
ITEM NO. PART NO. DESCRIPTION QTY
1R0201200-00 Handle Knob Assembly 1
2R0201201-00 Wheel Shelf Assembly 1
3R0201202-00 PCBA 1
4R0201203-00 Small Hitch Pin 1
5R0201694-00 Shield 1
6R0201695-00 Wheel 1
7R0201696-00 Motor Engagement Box 1
8R0201207-00 Large Hitch Pin 1
9R0201208-00 Tine Assembly 1
10 R0201209-00 Ring Pin 1
11 R0201210-00 Gear Box 1
123 4
6
58
910 11
7

Page 13
NOTES

Page 14
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
80V BRUSHLESS CULTIVATOR
WARRANTY
4-YEAR LIMITED WARRANTY
This MASTERFORCE™ brand power tool carries our famous No Hassle 4-Year Limited
Warranty to the original purchaser. If, during normal use, this MASTERFORCE™ power
tool breaks or fails due to a defect in material or workmanship within four (4) years from
the date of original purchase, simply bring the tool with the original sales receipt back
to your nearest MENARDS®retail store. At its discretion, MASTERFORCE™ agrees
to have the tool or any defective part(s) repaired or replaced with the same or similar
MASTERFORCE™ product or part free of charge, within the stated warranty period,
when returned by the original purchaser with original sales receipt. Not withstanding the
foregoing, this limited warranty does not cover any damage that has resulted from abuse
or misuse of the Merchandise. This warranty: (1) excludes expendable parts including
but not limited to blades, brushes, belts, bits, light bulbs, and/or batteries; (2) shall be
void if this tool is used for commercial and/or rental purposes; and (3) does not cover any
losses, injuries to persons/property or costs. This warranty does give you specific legal
rights and you may have other rights, which vary from state to state. Be careful, tools
are dangerous if improperly used or maintained. Seller’s employees are not qualified
to advise you on the use of this merchandise. Any oral representation(s) made will not
be binding on seller or its employees. The rights under this limited warranty are to the
original purchaser of the merchandise and may not be transferred to any subsequent
owner. This limited warranty is in lieu of all warranties, expressed or implied including
warranties or merchantability and fitness for a particular purpose. Seller shall not be
liable for any special, incidental, or consequential damages. The sole exclusive remedy
against the seller will be for the replacement of any defects as provided herein, as long
as the seller is willing or able to replace this product or is willing to refund the purchase
price as provided above. For insurance purposes seller is not allowed to demonstrate
any of these power tools for you.
For questions / comments, technical assistance or repair parts -
Please call toll free at: 1-844-678-7423 (M-F 8am - 6pm)

© 2019 Menard, Inc., Eau Claire, WI 54703 12/2019
