Matermacc IRRIGAMATIC PRO35 User manual

IRRIGAMATIC PRO 35
MANUAL FOR USE AND
MAINTENANCE
IRRIGAMATIC PRO35
Carefully read this Handbook before using the centraline
Via Gemona, 18 - 33078 San Vito al Tagliamento (PN) ITALIA - telefono 0434/85267 telefax 0434/85517
www.matermacc.it e-mail [email protected]
Matermacc S.p.a.

IRRIGAMATIC PRO 35

IRRIGAMATIC PRO 35
INTRODUCTION
This manual guide contains a description of the work and the necessary instructions for performing
basic operations and regular maintenance of the device.
This guide is for convenience divided into easily-defined chapters.
These instructions are intended for professional users only, who are to possess specific knowledge
about how to use the device, special admittance and training.
It is recommended to use original spare parts and accessories. Non-original parts in addition to
forfeiture of the guarantee can be dangerous and may affect the durability and specifications of the
machine.
This symbol indicates that it is necessary to pay maximum attention to the discussed issue.
This symbol indicates that it is necessary to pay maximum attention to the
discussed issue.
It is possible that some devices, described in the manual, will not be present in your device,
depending on the selected equipment and the intended market .
UPDATING THE MANUAL
Information, descriptions and illustrations contained herein shall reflect the state of the equipment at
the time of its sale.
The manufacturer reserves the right to perform from time to time possible changes in the equipment
for technical or commercial reasons. Such changes do not require the Producer to intervene in sold
up devices and do not render this publication inappropriate.
Possible additions the manufacturer finds necessary to provide in the future should be kept together
with this manual guide and shall be an integral part thereof.
COPYRIGHT
Copyright on this manual is owned by the manufacturer of the equipment. This guide contains texts,
drawings and technical schedule, which can not be released or transferred to a third party in whole or
in part without the written permission of the manufacturer of the device.
!!

IRRIGAMATIC PRO 35
WARRANTY
Verify on delivery that the equipment has not been damaged during the transport and that the
accessories are integral and complete.
Any claims must be made in writing within 8 days from reception.
The warranty against any defect of the materials is valid one year from the delivery date of the
equipment.
The warranty does not include shipment expenses (the material travels at risk and danger of the
addressee).
Any damage caused to people or things are excluded from the warranty.
The warranty is limited to the repair or free replacement of the faulty piece.
The retailers and the users are not entitled to any indemnification from the manufacturer for any
damages (costs for work, transport, defective job, direct or indirect incidents, no profit on harvests,
etc). .
WARRANTY DECLINE
Besides what is reported in the supply contract the warranty declines:
In case the limits referred to in the technical data table or in other tables in the handbook are
exceeded.
In case the instructions described in this handbook have not been followed carefully.
In case of wrong use, faulty maintenance or mistakes made by the client.
In case of non original spare parts.
The contractual guarantee is not applied if the cited conditions are not respected even only partially.
The use of spare parts not approved by the Manufacturer invalidates every guarantee and releases
the Manufacturer of Retailer from every liability due to malfunctioning or incidents.
The removal or modification of the shelters and protections releases the Manufacturer from every
liability due to damages to things and/or people.
However, the Manufacturing Company is available to assure an immediate and accurate technical
attendance and all that can be necessary for the better functioning maximum production of the
equipment.

IRRIGAMATIC PRO 35
NOTES ON SAFETY
For the safe operation of the device first read
carefully these notes.
Power supply
The device is designed for the specified type of
current.
Maintenance
Maintenance procedures performed by the
operator are described in the documentation
supplied to the customer with the product.
Do not perform maintenance operations, which
are not specified in the client documentation.
Cleaning
Before proceeding to cleaning, disconnect the
power cord from the device.
Use specific multifunctional cleaning spray,
since the use of other cleansers may result in
breakage and possible incidents.
Electrical safety
Use only the power cord supplied with the
equipment.
Do not place the unit where there is a chance of
stepping on the power cord.
Do not put any objects on the device.
In the case of one of the below mentioned
situations, immediately turn off the device and
disconnect the power cord.
The device produces noise or an unusual
smell.
Power cable is damaged or worn.
Some liquid spilled into device.
Any part of the device is damaged.
To resolve this issue, contact an authorized
service center.
·
·
·
·
Operational safety
Do not perform maintenance procedures, if
they are not described in the documentation,
or no training was provided to the operator by
the authorized regional dealer.
Always follow all warnings and instructions
marked on the device or supplied with it.
Always pay utmost care when moving or
transferring the device.
Always install the device in a spacious room,
so you can perform the maintenance.
Do not place the device near a source of heat .
Recycling and processing
In accordance with European standards
electrical and electronic devices should not be
recycled together with domestic waste.
In the member states of the European Union
you are to take electrical appliances to special
places free of charge . For further information
please contact the local agency responsible
for recycling.
For further information, contact the local
agency responsible for recycling, or ask for
special instructions.

IRRIGAMATIC PRO 35

IRRIGAMATIC PRO 35
1. GENERAL FEATURES.................................................................. Page01
2. GENERAL TECHNICAL................................................................. Page02
2.1 INTERFACE..................................................................................................... Page02
3. INSTRUCTIONS FOR USE............................................................... Page03
3.1 START UPAND MAIN MENU........................................................................... Page03
3.2 ACCESSING THE MENU................................................................................ Page03
3.3 PERFORMING AN IRRIGATION CYCLE ................................................ Page04
3.3.1 PREPARING.................................................................................................................... Page04
3.3.2 ACTIONS DURING THE IRRIGATION CYCLE................................................................ Page06
3.3.2.1 CHANGING THE INSTANTANEOUS SPEED..................................................... Page06
3.3.2.2 CHANGING THE SPEED FOR THE CURRENT SECTOR................................. Page06
3.3.2.3 INTERRUPTING/RESTARTING A CYCLE......................................................... Page06
3.4 CALIBRATING THE MACHINE................................................................ Page07
3.5 CONFIGURING THE MACHINE............................................................... Page07
3.6 SETTING THE CALENDAR...................................................................... Page08
3.7 ADJUSTING THE COUNTERS................................................................. Page08
4. USER PARAMETERS ...................................................................Page09
4.1 PASSWORD-PROTECTED USER PARAMETERS.................................. Page10
5. ERROR MESSAGES..................................................................... Page11
6. USING THE GSM MODULE (OPTIONAL)..................................... Page13
6.1 SIM CARD ASSEMBLY INSTRUCTIONS................................................ Page13
6.2 MANAGING THE CONTACT LIST ........................................................... Page13
INDEX
INTRODUCTION
NOTES ON SAFETY
WARRANTY
WARRANTY DECLINE

IRRIGAMATIC PRO 35
INDEX
6.2.1 ADDING A NUMBER TO THE LIST.................................................................... Page13
6.2.2 DELETING A NUMBER FROM THE LIST........................................................... Page14
6.2.3 ENABLING/DISABLING MESSAGES TO A USER.............................................. Page14
6.2.4 READING THE LIST............................................................................................ Page14
6.2.5 QUERYING THE MACHINE STATUS.................................................................. Page14
6.2.6 QUERYING THE RETURN SPEED..................................................................... Page14
6.3 SMS COMMANDS.................................................................................... Page16
6.2.7 SETTING THE LENGTH OF THE UNWOUND TUBE WHEN THE
GSM WILL CALL................................................................................................ Page15
6.2.8 CHANGING THE CURRENT RETURN SPEED.................................................. Page15

IRRIGAMATIC PRO 35
Page 01
1 GENERAL FEATURES
FUNCTIONS:
•Current date and time.
•Measurement of wound and unwound
tube.
•Setup of work start time at a given time
•Start delay 0...120 min.
•Work speed adjustment (5 to 850 m/h).
•Display of the irrigation time and work end
time.
•Setup of work end time and new
calculation of the adjusting parameters.
•Final pause 0...120 min.
•Operations once the irrigation is over.
•Automatic stop for energy saving.
•Auxiliary irrigator control
•Programmed start-up of rewind end
signaller.
•4 available irrigation criteria: 1) m/h, 2) rain
measurement: a) with flowmeter, b) by set
flow rate, c) by flow rate estimated setting
pressure on the nozzle, diameter of the
nozzle, width of the irrigated area and mm
of water.
OPTIONS:
Connection with a pressure switch
Speed measurement with feeling roller
Management of a timed auxiliary irrigator
Connection with wind - rain feelers
Connection with a flow meter.
Connection with an integrated GSM card
for data transmission and receipt.Through
a cellular phone it permits to:
Send a SMS when a programmed event takes
place (end of work, wind, rain, ...).
Check a few parameters of the installation
·carries out some speed start - stop - change
for the current sector.

IRRIGAMATIC PRO 35
Page 02
2 GENERAL TECHNICAL
SPECIFICATIONS
UProcessore GRAPHIC LCD 128X64 pixel
Display: With Baclight 128x64 pixel LCD
Commands: incremental encoder with button
Inputs:
Digital:
Speed sensor (on roller or pinion)
Unwinding end sensor
Rewinding end sensor
Pressostat
Wind/rain sensor
Flow meter (4-20mA)
Analog:
4-20mAtransducer
Battery monitor
Outputs:
Digital:
Relè SPDT 2A 30Vdc per funzioni aux
IN/OUT available
1 analog or digital IN
Power: 12 Vdc battery
Operating Range: -20…70 °C free air
Temperature and Humidity: Ambient
temperature
-5...25°C; Storage temperature 30...70°C; RH %
10...60 non condensing.
Modulated: 3 H-bridge max 3A to pilot
Shunt/Bypass valves and auxiliary irrigator
2.1 INTERFACE
The user interface is made up of a panel
comprising:
1. Agraphic LCD 128X64 pixel with Baclight.
2.
3. Push button to switch ON/OFF the console
The display shows the value of various parameters
during operation, where appropriate illustrated
with icons.
In the event of anomalies the corresponding
messages are shown, where appropriate illustrated
with icons.
During device setup the Baclight of the LCD
display is always on. It turns off automatically if the
encoder is idle for a preset period of time. The
Baclight switches on again automatically at the
first press of the encoder.
Incremental encoder to set up device

Page 03
IRRIGAMATIC PRO 35
Ver. 0.x(x)
NEXT
BACK
3. INSTRUCTIONS FOR USE
3.1 START UPAND MAIN MENU
1 Connect power supply cables of electronic
console to a 12V d.c. voltage source
2 When switching electronic console on the LCD will
display name and version of its firmware
3 A series of messages follow
The first message informs about the execution of the
machine initialization. Flow valve closing If mounted
at the inlet.
FLUX OPEN
A second message: the BYP valve opens to make sure
speed is set to zero.
BYP OPEN
A third message confirms the device has been
initialized correctly:
INIT
COMPLETE
The electronic console goes to standby waiting for
new commands from the user who can access the
menus listed below:
5 Position the focus on the desired menu by
browsing the menus, turning the control to the
left or right.
6 Press the control
3.2 ACCESSING THE MENU
General procedure
The console then awaits new commands from the
user, who can access the menus listed below:
To access the menus mentioned above, proceed as
follows:
1. By turning the knob position the focus on the
desired menu by browsing the menus.
2. Press the knob.
3. If the menu is password-protected, the label
“PASSWORD“ appears, under which the
characters making up the necessary password
must be entered.
4. To enter a password:
A) Press the knob: the first character will
become “0*“, meaning that the character is
now editable.
B) Change the character by turning the knob to
the left or right
C) Confirm the selected character by pressing
the knob.
D) Position the focus on the next space by
turning the knob to the left or right.
E) Repeat steps a) to d) until the last character
has been entered, then position the focus on
and press the knob; if the password
is correct the console will show the first
value of the menu parameter; otherwise, it
will remain at the password menu. To exit
this menu, position the focus on , and
the console returns to the main menu.
4 The control unit therefore awaits new controls
provided by the user who can access the menus listed
below (normally the “MANUAL” menu is not
visible).
OPERATION
CALIBRATION
CONFIGURATION
CALENDAR
COUNTER
MANUAL

IRRIGAMATIC PRO 35
Page 04
3.3 PERFORMING AN IRRIGATION
CYCLE
3.3.1 PREPARING
1 BEFORE STARTING TO LAY THE TUBE
position the focus on “OPERATION” and press the
knob. The display will indicate whether the
previous cycle completed correctly:
ROLL TUBE
0 m
2. If the value is not zero, set it to zero as follows:
A) Position the focus on the value, pressing the
knob. The display will show, for example:
ROLL TUBE
m
B) Turn the knob to the left to set the value to
zero and confirm by pressing the knob.
The display will show:
ROLL TUBE
m
3. Perform the tube unrolling operations as normal;
after completion, the display will show for
example:
ROLL TUBE
100 m
4. To change the value position the focus on the
value, press the knob and then turn it to the left or
right:
ROLL TUBE
m
5. Confirm by pressing the knob. The display
Will show the selected value, for example:
ROLL TUBE
m
6. To continue, position the focus on and
press the knob. The display will show, for
example:
START TIME
11:25
25/03/2008
07*
00*
100*
102
NEXT
ATo change the start time, position the focus on
the minute and/or hour value and press the
knob. The display will show, for example:
START TIME
:25
25/03/2008
BTo change the start time, turn the knob and
confirm by pressing it. The display will show,
for example:
START TIME
14:25
25/03/2008
7To continue, position the focus on and
press the knob. The display will show, for
example:
START PAUSE
0 min.
ATo change the duration of the start delay,
position the focus on the minute and/or hour
value and press the knob. The display will
show, for example:
START PAUSE
min.
BTo change the duration of the start delay, turn
the knob and confirm by pressing it. The
display will show, for example:
START PAUSE
min.
8To continue, position the focus on and
press the knob. The display will show, for
example
SECTOR 1
260 m
30 m/h
ATo change the value of the sector length
and/or speed, position the focus on the
parameter and press the knob. The display
will show, for example:
14*
0*
3
NEXT
NEXT

IRRIGAMATIC PRO 35
Page 05
SECTOR
260 m
30* m/h
BTo change, for example, the return speed, turn
the knob and confirm by pressing it. The
display will show, for example:
SECTOR
260 m
m/h
9To continue, position the focus on and press
the knob. The display will show, for example
END PAUSE
0 min
ATo change the duration of the end delay,
position the focus on the minute and/or hour
value and press the knob. The display will
show, for example:
END PAUSE
min
BTo change the duration of the end delay, turn the
knob and confirm by pressing it. The display
will show, for example:
END PAUSE
min
10 To continue, position the focus on and
press the knob. The display will show,
for example:
STOP TIME
17 : 29
15/03/08
ATo change the end time (reduction of times),
position the focus on the minute and/or hour
value and press the knob. The display will
show, for example:
STOP TIME
: 29
15/03/08
35
0*
5
17*
NEXT
NEXT
NEXT
BACK
BTo change the end time, turn the knob and
confirm by pressing it. The display will
show, for example:
STOP TIME
: 29
15/03/08
11 To continue, position the focus on “NEXT“ and
press the knob. The display will show a screen
summarising the operation cycle to be performed,
for example:
RECAPITULATE
14:25 - 15/03/08
03 [min]
102 [m]
052 [m/h]
03 [min]
16:28 - 15/04/08
AIf the values shown are acceptable, position
the focus on and press the knob
for 5 seconds to begin the irrigation cycle.
The console prepares to carry out all
operations necessary for the newly entered
cycle, showing on the display for example:
START PAUSE
11:32:03 14:25
_ _ _ _ _ _ _ _ _
BTo change the parameters entered, position
the focus on and go through the screens
in reverse as Shown in 1. to 9.
16

IRRIGAMATIC PRO 35
Page 06
3.3.2 ACTIONS DURING THE IRRIGATION
CYCLE
AManually change the instantaneous rewinding
speed by means of the BYP valve (following the
manual intervention the console will resume
regulation according the regulation algorithm
around the value entered).
BChange the rewinding speed set by the current
sector.
CInterrupt the cycle.
DRestart the cycle.
3.3.2.1 CHANGING THE INSTANTANEOUS
SPEED
1Position the focus on by turning the knob,
and press it. The label changes to show -
REG + .
2Position the focus on REG + by
turning the knob and press it to reduce the speed,
or on - REG and press it to increase
the speed.
3Position the focus on - + by turning
the knob, and press it. The label changes to show
.
During irrigation, the display alternates between:
- rewind speed
- hose to be gathered (morft)
- estimated end of work
To stop this rotation, place the cursor on the
alternating sizes. The display stops at the current one.
To change the size displayed, press the knob.
During irrigation, it is possible to:
MAN
-
+
REG
MAN
3.3.2.3 INTERRUPTING/RESTARTING A
CYCLE
1Interrupting: during a cycle, position the focus
on STOP by turning the knob, and press it. The
label changes to show RUN: the console
commands the valves to suspend the cycle:
Aclosing/opening the FLUX valve
(depending on whether it is in inflow or
outflow phase).
Bopening the BYP valve to set speed to zero.
2Restarting: when a cycle is suspended, position
the focus on RUN by turning the knob, and press
it. The label changes to show STOP: the
console commands the valves to restart the
cycle:
Aopening/closing the FLUX valve
(depending on whether it is in inflow or
outflow phase).
Bactivating the BYP valve to regulate the
return speed.
3.3.2.2 CHANGING THE REWINDINGSPEED
FOR THE CURRENT SECTOR
1
2
Place the cursor on , rotate the knob
and then press it for at least 5s. The label
changes and reads .
Rotate the knob to the right or left and then press
it for at least 5s to confirm the value set.
V 35 m/h
35* m/h

IRRIGAMATIC PRO 35
Page 07
3.4 CALIBRATING THE MACHINE
The calibration menu is password-protected.
It is only accessible to the manufacturer of the
!!! ATTENTION !!!
3.5 CONFIGURING THE MACHINE
The configuration menu is password-protected.
It is only accessible to the manufacturer of the
!!! ATTENTION !!!

IRRIGAMATIC PRO 35
Page 08
NEXT
3.6 SETTING THE CALENDAR
The calender is set using the menu CALENDAR.
The date is given in the format: dd/mm/yy.
The time is given in the format: hh/mm/ss.
1Position the focus on CALENDAR and press the
knob. The display shows the following:
CALENDAR
16 :15
15/03/08
2To change an item, position the focus on the value
to be changed and press the knob. The display
shows, for example:
CALENDAR
16 :
15/03/08
3Change by turning the knob to the left or right and
confirm by pressing the knob. The display shows
for example:
CALENDAR
16 :20
15/03/08
4To exit the menu, position the focus on and
press the knob.
15*
3.7 ADJUSTING THE COUNTERS
The counters are set by accessing the menu
CONTATORI.
Only the value of the partial knob can be reset.
Position the focus on CONTATORI and press the
knob. The display shows, for example:
COUNTER
TOTAL PARTIAL
2:33 0:33
To reset the value of the partial counter, position the
focus on the partial counter value and press the
knob for around 10 seconds. The display shows, for
example:
COUNTER
TOTAL PARTIAL
2:33 0:00

IRRIGAMATIC PRO 35
Page 09
4 USER PARAMETERS
The knob parameters - defined by the user - at the beginning and/or during an irrigation cycle are as summarised
in the following table.
6
7
N° Parameter Description
UNW. TUBE M of tube unwound before starting to work
START TIME Time when the irrigation cycle should begin
(system based on RTC, with self
increasing date)
Present time
START PAUSE Starting interval for irrigation on field edges
(v = 0 => BYP open)
SECTOR 1 Length of the unwound tube
Speed for trolley return for a single sector
available
SPEED OF RETURN
SECTOR 1
END TIME Time calculated based on 1)...5)
FINAL PAUSE
*calculated
modifiable
Lasted final pause

IRRIGAMATIC PRO 35
Page 10
4.1 PASSWORD-PROTECTED USER PARAMETERS
Parameter Description
Position of the flow valve. Position of the flow valve. 0 = inlet
1 = discharge
Sensor of end of winding up. Sensor of end of winding up. “0” = absent;
“1” = present
Measure units in use Measure units in use 0 = meters
1 = feet
Modem_gsm_actif Indicates if the GSM modem is
present This parameter is connected
with the parameter of
“modem_gsm_presente”.
0 = active
1 = not active
Sets the automatic turn-off time at
the end of work.
Length of hose used as reference
to validate the alarm threshold
supplied by the user via SMS.
Sets the distance from the starting
point at which the auxiliary irrigator
must be activated
Sets the distance from the starting
point at which the auxiliary irrigator
must be deactivated
Meters of hose unwound before
activating auxiliary output (relay).
Minutes to wait before signalling no
pressure alarm. This time is only for
the first “signalling” of the alarm.
The following ones use a time of 5
seconds.
57
58
61
62
64
65
auto_turn-off_time
alarm_activat_distance
m_fw_third_motor
m_rw_third_motor
m_rw_third_motor
min_wait_for_no_press
0...30
0...1500
0...1500
0...1500
0...1500
0...60
0
100
250
250
250
0
min.
m
m
m
m
min

IRRIGAMATIC PRO 35
Page 11
5 ERROR MESSAGES
The console keeps a list of the last 6 errors which may have occurred.
The error messages are displayed in order on the first line of the LCD in alternation with other messages on the
display, for example:
1 / 2 ALL 04 then for example 2 / 2 ALL 06
These flashing messages indicate, for example, that first there was an interruption in the BYP knob circuit,
followed by a lost trolley.
The following table lists the exceptions which may occur during and operation cycle, and the respective
messages displayed.
The list of events is intended to indicate a sequence of the errors which occur, in order to assist with the
reconstruction of events in case of malfunction.
Type Description Conditions Actions
Locking
Suspen
sion
Display
SC on flow
valve
A short circuit has been
detected on the flow valve. Yes No
Timeout on
flow valve
opening
The limit time for flow
valve opening has been
exceeded (par. C#2 or par.
C#4).
NoNo
The limit time for flow
valve closing has been
exceeded (par. C#3 or par.
C#5).
Timeout on
flow valve
closing Yes No
S C o n
b y p a s s
valve
A short circuit has been
detected on the flow valve. NoNo
Yes No
Timeout on
b y p a s s
v a l v e
opening
NoNo
S p e e d
adjustment
limit
End of stroke reached for
bypass valve without
reaching the required
speed
Trolley lost No p ul se s for some
time(par. C#8 or par. C#9).
If no pulses are received
for a time such as par. C#8
an average speed measured
as the minimum threshold
is set
Yes
No

IRRIGAMATIC PRO 35
Page 12
(determined by par. M#12)
in order to force the
transmission of long
pulses.
If no pulses are received
for a time such as par. C#9
d e s p i t e f o r c i n g t h e
transmission of long pulses
the cycle is stopped.
R a i n o r
wind
The cycle is suspended for
as long as the alarm
persists
Valid only if the rain or
wind sensor is provided
(par. C#18) and if no time
compression has been
carried out.
Yes
No
Z e r o
pressure
Detection of zero pressure
in the tube
Valid only if the sensor is
provided (par. C#13).
If the flow valve is located
at the inlet and the
pressure switch is located
downstream the flow
valve (par. C#13) a
cyclical emergency check
is carried out*.
In all other cases the cycle
is suspended.
No Yes
(waiting
f o r
pressure
to return)
Yes
Limit time
exceeded
When the time for end of
work has come, the cycle
is not over yet.
O n l y i f a t i m e
compression has been
carried out. No Yes
Error of end
of winding
up.
The alarm is triggered by
the signal of end of
winding up with a length
of the tube different from
0.
The alarm is released
only if the sensor of end
of winding up is provided
(par. C#17). No No
Type Description Conditions Actions Suspen
sion
Display
Locking
