matev MOW-MM-152 User manual

matev GmbH
Nürnbergerstr. 50
D-90579 Langenzenn
Phone: [phone]
Modifications and errors excepted!
Version: 01/13/2023
Reference number:
BA-MOW-38234
Multifunction mower
MOW-MM-152 for NH Boomer 25
Operating Manual

Page 2
Modifications and errors excepted! Version: 2020-09-29
Table of contents
Table of contents ...................................................................................................................2
1Introduction .......................................................................................................................4
2About this operating manual..............................................................................................5
3Technical data...................................................................................................................6
3.1 Basic unit MOW-MM-152 .........................................................................................6
3.2 Hydraulic lifting.........................................................................................................6
3.3 Hydraulic power diagram..........................................................................................7
4General safety notices.......................................................................................................8
4.1 Depiction of safety information .................................................................................8
4.2 Intended use ............................................................................................................8
4.3 Instructions for the owner.........................................................................................9
4.4 Warning pictograms .................................................................................................9
4.5 Safety devices........................................................................................................11
5Equipment variants..........................................................................................................20
5.1 Optionally required accessories..............................................................................20
5.2 Optional accessories..............................................................................................21
6Operating the multifunction mower..................................................................................22
6.1 Area of application..................................................................................................22
6.2 Function.................................................................................................................23
6.3 Mowing instructions................................................................................................26

Page 3
7Assembly.........................................................................................................................28
7.1 Attach and detach multifunction mower with...........................................................28
hydraulic lift.....................................................................................................................28
7.2 Position mower under tractor..................................................................................29
7.3 Couple mower to carrier vehicle (lift)......................................................................32
7.4 Connect PTO shaft with mower to tractor...............................................................33
7.5 Disassembly of the mower .....................................................................................33
7.6 Initial assembly of the hydraulic lift.........................................................................34
8Adjust cutting height for mowing......................................................................................38
8.1 The desired cutting height can be adjusted above the cutting height adjustment from
approx. 29 mm to approx. 107 mm..................................................................................38
9Securing for trips to the site of operation .........................................................................39
9.1 The hydraulic lift is equipped with a transport position............................................39
10Maintenance....................................................................................................................40
10.1 Safety during maintenance.....................................................................................40
10.2 Maintenance...........................................................................................................40
10.3 Lubricating schedule ..............................................................................................42
11Fault................................................................................................................................45
12Repair .............................................................................................................................45
13Disposal ..........................................................................................................................46
14Guarantee.......................................................................................................................46
15List of illustrations............................................................................................................47
16List of tables....................................................................................................................47

1
Page 4
1Introduction
Welcome to the matev family
and thank you for purchasing a product from matev GmbH; we appreciate your trust. You have ac-
quired a quality product, if contrary to expectations you should have problems with the implement,
contact your responsible sales partner.
Please read this entire manual carefully before operating the machine for the first time. The manual
describes the handling of the machine in detail and will help you to work safely and effectively.
We will not acknowledge warranty claims for damage resulting from improper use.
Variants may be described in the manual that do not agree with the scope of delivery of your imple-
ment.
Please enter the data of the rating plate on the implement in the manual. This information will be
helpful in communication if there is a service case.
Products from matev are subject to change in the interest of technical progress. All information, il-
lustrations, and technical specifications represent the latest status at the time this manual was pub-
lished. The manufacturer reserves the right to make changes at any time in the interest of technical
progress.
The illustrations in this manual are for explanatory purposes and may differ from the actual design.
Regards
matev GmbH
Company stamp –sales partner

2
Page 5
2About this operating manual
Read this entire manual carefully before operating this machine for the first time.
Keep this manual where it is easily accessible. This will enable you to refer to important information
and handling instructions as needed.
When the machine is delivered the owner receives instruction regarding operation and mainte-
nance of the machine from his sales partner.
The owner must ensure that operating and maintenance personnel have been instructed in full
scope in the operation and maintenance of the machine.
Listings with bullet points are marked as follows:
•Text
•Text
•Text. . .
Handling instructions are marked in the sequence in which they should be executed, as follows:
1. Text
2. Text
3. Text. . .
When directions (left, right, front, rear) are specified in the operating manual, they always refer to
the carrier vehicle’s direction of travel.
The front PTO shaft direction of rotation is always specified in the top view from the front. CW
(clockwise), CCW (counter clockwise).
Figure 1 : Definition of orientation and direction of rotation

3
Page 6
3Technical data
3.1 Basic unit MOW-MM-152
Mower dimensions L/W/H in mm
816 x 1,580 x 200 with mower insert
Cutting width in mm
1,520 / 60Zoll
Number of blades
3 pcs
Weight
approx.150 kg (depending on mower use)
Blade rotational speed
approx. 3000 U/min
Suitable for carrier vehicles
20PS-50PS /27KW-67KW
Mid-mount PTO shaft
Requirement
CCW 2000 rpm
Transmission oil / lubricating grease
Transmission capacity
0.5 liters
Transmission oil
Viscosity class 90 e.g. Shell Spira MB90
Transmission oil change
after the first 50 hours then every 500 hours
or at season change
Lubricating grease
Multi-purpose grease with a temperature resistance of -30°C
to +130°C e.g. lithium universal grease based on mineral oil
or similar products.
3.2 Hydraulic lifting
Cutting height adjustable from to
in mm
approx. 29-107 the transport position is at approx.120
(8 setting options)
Weight
ca.54kg
Lubricating grease
Multi-purpose grease with a temperature resistance of -30°C
to +130°C e.g. lithium universal grease based on mineral oil
or similar products.
Table 1 : Technical data

3
Page 7
3.3 Hydraulic power diagram
Use the following diagram to determine whether your vehicle provides sufficient hydraulic power.
1. Add up the power specifications of all available options on your machine.
2. Determine the hydraulic specifications of your vehicle.
Notice!
The hydraulic power available to your vehicle is generally much lower than
the engine power.
3. Enter the specifications in the table below:
Example: maximum vehicle hydraulic pressure 150 bar. Oil flow rate 40l/min. Result: maxi-
mum hydraulic power of approx. 8.8 kW.
Figure 2 : Hydraulic power diagram

4
Page 8
4General safety notices
This chapter summarizes regulations and information that must be observed in connection with
machines.
4.1 Depiction of safety information
The safety information in the text is combined with pictograms and signal words which together in-
dicate the severity of the expected risk
Danger!
Hazardous situations that will result in serious injuries or death.
Attention!
Hazardous situations that could result in moderate injuries or material dam-
age.
Notice!
Recommendations or information for the operator.
Read this notice. It will facilitate your work.
4.2 Intended use
Danger!
To prevent incorrect use, read also through chapter 6.1 Area of application
•The implements are designed for municipal tractors or carrier vehicles used
for comparable work.
•They may be operated only on carrier vehicles with the power range specified
in the technical data.
•Intended use also includes compliance with the operating, service, and
maintenance conditions prescribed by the manufacturer.
•Intended use also comprises the exclusive use of original replacement parts
and additional equipment or such components and equipment that meet the
manufacturer’s technical requirements.
•Unauthorized modifications to the implements will void any liability on the part
of the manufacturer.
All other uses are prohibited!
Non-intended use causes:
•Danger of injury to the operator or third parties
•Damage to the carrier vehicle and the implements
•Environmental damage
•Damage to the machine

4
Page 9
4.3 Instructions for the owner
4.3.1 Qualifications of assembly and maintenance personnel
Assembly and maintenance of safety-related components may be carried out only by personnel
with the following qualifications:
•They must have completed specialized training as an agricultural machinery
mechanic, motor vehicle mechanic, etc.
•Personnel without qualified training must be supervised by someone with qual-
ified training.
•They must have read and understood this operating manual.
•They must be familiar with the relevant safety regulations (accident preven-
tion).
4.3.2 Qualifications of operating personnel
•They must be fully instructed on how to operate the machine.
•They must have read and understood this operating manual.
•They must be familiar with the relevant safety regulations (accident preven-
tion).
4.3.3 Accident prevention
The safety regulations and accident prevention regulations are legally regulated in every country.
The shop foreman or the assigned occupational safety and health specialist of the company carry-
ing out the work is responsible for compliance with the applicable regulations.
4.3.4 Instruction
When the implement is delivered the owner receives instruction regarding operation and mainte-
nance.
The owner must take measures to ensure that operating and maintenance personnel are fully in-
structed regarding operation and maintenance.
4.4 Warning pictograms
Warning pictograms point out dangers that cannot be counteracted by means of safety measures.
Strict observance of the pictograms is necessary to prevent severe injuries or death.
Danger!
Missing warning notices must be replaced immediately.
Do not operate the machine if warning notices are missing.
You can order warning pictograms with the spare parts numbers specified in
chapter 0.

4
Page 10
4.4.1 General warning pictograms
This section explains general warning pictograms that are not specific to a particular machine.
Read the operating manual and observe the safety information.
Shut down the engine before performing maintenance and repairs
Remove the key.
Injuries from emerging high-pressure fluid.
Comply with the notice in the operating manual.
4.4.2 Machine-specific notice
This section explains machine-specific warning pictograms and notices for operation and mainte-
nance of the machine.
Do not operate the mower without the discharge guard or suction port!
Only touch machine parts after they have come to a complete standstill!
During operation, maintain a sufficient distance to the mowing blade!

4
Page 11
Danger due to thrown-out parts when the engine is running - maintain a safety
distance!
Do not position yourself in the area of the drive shaft!
Implement is suitable for a PTO shaft speed of 2000 rpm only!
Mainly mid-mount, front-end or independent engine PTO shafts.
Tighten all screws after each use
Lubricating point
Cutting height adjustment MOW-MM-150 Boomer 25
4.5 Safety devices
Machines are equipped with various safety devices to protect people who work with a machine or
are in the direct vicinity of the machine while working, to avoid premature wear and also to prevent
environmental damage. These safety devices are integral components of the machine; it is prohib-
ited to manipulate or remove them. Missing or damaged safety devices must be replaced immedi-
ately.
There are two types of safety devices: those that prevent contact with the hazard point, and those
that point out a hazard on the machine.
Hazards can also arise as a result of insufficient maintenance, so that warning notices are also to
be regarded as a type of safety notice.

4
Page 12
Before each use of the machine, ensure that all of the safety devices de-
scribed here are complete and fully functional. Do not operate the implement
if any safety devices are missing or damaged.
4.5.1 Guard on the machine
Cover
Belt drive
Figure 3 : Belt drive cover
Cover
Rear ejection
Figure 4 : Rear ejection cover

4
Page 13
Cover
Side ejection
Figure 5 : Side ejection cover

4
Page 14
Do not operate the mower without the mower insert and cover!
The blades must always be covered with an insert and cover provided for this
purpose.
4.5.2 Overview provided of blade covers
Side ejection cover
Mulch or rear ejection cover
Borderless mowing cover
Figure 6 : Blade cover overview

4
Page 15
4.5.3 Decals for Safety Notices and General Decals
Do not allow the
mower to run without
discharge guard or
port!
Order no.: V0 002 955
Lubricating point
Order no.: V0 002 963
Figure 7 : Safety notice Protection
During operation, maintain
a sufficient distance to the
mowing blade!
Order no.: V0 002 928
Figure 8 : Safety notice Mower blade

4
Page 16
Tighten all screws after
each use!
Order no.: V0 002 965
Read the operating man-
ual and observe the safety
information
Order no.: V0 002 922
Figure 9 : Safety notice Read operating manual and retighten screws
Belt guide
Order no.: V0 003 519
Do not position yourself in
the area of the drive shaft.
Order no.: V0 002 930
Type plate
Figure 10 : Safety notice Drive shaft and belt guide, type plate

4
Page 17
Danger due to parts being
thrown
Order no.: V0 002 931
max. rotational speed
2000
Order no.: V0 002 947
Figure 11 : Position of type plate and speed specification
During operation, maintain
a sufficient distance to the
mowing blade!
Order no.: V0 002 928
matev logo
Order no.: V0 003 094
Figure 12 : Safety notice Mower blade on cover Mulching or rear ejection

4
Page 18
During operation, maintain
a sufficient distance to the
mowing blade!
Order no.: V0 002 928
Danger due to ejected
parts when the engine is
running
Order no.: V0 001 866
matev logo
Order no.: V0 003 094
Figure 13 : Safety notice Mowing blades and propelling parts on cover Side ejection
During operation, maintain
a sufficient distance to the
mowing blade!
Order no.: V0 002 928
matev logo
Order no.: V0 003 094
Figure 14 : Safety notice Mower blade on cover Borderless mowing

4
Page 19
Attention Blade
Order no.: V0 002 920
Figure 15 : Safety notice Mower blade on suction port
Cutting height adjustment
Order no.: V0 003 690
Figure 16 : Cutting height adjustment

5
Page 20
5Equipment variants
5.1 Optionally required accessories
Mower insert, rear ejection
Mower insert mulching
Mower insert, side ejection
Mower insert borderless mowing
