Matki ONE MOC User manual

0950AF 01/19
MATKI ONE
MOC - CURVED CORNER SLIDER
INSTALLATION
PARTS LIST
MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL
TELEPHONE: [phone] (CUSTOMER SERVICES) EMAIL: [email protected]

B
RH CORNER
LH CORNER
Before disposing of carton and/or commencing assembly, please check all the parts to ascertain that none are missing and they are all
undamaged. No claim for missing/damaged parts will be accepted once the packing carton has been disposed of and/or assembly has
commenced.
In case of query contact your Stockist with details of model number and details of serial number.
PREPARATION IMPORTANT
1. Please read complete installation instructions before fitting for Enclosure and Tray (if fitting).
2. We recommend the use of Safety glasses and Non slip gloves when handling the glass panels.
3. Ensure that the product can be fixed to a solid masonry wall or suitable timber stud work grade C16/C24 in the area behind the
Wall frames.
4. Shower trays or tiled floors must be absolutely level where enclosures are fitted
5. If fitting a tray we recommend a drainage test is carried out before the tray is tiled in position.
6. The assembly should be installed onto a waterproof wall covering and installed after the Tray and wall coverings are in place. Where
Tiling lips are provided Trays should be let into the Wall with the Tiling lip flush with the wall to allow the Tiling to overlap the Tiling lip.
7. Seal between tray and tiles. Remove any excess sealant from the area/joint between the tray and the tiles where the Wall Mount is
to be fitted. This will ensure the Wall mount fits correctly to the wall and tray/or tiled floor.
CAUTION: TEMPERED GLASS CANNOT BE CUT, POLISHED METAL AND CHROME CAN BE SCRATCHED. CAREFULLY
REMOVE ASSEMBLY FROM CARTON, DO NOT PLACE GLASS ON HARD FLOOR OR EXPOSE EDGES TO IMPACT.
IMPORTANT TOOLS REQUIRED
Masonry Drill bit 6mm, Tape Measure, Screw Drivers, Safety Glasses,
Electric Drill, Level, Pencil, Adjustable Spanners, Non Slip Gloves
DIMENSIONS
CURVED CORNER SLIDER
900 X 900 / 900 X1200 / 900 X 1500
870-890 FIXED SIZE
A - OVERALL WIDTH
584-604 FIXED SIZE
460 - DOOR OPENING
2000 - TOP OF WALL MOUNT
Dimensions are approximate
Model A B
MOC900 870-890 310-330
MOC1290 1170-1190 610-630
MOC1590 1470-1490 910-930
RH CORNER
LH CORNER
2020 - TOP OF DOOR

CONFIGURATIONS
MOC LH OPENING MOC RH OPENING
1200/1500 MOC RH CORNER (OFFSET)1200/1500 MOC LH CORNER (OFFSET)
DOOR OPENS TO LEFT DOOR OPENS TO RIGHT
DOOR OPENS TO LEFT
DOOR OPENS TO RIGHT

2m 2m
B
A
7mm
7mm
B
A
STAGE 1
This stage is describing the placement of the Curved fixed panel wall mount and straight fixed panel wall mount.
Important – Check the walls for upright and that the product dimensions will fit the situation before installation. If the wall is leaning
outward or inwards at the top check that the product will fit within the maximum and minimum adjustment range.
The fixed panels have adjustable wall mounts to compensate for size adjustment or out of plumb walls or a combination of adjustment
and out of plumb. There is 20mm of adjustment in each wall mount.
If fitting the enclosure on a Matki ULC40 tray position the outside face of the wall mounts approximately 7mm in from the outside edge
of the tray. If fitting directly onto a tiled surface please see the maximum and minimum dimensions in the table above to the outside
face of the wall mounts.
* DIMENSIONS TO OUTSIDE FACE OF THRESHOLD TRACK
MODEL
CURVED SLIDER A * B *
MOC900 870 - 890 870 - 890
MOC1290 1170 - 1190 870 - 890
MOC1590 1470 - 1490 870 - 890

a
x 3
c
Ø6
SILICON
x 3
x 3
x 3 x 3
7mm
b
12
STAGE 2
TOP VIEW
FIXED PANEL
WALL MOUNT
This stage is describing the fitting of the Fixed Curved panel wall mount.
a. The Curved fixed panel wall mount has a top and bottom (Cut out at the bottom of wall mount). Position the wall mount
as required plumb the wall mount for upright mark the fixing holes in the centre of the slots. Drill 3 x fixing holes in the
wall and insert the wall plugs. Clean the area.
b. Before fitting the wall mount fit the curved panel floor rail adjuster (supplied in the kit of parts) into the bottom of the
wall mount. The adjuster clamping screw must face inwards, remove and refit the screw and nut assembly with the screw
on the inside if required. Fit the adjuster up the back of the wall mount in the recess shown.
c. Apply silicon sealant to the area behind the wall mount between the tray and tiles and 100mm
up the wall, central to the width of the wall mount. Fit the wall mount using the No.8 x 38mm pan head screws.
WALL MOUNT
THIS PAGE SHOWS THE PANEL INSTALLATION FOR A
RH DOOR OPENING.
BOTTOM
TOP
SCREW ON
INSIDE

1
a
2
2
1
b
4mm
STAGE 3
This stage is describing the fitting of the Fixed Curved panel.
a. Loosen the screw on the floor rail adjuster bracket so that it is at the maximum adjustment and can move freely.
b. Lightly wet the edge of the fixed panel with soapy water gently lower the fixed curved panel onto the adjuster ensuring
the adjuster screw locates into the notch on the inside of the curved panel floor rail. Then gently push the fixed glass
panel into the wall mount.
SOAPY
WATER
INSIDE
VIEW
INSIDE
VIEW

3mm
3mm
b
2
1
c
d
a
STAGE 4
This stage is describing the fitting of the floor rail.
a. Remove the factory assembled guide block from the floor rail and threshold cover. Carefully set aside for re- fitting.
b. Before fitting the floor rail remove and set aside the 2 x M5 x 12 socket screws from the floor rail bracket in the end
of the curved fixed panel.
c. Fit the floor rail over the floor rail bracket until it meets the curved fixed panel. Ensure the joint is tight between the
floor rail and fixed panel and secure with 2 x M5 x 12 socket screws using the 3mm allen key.
INSIDE
VIEW

Cette étape explique comment poser le profilé mural de la cloison fixe droite (non cintrée)
a. Positionnez le profilé mural contre le mur et sur le rail bas (attention: le haut et le bas du profilé sont différents; voir illustration
ci-dessus). Vérifiez si l'ajusteur du seuil est bien assis dans l'arrière du profilé mural, dans le creux comme illustré. Ajustez la position
de l'ajusteur du seuil comme il convient afin d'aligner le rail uniformément par rapport à la bordure avant du receveur de douche.
Pour ajuster, desserrez la vis d'un tour complet, resserrez après avoir ajusté (mais ne serrez pas trop). Mettez le profilé mural
parfaitement d'aplomb, faites des marques de fixation dans le centre des fentes/trous.
b. Percez les 3 trois dans le mur et insérez les chevilles murales. Nettoyez et appliquez un joint de silicone sur la zone qui se trouve
derrière le profilé mural, entre le receveur et le carrelage, sur 100mm à partir du bas. Fixez le profilé à l'aide des vis No 8 x 38mm.
a
x 3
b
Ø6
SILICON
3mm
7mm
TOP
BOTTOM
STAGE 5
TOP VIEW FIXED PANEL
WALL MOUNT
THRESHOLD
THRESHOLD
ADJUSTER

2
1
BOTTOM
b
SILICON
a
1
2
c
STAGE 6
This stage is describing the fitting of the straight fixed panels.
a. Apply a bead of silicon along the full length of the outer inside edge recess of the straight fixed panel floor rails where the fixed
panel is to be fitted.
b. Before fitting the fixed panels ensure that the wall mount glass guard is pushed up fully to allow the glass to easily slot into the wall
mount.
Important -The frame on the bottom of the fixed glass panel is slightly longer than the glass on one side. The opposite side is factory
assembled to be flush. Fit the fixed glass panel with the longer end bottom frame into the wall mount.
c. Lightly wet the edge of the fixed panel with soapy water and gently lower the panel into the floor rail then into the wall mount.
WALL MOUNT
GLASS GUARD
SOAPY
WATER
OUTSIDE
FACE

c
b
1
2
d
SILICON
a
SILICON
SILICON
SILICON
STAGE 7
This stage is describing the fitting of the threshold and guide block.
a. Apply a bead of silicon sealant along the outer inside edge of the floor rail in the door entrance
where the threshold cover is to be fitted.
b. Apply a bead of silicon in the floor rail at the end face of the straight fixed panel where the threshold cover is to be
fitted.
c. Fit the curved threshold cover onto the floor rail.
d. Apply a small bead of silicon to the joints between the guide and floor rail, glass and guide, guide and threshold cover.
Refit the guide. Adjust the straight fixed panel if required to close any gap between the glass and threshold cover.
INSIDE
VIEW
INSIDE
VIEW
DOOR GUIDE

3mm
20mm
32mm REF
c
e
d
9mm
d
2mm REF
3mm
b
f
92 +/- 2.5mm
106 +/- 2.5mm
99 +/- 2.5mm
STAGE 8
WALL MOUNT
MIN. ADJUSTMENT
WALL MOUNT
MAX. ADJUSTMENT
WALL MOUNT
MID. ADJUSTMENT
This stage is describing the temporary fitting of the top track to position the top track wall fixing.
a. Before fitting the top track plumb the glass panels to check for vertical.
b. Level a horizontal pencil line from the top of the Curved fixed panel wall mount. Mark a parallel line 9mm below the level line for the
centre reference of the top track wall fixing.
c. Loosen the top track wall mount cap and top track wall fixing adjuster to allow for fitting the top track.
d. Lower the top track into position, ensuring the top track glass clamps fit over the top edge of glass panels and the wall mount top
cap fits down the back of the wall mount at the top. Check the reference dimensions for the clamps to the edge of the glass panels.
e. Adjust the top track wall fixing adjuster to the wall. Centre the cylindrical fixing plate on the 9mm reference line and mark around to
determine the fixing centre. Remove the top track and carefully set aside.
f. The position of the wall fixing adjuster from the inside of the wall mount will vary depending on the adjustment/position of the glass
within the wall mount.

2.5mm
a
b
Ø6
32mm REF
2mm REF
No.8 x 50
9mm
STAGE 9
This stage is describing the fitting of the top track.
a. Remove the top track wall plate from the adjuster by loosening the set screws in the top and bottom using the 2.5mm allen key.
Place the wall plate on the wall (slot horizontal) on the previously marked position and mark the slot position.
b. Drill the fixing hole in the centre of the slot and insert the wall plug. Secure the wall plate using the No.8 x 50mm pan head screw
aligning the slot in the horizontal position.
c. Lower the top track into position, ensuring the top track glass clamps fit over the top edge of glass panels and the wall mount top
cap fits down the back of the wall mount at the top and the wall adjuster is fitted into the wall plate. Adjust as required checking the
reference dimensions for the clamps to the edge of the glass panels. a. Tighten the wall adjuster to the wall plate with the set screws in
the top and bottom of the wall plate using the 2.5mm allen key.

b
2.5mm
3mm
1
2
3
20mm
b
3mm
cc
a
STAGE 10
This stage is describing checking that the Top track and Bottom track are concentric.
a. It is important for the smooth operation of a curved enclosure that the top track and bottom track curvatures are concentric. Check
the concentricity by carefully placing a long 2m level between the outside face of the top and bottom track in the 3 positions shown and
check for vertical. Vertical will indicate that the curvatures are matching. Protect the top and bottom tracks from scratches with masking
tape on the face of the level to prevent metal to metal contact.
b. If not vertical then adjustment may be required to the top track position via the adjustment in the top of the wall mount and wall
adjuster in the top track. Adjusting these will move the top of the fixed glass panels and clamping positions outwards or inwards as
required. It may be necessary to move the wall adjuster plate horizontal position using the slot in the base of the part. Stage 9b.
c. The track position can also be moved outwards or inwards by carefully tapping the wall mounts out of vertical via the slotted holes in
the wall mounts. This will effectively move the fixed glass panels inwards or outwards at the top by the wall. Protect the wall mount
metal surfaces from damage if adjusting by tapping out of vertical.
TOP
TRACK
FLOOR
HORIZONTAL

e
2.5mm
3mm
c
d
a
b
2mm
3mm
3mm
f
STAGE 11
This stage is describing the final fitting of the top track.
a. Important – Tighten the top track locking screw underneath the top track on the fixed straight panel wall mount with the 3mm allen
key.
b. Tighten the top track glass clamps by tightening the socket set screws on both sides with the 2mm allen key. Important – Please
ensure the grey coloured glass clamp guards are fitted between the clamps and glass panels before tightening the set screws. Do not
over tighten.
c. Tighten the wall mount cap adjuster screw with the 3mm allen key.
d. Fit the Curved fixed panel wall mount top cap.
e. Fully tighten the top track wall adjuster screw using the 3mm allen key. Tighten the wall adjuster locking screws through the small
holes on the top and underside of the top track with the 2.5mm allen key.
f. Important – Before fitting the door. Fit one of the block covers (supplied in the kit of parts) onto the disc, on the curved panel, on
the inside of the unit.

3
1
2
d
a
b
c
3mm
3mm
4mm
4mm
STAGE 12
INSIDE
VIEW
ANTI-CLOCKWISE = ADJUSTS DOOR IN
CLOCKWISE = ADJUSTS DOOR OUT
ANTI-CLOCKWISE = ADJUSTS DOOR DOWN
CLOCKWISE = ADJUSTS DOOR UP
LOCK
ANTI-CLOCKWISE
This stage is describing attaching the door.
a. Important - Fit the plastic door supports to the Threshold track at either side of the Door opening.
b. Load the door glass firstly onto the door supports and guide block and then carefully guide the door up to the door roller threads
and wind them through the door roller blocks fixed to the glass. .
c. Remove both the cardboard top track door roller guides by pulling the tabs and unfolding them away from the top track.
d.Adjust the door panel if required so that it runs parallel to the door opening by adjusting the Roller blocks on the inside of the door. To
adjust the door away from the top track rotate the central set screw clockwise using the 4mm allen Key. To adjust the door to the top
track, rotate the central set screw anti-clockwise.
d.The door glass can also be raised or lowered by the adjustment screw in the top of the roller block using the 3mm allen key supplied.
Rotate clockwise to raise the door, rotate anti-clockwise to lower the door.
d.Lock the adjustment by rotating the set screw anti-clockwise in the bottom of the roller block using the 3mm allen key supplied.

a
b
c
d
x 2
STAGE 13
This stage is describing the fitting of the handle and colour details.
a. Fit the 2 x door roller block covers (supplied in the kit of parts) to the back of the door roller blocks.
b. Disassemble the handle by unscrewing the 2 x M5 x 16 Csk socket screws. Place the glass washers either side of the
2 holes in the door glass. Re-assemble the handle to the glass and tighten into position. Fit the Cover caps (supplied in
the kit of parts) to either side of the handle.
c. Fit the door guide screw cover (supplied in the kit of parts) to the door guide.
d. Fit the 6 x panel block covers (supplied in the kit of parts).
INSIDE
VIEW

SILICON
SILICON
SILICON
SILICON
SILICON
SILICON
a
b
d
d
SILICON
100mm
e
SILICON
SILICON
100mm
c
STAGE 14
This stage is describing fitting of the Seals and Silicon
a. Apply a bead of silicon along the top of the door guide. Fit the fixed panel vertical seal (shorter of the 3 seals) to the edge of the
fixed panel, ensuring it is pressed firmly against the face of the door guide.
b. Apply a bead of silicon along the top of the threshold cover where it meets the closure panel. Fit the closure panel vertical seal to
the edge of the closure panel, ensuring the seal sits firmly down onto the face of the threshold cover.
c. Fit the door vertical seal to the back edge of the door glass, the bottom of the seal should be lined up with the top of the floor
horizontal.
d. Apply a thin bead of silicon along the bottom edge of both the wall mounts and all the way up the outside of both the wall mount
extrusions between the wall mounts and the tiles. Apply a thin bead all the way along the threshold between the extrusion and the
finished floor surface/tray around the corner extrusion and along the bottom of the side panel where it meets the floor/tray. Continue
around the joint where the threshold joins the wall mounts and also 100mm up on the outside where the wall mounts and glass meet
and where the corner extrusion and glass meet. Apply a bead of silicon on the outside around the joints between the door guide and
threshold extrusion (e).
Masking tape can be used to achieve a tidy edge to the sealant. Remove the masking tape immediately and allow the silicon to cure for
24 hours before using the shower.
TOP VIEW
INSIDE
VIEW
DOOR
GLASS

QTY
PART No
DESCRIPTION
ITEM 2
8408 A SILVERROLLER BLOCK BODY COVER CAP
*72 6
8252 A SILVERDECO DISK COVER RING
73 6
8652 A SILVERDECORATIVE PIVOT DISK 2
8400 A SILVERDECORATIVE HANDLE CAP
*74
2
8582 AF
DIN O-Ring 0140-20
*75
1
4681 AF
MTK1 SLIDER & CURVED DISK DISPLAY PACK
76
1
1005 CHROMEMATKI CHROME EMBLEM
77
29
21
52
31
35
29
48
44
7
76
74 73
70 10
51
66
63
62
57
78
7
20
5
22 24 2
3
60
1
8
12
36
38
61
31
37 29
PARTS LIST
CURVED SLIDER DISK KIT OF PARTS (7370 AF)

QTY
PART No
DESCRIPTION
ITEM 1
CURVED FIXED PANEL
11
8717 ASILVER(LH) / 8730A SILVER(RH)CURVED PANEL FLOOR RAIL
21
CURVED FIXED PANEL WALL MOUNT
*3 8
1752 AF
BS nsp 5mm DIA FOAM CORD INSERT
41
7605 A SILVER/BLACK/WHITE/BRONZESLIDER WALL MOUNT
*5 1
8415 GREY/WHITE/BLACKWALLMOUNT GLASS GUARD
71
8266 AF
WALL MOUNT LOCKING SCREW
81
CURVED DOOR GLASS
91
8617 AF
SLIDER VERTICAL DOOR SEAL
10 2
7362 AF
111 SLIDER ROLLER BLOCK ASSEMBLY
11 1
8444 AF
CURVED CORNER FLOOR RAIL BLOCK
12 1
1488 A SILVERM5 x 10 CSK SKT
13 2
1282 A SILVERM5 X 12 SOCKET DOMED ST.ST
14 1
8449 A SILVERCURVE FLOOR RAILADJUSTER
15 1
8427 AF
ADJUSTER CLAMP
16 1
8261 AF
PIVOT BLOCK ADJUSTER SCREW
*17 1
7370 AF (SILVER/BLUE/GREEN/RED/GOLD/COPPER/BRASS/WHITE/BLACK)
MATKI ONE CURVED DISK KIT OF PARTS
18 1
0950 AF
MATKI ONE CURVED SLIDER INSTALLATION INSTRUCTIONS
*19
1
MATKI ONE CURVED SLIDER KIT OF PARTS
6
QTY
PART No
DESCRIPTION
ITEM 1
STRAIGHT FIXED PANEL GLASS 1
STRAIGHT PANEL FLOOR RAIL
1
CURVED STRAIGHT PANEL GLASS RAIL 1
8409 WHITE
THRESHOLD END CAP 1
SLIDER THRESHOLD COVER 2
1488 A SILVERM5 x 10 CSK SKT 1
8427 AF
ADJUSTER CLAMP 1
8431 AF
BOTTOM WALL CORNER BRACKET 1
CURVED TOP TRACK 2
8262 AF
PIVOT BLOCK ADJUSTER SCREW 2
1339 AF
SMALL WHITE DAMPER 4
8416 BLACKSLIDER WHEEL STOP 2
8429 A SILVERSLIDER TOP TRACK END 1
TOP TRACK SPACER 1
8450 A SILVERCURVED MIDDLE TOP TRACK BRACKET 2
111 CURVED INTERNAL ROLLER -TRACK PROF 1
8447 A SILVERCURVED WALL PLATE 1
8445 A SILVERWALL PLATE ADJUSTER 1
8451 A SILVERTOP TRACK ADJUSTER END BRACKET
20
1
8448 A SILVERADJUSTER END COVER PLATE
21
2
1467 A SILVERM5 X 10 SOCKET SET SCREWA2
22
2
1502 A SILVERM5 X 6 SOCKET SET SCREWA2
23
2
8261 AF
PIVOT BLOCK ADJUSTER SCREW
24
2
8436 A SILVERPIVOT CLAMP BODY
25
3
1503 A SILVERM5 x 20 CSK SKT
26
4
8579 AF
DIN O-Ring 0190-20
27
4
1298 A SILVERM4 X 4 SOCKET SET SCREWA2
28
2
8432 GREYSLIDER PIVOT CLAMP GUARD
29
1
8407 AF
SLIDER WALL MOUNT TOP CAP
30
1
1442 A SILVERNO. 8 X 12 CSK POZI S TAP ST/ST
31
2
8581 AF
M.Y MOD SOCK SET + ST.ST BEARING(MIS3432)
32
0.55
1306 AF
WHITE PTFE ROD 6mm DIA
33
1
7363 AF
111 SLIDER GUIDE BLOCK ASSEMBLY
QTY
PART No
DESCRIPTION
ITEM 7
1818 AF
WALL PLUG 1
8622 AF
3mm AF BALL END 1
1286 AF
2mm ALLEN KEY 1
1166 AF
4mm ALLEN KEY 1
8435 A SILVER
BRACKET HOLE COVER 1
8448 A SILVER
ADJUSTER END COVER PLATE 1
1967 AF
CLEAR MATKI SEALANT 78g WITH LOGO
59 1
60
2
8592 BLACK
INSTALLATION DOOR SUPPORT
61 2
8439 GREY
HANDLE WASHER
62 2
8257 A SILVER
HANDLE CAP WASHER
*63 1
8250 A SILVER
HANDLE CENTRAL BAR
64 2
1417 A SILVER
CSK SKT SCREW
65 2
7645 A SILVER
HANDLE SLEEVE
*66
67
7699 M CLEAR/PLAIN(LH) / 7698 M CLEAR/PLAIN(RH)
8727 A SILVER/BLACK/WHITE/BRONZE
7371 A SILVER (BRASS/COPPER)
7704 M CLEAR/PLAIN(LH) / 7703 M CLEAR/PLAIN(RH)
8446 A SILVER
CURVED WALL MOUNT CAP
6
1210 A SILVER
No.8 x 38 PAN HEAD POZI S TAP ST/ST
68 1
1492 A SILVER
69 No.8 x 50 PAN HEAD POZI S TAP ST/ST
34
35
36
37
7700 M CLEAR/PLAIN(900) / 7701 M CLEAR/PLAIN(1200) / 7702 M CLEAR/PLAIN(1500)
8714 A SILVER(900) / 8715A SILVER(1200) / 8716 A SILVER(1500) (RH)
8724 A SILVER(900) / 8725A SILVER(1200) / 8726 A SILVER(1500)
8723 A SILVER
8740 A SILVER(900) / 8741A SILVER(1200) / 8742 A SILVER(1500)
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
8711 ASILVER(900) / 8712 A SILVER(1200) / 8713 ASILVER(1500) (LH)
8804 BLACK
1
8449 A SILVER
70 CURVE FLOOR RAILADJUSTER
8805 A SILVER(900) / 8806A SILVER(1200) / 8807 A SILVER(1500)
1
8261 AF
71 PIVOT BLOCK ADJUSTER SCREW 1
8427 AF
ADJUSTER CLAMP
PARTS LIST
SLIDER DOOR PACK
* colour variant on parts
CURVED SLIDER KIT OF PARTS (7371 AF)
PANEL PACK

BLEACH
WHITE
SPIRIT
13
Matki PLC, Churchward Road, Yate,
Bristol BS37 5PL
EN 14428:2008+A1
Matki Glass Guard Easy Clean Surface Protection (optional) and General Cleaning Guide
Cleaning Instructions
Matki Glass Guard allows water to form minute beads which easily trickle off the surface of the glass. This makes the glass easier to
clean - the glass does not need to be cleaned as frequently, but it does require occasional maintenance. As less cleaning is required
the use of detergents can be minimised thus helping to protect the environment. The lifespan of the Matki Glass Guard is
dependant on the frequency of use of the shower and the degree of water hardness.
The combination of alkaline materials and humidity affects glass in an extremely aggressive way. Do not use bleach, alkaline,
acid-based or aggressive and abrasive glass cleaners, detergents or household cleaning products on the glass or frames.
We recommend that glass is washed down with clean water and a soft clean cloth or sponge and dried off with a microfibre cloth.
The special coating is only present on the inside of the glass.
Matki Glass Guard is guaranteed for 2 years provided that the guidelines and cleaning instructions are followed.
Aluminium and Chrome parts should be cleaned with a mild non scratch household cleaner and a soft cloth or sponge.
Do not use acidic-based descaler products or products which are unsuitable for cleaning enamelled surfaces, including abrasive
cleaners or cleaners containing bleach or solvents, as the products will effect the anodised framework. Under no circumstances use
cleaners with a pH level exceeding 8.
Matki does not recommend the use of 'Leave-on' shower cleaners on Matki Glass Guard Products.
Water Softeners and Glass Guard - Certain types of water softeners increase the alkalinity of the water due to a carry-over of
Chloride during re-generation which can cause aggressive water spots on both untreated and Glass Guarded glass. If using a water
softener we recommend a two-cylinder machine with automatic re-generation instead of a timer. If a single-cylinder water softener
with timer is already installed it is recommended that after each shower excess water is removed from the glass with a squeegee or
with a micro-fibre cloth.
MAINTENANCE
Flash Bathroom Spray or Cif Bathroom Spray can be used on Matki Products.
Read manufacturers label before using any cleaning materials.
IMPORTANT
Matki Glass Guard is guaranteed for 2 years. It is essential that the cleaning instructions are followed in order
to maintain the hydrophobic properties of the glass coating. In the event of the failure to comply in any way
with these instructions, any warranty or guarantee will be null and void.
Wash down with clean warm water
and a soft clean cloth or sponge. Do not use bleach, alkaline or acid-based,
aggressive or abrasive cleaning products.
MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL
TELEPHONE: [phone] (CUSTOMER SERVICES) EMAIL: [email protected]
Annual recommended maintenance - Matki recommend annually lubricating the barrel of the hinge with a lubricating spray such
as WD-40 to remove dust build-up and to aid the movement of the hinge.
