Matrix MR111SS/2 Reference manual

Range Cooker
Manual for installation,
use and maintenance
MR111SS/2
parts +1 year labour
year
guarantee
www.matrixappliances.co.uk

2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault
with your appliance and to register your appliance for guarantee
purposes.
Appliance Model
Serial Number
EU Declarations of Conformity
This appliance has been manufactured to the strictest standards
and complies with all applicable legislation, including Electrical safety
(LVD) 2014/35/EU and Electromagnetic interference (EMC) 2014/30/
EU.

3
Parts intended to come into contact with food conform to 1935/2004/
EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both
energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
Important
Read the instructions carefully before using the cooker.
Keep the instructions in a safe place for future reference.
Follow the instructions for first use.
Always use oven gloves when removing shelves and trays from the
cooker.
Always grill with the door closed.
Do not grill food containing fat without using the grill pan grid.
Do not use the grill pan for roasting.
Do not place cooking utensils or plates directly on the oven base.
Do not cover the grill pan grid or the oven walls with aluminium foil.
Do not attempt to repair the internal workings of your oven.

4
Cookers become hot during and immediately after use. Do not touch
the pan stands, burners, hob spill tray or oven internal parts until the
appliance has been allowed to cool.
After use, ensure that all the control knobs are switched off.
Keep children away from the cooker when in use and immediately
after use.
Ensure that the appliance is correctly adjusted for the type of gas
available before installation.
The use of a gas appliance produces heat and humidity in the room
in which it is installed. Ensure that the room is well ventilated, either
by the use of natural ventilation outlets (e.g. windows) or a ducted
extractor.
This cooker has been designed for use only as a cooking appliance.
Any other use (e.g. heating rooms) should be considered incorrect
and therefore dangerous.
This cooker must not be installed in a bed-sit room of less than 20m³.
These instructions are valid only for the intended countries of
destination, the symbols of which appear on the cover, the
packaging and on the appliance. Use outside of these countries
may or may not be possible. You should consult the manufacturer for
appropriate advice.
Do not spray aerosols in the vicinity of this appliance when in use.
Do not store or use flammable substances in the vicinity of this
appliance when in use.

5
When correctly installed, your product meets all safety requirements
laid down for this type of product.
However, special care should be taken around the rear or the
underneath of the appliance as these areas are not designed or
intended to be touched and may contain sharp or rough edges that
could cause injury.

6
Before first use
• Before using the oven for the first time we recommend that you
clean the oven with soapy water, rinse carefully dry thoroughly,
and then heat at maximum temperature on the grill function
for 15 minutes and the fan oven function for one hour. A slightly
unpleasant smell may be produced, caused by grease remaining
on the oven elements from the production process.
• Your hob may take a little longer than normal to ignite each burner
upon first use. This is normal and is not indicative of a fault. Before
igniting your burner(s) for the first time, please carry out the checks
on page 7.
Please note:
• This oven has been fitted with a cooling fan to achieve maximum
efficiency and to maintain low surface temperatures. The cooling
fan will switch on automatically when the oven reaches a preset
temperature and switch off automatically when the oven has
cooled sufficiently, even after the oven is switched off (but
not when the appliance has been disconnected from the mains
supply).
• The oven is equipped with a safety thermostat which will switch
off the oven to prevent overheating. Overheating can be caused
by incorrect use of the oven or defective components. If the
oven switches off due to overheating, wait for the oven to cool
down before using it again. If the error continues, contact CDA
Customer Care.

7
Before using the hob
• Before lighting the hob burners, check
that the flame-spreaders (F) are in
position with their respective burner
caps (C), ensuring that the holes in the
flame-spreaders are aligned with
the ignition electrodes (S) and
thermocouples (T) as shown in fig. 1.
• Once the contents come to the
boil, turn down the flame far enough to
prevent the liquid from boiling over. To
prevent burns or damage to the
hob during cooking, all pans or
griddle plates must be placed inside the perimeter of the hob.
• Place the pan on the pan supports with the handles facing away
from the edge of the work top. This will reduce the risk of the pan
being knocked or pulled over.
Deep Fat Frying
• Only fill the pan one third full of oil.
• Do not put a lid on the pan and never leave the pan unattended.
• In the event of a fire, do not move the pan and turn off all
control knobs.
• Then put a damp cloth over the pan, or a correctly fitting lid to
smother the flames.
• Do not put water on the fire.
• Leave the pan to cool for at least 30 minutes before attempting to
move it.
fig. 1
C
F
S
T

8
Gas burners:
1. Left Rapid 3.0kW
2. Left Semi-rapid 1.75kW
3. Triple-ring/Wok 3.7kW
4. Right Semi-rapid 1.75kW
5. Right Rapid 3.0kW
1
2 3 4
5
Control panel:
6. Front left rapid burner control
7. Rear left semi-rapid burner control
8. Centre Triple ring/Wok burner control
9. Rear right semi-rapid burner control
10. Front right rapid burner control
This appliance is class 2/1
6 7 8 9 10
Using your hob
Fig.2

9
Gas burners:
Gas flow to the burners is controlled by the control knobs (6 - 10 on the
diagram on the previous page). There are 3 positions shown on the
control panel. Turning the control knob to the positions shown below
achieves the following:
Closed (OFF position)
Maximum position: Provides fast boiling function
Minimum position: Provides simmer function
The hob can be set to the desired position by turning the control
knob through the adjustment range in an anti-clockwise direction.

10
Igniting the burners
The hob is fitted with a flame failure device. Flame failure devices
operate by shutting off the supply of gas to the burner in the event
that the flame is extinguished accidentally.
To ignite the burners, follow these
instructions:
1. Lightly press the control knob down
and turn the knob anticlockwise to
the maximum position. Firmly press and
hold down the control knob to begin the ignition process (a clicking
sound will be heard). Hold down the control knob for a few
seconds after ignition to allow the safety device to detect that the
burner is lit.
2. Once the burner is lit, adjust the burner power to the required
position.
Please note:
• The ignition device should not be operated for more than
15 seconds.
• If a burner does not ignite, or turns off accidentally, turn the
control knob to the ‘off’ position, and wait for one minute before
attempting to reignite the burner.
• If the burner does not ignite, repeat the ignition process with the
burner at the minimum position.
Fig.3

11
Efficient use of your Hob
The hob is equipped with burners of different sizes, designed to
accommodate most shapes and sizes of pan. For best results,
only use pans with flat bottoms and choose an appropriate burner
depending on the size of the pan. The most efficient use of the hob is
shown below, where the pan and burner are correctly chosen.
Ensure that the pans do not overlap the edge of the pan stand, or
cover the control panel. Position the pan centrally above the burner.
The table below shows the sizes of pan that should be used with
each burner:
Fig.4
Burner Size Minimum Pan Diameter (cm) Maximum Pan Diameter (cm)
Semi-Rapid 12 20
Rapid 20 26
Triple ring 24 28
Wok - 36

12
Correct use of the wok
pan adaptor
The wok pan adaptor is a special
stand that is designed to be fitted over
the triple ring burner to give support to
round bottomed woks.
When using a wok, always place the
wok pan adaptor in position over the
pan support on the triple ring burner as
shown in Fig.6.
IMPORTANT:
• The wok pan adaptor (Fig.6) must be
placed over the pan support on the
triple ring burner.
• Do not use the wok pan adaptor for
standard flat bottomed pans.
Fig.5
Fig.6

13
Using your oven
Cooking function knob
To set the function, turn the cooking function knob clockwise to the
required function.
Each of the oven functions uses different elements within the oven to
offer you the best choice of cooking every time. These are explained
below:
Oven Light
This function switches on the oven light without using any heating
elements to illuminate the oven cavity.
The oven light remains on with every cooking function.
Fanned Grill
This function uses the fan to circulate the heat from the grill
element around the food.
The temperature must be set between 60-200ºC
Grill
This function radiates the heat from the grill element.
The temperature must be set between 60-200ºC
Fig.7
1 2

14
For both grill functions please note:
• Always grill with the oven door closed.
• Put the grill pan as close to the grill as possible.
• Do not grill for more than 30 minutes at a time.
• Preheat the grill for approximately five minutes with the oven door
closed.
Defrost
Using the fan only this oven function circulates the air around
the oven cavity, speeding up the natural defrost process (1kg
takes approximately one hour, depending on the type of food).
Fan Oven
Using the circular element and the fan with a temperature
between 60ºC and Max, this cooking function blows the
air into and around the oven cavity. Temperatures are achieved
quicker, reducing or even removing the need for preheating.
Both cooking temperatures and cooking times can be reduced
for a more energy efficient cooking programme.
Perfect for cooking various food types simultaneously as foods
are sealed quickly to prevent flavour transfer.

15
Temperature knob
To set the temperature, turn the temperature knob clockwise
to the required temperature.
Once the oven has reached the required temperature, the
temperature indicator lamp on the control panel will switch off.
The temperature indicator lamp will light up when the oven
elements are working.
Timer knob
The oven is equipped with a cut off timer to switch off the oven
after a preset time of up to 120 minutes.
To set the timer, turn the timer control knob fully clockwise to the
maximum, and then anticlockwise until the control knob indicates
the required time.
At the end of the preset time, a buzzer will sound and the oven
elements will be switched off.
Please note: Always ensure that you turn all the control knobs back
to their off positions after cooking.

16
Care and Maintenance
Cleaning the Cooker
IMPORTANT:
Always disconnect the appliance from the power supply before
undertaking any cleaning or maintenance.
You should always allow the cooker to cool fully after use before
undertaking any cleaning or maintenance.
• Steam cleaners must not be used when cleaning this appliance
• Clean the cooker regularly and remove spills as soon as they
occur.
• Do not allow fat or oils to build up on the hob or in the oven.
• Do not place hot enamel parts (e.g. burner caps, grill pan) in water.
Leave them to cool first.
• Do not allow vinegar, coffee, milk, saltwater, lemon or tomato juice
to remain in contact with enamel parts
• Do not use abrasive or corrosive cleaners (including scouring pads
or Cif) as these could scratch the appliance, remove control panel
markings or damage the cooker.
• Do not clean the removable parts of the cooker in a dishwasher,
these must be washed by hand.
For the glass and stainless steel surfaces, you should use a
nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch
the surface and could erase the control panel markings. Stainless
steel can be effectively cleaned by simply using a dilute solution of
water and mild detergent and drying to a shine with a clean cloth.

17
Over time with use, the stainless steel surface may discolour;
this is normal and does not constitute a fault with this appliance.
Proprietary stainless steel cleaners are available.
Cleaning the oven interior
To clean the oven interior, suitable proprietary
chemical cleaners may be used after
first consulting with the manufacturer’s
recommendations and testing a small sample
on the oven cavity.
Do not use metal scrapers or harsh cleaners on the oven door
glass. These could cause scratches, which may result in the glass
shattering.
To remove the side racks, press down on the
top bar of the side rack to free the rack from the
top securing pin, then remove the side rack by
lowering it out so that the hooks on the lower edge are freed from the
oven cavity (as shown in fig. 9 and 10).
To replace the side racks, locate the lower
hooks in the oven cavity, then pivot the side rack
back into position, pressing the top bar down to
relocate it against the securing pin.
Ensure that all parts are correctly replaced after cleaning before
attempting to use the cooker, and that the rubber pads are in place
on the base of the pan stands before repositioning the pan stands
on the hob top. To replace the hob burner parts correctly, refer to fig.
1 on page 7.
Fig.8
Fig.9
Fig.10

18
Removing the Oven Door
The oven door can easily be removed
as follows:
• Open the door to the full extent
(fig. 11)
• Open the lever A completely on
the left and right hinge see (fig. 12)
• Hold the door as shown in fig. 15
• Gently close the door (fig. 14) until
left and right hinge levers A are
hooked to part B of the door (fig.
13)
• Withdraw the hinge hooks from
their location following arrow C
(fig. 14)
• Rest the door on a surface.
To replace the door, repeat the above
steps in reverse order.
Fig.11
Fig.12
Fig.13
Fig.14
Fig.15

19
Care and Maintenance
Flexible gas pipe
Check the flexible gas pipe connecting the gas supply to the cooker
regularly.
It must be always in perfect condition; in case of damage contact
Customer Care for advice.
Control knobs
Should any of the control knobs become stiff, do not use force.
Contact Customer Care for advice.
Changing the oven light
1. Disconnect the electrical power supply (for example, by switching
off the main isolator switch).
2. Unscrew the light cover.
3. Fit a new bulb.
4. Refit the cover.
Note:
Use only bulbs designed to resist up to 300°C with the following
characteristics: 230 V, type E14 and same power of the replaced bulb
(check watt power as stamped on the bulb itself).

20
What to do if you smell gas:
1. Open doors and windows
2. Turn the gas supply off
3. Call TRANSCO on 0800 111 999
Total rated gas input: 13.2 kW
Mains electrical voltage: 230-240Vac, 50Hz
Total rated electrical consumption: 2.965 kW
If your cooker is not working
1. Check that the mains supply has not been switched off.
2. Check that the fuse in the spur has not blown.
3. Ensure that the burner components are not excessively soiled as
this can lead to ignition problems
Burner size Nominal Rating
(kW)
Simmer Rating
(kW)
LPG ow rates (l/h)
G30 (Butane) G31 (Propane)
Semi-Rapid 1.75 0.6 127 125
Rapid 3.0 1.0 218 214
Triple ring / Wok 3.7 1.25 269 264
