Matrox Supersight Assembly Instructions

Matrox Supersight
Installation and Hardware Reference
Manual no. Y11162-101-0301
October 15, 2014

Matrox
®
is a registered trademark of Matrox Electronic Systems Ltd.
Microsoft
®
and Windows
®
are registered trademarks of Microsoft Corporation.
Intel
®
, SpeedStep
®
, and Sean
®
are registered trademarks of Intel Corporation.
AMIBIOS
®
is a registered trademark of American Megatrends Inc.
PCIe
®
and PCI Express
®
are registered trademarks of PCI-SIG.
PICMG
®
is a registered trademark of the The PCI Industrial Computer Manufacturers
Group.
Hilgraeve Hyper Terminal Private Edition is copyright Hilgraeve Inc.
Some of the software included in this product contains copyrighted software that is licensed
under the GPL.
All other nationally and internationally recognized trademarks and tradenames are hereby
acknowledged.
© Copyright Matrox Electronic Systems Ltd., 2009-2014. All rights reserved.
Limitation of Liabilities: In no event will Matrox Electronic Systems Ltd. or its suppliers be
liable for any indirect, special, incidental, economic, cover or consequential damages
arising out of the use of or inability to use the product, user documentation or related
technical support, including without limitation, damages or costs relating to the loss of
profits, business, goodwill, even if advised of the possibility of such damages. In no event
will Matrox Electronic Systems Ltd. and its suppliers’ liability exceed the amount paid by
you, for the product.
Because some jurisdictions do not allow the exclusion or limitation of liability for
consequential or incidental damages, the above limitation may not apply to you.
Disclaimer: Matrox Electronic Systems Ltd. reserves the right to make changes in
specifications at any time and without notice. The information provided by this document is
believed to be accurate and reliable. However, neither Matrox Electronic Systems Ltd. nor
its suppliers assume any responsibility for its use; or for any infringements of patents or
other rights of third parties resulting from its use. No license is granted under any patents or
patent right of Matrox Electronic Systems Ltd.
PRINTED IN CANADA

Contents
Chapter 1: Before you begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Types of units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Documentation conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SHBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inspecting the Matrox Supersight package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Standard components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Optional installed components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Accessing your Matrox Supersight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Starting the Matrox Supersight unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Powering your Matrox Supersight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Limited automatic logins and default passwords . . . . . . . . . . . . . . . . . . . . . . 22
BIOS setup utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Restarting individual SHBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Turning off the Matrox Supersight unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operating states of the Matrox Supersight unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LEDs on the bracket of the SHB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Handling precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Manual overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 2: Connecting peripherals to the
front and back panels of the unit . . . . . . . . . . . . . . . . . . . . . . . . . 29
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting a USB device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting video output display devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Networking connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Chapter 3: Connecting devices to the backplane
and to the Matrox Supersight SHB-5520 board. . . . . . . . . . . . . . 33
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Removing the chassis cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Removing the retainer guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing the drive-tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Adding boards to the backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Establishing which boards can be installed . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Adding boards to the Matrox Supersight Solo unit . . . . . . . . . . . . . . . . . . . . . 46
Adding boards to the Matrox Supersight e2 unit. . . . . . . . . . . . . . . . . . . . . . . 49
Connecting devices to the internal connectors of the SHB . . . . . . . . . . . . . . . . . . . . 54
Connecting additional mass storage devices . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Installing a mass storage device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Installing or removing RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Connecting the chassis’ fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Chapter 4: Power management and temperature control . . . . . 65
Power management and temperature control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
ACPI technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Enhanced Intel SpeedStep technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Appendix A: Hardware glossary . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Appendix B: Technical reference . . . . . . . . . . . . . . . . . . . . . . . . . 79
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Matrox Supersight SHB-5520 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Default hard disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Optional optical disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Pinout descriptions of external connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
USB connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Gbit Ethernet connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Analog video output connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Pinout descriptions of internal Matrox Supersight SHB-5520 connectors . . . . . . . . . 93
USB header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Serial port headers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Automatic power-up connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Board power-supply connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Fan power-supply connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Pinout descriptions of backplane connectors and LEDs . . . . . . . . . . . . . . . . . . . . . . . 99
Chassis fan power-supply connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
LED, system reset, and power connectors . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Voltage rail LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Appendix C: BIOS reference for
Matrox Supersight SHB-5520 . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
One SHB at a time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Maximizing performance by default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
The BIOS setup utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Entering the BIOS setup utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
The Menu bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
The Legend window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
The Selection window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
The Item Specific Help window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Default settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Advanced menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
PCI Subsystem Settings submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Trusted Computing submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
WHEA Configuration submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
ACPI Settings submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
CPU Configuration submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Runtime Error Logging submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Spread spectrum (clockgen) configuration submenu . . . . . . . . . . . . . . . . . . . 121
SATA Configuration submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
USB Configuration submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Super IO Configuration submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Serial Port nConfiguration sub-submenu . . . . . . . . . . . . . . . . . . . . . 124

Serial Port Console Redirection submenu . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Console Redirection Settings sub-submenu . . . . . . . . . . . . . . . . . . . 125
Serial Port for Out-of-band Management/Windows
Emergency Management Services Console
Redirections sub-submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Network Stack submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Chipset menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
North Bridge submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Tylersburg IOH Configuration sub-submenu . . . . . . . . . . . . . . . . . 132
Intel VT for Directed I/O Configuration sub-submenu. . . . . . . . . . 133
IOH Thermal Sensors sub-submenu . . . . . . . . . . . . . . . . . . . . . . . . 134
QPI Link sub-submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
DIMM Information sub-submenu. . . . . . . . . . . . . . . . . . . . . . . . . . 136
South Bridge Configuration submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
USB Configuration sub-submenu . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Server Mgmt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
System event log submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
BMC network configuration submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Error simulation submenu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
iSCSI menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Boot menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
CD/DVD ROM Drive BBS Priorities submenu . . . . . . . . . . . . . . . . . . . . . 144
Hard Drive BBS Priorities submenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Security menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Save and Exit menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
BIOS messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Types of POST errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Types of beep codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Types of POST messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Appendix D: Listing of Matrox Supersight units . . . . . . . . . . . . 153
Key feature changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Index
Regulatory Compliance
Limited Warranty

Chapter
1
Chapter 1: Before you begin
This chapter introduces you to the key features of your
Matrox Supersight unit.

10 Chapter 1: Before you begin
Overview
A Matrox Supersight unit is a high-performance computing (HPC) platform that
allows the connection of Matrox Supersight SHB-5520 system Host board(s),
GPU boards (display boards), boards with field-programmable gate arrays
(FPGAs), and frame grabber/processing boards in one chassis. All these boards are
connected to a PCIe switched fabric backplane; allowing Matrox Supersight and
its associated boards to communicate with each other on its own network.
Each Matrox Supersight SHB-5520 in the unit acts as a separate computer with
its own BIOS, operating system, memory, hard disk drives, USB ports, and
network ports. An SHB’s access to an auxiliary board (such as a GPU, FPGA, and
frame grabber/processing board) depends on the number of SHBs connected to
the backplane and on the slot in which the SHB board and the auxiliary board
are connected. Each SHB can either be connected to one or more of its own hard
disk drives.
Types of units
There are two types of Matrox Supersight units available. They differ as follows:
• Matrox Supersight e2 can have up to 4 possible SHBs.
• Matrox Supersight Solo can only have 1 SHB. In addition, there is an 8-connector
version and a 13-connector version. Other than the difference in the number of
PCIe connectors, the two variations function identically.

Backplane 11
The Matrox Supersight units come pre-installed with a backplane, one SHB-5520
with memory modules, Microsoft Windows 7 for Embedded Systems 64-bit, a
mass storage device, a CD-RW/DVD-ROM drive, a power supply, and three
cooling fans; these are encased within a metal chassis.
Documentation conventions
The following conventions are used in this manual.
Node A node consists of one SHB-5520, along with any additional boards that are
connected to the SHB through the backplane, such as GPU boards, boards with
FPGAs, frame grabber boards, and processing boards.1
Naming convention This manual refers to both Matrox Supersight e2 and Matrox Supersight Solo
units as Matrox Supersight. When necessary, their full names are used.
Backplane
The Matrox Supersight backplane is a switched fabric backplane. A switched fabric
backplane allows one SHB to communicate without additional connectors with
the PCIe 2.0 boards connected to the same backplane and belonging to the same
node. This communication occurs below the operating system level, and can be
accessed by programs like a Distributed MIL application. Note that, since this
communication occurs below the operating system level, no Ethernet network
connection is required.
The Matrox Supersight backplane differs between versions:
1. Note that in previous versions of this manual, a node was referred to as a
cluster.
Hardware differences Matrox Supersight e2 Matrox Supersight Solo
Number of PICMG 1.3 SHB connectors 4 1
Number of x16 PCIe 2.0 connectors 8
*
7
†
or 4
‡
Number of x8 PCIe 2.0 connectors 4
*
13
†
or 8
‡
Number of SATA 2.0 (3 Gbps) connectors 5 -14 (2 on the backplane and 3 per SHB) 5 (2 on the backplane and 3 on the SHB)
*. Depending on the number of SHB’s connected, you can have a maximum of six x16 PCIe boards, and either four x8 PCIe boards or an additional two x16 PCIe
boards.
†. For the 13-connector version, you can have either seven x16 PCIe boards and one x8 PCIe board or thirteen x8 PCIe boards.
‡. For the 8-connector version, you can have either four x16 PCIe boards or eight x8 PCIe boards.

12 Chapter 1: Before you begin
Matrox Supersight
SHB-5520 in a Matrox
Supersight Solo
13-slot PCIe backplane
Matrox Supersight
SHB-5520 in a
Matrox Supersight Solo
8-slot PCIe backplane
SHB
frame grabber board
Four Matrox Supersight
SHB-5520 in a
Matrox Supersight e2
backplane with four
frame grabbers boards

Backplane 13
Switched fabric
backplanes
As a switched fabric backplane, the Matrox Supersight unit uses a series of PCIe
switches to control the connections between your PCIe boards and the Matrox
Supersight SHB-5520 board(s). A switched fabric backplane allows traffic from
one PCIe connector to pass through to the next available PCIe switch without
being bottlenecked, while providing maximum bandwidth to the SHB.
Some PCIe connectors on the Matrox Supersight backplane are paired, allowing
one of two PCIe connectors to communicate at x16 while the other is
non-functional or both PCIe connectors of the pair to communicate at x8. These
PCIe connector pairs have their PCIe lanes routed through a series of
multiplexers/demultiplexers (muxes/demuxes). These muxes/demuxes are
initialized upon start-up, based on the presence of a board in the PCIe connector
that can be x8 or non-functional (x0).
Matrox Supersight Solo (13-connector version) uses two x16 lanes for
communication with the SHB, while Matrox Supersight e2 and the 8-connector
version of Matrox Supersight Solo uses only one.
x16
x8 x16
x16
PCIe 2.0 switch
Matrox Supersight Solo - 7 + 6 PCIe connector configuration
PCIe 2.0 switch
x16
Mux/Demux
14
x16
x0/x8 x16/x8
x8
13
x16
10 11
Mux/Demux
x16
x0/x8 x16/x8
x8
8 9
Mux/Demux
x16
x0/x8 x16/x8
x8
x16
67
Mux/Demux
x16
x0/x8 x16/x8
x8
x16
45
Mux/Demux
5
x16
x0/x8 x16/x8
x8
4
x16
Mux/Demux
3
x16
x0/x8 x16/x8
x8
2
x8
x8
1
2 x16
Note that this PCIe connector configuration is only available on the 13-connector version.
Paired PCIe connectors are connectors where either: one works at x16, or both work at x8.
PCIe connectorSHB connector
Legend
Paired connectors

14 Chapter 1: Before you begin
[
o
x16
x16
x16
PCIe 2.0 switch
Mux/Demux
Matrox Supersight Solo - 8 + 5 PCIe connector configuration
PCIe 2.0 switch
2 x16
x16
12 13
x16
x0/x8 x16/x8
x8
Mux/Demux
11
x16
10 11
x16
x0/x8 x16/x8
x8
Mux/Demux
x16
x16
98† 8†
x16
*
x0/x8 x16/x8
x8
1
x16
67
Mux/Demux
x16
x0/x8 x16/x8
x8
x16
45
Mux/Demux
x16
x0/x8 x16/x8
x8
x16
Mux/Demux
3
x16
x0/x8 x16/x8
x8
2
*. These PCIe connectors are only present on the 13 connector v of Matrox Supersight Solo.- ersion
†. PCIe connector 1, and 8 are paired.
Paired PCIe connectors are connectors where either: one works at x16, or both work at x8.
PCIe connectorSHB connector
Legend
Paired connectors
PCIe connectorSHB connector
Legend
Paired connectors
Paired PCIe connectors are connectors where either: one works at x16, or both work at x8.
Matrox Supersight e2
PCIe 2.0 switch PCIe 2.0 switch PCIe 2.0 switch
PCIe 2.0 switch PCIe 2.0 switch
x16
x16
1
PCIe 2.0 switch PCIe 2.0 switch
x16
1
x16
Mux/Demux
2
x16
x16/x0 x /x016
x16
25
x16
x16x16
x16
3
PCIe 2.0 switch
34
x16
x8
x0/x8 x16/x8
Mux/Demux
67
x16
x16
x16 x16
8
x16
x16/x0 x /x016
x16
4
Mux/Demux
910
x16
x8
x0/x8 x16/x8
Mux/Demux

SHBs 15
SHBs
The Matrox Supersight SHB-5520 board is a PICMG 1.3 board that intergrates
the following functionality:
•Processing. Processing comes from either one or two multi-core Intel Xeon
processors. There are two types of processors available:
- Intel Xeon Quad-Core E5620 2.4 GHz processor.
- Intel Xeon Six-Core E5645 2.4 GHz processor.
These processors use processor technologies designed to accelerate multimedia and
imaging applications. The processors use multimedia extension (MMX)
technology, streaming SIMD extensions (SSE, SSE2, SSE3, and SSSE3)
technology, and EM64T (Intel 64 architecture) technology. These technologies
are extensions to the Intel architecture, which address the key characteristics of
applications that must handle large amounts of image, video, and graphics data.
•Display. Display capabilities come from a dedicated graphics controller. The
graphics controller allows you to send analog video data to one high-resolution
analog display device, such as an analog monitor or analog flat panel. The
maximum display resolution is 1600 x 1200 with 16 bits/pixel.
•Memory. Memory comes from the SO-DIMM memory modules installed in the
six 204-pin SO-DIMM slots; each slot supports a SO-DIMM memory module
up to 8 Gbytes in size. The DDR3 modules run at up to 666 MHz (DDR3-1333).
The total amount of memory can be 48 Gbytes.
•Mass storage. Mass storage comes from a 2.5-inch SATA hard disk drive,
connected to the first SHB1through the backplane. Each SHB must be connected
to a mass storage device containing its operating system; without it, the SHB
cannot boot. The chassis has room for four 2.5-inch SATA hard drives and one
CD RW/DVD ROM drive.
1. The first SHB is the SHB that is in the left-most SHB slot on the backplane, as seen
from the front panel (see the illustration in the Establishing which boards can be
installed section, in Chapter 3: Connecting devices to the backplane and to the
Matrox Supersight SHB-5520 board).

16 Chapter 1: Before you begin
•Networking. Networking comes from the two integrated Gbit Ethernet
interfaces. Each Gbit Ethernet interface supports 10BaseT, 100BaseT, and
1000BaseT, which can be used to connect the Matrox Supersight SHB-5520
board to your network.
•BIOS. The BIOS is stored on an on-board flash memory device. The BIOS acts
as an interface between the operating system and the Matrox Supersight
SHB-5520 board.
The installation of a Matrox Supersight SHB-5520 board can block some PCIe
connectors on the backplane, as each Matrox Supersight SHB-5520 board takes
up to two slots, and partially blocks a third slot. This partially blocked third slot
can still be used, but only by short (1/2 length) PCIe boards or auxiliary I/O
adapter brackets.

SHBs 17
RAM
North bridge
chip
(IOH):
Intel 5520
South bridge
chip
(IOH-IOC):
Intel ICH10R
Intel Xeon
Quad Core
or
Six Core
Processors
Chip
set
PICMG 1.3
edge
connector
to the
backplane
Matrox Supersight
SHB-5520 board
2x SATA
4x USB 2.0
Three SATA
hard drive ports
(on headers)
Two
10/100/1000
BaseT ports
Intel 82576
Gigabit
Ethernet
controller
Two USB 2.0
external ports
(on )bracket
Two USB 2.0
internal ports
(on header)
QPI
QPI QPI
Graphics
controller
and Super I/O
controller
ESI
x4 PCIe
RAM
Analog video
display port
Two
RS-232 ports
x1 PCIe
2x USB
LPC
RMII
x4 PCIe
Intel Xeon
Quad Core
or
Six Core
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
2 x16 PCIe 2.0
DDR3 204-pin
SO-DIMM
module up to
8 Gbytes
1
1. Matrox Supersight SHB-5520 has two x16 PCI 2.0 connections on its edge connector. Note that while Matrox Supersight e2 supportse
only one x16 PCI 2.0 connection, Matrox Supersight Solo supports both connectionse (13-connector version) .
2. The number of CPUs (1 or 2), number of cores (4 or 6), and amount of memory are configurable. Contact your Matrox aless
representative for more information.
2

18 Chapter 1: Before you begin
Operating system
The Matrox Supersight unit is shipped with Microsoft Windows 7 for Embedded
Systems, 64-bit.
The following 32- and 64-bit operating systems are also supported, and can be
installed using Microsoft’s Migration rights1:
• Microsoft Windows Vista for Embedded Systems.
• Microsoft Windows XP Professional for Embedded Systems.
If you downgrade to Microsoft Windows XP Professional for Embedded Systems,
you will need to install Microsoft Windows XP Service Pack 2 (SP2) to take
advantage of all the features available in the Matrox Supersightunit and the Matrox
Imaging Library (MIL).
To downgrade the operating system, contact your Matrox representative.
❖Note that if you try using any other operating system, there might be driver issues
(for example, driver issues with USB devices). Refer to the documentation
accompanying the operating system for more information.
If installing an operating system on your unit, refer to the readme file on your
Matrox Supersight system drivers and utilities DVD. It contains additional
information regarding installing the appropriate the device driver/utility software
for the Intel chipset, display driver, and Intel Integrated Ethernet driver for your
Matrox Supersight SHB.
1. Migration rights allow you to use prior versions of Microsoft Windows software. For
more information, read about migration rights on http://www.microsoft.com.

Inspecting the Matrox Supersight package 19
Inspecting the Matrox Supersight package
You should check the contents of your Matrox Supersight package when you first
receive it. If something is missing or damaged, contact your Matrox representative.
Standard components
The following components are included with your Matrox Supersight unit:
Standard package item Details
A Matrox Supersight unit Includes the following components pre-installed in a metal chassis:
• An SHB with memory modules
*
.
• A switched-fabric backplane.
•Amassstoragedevice
*
and its associated connection and power
cable.
• Microsoft Windows 7 for Embedded Systems, 64-bit
(pre-installed on the mass storage device).
• A CD-RW/DVD-ROM 5-inch (slim) optical disk drive
†
and its
associated connection and power cable.
• Three cooling fans and a power supply.
*. The exact amount of storage and memory available might change over time. Contact your Matrox representative for more
details. The number of hard disk drives installed in the chassis is determined by your order and the number of Matrox
Supersight SHB-5520 boards installed. If you ordered more hard disk drives than Matrox Supersight SHB-5520 boards,
additional hard disk drives are shipped as additional parts.
†. You can request a Matrox Supersight unit without a pre-installed CD-RW/DVD-ROM drive. Contact your Matrox representa-
tive for more details.
Additional parts • Two retainer bars and a bag of pressure feet (used to secure the
SHB to the unit).
• 4 additional PCIe/EPS power cables with 6+2 connectors
‡
.
• 1 LP4 to floppy power cable.
• A key to unlock the front panel of the unit.
‡. The Matrox Supersight e2 unit comes with 4 PCIe/EPS power cables (with 6 + 2 connectors) either installed (one per
Matrox Supersight SHB-5520 installed) or bundled as additional components. With the Matrox Supersight Solo unit, one is
installed and the other 3 of these cables are bundled as additional components.
DVDs Two DVDs are included with every Matrox Supersight unit:
• A DVD that includes Matrox Supersight system drivers, utilities,
applications needed to use Matrox Supersight, and a ReadMe file.
• A Microsoft Windows Rescue DVD.
Instructions to receive this manual --

20 Chapter 1: Before you begin
Optional installed components
You might have also purchased any of the following optional Matrox components
to complete the unit. Note that, typically, these components are pre-installed if
purchased at the same time as your Matrox Supersight unit.
❖Note that to order these items separately, contact your Matrox sales representative.
Optional components
You might have also purchased any of the following optional Matrox components
to complete the unit. These will not come pre-installed.
❖Note that to order these items separately, contact your Matrox sales representative.
Additional component Details
Matrox Supersight
SHB-5520 boards
You can order up to 3 additional Matrox Supersight SHB-5520 boards for a
Matrox Supersight e2 unit.
Hard disk drives You can order three additional SATA hard disk drives (for a maximum total of
four), along with its associated cabling. Note that, in a typical installation, one
hard disk drive for each SHB in your Matrox Supersight will come
pre-installed with an operating system.
Additional component Details
Adapter boards You can install PCIe boards. For third-party GPU boards, contact your Matrox
sales representative for the list of pre-qualified vendors.
USB and COM port I/O
adapter bracket
You can order a USB and COM port I/O adapter bracket, featuring two USB
ports and two COM port connectors (DB-9). This bracket allows you to
access the internal USB ports and/or COM ports of the SHBs from outside of
the chassis.
Additional I/O adapter
bracket
Additional I/O adapter brackets might be available. depending on the adapter
board(s) you order.
