Matsushima GRAPHIC COM4 User manual

TGRAPHIC_COM4-003E
Rev0：1. Mar, 2018
INSTRUCTION MANUAL
FOR
LCD ADJUSTMENT UNIT
TYPE: GRAPHIC COM4
※The operator should read this Instruction Manual carefully and handle the
device correctly．
1-8-18Norimatsu-Higashi,Yahatanishi-ku,Kitakyushu807-0837Japan
PhoneNo.(8193)691-3731FaxNo.(8193)691-3735
http://www.matsushima-m-tech.com
E-mail[e-mail]

1
Table of contents
Safety precautions ・・・・・・・・・2
1. Overview ・・・・・・・・・3
2. Mounting/dismounting the LCD adjustment unit ・・・・・・・・・3
3. Key functions ・・・・・・・・・3
4. Display description ・・・・・・・・・4
4.1 Measurement display ・・・・・・・・・4
4.2 Menu display ・・・・・・・・・4
4.3 Waveform display ・・・・・・・・・5
4.4 PC Remote active display ・・・・・・・・・5
4.5 Error display ・・・・・・・・・6
5. Adjustment and functions ・・・・・・・・・7
5.1 Start up ・・・・・・・・・7
5.2 Sensor identification setting ・・・・・・・・・8
5.2.1 Tag ・・・・・・・・・8
5.2.2 Descriptor ・・・・・・・・・9
5.2.3 Message ・・・・・・・・・10
5.2.4 Date ・・・・・・・・・11
5.3 Basic setting ・・・・・・・・・12
5.3.1 Application ・・・・・・・・・12
5.3.1.1 Measurement unit ・・・・・・・・・12
5.3.1.2 Measuring object ・・・・・・・・・13
5.3.1.3 Level change rate ・・・・・・・・・14
5.4 Measurement range span ・・・・・・・・・15
5.5 Damping ・・・・・・・・・16
5.6 Current output setting ・・・・・・・・・17
5.6.1 0-100% current selection ・・・・・・・・・17
5.6.2 Alarm output current ・・・・・・・・・18
5.7 Echo learning ・・・・・・・・・20
5.8 TW adjustment ・・・・・・・・・22
6. Graph display ・・・・・・・・・23
6.1 Echo curve ・・・・・・・・・23
6.2 Echo detection curve + Echo curve + Time window ・・・・・・・・・24
7. Self test ・・・・・・・・・25
8. Reset ・・・・・・・・・26
9. Current output test ・・・・・・・・・27
10. HART communication settings ・・・・・・・・・28
10.1 Polling address ・・・・・・・・・28
10.2 Preamble number ・・・・・・・・・29
10.3 Multidrop mode ・・・・・・・・・30
10.4 Dynamic variables ・・・・・・・・・31
11. Sensor information ・・・・・・・・・32
12. Display ・・・・・・・・・33
12.1 Language ・・・・・・・・・33
12.2 Indication value ・・・・・・・・・34
12.3 Backlight ・・・・・・・・・35
12.4 Contrast ・・・・・・・・・36
13. Parameter list ・・・・・・・・・37
14. Troubleshooting ・・・・・・・・・39

2
Safety precautions
Be sure to thoroughly read the instruction manual before using the products.
Keep the instruction manual in a safe, convenient location for future reference.
All or part of the contents described in this manual may be changed without any notice.
Due to our constant striving for further improvement of products, parts or products that differ from
those described in this manual may be substituted.
WARNING (Failure to observe this WARNING may cause a fatal or serious injury.)
・Be sure to confirm that any peripheral equipment does not move before installation work.
In addition, observe safety requirements for installation work where high-place work is expected.
・Be sure to turn off the power source before wiring, mounting and transportation work.
(Failure to observe this WARNING may result in an electric shock/ injury or equipment damage due to
short-circuit.)
・Carry out wiring work correctly with reference to a proper drawing.
・Never disassemble the equipment.
(Failure to observe this WARNING may result in an electric shock.)
・Do not open the cover under an explosive environmental condition when power is entered.
(Failure to observe this WARNING may result in an injury or equipment damage.)
・Do not place or store the equipment in any hostile environmental place where it will be subjected to
direct sunlight, rain, water droplet, hazardous gas / water, etc..
！
CAUTION (Failure to observe this CAUTION may cause a moderate injury or equipment damage.)
・Do not use the equipment for any purpose other than the original purpose of use.
・Be sure to confirm the specification of equipment and use the equipment within the range of specification.
(Mounting conditions such as temperature, power source, frequency, etc.)
・Make sure a correct wiring before applying power source.
・Do not have a shock or strong impact to the equipment.
(Failure to observe this CAUTION may result in equipment damage.)
・Be sure to connect necessary terminals (grounding, etc.).
・Remove all wiring to the equipment before doing electrical welding work near the equipment.
・Do not forcedly bend or pull the lead wire also do not use unnecessarily long wire.
・Tighten the cover, lead outlet, etc. properly so that dust, rainwater, etc. do not enter inside the equipment.
・Do not use the equipment under a corrosive condition (NH3, SO2, CI2, etc.).
・Be sure to tighten the cable grand so that outer air does not enter inside the equipment.
・When applying piping connection such as conduit, etc. instead of cable gland, apply putty or equivalents
On the cable entry so that outer air does not enter inside the equipment.
IMPORTANT (indicates notes or information to help customers.)
Limitations of Warranty:
・Warranty period shall be one year from the date of delivery (ex-factory).
・Any damage of any other products that have occurred for use of the equipment is not covered by
this warranty. Also any loss induced by failure or malfunction of the equipment is not covered by
this warranty.
・Failure or malfunction caused by following are not covered by this warranty:
a. Modification or repair by a party other than MATSUSHIMA’s authorized personnel, or replacement of
parts not recommended by MATSUSHIMA.
b. Inadequate storage, installation, use, inspection or maintenance that does not comply with specifications.
c. Cause for any peripheral equipment or device.
d. Accident beyond control and force majeure (fire, earthquake, flood, riots, etc.).
Lack of instructions to MATSUSHIMA for information or safety requirements that can be predicted only by
customers’ side.
This warranty conditions do not limit customers’ legal right.
Price for the equipment does not include any charge for services such as commissioning, supervising, etc..
！
！

3
1. Overview
The LCD adjustment unit is dedicated for adjustment and diagnosis of the microwave level meter
type of MWLM-PR26 (hereafter referred to as the "Level meter"). This unit is attached to top of the
level meter electronics part in the housing.
Summary of functions: Waveform display, parameter settings, self test, reset and current
output test.
2. Mounting/dismounting the LCD adjustment unit
Mounting: Unscrew the level meter housing cover. Attach LCD adjustment unit on the electronics
part case and rotate it right to the direction "LOCK".
Dismounting: Rotate LCD adjustment unit left to the direction "OPEN" and remove.
3. Key functions
Detailed key functions of the LCD adjustment unit are described below.
Fig. 3.1 GRAPHIC COM4 external view
Table 3.1 Key functions
Key Whenmenuselected Whenenter/select
digitsorcharacters
Whendisplay
waveform
Enter to menu
Select menu item Accept entered value −
−Move cursor right Change X axis
(distance) scale
Move cursor down
Select value
Increment digit
Move cursor when
entering characters
Change Y axis
(reflection) scale
Shift to parent layer Interrupt entry (cancel) Shift to parent layer
Esc
Ent
LOCK
OPEN

4
④
4. Display
4.1 Measurement display
①Measured value
Display current measured value and respective unit.
Measured value can be displayed in distance (m/ft),
level (m/ft), level percent (%) or current (mA) mode.1
②Display mode
Indicates selected display mode.1
③Auto power save (APS）
Indicates backlight usage is limited.
※There is no optional adjustment for backlight.
When there is enough power backlight will be switched
on.
Note 1. Refer to chapter 12.1 Display Selection, for display mode setting.
4.2 Menu display
①Current menu
Current selected menu layer.
②Cursor
Indicates current menu item.
③Layer number
Current selected menu layer number.
④Menu list
Selectable menu item list.
⑤ Down cursor
Indicates there are more selectable menu items below.
Block cursor were used to indicate position when changing
parameter values or entering characters. The block cursor
was created by inverting the pixels of the characters.
Display mode Description
Distance Distance from level
meter
Level
Distance
Distance from tank
base
Level ％Level percentage
Current Current output value
①
③
③
①
Menu
0
1.IdentificationSet.
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
１２．３４５ｍ
Distance
APS
②
②
⑤
Fig. 4.1.1 Measurement view
Fig. 4.2.1 Menu view
Tagchange
1.1
SENSOR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?

5
4.3 Waveform display
  ① Measured distance
Current measured distance
 ② Y axis
Reflection level (unit: dB)
 ③ X axis
Distance (unit: m or ft)
   ④ Echo curve (EC)
Current measured waveform.
 ⑤ Measurement line
Indicate current measured distance on waveform.
 ⑥ Echo detection curve (EDC)
Threshold curve for echo reflection detection.
 ⑦ Time windows (TW)
Indicates reflection echo judgement frame.
4.4 PC remote active display
 ①PC Remote
Indicates the level meter is connected to the computer.
Operation of LCD adjustment unit is not possible when
the level meter is connected to the computer.
 ②Level meter operating mode
Presents operating mode of the level meter.
Detailed descriptions of modes are shown below.
Table 4.1.1 Level meter modes
Mode Description
Test mode Current output test
Echo learning Echo learning active
Reset Resetting
Self test Running diagnosis
①
100
dB
200
70
35 m
D
0
4.1D=35.000m
図4-3-1.エコーカーブ画面
③
②
⑤
④
①
100
dB
200
70
35 m
D
0
4.1
D=35.000m
図4-3-2.ディテクションカーブ
+EC+TW画面
⑤⑥
④⑦
PCRemote
１２．３４５ｍ
Distance
②
PCRemote
Testmode
Fig. 4.3.1 Echo curve view
Fig 4.3.2 Echo detection curve +
+ EC + TW view
Fig. 4.4.1 PC Remote active view 1
Fig. 4.4.2 PC Remote active view 2

6
4.5 Error display
①Error code (E****)
When there is fault in the level meter or error occurs in
communication between level meter and adjustment
unit, then error code will be presented.
Refer to table below for error code details.
Table 4.5.1 Error code details
Error
code Error type Description
E8000 SRAM Error SRAM failure
E4000 EEPROM Error EEPROM failure
E2000 MIC Error MIC unit failure
E1000 Trig Error Trigger signal lost
E0800 LCD Error LCD adjustment unit failure
E0400 Charge Error Charge circuit failure
E0200 I2C Checksum error Communication between level meter and LCD
adjustment unit failed
E0100 Loop Current Error Loop Current failure
E0080 Lost echo
･Reflection echo is currently being detected
･There is no reflection echo
･There is no reflection echo in the measurement
span
E0010 During Startup Processing Startup Processing(Warning)
E0008 Min. meas. limit over Measured distance is lower than "Min. meas. limit"
E0004 Max. meas. limit over Measured distance is higher than "Max. meas. limit".
E0002 Upper range limit over
(100％over)
Measured distance exceeds "Upper
range limit over (100% over)".
E0001 Lower range limit over
(0％over)
Measured distance undergoes "Lower range limit over
(0% over)".
S.CPU Level meter not responding No response from level meter
S.I2C I2C Checksum error Communication between level meter and LCD adj.
unit failed
※Refer to chapter 15, for troubleshooting details.
１２．３４５ｍ
Distance
E1000 ①
Fig. 4.5.1 Error code presentation

7
Adjustment and functions
5.1 Start up
≪Start up view≫
≪Measured value≫
Table 5.1 Menu summary
No. Menu Description
1 Sensor Identification setting Tag, Descriptor, Message, Date
2 Basic setting Application, Measurement range
span, Damping
3 Sensor adjustment Current output, Echo
learning,TW adjustment
4 Graph display Waveform display
5 Self test Run self test
6 Reset Reset
7 Current output test Execute current output test
8 HART communication HART communication setting
9 Sensor information Level meter information
10 Display Measured value, language
setting
11 Service Service parameter setting
Display mode Description
Distance Distance from level meter
Level Distance Distance from tank base
Level % Level percentage
Current Current output value
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
GRAPHICCOM4
REV.＊.＊＊
After power up the level
meter initialize view is
displayed.
Push『Ent』to enter main menu.
Main menu summary is listed below in table.
Ent × Once
１２．３４５ｍ
Distance

8
5.2 Sensor identification setting
In this menu you can adjust following parameters: Tag, Descriptor, Message and Date.
5.2.1 Tag
In the menu item "Tag" enter tag name with less than 16 characters. (Default: SENSOR)
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Identification
s
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Tagchange
1.1
SENSOR
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
１２．３４５ｍ
Distance
Ent × 1 click
Ent × 1 click
Ent × 1 click
Tagchange
1.1
SENSOR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Tagchange
1.1
SENSOR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Push『Ent』to enter
main menu.
Identification setting
menu will be
displayed.
Push 『Ent』to select
Tag.
Tag change view will
be displayed.
Push『®』to move
cursor. Edit position
indicated by
inverting the pixels of
the character.
Push 『Ent』switch
to input area for
current cursor
selected position.
→ × several times
Ent × 1 click
→× several times or ＋× several times
Character input area will
be activated.
Push 『＋』or『®』to
select input characters.
Tagchange
1.1
SENSOR
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Push『Ent』after selecting
input characters.
The pixels of the
character returned to
normal.
Input area
Ent × 1 click
Tagchange
1.1
SENSOR1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
When edit or add
completed push『＋』to
shift cursor to OK.
If there is more editing
needed push『®』and
repeat actions.
Tagchange
     1.1
SENSOR1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Measurement view
× 2 click
Esc
Tag change completed.
Push 『Esc』two times
return to measurement
view.
Push 『Ent』while
cursor is on OK position
to set tag change.
Identifications
et
ting
1
1.Tag=SENSOR1
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Ent × 1 click
Menu view will be
displayed.
Push 『Ent』to enter
Identification setting
menu.
【
Measurement view
】
＋× 1 click →× several times
Ent × 1 click

9
5.1.2 Descriptor
In the menu item "Descriptor", enter descriptor with less than 16 characters. (Default: PULSE-RADAR)
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Identifications
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Descriptorchange
1.2
PULSE-RADAR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
１２．３４５ｍ
Distance
Ent × 1 click
Ent × 1 click
＋ × 1 click
Descriptorchange
1.2
PULSE-RADAR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Descriptorchange
1.2
PULSE-RADAR
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Push 『Ent』to enter
input area for current
cursor selected
position.
→ × several times
Ent × 1 click
Character input area
will be activated.
Push 『＋』or 『®』
button to select input
characters.
Descriptorchange
1.2
PULSE-RADAR
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Push『Ent』after
selecting input
characters.
The pixels of the
character returned to
normal.
Input area
Ent × 1 click
Descriptorchange
1.2
PULSE-RADAR1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
When edit or add
completed push『＋』to
set cursor to the OK.
If there is more editing
needed push『®』and
repeat
actions.
Descriptorchange
1.2
PULSE-RADAR1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Measurement view
× 2 click
Esc
Descriptor change
completed.
Push 『Esc』two
times return to
measurement view.
Identifications
et
ting
1
1.Tag=SENSOR1
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Ent × 1 click
Identification
s
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Ent × 1 click
Push 『Ent』to select
Descriptor.
【
Measureme
n
t
view
】
Descriptor change
view will be
displayed.
Push『®』to move
cursor. Edit position
indicated by
inverting the pixels of
the character.
Identification setting
menu will be
displayed.
Push『＋』shift
cursor to Descriptor.
Menu view will be
displayed.
Push 『Ent』to enter
Identification setting
menu.
Ent × 1 click
→× several times or ＋× several times
→× several times ＋× 1 click or
Push 『Ent』to
enter main menu.
Push『Ent』while
cursor is on OK
position to set
descriptor change.

10
5.2.3 Message
In the menu item "Message", enter message with less than 21 characters. (Default: LEVEL METER)
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Identification
s
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Message
change
1.3
LEVELMETER
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
１２．３４５ｍ
Distance
Ent × 1 click
Ent ×1 click
＋ × 2 click
Messagechange
1.3
LEVELMETER
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Messagechange
1.3
LEVELMETER
OK
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Message change
view will be
displayed.
Push『®』to move
cursor. Edit position
indicated by
inverting the pixels of
the character.
→ × several times
Ent × 1 click
Character input area
will be activated.
Push 『＋』or 『®』
button to select input
characters.
Push『Ent』after
selecting input
characters.
The pixels of the
character returned to
normal.
Input area
Ent × 1 click
Messagechange
1.3
LEVELMETER1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Messagechange
1.3
LEVELMETER1
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Measurement view
× 2 click
Esc
Message change
completed.
Push 『Esc』twice
return to
measurement
view.
Identification
s
et
ting
1
1.Tag=SENSOR1
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Ent × 1 click
Identification
s
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
Ent × 1 click
Push 『Ent』to select
Message.
Message
change
1.3
LEVELMETER
OK
@
@ABCDEFGHIJKLMNO
PQRSTUWXYZ[\]^
!#$%&()*+,-./
0123456789:;<=>?
Identification setting
menu will be
displayed.
Push『＋』twice to
shift cursor to
Message menu.
Menu view will be
displayed.
Push 『Ent』to enter
Identification setting
menu.
When edit or add
completed push『＋』to
set cursor to the OK.
If there is more editing
needed push 『®』and
repeat actions.
Ent × 1 click
【
Measuremen
t
view
】
＋× several times →× several times or
＋× 1 click or →× several times
Push『Ent』to enter
main menu.
Push 『Ent』while
cursor is on OK
position to set
message change.
Push『Ent』to enter
input area for current
cursor selected
position.
→× several times

11
5.2.4 Date
Set installation date of level meter. (Default: 2018/1/1)
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Identification
s
et
ting
1
1.TAG=SENSOR
2.Descriptor
  =PULSE-RADAR
3.Message
  =LEVELMETER
▼
１２．３４５ｍ
Distance
Ent × 1 click
Ent × 1 click
＋ × 3 times
Ent × 1 click
Identification
s
et
ting
1
  =PULSE-RADAR
3.Message
   =LEVELMETER
4.Date
   =2018/01/01
▼
Ent × 1 click
Push『Ent』to select
Date.
Identification
s
et
ting
1
  =PULSE-RADAR
3.Message
   =LEVELMETER
4.Date
   =2018/01/01
▼
Date change view
will be displayed.
Push『®』to move
cursor.
Push『＋』to change
values.
Identification
s
et
ting
1
  =PULSE-RADAR
3.Message
   =LEVELMETER
4.Date
   =2018/09/01
▼
Identification
s
et
ting
1
  =PULSE-RADAR
3.Message
   =LEVELMETER
4.Date
   =2018/09/01
▼
Date change
completed.
Push 『Esc』twice
return to measurement
view.
× 2 click
Esc
Identification setting
menu will be
displayed.
Push『＋』three
times shift to Date
menu.
Menu view will be
displayed.
Push『Ent』to enter
Identification setting
menu.
【
Measuremen
t
view
】
→× several times or ＋× several times
Measurement view
Push 『Ent』to set
date change.
Push『Ent』to enter
main menu.

12
5.3 Basic setting
In this menu basic setting for level meter measurement will be adjusted.
5.3.1 Application
Measurement unit, measuring object and level change rate will be set.
5.3.1.1 Measurement unit (Meas.unit)
Selects measuring unit of level meter from meter (m) and feet (ft). (Default: m)
※This setting will affect all measuring units.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
１２．３４５ｍ
Distance
Ent × 1 click
＋ × 1 click
Menu view will be
displayed.
Push『＋』to shift
cursor to Basic
setting menu.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Ent × 1 click
Push『Ent』to enter
Basic setting menu.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Ent × 1 click
Basic setting menu
will be displayed.
Push『Ent』to select
Application
.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
=
Normal
<1m/min
Ent × 1 click
Application view will be
displayed.
Push 『Ent』to select
Measurement unit.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
=
Normal
<1m/min
＋ × 1 click
Measurement unit
value will be indicated
by block cursor.
Push『＋』 to change
meas.unit value.
Application
2.1
1.Meas.unit=ft
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
Ent × 1 click
Push
『
Ent
』
to set
measurement unit.
Application
2.1
1.Meas.unit=ft
2.Measuringobject
    =Liquid
3.Levelchangerate
=
Normal
<1m/min
Measurement unit
change completed.
Push 『Esc』three times
return to measurement
view.
Measurement view
× 3 click
Esc
【
Measuremen
t
view
】
Push『Ent』to enter
main menu.

13
5.3.1.2 Measuring object
Measuring object can be selected form “Liquid” and “Solid”, to change parameter sets for
easier measurement. (Default: Liquid)
※The measuring object will change other parameters simultaneously.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
１２．３４５ｍ
Distance
＋ × 1 click
Menu view will be
displayed.
Push『＋』to shift
cursor to Basic
setting menu.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Ent × 1 click
Push『Ent』to enter
Basic setting menu.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Ent × 1 click
Basic setting menu
will be displayed.
Push『Ent』to select
Application.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
＋ × 1 click
Application view will
be displayed.
Push 『＋』to shift
cursor down to
Measuring object.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
Ent × 1 click
Push『Ent』to select
Measuring object.
＋ × 1 click
Measuring object
value will be
indicated by block
cursor.
Push『＋』to change
value.
Ent × 1 click
Push
『
Ent
』
to set
measuring object.
Measuring object
change completed.
Push『Esc』three
times return to
measurement view.
× 3 click
Esc
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Solid
3.Levelchangerate
=
Normal
<1m/min
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
=
Normal
<1m/min
Ent × 1 click
【
Measuremen
t
view
】
Measurement view
Push『Ent』to enter
main menu.

14
5.3.1.3 Level change rate
Measuring object level change rate can be selected form “Normal” and “Fast” to change
parameter sets for easier measurement. (Default: Normal <1m/min)
※The level change rate will change other parameters simultaneously.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Ent × 1 click
＋ × 1 click
Menu view will be
displayed.
Push『＋』to shift
cursor to Basic
setting menu.
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Ent × 1 click
Push『Ent』to enter
Basic setting menu.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Ent × 1 click
Basic setting menu
will be displayed.
Push『Ent』to select
Application.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
＋ × 2 click
Application view will
be displayed.
Push 『＋』twice to
shift cursor down to
Level change rate.
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<m/min
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
Ent × 1 click
Push『Ent』to select
Level change rate.
＋ × 1 click
Level change rate
value will be indicated
by block cursor.
Push『＋』 to change
value.
Ent × 1 click
Push『Ent』to set
level change rate.
Level change rate
change completed.
Push『Esc』three
times return to
measurement view.
Measurement view
× 3 click
Esc
Application
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Fast>1m/min
Applicat
ion
2.1
1.Meas.unit=m
2.Measuringobject
    =Liquid
3.Levelchangerate
    =Normal<1m/min
１２．３４５ｍ
Distance
【
Measuremen
t
view
】
Push『Ent』to enter
main menu.

15
5.4 Measurement range span (Meas. range span)
Measurement range span sets full/empty distance and related percentage.
Here, measurement distance is distance from level meter.
１２．３４５ｍ
Distance
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu view will be
displayed.
Push『＋』to shift
cursor to Basic
setting menu.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Meas.rangespan
2.2
1.Fullsetting
Distance=1.000m
Percent=100.00%
2.Emptysetting
Distance=70.000m
Percent=0.00%
Meas.rangespan
2.2
1.Fullsetting
Distance=02.000m
Percent=100.00%
2.Emptysetting
Distance=70.000m
Percent=0.00%
Push『Ent』to set change
and complete Full setting
Distance setting.
Next push『＋』twice and
move cursor to Empty
setting 0% level.
Meas.rangespan
2.2
1.Fullsetting
Distance=2.000m
Percent=100.00%
2.Emptysetting
Distance=70.000m
Percent=0.00%
Example: Change
70.000m to 6.000m.
Push『Ent』to enter
Distance.
Selected entry will be
indicated by block
cursor.
Meas.rangespan
2.2
1.Fullsetting
Distance=01.000m
Percent=100.00%
2.Emptysetting
Distance=70.000m
Percent=0.00%
Meas.rangespan
2.2
1.Fullsetting
Distance=2.000m
Percent=100.00%
2.Emptysetting
Distance=70.000m
Percent=0.00%
Push『＋』or『®』to
change 70.000m to
6.000m.
Push『Ent』to set
changed value and
complete setting.
Basic setting menu
will be displayed.
Push『＋』to shift
cursor down to
Meas. Range span.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Push『Ent』to enter
Meas. Range span
menu item.
Meas. range span
view will be
displayed. Here we
set 100% level.
Move cursor to Full
setting Distance and
push 『Ent』.
Selected entry will be
indicated by block
cursor.
Meas.rangespan
2.2
1.Fullsetting
Distance=2.000m
Percent=100.00%
2.Emptysetting
Distance=6.000m
Percent=0.00%
Meas. range span
change completed.
Push『Esc』three times
return to measurement
view.
Measurement view
Ent × 1 click
＋ × 1 click
Ent × 1 click
＋ × 1 click
Ent × 1 click
→ × 1 click
＋ × 1 click
Ent × 1 click
＋ × 2 click
Ent × 1 click
＋ or → × several click
Ent × 1 click
Ent × 1 click
× 3 click
Esc
【
Measuremen
t
view
】
Push『Ent』to enter
main menu. Push『→』to move
cursor to desired
position.
Push『＋』to change
values
.
Push『Ent』to enter
Basic setting menu.

16
5.5 Damping
Sets amount of damping in number of seconds to respond fast step inputs.
１２．３４５ｍ
Distance
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu view will be
displayed.
Push『＋』to shift
cursor to Basic
setting menu.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Basic setting menu
will be displayed.
Push『＋』twice to
select Damping.
Basicsetting
2
1.Application
2.Meas.rangespan
3.Damping
Push『Ent』to enter
Damping menu
item.
Damping
2.3
    =0sec
Damping view will be
displayed.
Push『Ent』to enter edit
entry.
Damping
ﾞ
2.3
    =000sec
Example: Set damping to
30 seconds.
Push『＋』or『®』to
change 0 sec to 30sec.
Push『Ent』to set
damping value.
Damping
ﾞ
2.3
    =30sec
Damping change
completed.
Push『Esc』three times
return to measurement
view
.
Measurement view
Ent × 1 click
Ent × 1 click
Ent × 1 click
Ent × 1 click
Ent × 1 click
＋ × 1 click
＋ × 1 click
＋ or → × several click
× 3 click
Esc
【
Measuremen
t
view
】
Push『Ent』to enter
main menu.
Push『Ent』to enter
Basic setting menu.

17
5.6 Current output setting (Current output set.)
5.6.1. 0-100％current output selection
Sets 0-100％current output values. (Default: 4-20mA)
『4-20mA』＝ 100％level (Upper level) is 20mA
0％level (Lower level) is 4mA
『20-4mA』＝ 100％level (Upper level) is 4mA
0％level (Lower level) is 20mA
Currentoutputset.
3.1
1.Currentoutputsel.
=20-4mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
１２．３４５ｍ
Distance
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu view will be
displayed.
Push『＋』twice shift
cursor to Sensor
adjustment menu.
Sensoradjustment
3
1.Currentoutputset.
2.Meas.adjustment
Currentoutputset.
3.1
1.Currentoutputsel.
= 4-20mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
Currentoutputset.
3.1
1.Currentoutputsel.
= 4-20mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
Example: Set current
output to 20-4mA.
Push『＋』change value
to 20-4mA.
Push『Ent』set to
selected value.
0-100% current output
setting completed.
Push『Esc』three times
return to measurement
v
iew
.
Measurement view
Ent × 1 click
Ent × 1 click
Ent × 1 click
Ent × 1 click
Ent × 1 click
＋ × 2 click
＋ × 1 click
× 3 click
Esc
【
Measuremen
t
view
】
Push『Ent』to enter
main menu.
Push『Ent』to enter
Sensor adjustment
menu.
Current output
setting view will be
displayed.
Push『Ent』to enter
current output
selection.
Sensor adjustment
menu will be
displayed.
Push『Ent』to select
Current output set.

18
5.6.2 Alarm current output
Sets output current value during fault condition.
Alarm current selection: Output current value when measurement is not valid because of no
reflection echo loss or other reasons.
Selection =「Hold」「Sel.val.」「Max」「Min」
・Hold: Output remains at previous measured result during alarm.
・Selected value (Sel.val.): Alarm output current is set to value entered in “5.Sel. alarm
current val.”
・Max: Alarm output current is set to value selected in “3. Max current sel.”
・Min: Alarm output current is set to value selected in “4.Min current sel.”
Max current sel.: Selects current output value when「Max」is selected in 2. Alarm output sel.
Selection range =「20mA」「20.5mA」「22mA」
Min current sel.: Selects current output value when「Min」is selected in 2. Alarm output sel.
Selection range =「4mA」「<3.6mA」「3.8mA」(Microwave Level Meter over Ver2.0)
Selection range =「4mA」「3.6mA」「3.8mA」(Except for the above)
Sel. alarm current val: Sets current output value when「Sel.val.」is selected in 2.Alarm output sel
Selection range = 3.55mA to 22.0mA (Microwave Level Meter over Ver2.0)
Selection range = 3.60mA to 22.0mA (Except for the above)
※You can not select several options for alarm current output.
１２．３４５ｍ
Distance
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu
0
1.Identificationsetting
2.Basicsetting
3.Sensoradjustment
4.Graphdisplay
5.Selftest
6.Reset
▼
Menu view will be
displayed.
Push『＋』twice shift
cursor down to
Sensor adjustment
menu.
Push 『Ent』to
enter Sensor
adjustment menu.
Sensoradjustment
3
1.Currentoutputset.
2.Meas.adjustment
Currentoutputset.
3.1
1.Currentoutputsel.
=4-20mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
Sensor adjustment
menu will be
displayed.
Push『Ent』to enter
Current output set.
Ent × 1 click
Ent × 1 click
Ent × 1 click
Ent × 1 click
＋ × 2 click
Currentoutputset.
3.1
1.Currentoutputsel.
=4-20mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
Push 『Ent』to enter
Alarm current sel.
Currentoutputset.
3.1
1.Currentoutputsel.
=4-20mA
2.Alarmcurrentsel.
= Hold
3.Maxcurrentsel.
=20mA
▼
＋ × several times
Push 『＋』to change
value to Sel.val.
Push『Ent』set to
selected value.
Currentoutputset.
3.1
1.Currentoutputsel.
=4-20mA
2.Alarmcurrentsel.
= Sel.val.
3.Maxcurrentsel.
=20mA
▼
Push『＋』3 times shift to
Sel. alarm current val.
Cont’d on next page
＋ × 3 click
Ent × 1 click
＋
【
Measuremen
t
view
】
Push『Ent』to enter
main menu.
Current output setting
view will be displayed.
Example: Set alarm
current to 21mA.
Push『＋』shift to Alarm
c
urrent sel.

19
Push『Esc』three times
return to measurement
view.
Measurement view
× 3 click
Esc
Cont’d from previous page
Currentoutputset.
3.1
3.Maxcurrentsel.
=20mA
4.Mincurrentsel.
 =4mA
5.Sel.alarmcurrentval.
= 22mA
▼
Push『Ent』to enter Sel.
alarm current value.
Sel. alarm current val.
will be indicated by block
cursor.
Currentoutputset.
3.1
3.Maxcurrentsel.
=20mA
4.Mincurrentsel.
 =4mA
5.Sel.alarmcurrentval.
   = 22mA
▼
Ent × 1 click
Use『＋』or『®』and change
22mA to 21mA.
Push『Ent』set current value.
＋ or → × several times
Ent × 1 click
Currentoutputset.
3.1
3.Maxcurrentsel.
=20mA
4.Mincurrentsel.
 =4mA
5.Sel.alarmcurrentval.
   = 21mA
▼
