Control Module
CR-6
Description
The addressable Control Module CR-6 serves for the ac-
tuation of external devices by means of 6 independent
dry relay contacts, via the bidirectional communication
on the ADM loop with System Sensor/200 protocol.
The Control Module CR-6 occupies 6 consecutive
addresses on the ADM loop. During commissioning, the
base address, i.e., the lowest one of the 6 addresses,
is set by means of decadic rotary switches.
The optional steel sheet Surface Mounting Box
M200SMB-MM accommodates one Monitor Module
IM-10 or Control Module CR-6.
• ADM loop technology with
System Sensor/200 protocol
• 6 independent, dry relay outputs
• Status LED for each output
• Setting of module address via
decadic rotary switches
• Mounting in surface mounting box
Specifi cations
Operating voltage Supply through loop voltage
Current consumption approx. 1.5mA (quiescent)
Contact rating 2A/30VDC
Ambient temperature 0°C to +50°C
Dimensions L × W × H 172 × 147 × 25 (mm)
Weight 500g
Order number 249116
Order name Control Module 6xRel.Out/Anal./200/SS CR-6
Surface Mounting Box
Ambient temperature 0°C to +50°C
Dimensions L × W × H 285 × 225 × 62 (mm)
Colour cream
Weight 2kg
Order number 249117
Order name Surface Mounting Box for Multimodule/SS M200SMB-MM
