Maverick Storm 4 Profile User manual

Model ID: MAVERICKSTORM4PROFILE
User Manual

Maverick Storm 4 Profile User Manual Rev. 1
Edition Notes
The Maverick Storm 4 Profile User Manual includes a description, safety precautions, installation,
programming, operation and maintenance instructions for the Maverick Storm 4 Profile as of the release
date of this edition.
Trademarks
Chauvet, Chauvet Professional, the Chauvet logo, Maverick, and Maverick Storm are registered
trademarks or trademarks of Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United
States and other countries. Other company and product names and logos referred to herein may be
trademarks of their respective companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2022 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information purposes
only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this
manual or its content for any other purpose without written consent from Chauvet.
Document Printing
For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4
paper (210 x 297 mm), configure the printer to scale the content accordingly.
Intended Audience
Any person installing, operating, and/or maintaining this product should completely read through the guide
that shipped with the product, as well as this manual, before installing, operating, or maintaining this
product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetprofessional.com.
Document Revision
This Maverick Storm 4 Profile User Manual is the 1st edition of this document. Go to
www.chauvetprofessional.com for the latest version.

Maverick Storm 4 Profile User Manual Rev. 1
Table of Contents
i
TABLE OF CONTENTS
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Claims ........................................................................................................... 1
Text Conventions .......................................................................................... 1
Symbols ........................................................................................................ 1
FCC Compliance........................................................................................... 1
Safety Notes.................................................................................................. 2
Personal Safety.................................................................................................. 2
Mounting and Rigging ........................................................................................ 2
Power and Wiring............................................................................................... 2
Operation ........................................................................................................... 3
Expected LED Lifespan................................................................................. 3
2. Introduction ................................................................................ 4
Description .................................................................................................... 4
Features........................................................................................................ 4
Product Overview.......................................................................................... 4
Product Dimensions ...................................................................................... 5
3. Setup ........................................................................................... 6
AC Power...................................................................................................... 6
AC Plug .............................................................................................................. 6
Fuse Replacement ............................................................................................. 6
Remote Device Management (RDM) ............................................................ 6
USB Software Update ................................................................................... 6
Mounting ....................................................................................................... 7
Orientation.......................................................................................................... 7
Rigging ............................................................................................................... 7
Procedure........................................................................................................... 7
Signal Connections ....................................................................................... 8
Control Personalities .......................................................................................... 8
DMX Linking....................................................................................................... 8
Art-Net™ Connection ......................................................................................... 8
sACN Connection............................................................................................... 8
Connection Diagram .......................................................................................... 8
4. Operation .................................................................................... 9
Control Panel Description ............................................................................. 9
Battery-Powered Display.................................................................................... 9
Home Screen ................................................................................................ 9
Control Panel Lock........................................................................................ 9
Passcode ........................................................................................................... 9
Technician Mode........................................................................................... 9
Menu Map ..................................................................................................... 10
Configuration (DMX, Art-Net™, sACN) ......................................................... 15
Control Mode...................................................................................................... 15
Control Personalities .......................................................................................... 15
Starting Address................................................................................................. 15
Network Setup............................................................................................... 15
IP Mode........................................................................................................................... 15
Universe.......................................................................................................................... 15
Manual IP Address.......................................................................................................... 15
Subnet Mask ................................................................................................................... 15

Table of Contents
Maverick Storm 4 Profile User Manual Rev. 1
ii
Control Channel Assignments and Values.................................................... 16
Configuration (Settings) ................................................................................ 20
Pan Reverse ...................................................................................................... 20
Tilt Reverse ........................................................................................................ 20
Screen Reverse ................................................................................................. 20
Pan Angle........................................................................................................... 20
Tilt Angle ............................................................................................................ 20
Black out on Movement...................................................................................... 20
Swap Pan and Tilt .............................................................................................. 20
WDMX Reset ..................................................................................................... 20
Display Backlight Timer...................................................................................... 20
Loss of Data ....................................................................................................... 21
Fan Mode ........................................................................................................... 21
Dimmer Curve .................................................................................................... 21
Pulse Width Modulation ..................................................................................... 21
LED Power ......................................................................................................... 21
Minimum Zoom Focus........................................................................................ 21
Preset Selection ................................................................................................. 21
Preset Synchronization ...................................................................................... 22
USB Update ....................................................................................................... 22
Reset Function ................................................................................................... 22
Factory Reset..................................................................................................... 22
Test Mode ..................................................................................................... 22
Auto Test............................................................................................................ 22
Manual Test ....................................................................................................... 22
System Information ....................................................................................... 23
Offset Mode (Zero Adjust) ............................................................................. 23
Web Server ................................................................................................... 23
Gobo Wheels ................................................................................................ 24
Gobo Dimensions............................................................................................... 24
Gobo Replacement ............................................................................................ 25
5. Maintenance................................................................................ 26
Product Maintenance .................................................................................... 26
6. Technical Specifications ........................................................... 27
Returns............................................................................................ 28
Contact Us ...................................................................................... 29

Page 1 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Claims
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Symbols
FCC Compliance
This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
• Maverick Storm 4 Profile
• Seetronic Powerkon IP65 power cable
• 2 Omega brackets with mounting hardware
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
Symbol Meaning
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function correctly
if this information is not used.
Useful information.
Any reference todataor power connections in this manual assumes the use of
Seetronic IP-rated cables.
The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data
transmission protocol.

Page 2 of 29
Before You Begin
Maverick Storm 4 Profile User Manual Rev. 1
Safety Notes
Read all the following safety notes before working with this product. These notes contain important
information about the installation, usage, and maintenance of this product.
Personal Safety
• The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer
than 6.56 ft (2 m) is not expected.
• If the external flexible cable or cord of this luminaire is damaged, it shall be replaced by a special
cord or cord exclusively available from the manufacturer or his service agent.
• The light source contained in this luminaire shall only be replaced by the manufacturer or his service
agent or a similar qualified person.
• The luminaire is intended for professional use only.
• Always disconnect the product from the power source before cleaning or replacing the fuse.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Do not touch the product’s housing when operating because it may be very hot.
Mounting and Rigging
• Do not submerge this product (IP65). Temporary outdoor operation is fine.
• When using this product in an outdoor environment, use IP65 (or higher) rated power and data
cables. Secure unused power and data ports with attached IP65 covers.
• CAUTION: When transferring product from extreme temperature environments, (e.g., cold truck to
warm, humid ballroom) condensation may form on the internal electronics of the product. To avoid
causing a failure, allow product to fully acclimate to the surrounding environment before connecting
it to power.
• Not for permanent outdoor installation in locations with extreme environmental conditions. This
includes, but is not limited to:
• Exposure to a marine/saline environment (within 3 miles of a saltwater body of water).
• Locations where the normal high or low temperatures exceed the temperature ranges in this
manual.
• Locations that are prone to flooding or being buried in snow.
• Areas where the product will be subjected to extreme radiation or caustic substances.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
• Make sure there are no flammable materials within 20 cm of this product while it is operating.
• When hanging this product, always secure to a fastening device using a safety cable.
• Never carry the product by the power cable.
Power and Wiring
• Make sure the power cable is not crimped or damaged.
• Always make sure you are connecting this product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
• Never connect this product to a dimmer pack or rheostat.
• Make sure to replace the fuse with another of the same type and rating.
• Never disconnect this product by pulling or tugging on the power cable.
This product contains no user-serviceable parts. Any reference to servicing in this User
Manual will only apply to properly trained, certified technicians. Do not open the housing
or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.

Page 3 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Before You Begin
Operation
• Do not operate this product if there is damage on the housing, lenses, or cables. Have the damaged
parts replaced by an authorized technician at once.
• Do not cover the ventilation slots when operating to avoid internal overheating.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher
temperatures.
• The minimum startup temperature is -4°F (-20°C). Do not start the product at lower temperatures.
• The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower
temperatures.
• In the event of a serious operation problem, stop using this product immediately!
Expected LED Lifespan
Over time, use and heat will gradually reduce LED brightness. Clustered LEDs produce more heat than
single LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is
40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit
the overall intensity.
If your Chauvet product requires service, contact Chauvet Technical Support.

Page 4 of 29
Introduction
Maverick Storm 4 Profile User Manual Rev. 1
2. Introduction
Description
Maverick Storm 4 Profile brings indomitable long throw performance to even the largest venues. Its ambitious
design launches over 60,000 lumens across incredible distances with commanding brightness. Built to
outshine, this Maverick brings more to your show than its long throw. Master the art of domination with a
sophisticated variable CMY+CTO system that delivers fantastic color rendering. Double down on crisp gobos
to create complex looks with two rotating gobo wheels, two prisms, two frost filters, and an animation wheel
to add even more texture. Sharp shutter framing, smooth iris and 8.5:1 zoom complete a Maverick that
delivers key light and high-energy kinetic effects, in an advanced IP65 alloy body that carries SunShield tech
inside to protect optical components from any solar ingress through its audacious 188mm front lens.
Features
• Fully featured, compact, and lightweight IP65 1250 W LED yoke profile fixture, including CMY + CTO
color mixing, a four-blade framing shutter system with rotation, a color wheel, 8:1 zoom, two prisms (five-
facet round and linear), two rotating gobo wheels, and integrated sun shield
• 16-bit dimming of master dimmer for smooth control of fades
• Variable CMY + CTO color mixing system to create a wide pallet of colors
• CRI and CTB filters on color wheel for added flexibility
• Two rotating, indexing, and interchangeable slot and lock gobo wheels
• An animation wheel for kinetic textured effects
• DMX, WDMX, sACN, and Art-Net for full flexibility of control options
• RDM control over DMX for fixture reporting
• 5.6° to 56.8° zoom range for variable beam sizes
• Iris, five-facet round and linear prisms, and two frosts (light and medium) for beam control
• TRUE1-compatible power input
• Integrated sun shield for protecting the optical path from sunlight when the fixture is off
• Three setup menu presets and preset sync for cross-loading to multiple like fixtures for easy shop setup
• USB slot for software uploads
• Battery backup display with auto-rotate depending on fixture orientation
Product Overview
Menu
buttons
LCD
display
DMX
in/out
Carry
handles
Power
in
Fuse
holder
USB C
port
Condensation
valve
Ethernet
ports
Antenna

Page 5 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Introduction
Product Dimensions
10.82 in
275 mm
11.94 in
303 mm
5.04 in
128 mm
24.80 in
630 mm
17.50 in
445 mm
32.91 in
836 mm
21.10 in
536 mm
18.47 in
469 mm
12.04 in
306 mm
25.54 in
649 mm
6.18 in
157 mm

Page 6 of 29
Setup
Maverick Storm 4 Profile User Manual Rev. 1
3. Setup
AC Power
The Maverick Storm 4 Profile has an auto-ranging power supply, and it can work with an input voltage
range of 100 to 240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current
value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.
The listed current rating indicates the product’s average current draw under normal conditions.
AC Plug
The Maverick Storm 4 Profile comes with a power input cable terminated with a Seetronic Powerkon A
connector on one end and bare wire on the other end (U.S. market). Use the table below to wire a plug.
Fuse Replacement
1. Disconnect this product from the power outlet.
2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove the blown fuse and replace with another fuse of the same type and rating (25 A, 750 V).
4. Screw the fuse holder cap back in place and reconnect power.
Remote Device Management (RDM)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate
bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the
manufacturer as not all DMX controllers have this capability. The Maverick Storm 4 Profile supports RDM
protocol that allows feedback to make changes to menu map options.
USB Software Update
The Maverick Storm 4 Profile allows for software update through USB using the built-in USB port. The
product's USB port supports up to 32GB capacity and only works with FAT32 file format. To update the
software using a USB flash drive, do the following:
1. Power on the product and plug the flash drive into the USB port.
2. Once the flash drive has been detected, the message “Upgrade Firmware” will be displayed. Press
<ENTER>. If a different message appears on the display, search for the updated software in the
menu (Updated Firmware). A list of the updated software files will be displayed.
3. Select the file that needs to be uploaded. The message “Are you sure?” will be displayed. Press
<ENTER>.
4. If the selected file is correct, the update will be completed. Restart the product.
If the selected file is incorrect, the update will fail, and the display will go back to the main interface.
Repeat steps 1–3 using the correct file.
• Always connect the product to a protected circuit (a circuit breaker or fuse). Make sure
the product has an appropriate electrical ground to avoid the risk of electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green

Page 7 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Setup
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
For our CHAUVET Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position, making sure there is adequate room for ventilation,
configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
• Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product’s
weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
Procedure
The Maverick Storm 4 Profile comes with 2 omega brackets to which mounting clamps (sold separately)
can be directly attached. Make sure the clamps are capable of supporting the weight of this product. Use at
least two mounting points per product. For the CHAUVET Professional line of mounting clamps, go to http:/
/www.trusst.com/products.
Mounting Diagram
Use the 140-D Omega brackets that is supplied with the fixture when doing an overhead
mount.
Safety cable
Mounting
clamp (2x)
Omega
bracket (2x)
Overhead mounting Surface mounting

Page 8 of 29
Setup
Maverick Storm 4 Profile User Manual Rev. 1
Signal Connections
The Maverick Storm 4 Profile can receive a DMX, Art-Net™, or sACN, signal. The
Maverick Storm 4 Profile has two Amphenol XLRnet through ports, and 5-pin DMX in and out ports. If
using other compatible products with this product, you can control each individually with a single controller.
Control Personalities
The Maverick Storm 4 Profile uses a 5-pin DMX data connection, WDMX, Art-Net™, or sACN for its two
control personalities: Dmx Mode 38 CH and Dmx Mode 55 CH.
• Refer to the Operation chapter to learn how to configure the Maverick Storm 4 Profile to work in
these personalities.
•TheControl Channel Assignments and Values section provides detailed information regarding the
control personalities.
DMX Linking
You can link the Maverick Storm 4 Profile to a DMX controller using a 5-pin DMX connection or a WDMX
connection. For more information about DMX, read the DMX primer at: https://
www.chauvetprofessional.com/wp-content/uploads/2016/06/DMX_Primer.pdf.
Art-Net™ Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP that transfers a large amount of DMX512 data using an
Amphenol XLRnet RJ45 connection over a large network. An Art-Net™ protocol document is available
from www.chauvetprofessional.com.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN Connection
Also known as ANSI E1.31, streaming ACN is an Ethernet protocol that uses the layering and formatting of
Architecture for Control Networks to transport DMX512 data over IP or any other ACN-compatible network.
Connection Diagram
If you are not familiar with or need more information about DMX standards or the DMX
cables needed to link this product to a DMX controller, download the DMX Primer from the
Chauvet website: www.chauvetprofessional.com.
Computer/
Controller
(running Art-Net™
or sACN protocol)
Switch or Router
To other Art-Net™ or sACN devices
Maverick Storm 4 Profile

Page 9 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Operation
4. Operation
Control Panel Description
Battery-Powered Display
The Maverick Storm 4 Profile has a battery-powered display that enables access to the menu when the
product is powered off. Press and hold <MENU> until the display activates (approximately 15 seconds).
Home Screen
The Maverick Storm 4 Profile has a home screen that shows the current control protocols, personalities,
starting addresses, IP addresses, and universes. To see the home screen, press <MENU> repeatedly until
it shows on the display. From the home screen, touch any of the displayed control settings to immediately
jump to that part of the menu, such as the personality, starting address, or universe, or press <ENTER> to
reach the main menu.
Control Panel Lock
The setting locks or unlocks the control panel.
1. Go to the Settings main level.
2. Select the Lock Screen option.
3. Select NO (control panel stays unlocked) or YES (locks control panel).
Passcode
After being prompted to enter the passcode, enter the numbers 0920.
Technician Mode
The technician mode disables the pan and tilt motors, allowing the output of the product to be aimed by hand.
To enable the technician mode of the Maverick Storm 4 Profile, hold
<UP> and <LEFT> while the product is
powering on. When the product is turned off and back on, the pan and tilt will return to normal function.
Button Name Function
<UP> Navigates upwards through the menu list or increases the value when in a function
<MENU> Exits from the current menu or function
<DOWN> Navigates downwards through the menu list or decreases the value when in a function
<LEFT> Navigates leftwards through the menu list
<ENTER> Enables the currently displayed menu or sets the selected value into the function
<RIGHT> Navigates rightwards through the menu list
When the control panel lock is activated, the product will prompt for the passcode in order
to access the menu. Enter the passcode as described below.

Page 10 of 29
Operation
Maverick Storm 4 Profile User Manual Rev. 1
Menu Map
Refer to the Maverick Storm 4 Profile product page on www.chauvetprofessional.com for the latest menu map.
Main Level Programming Levels Description
Address 001–512 Sets the starting address
Network
Setup
IP Mode
Manual Manually set IP address
DHCP Network sets IP address
Static Product sets IP address
Universe 000–255 (Art-Net™)
001–256 (sACN) Sets the universe
Ip _ _ _._ _ _._ _ _._ _ _ (000–255) Sets the IP address in Manual mode
SubMask _ _ _._ _ _._ _ _._ _ _ (000–255) Sets the Subnet Mask in Manual mode
Personality Dmx Mode 38 CH NO
YES
Selects the 38-channel mode
Dmx Mode 55 CH Selects the 55-channel mode
Settings
Control
Mode
DMX
Sets the control protocol
ArtNet
sACN
WDMX
Pan
Reverse
NO Normal pan
YES Reversed pan
Tilt Reverse NO Normal tilt
YES Reversed tilt
Screen
Reverse
NO Normal display orientation
YES Inverted display orientation
AUTO Automatic display orientation
Pan Angle
540 540° pan range
360 360° pan range
180 180° pan range
Tilt Angle
270 270° tilt range
180 180° tilt range
090 90° tilt range
BL. O. P/T
Move
NO Enable/disable blackout while panning/
tilting
YES
BL. O.
ColorMove
NO Enable/disable blackout while color
wheel is moving
YES
BL. O.
GoboMove
NO Enable/disable blackout while gobo
wheels are moving
YES
Lock
Screen
NO Lock the buttons
Passcode: 0920
YES
Swap XY NO Do not swap pan and tilt
YES Pan controls tilt, tilt controls pan
WDMX
Reset
NO Do not reset WDMX
YES Reset WDMX
Backlight
Timer
30S Display turns off after 30 seconds
1M Display turns off after 1 minute
5M Display turns off after 5 minutes
ON Display stays on
Loss of
Data
Hold Holds last signal received
Close Blacks out fixture

Page 11 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Operation
Settings
(cont.)
Fans
Auto Fan speed according to product
temperature
Full Fan speed set on high
ECO Quiet mode
TV25
Maintains LED output up to an ambient
temperature of 77 °F (25 °C) (TV25) or
95 °F (35 °C) (TV35).
TV35
When using these fan modes, please
set the PWM Options to 6000Hz or
15000Hz to prevent any harmonization
noise.
Dimmer
Curve
Linear
Set the dimmer curve
Square
I Squa
SCurve
Linear2
PWM
Option
600 Hz
Sets the Pulse Width Modulation
frequency
1200 Hz
2000 Hz
4000 Hz
6000 Hz
15000 Hz
LED
POWER 64–255 Sets LED power
Min Zoom
Focus
NO Enables/disables Min Zoom Focus
YES
Preset
Select
PRESET A
Recorded preset menu optionsPRESET B
PRESET C
Preset
Sync
NO Transfers recorded preset menu
options to other
Maverick Storm 4 Profile fixtures in the
DMX daisy chain
YES
USB
Update
NO Update firmware via USB C
YES
Reset
Function
Pan/Tilt
NO
YES
Reset individual functions or all
functions from start-up
Iris/Prism
Color/CMY/
Blade
Gobo/Gobo
Rotate
Frost/
Animation
All
Factory
Settings
NO Reset to factory default settings
YES
Main Level Programming Levels Description

Page 12 of 29
Operation
Maverick Storm 4 Profile User Manual Rev. 1
Test
Auto Test Auto test all functions
Manual
Test
Pan
0–255 Manually control and test all settings
through the control panel
Pan Fine
Tilt
Tilt Fine
P/T Speed
Dimmer
Dimmer Fine
Shutter
Virtual Shaking
Cyan
Magenta
Yellow
CTO
Color
Gobo
Gobo Rotate
Gobo Index
Gobo2
Gobo2 Rotate
Gobo2 Index
Animation
Animation
Rotate
Blade1-1
Blade1-1 Fine
Blade1-2
Blade1-2 Fine
Blade2-1
Blade2-1 Fine
Blade2-2
Blade2-2 Fine
Blade3-1
Blade3-1 Fine
Blade3-2
Blade3-2 Fine
Blade4-1
Blade4-1 Fine
Blade4-2
Blade4-2 Fine
Blade Rotate
Blade. Rota
Fine
Focus
Focus Fine
Focus Auto
Zoom
Zoom Fine
Main Level Programming Levels Description

Page 13 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Operation
Test
(cont.)
Manual
Test
(cont.)
Prism
0–255 Manually control and test all settings
through the control panel
Prism Rotate
Prism2
Prism2 Rotate
Iris
Frost
Frost2
CMY Macro
CMY Macro
Speed
Special
Function
Information
Fixture
Information
Ver V_ Shows firmware version
Running Mode _ _ _ Shows current running mode
DMX Address _ _ _ Shows current starting address
Temperature _ _ _
Shows current product temperature in
°C
Fixture Hours _ _ _ _ _ Shows hours product has been on
LED Hours _ _ _ _ _ Shows hours LED has been on
Ip _ _ _ _ _ _ _ _ Shows current IP address
SubMask _ _ _ _ _ _ _ _ Shows current Subnet Mask
Fan
Information
Base Fan1–4 Speed _ _ _ _
Shows speed of each fan in rpm
_FAN_ _ _ _
(x17) Speed _ _ _ _
Error
Information _ _ _ _ _ Shows any errors, or No Error!
Channel
Information
Frequency
000–255 Shows all current values from input
signals
Pan
Pan Fine
Tilt
Tilt Fine
P/T Speed
Dimmer
Dimmer Fine
Shutter
Virtual Shaking
Cyan
Magenta
Yellow
CTO
Color
Gobo
Gobo Rotate
Gobo Index
Gobo2
Gobo2 Rotate
Gobo2 Index
Animation
Animation
Rotate
Main Level Programming Levels Description

Page 14 of 29
Operation
Maverick Storm 4 Profile User Manual Rev. 1
Information
(cont.)
Channel
Information
(cont.)
Blade1- 1
000–255 Shows all current values from input
signals
Blade1- 1 Fine
Blade1- 2
Blade1- 2 Fine
Blade2- 1
Blade2- 1 Fine
Blade2- 2
Blade2- 2 Fine
Blade3- 1
Blade3- 1 Fine
Blade3- 2
Blade3- 2 Fine
Blade4- 1
Blade4- 1 Fine
Blade4- 2
Blade4- 2 Fine
Blade Rotate
Blade. Rota
Fine
Focus
Focus Fine
Focus Auto
Zoom
Zoom Fine
Prism
Prism Rotate
Prism2
Prism2 Rotate
Iris
Frost
Frost2
CMY Macro
CMY Macro
Speed
Special
Function
Main Level Programming Levels Description

Page 15 of 29
Maverick Storm 4 Profile User Manual Rev. 1
Operation
Configuration (DMX, Art-Net™, sACN)
Use control configurations to operate the product with a DMX, Art-Net™, or sACN controller.
Control Mode
The Maverick Storm 4 Profile works with wired DMX, WDMX, Art-Net™, and sACN control signals. To
select which protocol to use:
1. Go to the Settings main level.
2. Select the Control Mode option.
3. Select the desired protocol, from DMX, ArtNet, sACN, or WDMX.
Control Personalities
To set the control personality:
1. Go to the Personality main level.
2. Select the desired personality, from Dmx Mode 38 CH or Dmx Mode 55 CH.
Starting Address
Each product will respond to a unique starting address from the controller. All products with the same
starting address will respond in unison. To set the starting address:
1. Go to the Address main level.
2. Select the starting address (001–512).
• The highest recommended starting address for Dmx Mode 38 CH is 475.
• The highest recommended starting address for Dmx Mode 55 CH is 458.
Network Setup
The Network Setup settings control the IP address, subnet mask, and universe of the product.
IP Mode
To choose how the IP address is set:
1. Go to the Network Setup main level.
2. Select the IP Mode option.
3. Select the desired IP mode, from Manual (to set a custom IP address), DHCP (the IP address is
assigned by the connected network), or Static (the product uses a default, preset IP address).
Universe
To assign an Art-Net™ or sACN universe to the Maverick Storm 4 Profile:
1. Go to the Network Setup main level.
2. Select the Universe option.
3. Set the universe, from 000–255 (for Art-Net™) or from 001–256 (for sACN).
Manual IP Address
To set the IP address when the IP Mode is set to Manual:
1. Go to the Network Setup main level.
2. Select the Ip option.
3. Set the 4 values of the IP address from 000–255.
Subnet Mask
To set the subnet mask:
1. Go to the Network Setup main level.
2. Select the SubMask option.
3. Set the 4 values of the subnet mask from 000–255.
• See the Starting Address section for the highest starting address you can select for each
personality.
• Make sure that the starting addresses on the various products do not overlap due to the new
personality setting.

Page 16 of 29
Operation
Maverick Storm 4 Profile User Manual Rev. 1
Control Channel Assignments and Values
38CH 55CH Function Value Percent/Setting
11Pan 000 255 0–100%
2 2 Fine pan 000 255 Fine control (16-bit)
33Tilt 000 255 0–100%
4 4 Fine tilt 000 255 Fine control (16-bit)
5 5 Pan/tilt speed 000 255 Fast to slow
6 6 Dimmer 000 255 0–100%
– 7 Fine dimmer 000 255 Fine control (16-bit)
78Strobe
000 003 Off
004 007 On
008 076 Synchronized strobe, slow to fast
077 145 Pulse strobe, slow to fast
146 215 Random strobe, slow to fast
216 255 On
8 9 Virtual shaking
000 001 No function
002 128 Shaking effect, slow to fast
129 255 Fade effect, slow to fast
9 10 Cyan 000 255 0–100%
10 11 Magenta 000 255 0–100%
11 12 Yellow 000 255 0–100%
12 13 CTO 000 255 0–100%
13 14 Color wheel
000 007 Open
008 015 Color 1
016 023 Color 2
024 031 Color 3
032 039 Color 4
040 047 Color 5
048 059 Color 6
060 187 Color wheel indexing
188 219 Color scroll, fast to slow
220 223 Stop
224 255 Reverse color scroll, slow to fast
14 15 Gobo wheel 1
(see Gobo Wheels)
001 007 Open
008 015 Gobo 1 (Dots)
016 023 Gobo 2 (Paperclip Party)
024 031 Gobo 3 (Orbital)
032 039 Gobo 4 (Dirty Dirt)
040 047 Gobo 5 (Box Cutter)
048 063 Gobo 6 (Crazy Turns)
064 071 Gobo 6 shaking, slow to fast
072 079 Gobo 5 shaking, slow to fast
080 087 Gobo 4 shaking, slow to fast
088 095 Gobo 3 shaking, slow to fast
096 103 Gobo 2 shaking, slow to fast
104 111 Gobo 1 shaking, slow to fast
112 127 Open
128 191 Gobo scroll, slow to fast
192 255 Reverse gobo scroll, slow to fast
