Maxcom MXOPM26-50 Series Manual

O
Op pt ti ic ca al l P Po ow we er r M Me et te er r · · M MX XO OP PM M2 26 6- -5 50 0 S Se er ri ie es s
T
Te ec ch hn ni ic ca al l S Sp pe ec ci if fi ic ca at ti io on n
www.maxcomcorp.com
209-339-2333
Ver. 1.0

CONTENTS
1.0 PRODUCT DESCRIPTION
2.0 PRODUCT FEATURES
3.0 MAIN APPLICATIONS
4.0 SPECIFICATIONS
5.0 QUICK START GUIDE
1.0 Product description
With six wavelength calibrating wavelengths (850nm,1300nm,1310nm,
1490nm,1550nm and 1625nm), refined design, easy operation, linearity or
non-linearity display, the MXOPM26-50 hand-held optical power meter can be used
for direct optical power measurement as well as relative measurement of optical
link loss. It is an essential test instrument in Optical Communication systems, CATV
systems, construction and maintenance applications and more.
2.0 PRODUCT FEATURES
•Quick response and measurement: It can display fast-tracking and real-time
measurement of optical power when output power changes.
•Wide measurement range provides measurements between -50 to +26 dBm of
optical power measurement range. High measurement accuracy and display
resolution.
•Six calibrated wavelengths: 850nm,1300nm,1310nm, 1490nm,1550nm and
1625nm.
•Provide absolute optical power measurement and relative power measurement.
•Real time monitoring and displaying the battery level Warning notice is available
when the battery is low.
•Backlight LCD display, Auto-off function, self-calibration function.
3.0 Main applications
•Various CATV/Data optical applications where the measurement of optical power
levels are required
•Optical fiber testing and research
•Teaching and experimenting of optical communications
•Optical fiber communication engineering

4.0 SPECIFICATION
Model
MXOPM26-50
Connector
FC/PC
Wavelength Range
(nm)
850nm,1300nm,1310nm,1490nm,
1550nm,1625nm (800-1650nm)
Probe Type
InGaAs
Power measurement range
(dBm)
-50
+26
Calibrating Wavelength No
6
Accuracy
±5%
Display Resolution
(s)
Logarithmic display: 0.01dBm
Preheated Time
0
Display Unit
dBm/W
Display Refresh Frequency
(Hz)
3
Auto Power Off Time
(min.)
Optional
Battery Operating
Endurance Time
(h)
>240
Work temperature
(℃)
-10 ~ +50
Storage temperature
(℃)
-25 ~ +70
Relative Humidity
(%)
0~95 without condensation
Size
130x66x27mm / 5.07x2.57x1.05 inch
Weight
160G / 5.6 oz.
Power supply
(3) AAA 1.5V battery
www.maxcomcorp.com
209-339-2333

5.0 Quick Start Guide
• Measurement of the power of an optical signal (dBm and W)
Turning Meter On/Off
Press the button to turn unit on.
Press the button and hold for 2 or 3 seconds to turn the meter off.
Wavelength Button
This button is used to select the wavelength. 850nm, 1300nm, 1310nm, 1490nm, 1150nm, and 1625nm.
Press the button repeatedly to step through the wavelengths. Simply select to closest wavelength to
the one you are measuring for best accuracy.
Measurement Selection Button
This button is used to select either dBm or nW between the absolute and relative measurements of
optical power. (mW is milliwatt, or 10 ˉ3, nW is nanowatt or 10 ˉ9 watt).
*Note, most customers will use dBm to measure the absolute power.
Reference Button
Press this button to save the current power value (zero the test setup). This value can be used as a
reference and will be displayed in the upper right hand corner of the LCD screen. Pressing this button
quickly will switch the function to a relative power measurement. With the reference power value
showing, the relative value will now be displayed between the current measurement and the reference
power.
Using the Meter for a simple optical power measurement
(1) Use one fiber optic jumpers to connect the output port of the light source with the detecting port of the
fiber power meter.
(2) Turn on the light source and then select the wavelength to be tested.
(3) Select (dBm) to measure the absolute optical power.
(4) The LCD display now shows the actual output power of the light source as shown in the dBm
(example: power shown may be 05.73 dBm, or -09.25 dBm).
