Maxforce ELITE e-Agitator Guide

M10442-20-A(888) 257-7729 | maxforce.com
Operation & Parts
MAXFORCE
ELITE e-Agitator
M10442-20-A
Product Description
AGITATOR, HIGH VIS, ELEC, ELITE
2845 W Service Rd Eagan, MN 55121
WARNING
FIRE AND EXPLOSION HAZARD
Use only non-flammable or water-based materials
with this equipment. Do not use materials having
flash points lower than 140° F (60° C). For more
information about your material, request Safety
Data Sheet (SDS) from the supplier. Not for use in
explosive environments or environments where
ignitable vapors may be present. Inspect the work
area for potential hazards before operating this
equipment.
Manual Revisions
Revision Date Serial No
A7/13/23 9066742—

2(888) 257-7729 | maxforce.com M10442-20-A
Table of Contents
Safety 3
Equipment Layout 4
Control Panel Layout 5
Specifications 6
Operation 7
Technical Data
Dimensions 8
Parts 9
Wiring Diagram 13
Warranty 16
For parts, service, and technical assistance,
contact your equipment distributer:

M10442-20-A(888) 257-7729 | maxforce.com 3
Safety
General Safety Information
READ THE MANUAL
• Ensure any operator of this equipment has read and
understands the manual before operating.
• Do not attempt to repair or modify this equipment
without consulting the manual.
EQUIPMENT MISUSE HAZARD
• Equipment misuse can cause the equipment to rupture
or malfunction and result in serious injury.
• This equipment is for professional use only.
• Read all instruction manuals, tags, and labels before
operating the equipment.
• Use the equipment only for its intended purpose. If you
are not sure, call your distributer.
• Do not alter or modify this equipment. Use only genuine
OEM parts.
• Check equipment daily. Repair or replace worn or
damaged parts immediately.
• Comply with all applicable local, state, and national fire,
electrical, and safety regulations
• Do not leave the work area while equipment is
operating.
FIRE AND EXPLOSION HAZARD
• Improper grounding, poor ventilation, open flames or
sparks can cause a hazardous condition and result in a
fire or explosion and serious injury.
• Keep the equipment area free of debris, including
solvent, rags and uncontained fuel.
• Use only with non-flammable or water-based materials
• Keep a working fire extinguisher on hand at all times in
the work area.
Equipment Hazards & Warnings
DANGER
• Do NOT use near solvents or solvent based materials
• Do NOT use near flammable materials or in poorly
ventilated areas
• The motor and associated components are not rated for
use in explosive environments.
WARNING
• Read the operators manual before starting this unit.
Failure to adhere to instructions can result in severe
personal injury.
• Do NOT operate equipment that is not mounted in a 2”
bung on a 55 gallon drum.
• To avoid potential injury, disconnect power cord prior to
transporting or moving equipment from one drum to the
next drum.
• Keep clear of moving parts, do not operate equipment
with enclosure panels removed.
CAUTION
• To avoid electrical shock, disconnect power cord prior
to electrical system service
• Motor enclosure may get warm to the touch when
equipment is run for long periods of time.

4(888) 257-7729 | maxforce.com M10442-20-A
Equipment Layout
A
B
G
E
D
C
e-Agitator Components
A110/120VAC Plug
BCooling Air Intake
CMotor Start/Stop
DMotor RPM Display
EON/OFF Switch
F2” NPT Bung Adapter
GMixing Shaft
HMixing Blade (3 Total)
H
F

M10442-20-A(888) 257-7729 | maxforce.com 5
Control Panel Layout
Control Panel
APower ON/OFF Switch
BMotor START/STOP Pushbutton
CRPM SET Button
DRPM Up Arrow
ERPM Down Arrow
FRPM Display/Setpoint
B
A
SET
RPM E
D
C
F

6(888) 257-7729 | maxforce.com M10442-20-A
Specifications
Performance
Output Speed 0-500 rpm
Output Torque 55 in-lbs
Power
Voltage 110/120 VAC
Amperage 4A
Rated Motor Power 378 W
Dimensions
Length 7.1”
Width 5.6”
Height 47” (12.1” From Top of Drum)
Weight 16.5 lbs
Bung Adapter Size 2” NPT
Wetted Parts Stainless Steel

M10442-20-A(888) 257-7729 | maxforce.com 7
Operation
Install the agitator
1. Due to differing drum heights, the
expanding agitator blades may need to
be adjusted up and down the agitator
shaft. Loosen the set screws on each
blade and adjust to the appropriate
height, then re tighten securely to the
shaft.
2. Install the agitator into a 55 gallon drum
by folding the expanding blades and
inserting them into the 2” NPT female
bung on the topside of the drum. Thread
the agitator clockwise to tighten.
NOTICE
• Ensure the agitator shaft is not contacting the bottom of
the drum.
• The agitator should be hand tightened into the drum.
Operating the agitator
1. With the agitator fully tightened into a
drum of material, connect the agitator to
a 120VAC power source with the
attached plug.
2. Switch the power switch to the ON
position. The RPM display will illuminate
and the cooling fan will turn on.
CAUTION
• Never operate the agitator in an empty drum or not
installed in a drum.
• Do not attempt to use the agitator while holding it, or
otherwise supporting it in a smaller container.
3. To change the desired RPM setpoint,
press the up or down arrow on the RPM
display. The number that is displayed is
the RPM setpoint. Use the arrows to
adjust the RPM setpoint to the desired
value, and then press the SET button to
lock the setpoint.
NOTICE
• The agitator will store the previous RPM setpoint from
the last time it was shutdown.
• If the SET button is not pressed, after approximately 3
seconds the unit will revert to the previous RPM
setpoint.
4. Press the motor START/STOP button to
begin agitating. The agitator will begin
turning, and the agitator RPM will display
on the screen. It may take a few moments
to adjust it’s speed to the RPM setpoint.
5. To stop the agitator, press the motor
START/STOP pushbutton again, or
switch the power switch to the OFF
position. It may take a few moments for
the agitators blades to slow.
6. When finished for the day, stop the
agitator motor, and unplug the 120V
power cord.

8(888) 257-7729 | maxforce.com M10442-20-A
Technical Data
Agitator Dimensions

M10442-20-A(888) 257-7729 | maxforce.com 9
Parts
Motor Assembly
Ref. Part No. Description Qty
1V10442-50 BRUSHLESS DC GEARMOTOR 1
2C10442-68 SHAFT COUPLER 1
3C10442-70 BUNG MOUNT WELDMENT 1
4C10442-84 MOUNT PLATE, HV AGITATOR 1
5V10442-35 SOCKET HEAD CAP SCREW 1
6V10442-36 DOG POINT SET SCREW 2
7V10442-60 THERMOSTAT 1
19 V10442-48 PRESS-FIT NUT 6
26 C10442-89 THERMO SWITCH MOUNT 1
6

10 [phone] | maxforce.com M10442-20-A
Power Supply, Enclosure Parts — Cont.
Ref. Part No. Description Qty
8C10442-86 COVER, RIGHT 1
9C10442-87 COVER, LEFT 1
10 V10442-62 BUTTON HEAD SCREW 4
12 V10442-67 STRAING RELIEF ELBOW 1
13 V10442-68 LOCKING NUT 1
14 V10442-52 POWER SUPPLY 1
46 V10443-49 SPRING PIN 1

M10442-20-A(888) 257-7729 | maxforce.com 11
Control Panel
Parts — Cont.
Ref. Part No. Description Qty
14 C10442-81 1
19 S10442-18 CONTORL BOARD ASSM 1
20 V10442-53 COOLING FAN 1
22 V10442-65 SPACER 4
23 V10442-63 PRESS FIT STUD 4
24 V10442-96 LOCK NUT 4
26 L10442-20 LABEL 1
28 V10442-14 RPM DISPLAY 1
29 V10442-42 POWER SWITCH 1
32 V10442-77 BUTTON HEAD CAP SCREW 4
46 V10443-53 PUSHBUTTON 1
50 V10442-78 NYLON NUT 4

12 [phone] | maxforce.com M10442-20-A
Cover, Agitator Blade Assembly
Parts — Cont.
Ref. Part No. Description Qty
517V342 KIT, AGITATOR, SHAFT 1
11 V10442-36 DOG POINT SET SCREW 2
16 V10442-62 BUTTON HEAD SCREW 6

M10442-20-A(888) 257-7729 | maxforce.com 13
Wiring Diagram

14 [phone] | maxforce.com M10442-20-A
Wiring Diagram — Cont.

M10442-20-A(888) 257-7729 | maxforce.com 15
Notes

16 [phone] | maxforce.com M10442-20-A
Warranty
MaxForce warrants all equipment listed in this manual which is manufactured by MaxForce and bearing its name
to be free from defects in material and workmanship on the date of sale by MaxForce or authorized distributor to
the original purchaser for use. With the exception of any special extended or limited warranty published by
MaxForce, MaxForce will, for a period of twelve months from the date of sale, repair or replace any part of the
equipment determined by MaxForce to be defective. This warranty applies only when the equipment is installed,
operated and maintained in accordance with MaxForce’s written recommendations.
This warranty does not cover, and MaxForce shall not be liable for general wear and tear, or any malfunction,
damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper
maintenance, accident, tampering, or substitution of non-MaxForce component parts. Nor shall MaxForce be
liable for malfunction, damage or wear caused by the incompatibility of equipment with structures, accessories,
equipment or materials not supplied by MaxForce, or the improper design, manufacture, installation, operation or
maintenance or structures, accessories, equipment or materials not supplied by MaxForce.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized
MaxForce distributor for verification of the claimed defect. If the claimed defect is verified, MaxForce will repair or
replace free of charge any defective parts. The equipment will be returned to the original purchaser transportation
prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will be
made at a reasonable charge, which charges may include the costs of parts, labor and transportation.
MaxForce’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The
buyer agrees that no other remedy (including, but no limited to, incidental or consequential damages for lost
profits, lost sales, injury to person or property, or any other incidental or consequential loss) shall be available.
Any action for breach of warranty must be brought within two (2) years of the date of sale.
MaxForce makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular
purpose in connection with accessories, equipment, materials or components sold but not manufactured by
MaxForce. These items sold, but not manufactured by MaxForce (such as electric motors, gas engines, switches,
hose, hydraulic components, etc.) are subject to the warranty, if any, of their manufacturer. MaxForce will provide
purchaser with reasonable assistance in making any claim for breach of these warranties.
In no event will MaxForce be liable for indirect, incidental, special or consequential damages resulting from
MaxForce supplying equipment hereunder, or the furnishing, performance, or use of any products or other goods
sold hereto, whether due to a breach of contract, breach of warranty, the negligence of MaxForce, or otherwise.
All written and visual data contained in this document reflect the latest product information available at the time of
publication. MaxForce reserves the right to make changes at any time without notice.
