1. Precautions
This user manual contains the necessary information regarding the installation and use of
ModSecur MT40. Before beginning installation and use, you are asked to read this manual
carefully. The UPS must be installed and congured by an authorized service center of the
manufacturer or distributor. In the case of installation by people without the required
experience, there is a risk of users being exposed to health or life. Persons not authorized to
install may damage the power supply, which in this case is not subject to warranty conditions.
COMPLETE STANDARDS
The device complies with the directive CE 73/23 and 93/68 (low voltage safety) and also 89/336 (EMC)
and the following standards:
*IEC62040-1-1
*IEC/EN62040-2 EMC CLASS C3
*IEC62040-3
Connecting the protective conductor (PE) is essential and must be done before connecting the
remaining working cables (power supply, receiving, battery). Grounding should be carried out in
accordance with prevailing standards and practical on-site knowledge.
The leakage current exceeds 3.5 mA and is less than 1000 mA.
When selecting RCCB or RCD devices for immediate operation, the transient and xed leakage currents
that may occur during commissioning must be considered.
Automatic residual current circuit breakers (RCCBs) that are sensitive to DC unidirectional (Class A)
pulses and are insensitive to transient current pulses shall be selected.
Also note that the RCCB or RCD device will conduct the leakage current of the receiver.
NOTE - High leakage current
There is dangerous voltage in the UPS housing. The risk of contact with such voltage is minimized as the
live parts are behind the enclosure. Additional internal protection guards ensure that the device is
protected in accordance with IP20 protection class.
Normal operation of the device, taking into account recommended operating procedures, does not
pose any risk to personnel.
All maintenance and service procedures require access to the inside of the machine and should only be
carried out by trained personnel.
Operation

2
High battery voltage> 400 Vdc
All maintenance and installation work may be performed by a properly trained service technician.
After connecting the battery the voltage at their terminals exceeds 400 Vdc and is potentially fatal.
Battery manufacturers give detailed precautions that must be followed when working on or near large
battery packs. Such measures must always be strictly observed.
Special attention should be paid to recommendations regarding local environmental conditions and
the provision of protective clothing, rst-aid and re-ghting equipment.

3
2. Installation procedure
This chapter is dedicated to the installation method, how to mount and wiring the UPS.
2.1 Introduction
This chapter describes the basic requirements for the positioning and wiring of the power
supply. This description is a step-by-step installation guide, which provides a number of
guidelines for how to guide your service during assembly.
Warning - Installation may only be carried out by an authorized service center
1. Do not connect electrical appliances to the power supply before conrming that the power supply is
properly connected and congured.
2. The UPS should be installed by qualied technicians in accordance with the guidelines in this chapter.
Do not perform any electrical work that interferes with the electrical installation before and after the
UPS while the UPS is operating. Damage arising from this title (eg phase sequence replacement) is not
covered by the warranty.
Warning: dangerous batteries
Special precautions must be observed when working with batteries connected to the power supply.
After connecting the battery, the voltage at the terminals exceeds 400 Vdc and is potentially fatal.
It is recommended to use protective eyewear to protect your eyes from accidental electric arc. In
addition, it is recommended that:
- Remove rings, watches and all metal objects.
- Only use tools with insulated handles.
- If the battery leaks or the battery is otherwise damaged, replace it. Damaged batteries should be
stored in a container resistant to sulfuric acid and disposed of in accordance with local regulations.
If the electrolyte comes in contact with the skin, the contaminated area should be washed immedia-
tely with water.
2.2 Preliminary review
Please perform the following checks before installation:
- Verify that the supplied equipment, ie UPS and batteries, is not damaged by shipping. Any
damage should be reported immediately to the supplier.
- Verify the compliance of the supplied equipment with the installation requirements. The
power of the power supply is described on the label each time.

4
2.3 Location
The UPS is designed for indoor installation. The device should be in a clean, ventilated environ-
ment in order to maintain the ambient temperature within the required specications. The UPS
provides forced convection cooling through internal fans. Cold air enters the unit through the
ventilation openings located in the front of the enclosure and is blown out by the grills in the
rear of the enclosure. Do not block the ventilation openings.
Depending on the conditions of the room, the ventilation openings of the power supply
should be regularly cleaned, eg with a vacuum cleaner. Ventilation will ensure ecient cooling
and longer service life.
Note: The UPS should be installed on a stable and non-ammable surface.
2.3.1 UPS Room
The battery temperature should be stable as it is the main parameter that aects battery life
and capacity. The optimal operating temperature of the battery is 15-25 ° C. It is recommended
to maintain a nominal temperature of 20 ° C.
Working at higher temperatures shortens the battery life and reduces the battery capacity in
the lower battery. Each increase in battery operating temperature by another 8 ° C, reduces the
service life by 50%.
Keep batteries away from heat sources and hot air outlets.
When installing the battery outside the UPS, use the battery circuit as close as possible to the
battery. The connecting cables for the batteries and UPS should be as short as possible.
2.3.2 Battery room
If the device is not installed and needs to be stored, protect it from excessive humidity and high
temperatures. Keep batteries in a dry and cool place. The most suitable storage temperature for
batteries is 20-25 ° C. If the unit is not installed immediately, store it indoors to protect it from
excessive humidity and heat sources.
2.3.3 Storage
Before unpacking, carefully inspect the package provided or damage during transportation.
After removing from the package, check that the equipment does not show signs of damage. If
there are any damages, please notify the supplier immediately.
2.4. Unpacking, checking and setting up

5
The power supply is delivered in a cardboard package on a wooden pallet. For unpacking,
remove the carton and foam inside the package. Below is shown the device after dismantling
the package.
2.4.1 Unpacking
View of the power supply after dismantling the packaging
Tip: Remove the screws connecting the UPS power casing to the wooden pallet, and then
place the UPS at the installation point. Disassembly should be carried out with care not to
scratch the case.
The gure below shows the view of the power supply base, the location of the drive wheels,
and the UPS stabilizing components when it is positioned at the destination.
Verify that the supplied equipment is properly labeled on the back of the UPS door. The label
contains basic information about model, power, etc.

6
Note: Remaining materials (timber, plastic, etc.) must be disposed of in accordance with applica-
ble local environmental regulations.
In order to prolong the life of the device, a suitable installation site should be provided to ensure
that:
- Easy to connect to the electrical system
- Sucient space to handle
- Ventilation or air conditioning to ensure adequate cooling of the power supply
- Protection against gases and vapors that may cause corrosion
- Protection against excessive humidity and heat sources
- Protection against dust, dust and other contaminants
- Proper re protection
- The working temperature should be between 20 and 25ºC. At such temperatures, the batteries
show optimum performance.
2.4.2. Design and dimensions of the UPS
The appearance and dimensions [mm] of the UPS are shown in the gures below:
Front view / side of UPS

7
Front view of the UPS
Front view of the UPS

8
2.4.3. Service space
On the side walls of the power supply unit there are no ventilation openings, therefore no space
is required on the side for ventilation purposes. For access to the device on each side, it is recom-
mended to keep min. 50 cm service area.
It is necessary to provide adequate space from the front of the power supply for easy operation
and the ability to draw cold air from the environment. Recommended 80 cm front space.
Due to the required access to the back of the power supply and free airow and circulation, the
recommended back space of the power supply is 50 cm.
2.5. Security systems
For safety reasons, it is necessary to install appropriate protections in the form of surge suppres-
sors or other protective devices in the UPS distribution board. This chapter provides general
practical information for installation by qualied electricians. In addition, sta with the appropria-
te knowledge and authority should be aware of the standards and standards applicable to the
local market for type and cross-section of wires, their arrangement and their load capacity. It is
recommended to use exible hoses type LgY or OpD.
2.5.1. UPS input power
The UPS should be powered from an electrical switchgear equipped with a suitable security
apparatus selected for maximum system power and exible hoses with appropriate current
carrying capacity selected for the protection used.
If you need to install RCDs on the UPS power supply, keep in mind that these units should:
Be sensitive to unidirectional DC current pulses (Class A)
Not be sensitive to transient current impulses
Adjustable sensitivity range 0.3 - 1A.
The RCD must be sensitive to unidirectional DC current pulses and insensitive to transient
current pulses as shown below:

9
RCD switch designation
2.5.2. Battery circuit protection
The battery required for proper operation of the power supply consists of a standard of 40 12 V
batteries connected in series. A 3 watt lead with center neutral is required, taken from a central
connection between battery 20 and 21. The battery circuit must be protected by a suitable fuse
that is rated for the power of the UPS.
A detailed drawing of the battery installation is shown below:
Diagram of serial connection of 40pcs batteries with central neutral point
2.6. Power supply cables
The main factors that aect the selection of wires are the supply voltage, current, and room
temperature and cable installation conditions.
The power supply cables of the system must be selected in accordance with the applicable
regulations at the site and comply with the following description:
Input power cords must be matched to the maximum input current and maximum charging
current shown in the table below, including the power rating of the power supply and AC
input voltage. Output and bypass cables must be matched to the rated output currents given
in the table, taking into account the power rating of the power supply and the AC output
voltage. Battery cables must be matched to the battery discharging current at the end of the
discharge voltage given in the table, taking into account the power rating of the power supply.
The terminal block for connecting the power / receiving cables is located on the back of the
power supply. Bolts with eyelet for M6 bolt, screw tightening torque of 4.9Nm.

10
View of the rear of the power supply and the cable approach
View of the rear of the power supply and the cable approach

11
Before performing the power supply circuit must happen to the position and operation of the
external switch to connect the input / output supply of the power supply with the network distribu-
tion panel. Check that the above power sources are electrically disconnected and to make necessary
warning controls to be uninded that they are incidentally actually actually once that the ups should
not show on the cable at the ups.
Attention
2.6.1. Maximum power supply currents
The following table shows the currents for the maximum system power, depending on the
power system. These currents are used to select the appropriate protection in the power, battery
and receiver paths and the corresponding cable cross-sections.
Currents given at a 230 / 400Vac installation.
System MT10 MT15 MT20 MT30 MT40
Power 10kVA 15kVA 20kVA 30kVA 40kVA
Dimensions (mm)
(WxDxH) 250x872.6x714.5 350x737x1335 500x840x1400
Supply Nominal
current [A]
Output Nominal
current [A]
Battery Nominal
current [A]
18 28 35 55 70
15 23 30 45 60
20 30 40 60 80
The power supply needs to be connected to the PE protective conductor. Incorrect connection of the
protective conductor may cause malfunction of EMI lters and result in electric shock or re.
Warning
2.6.2. Connecting wires
The operations described in this section should be performed by a suitably trained service team. The
contractor is responsible for preparing the power supply and the power supply to the power supply.
Warning

12
View of the terminal block for connection of cables
View of the terminal block for connection of cables
View of the terminal block for connection of cables
After properly aligning and securing the power supply from moving, connect the wires with
the following rules:
1.Check that the power supply is completely disconnected from the external power source and
that the Service bypass switch on the power supply is open. Ensure that these power sources
are electrically isolated and arrange the necessary warning signs to prevent accidental activa-
tion.
2. Open the rear door of the power supply and remove the cover to gain access to the power
supply. The terminal block for connecting cables is located on the front of the power supply.
3.Connect the earth ground wire. The connection must comply with local regulations and
standards.
4. Connect the power supply cables to the input (Main Input mA-mB-mC-N), output leads are
output A-B-C-N. Check the correct sequence (rotation) of the phases. When connecting two
paths with separate rectier and Bypass path power supply, the bridges connecting the rectier
and bypass inputs (mA-bA; mB-bB; mC-bC) must be dismounted.
5. Connect the power cords between the UPS and the battery disconnect switch.
Check correct polarity.

13
Warning - Dangerous voltage on battery terminals
Make sure that the polarity of the battery is correctly connected. Battery positive terminal for positive
terminal (BAT +) on UPS, negative battery terminal for negative terminal (BAT-) on UPS, neutral terminal
for neutral terminal (N) on UPS.
6. Replace the protective cover and the rear cover of the power supply.
2.7. Internal battery connections
The MT 10-15-20-30 series power supplies allow you to install batteries inside.
Standard UPS NGS 10-15 is designed to mount 40 batteries 7 / 9Ah / 12V, while MT 20-30 to install
40 batteries 12Ah / 12V or 2x32x9Ah.
The following gure shows the assembly and location of the battery inside the device.
View of battery location and connection depends on UPS model
2.8. Communication cables
As shown in the gure below, the power supply interface is located at the back of the power
supply, and consists of a contact interface (Dry Contact J2-J10), a USB communication interface,
RS-232, RS-485, parallel card slot and SNMP card slot. There is also a button called. A "cold start",
which allows the battery to run from a battery even when the power supply is o.

14
Communication interface
The wires connected to the DryContact interface must be potential-free and separate from AC
conductors. Wires should be double insulated with a cross section of 0.5-1.5 mm2 and their
maximum length should not exceed 50m.
2.8.1. Dry Contact - sensor for detecting battery temperature and environment
The Dry Contact J2 and J3 input signals are used to detect the temperature of the battery and
the environment at the sensor site. The battery temperature sensor is used to compensate the
temperature of the battery charging voltage. The interface and connection description are
shown below.
View of the interface DryContact J2 and J3

15
PIN
J2.1
J2.2
J3.1
J3.2
Description
TEMP_BAT
GND
TEMP_ENV
GND
Purpose
Battery temperature detection
Ground
Environmental temperature detection
Ground
Note: Use suitable temperature sensors for proper detection (R25 = 5 Ohm, B25 / 50 = 3275). Please conrm the compliance
of the supplier at the time of placing the order.
2.8.2. REPO switch port
The UPS has a REPO interface to remotely shutdown the UPS in case of an emergency (eg re).
The function can be activated by pressing the key on the front panel of the power supply or
remotely using the remote REPO switch.
Use the J4 connector to connect the remote REPO. During normal operation, NC and + 24V
short-circuits are required. Activation of the EPO signal occurs when the NC signal is + 24V open
or short circuit of the NO and + 24V pins. The interface and connection description are shown
below.
Interface REPO
PIN
J4.1
J4.2
J4.3
Description
EPO_NC
＋24V
EPO_NO
Purpose
EPO is activated when disconnected from J4.2
+ 24V, voltage to connect with NC and NO
EPO is activated when connecting to J4.2

16
Use an external potential-free REPO circuit breaker using a normally closed (NC) or normally
open (NO) contact.
If you do not use the remote REPO, pin J4.1 must be connected to J4.2 and pin J4.2 disconnected
from J4.3.
1. Using the EPO switch causes the rectier, inverter, and Bypass to stop, and disconnect the power
supply at the output of the power supply.
2. Standard pin J4.1 and J4.2 are connected to each other at the time of delivery.
Warning
2.8.3. External bypass interface
Input connector J5 is used for communication with external bypass. Pins J5.1 and J5.2 are open
(NO) while the UPS is operating normally (bypass bypass in UPS position). Bypassing the external
bypass to the BYPASS position closes the 5.1 and 5.2 (NC) pins.
The UPS automatically returns to normal operation when the bypass is switched to the UPS
position.
PIN
J5.1
J5.2
J5.3
Description
EXT Bypass
EXTBypass
N/A
Purpose
Signaling work bypass external
Signaling work bypass external
N/A
2.8.4. Interface to BCB battery switch
J6 and J7 connectors are used in conjunction with the optional BCB battery circuit breaker.
The interface and connection description are shown below.
Interface BCB
