Maxkin SP-R01 User manual

Printed in China
2016 V 1.0
SP-R01(PLUS) is a wireless repeater that extends the range of RF
devices. It is in elegant design and easy to install. It eliminates
the needs to upgrade to a larger alarm control panel that supports
two receivers. Its for installation that requires extended RF range
with good stability, high receiving sensitivity, longer transmitting
distance and anti-interference. The replaceable plugs is more
flexible to meet different customers’ needs.
1.LED Indicator
Red LED Flashes Once：Enrolling
Green LED On：System disarmed
Green LED Flashes Once: Transmitting wireless signal
Blue LED On: System armed in away mode.
Blue LED Flashes: System armed in stay mode.
2.Enroll/Testing Button
3.Plug Handle
4. Interchangeable Plugs
1
2
4
3
SP-R01 (PLUS)
Wireless RF Repeater
User Manual
Extends the range of wireless devices
Receives alarm, status and control messages from accessories,
and repeats these messages to the control panel
LED circle in 3 different colors indicate the alarm current status
for arming/disarming...
One single touch to turn on/off the LED indicator
Replaceable plug, more flexible to change
Back up battery for 12 hours when power lost
Specification
Description
Features
General View/LED Indication
Voltage: DC100-240V 50/60HZ
Max Current: 20mA/220V
Power Rating: ≤5W(220V)
Back-up Battery: 3.7V/600mA
Receiving Distance: 100M
Transmitting Distance: 500M
Housing Material: ABS plastic
Plus Type: EU/US/UK/AU
Operation Condition: -10°C~55°C
Size:Φ80 x 41.7mm

Enrollment
1. Press the enroll button of RF repeater, one beep is heard and the
LED lights up in red to enter into enrolling status ( Press again the
Enroll Button within 30 seconds to exit enrolling state.)
2. Enroll the alarm control panel by triggering its enroll button or
tamper switch.
Enroll the accessories by triggering, for example, pressing any
button of remote control, depart the transmitter and magnet of
door sensor etc.
Button Operation
Note: Accessories which already connected with
control panel also need to pair with repeater.
2
3
Repeater beeps once, the LED light flashes
once, the enrollment is successful.
If repeater beeps twice and the LED light
flashes once,the accessories have been
enrolled before.
If three beeps are heard and LED light
flashes once, the storage is full.
1Notice:
1. The back-up battery only for emergency use, AC power should
be the main supply.
2. Do hot hit or drop the repeater in case of damage component
inside.
3. The strobe siren should be tested regularly, so that all fault
can be fixed in time.
4. Do not install the device lower than 1.2 m .
5. Each accessory and the control panel can not be too close,
otherwise it will effect the transmitting.
Installation
Fix the the plug on detector properly by rotating.
And then power it on.
Delete Enrolled Wireless Accessories
Press and hold the enroll button for 5 seconds
until one beep is heard. All enrolled wireless
accessories will be deleted.
Function Opcration
Turn On Repeater
Status
Turn Off Repeater
Turn On/Off LED
Indicator
Enters into Enroll
State
Delete Enrolled
Wireless
Accessories
Press Enroll Button
for 3 seconds
The repeater beeps once,
the LED indicator light up
in green color.
The repeater beeps once,
the LED indicator blacks out.
The repeater beeps once,
the LED indicator blacks
out or light up.
The repeater beeps once,
LED indicator light up in red.
The repeater beeps once.
Press Enroll Button
once
Press Enroll Button
for 5 seconds
Press Enroll Button
for 5 times
Press Enroll Button
for 10 times
1
Turn On/Off
Siren Sound
Press Enroll Button
3 times
The repeater beeps once,
the LED indicator blacks
out or light up.
