C O N TA C T I N F O R M AT I O N
In keeping with Maxon's dedicated customer support policy, we
encourage you to contact us.
TECHNICAL:
Hours of Operation: Monday to Friday 8.30am to 5.30pm*
Telephone: [phone]
Facsimile: [phone]
Email: [email protected] * Public holidays
excluded
SALES:
Hours of Operation: Monday to Friday 8.30am to 5.30pm*
Telephone: [phone]
Facsimile: [phone]
Email: [email protected] * Public holidays excluded
WEBSITE: www.maxon.com.au
Maxon has also added for the benefit of developers and integrators, a
forum on our website that can be accessed to discuss this product
and/or technical matters in relation to your applications. All questions
raised within this portal will be answered.
FORUM: www.maxon.com.au/forum
ADDRESS:
Maxon Australia Pty Ltd
36a Gibson Avenue, Padstow
Sydney, NSW, Australia 2211
POSTAL ADDRESS
Maxon Australia Pty Ltd
Po Box 1, Revesby North,
Sydney, NSW Australia 2212

Page - 5 -
RF EX P O S U R E C O M P L I A N C E
The use of this device in any other type of host configuration may not
comply with the RF exposure requirements and should be avoided.
During operation, a 20 cm separation distance should be maintained
between the antenna, whether extended or retracted, and the
user’s/bystander’s body (excluding hands, wrists, feet, and ankles) to
ensure RF exposure compliance.
Caution
Change or modification without the express consent of Maxon
Electronics Australia Pty. Ltd. voids the user’s authority to use the
equipment. These limits are designed to provide reasonable protection
against harmful interference in an appropriate installation. The modem is
a transmitting device with similar output power to a mobile phone. This
equipment generates, uses, and can radiate radio frequency energy
and, if not used in accordance with instructions, can cause harmful
radiation to radio communication. Use only the supplied or an approved
antenna. Unauthorized antennas, modifications, or attachments could
impair call quality, damage the device, or result in violation of RF
exposure regulations.
However, there is no guarantee that interference will not occur in a
particular installation. If the equipment does cause harmful interference
in radio and television reception, which can be determined by turning
the equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
Re-orient or relocate the receiving radio or TV antenna
Increase the separation distance between the equipment and
the receiver
Contact Maxon Australia Technical Support for assistance.
Notes The user is cautioned that changes or modifications not expressly
approved by Maxon Australia could void the warrantee.
* The product needs to be supplied by a limited power source
or the power supply provided. Otherwise, safety will not be
ensured

Page - 6 -
Potentially Unsafe Areas
Posted Facilities: Turn off this device in any facility or area when
posted notices require you to do so.
Blasting Areas: Turn off your device where blasting is in progress.
Observe restrictions and follow any regulations or rules.
Potentially Explosive Atmospheres: Turn off your device when you
are in any area with a potentially explosive atmosphere. Obey all
signs and instructions. Sparks in such areas could cause an
explosion or fire, resulting in bodily injury or death.
Areas with a potentially explosive atmosphere are often but not
always clearly marked. They include:
fuelling areas such as gas or petrol stations
below deck on boats
transfer or storage facilities for fuel or chemicals
vehicles using liquefied petroleum gas, such as propane or
butane
areas when the air contains chemicals or particles such as
grain, dust or metal powders
avoid using the modem in areas that emit electromagnetic
waves or enclosed metallic structures e.g. lifts
any other area where you would normally be advised to turn off
your engine

Page - 7 -
R E V I S I O N H I S T O RY
Product
Datamax HSPA Ethernet Router with RS232 &
wifi.
Model
MA100-1010
Document Type
FDS
Current Version Number
1.1
Status of the Document
Public Release
Revision Date
July 2013
Total Number of Pages
-Revision History
Level
Date
History
1.0
October 2011
Internal Release Version
1.1
July 2013
Release Version

Page - 8 -
I n t r o d u c t i o n
MA100-1010 is a HSUPA Ethernet router providing data communications
via the public cellular network.
The MA100-1010 utilises an industrial 32-bit CPU embedded with a real
time operating system. The device supports RS232 connection, four
Ethernet ports and wifi that conveniently and transparently connect one
device to a cellular network, allowing you to connect to your existing
serial and Ethernet devices with minimal configuration.
The MA100-1010 has been widely used within M2M applications, such as
intelligent transportation, smart grid, industrial automation and telemetry.
Features and Benefits
Design for Industrial Application
Industrial cellular module EM770W
High-powered industrial 32bit CPU
Industrial GPS module
Supports low power consumption mode, including sleep mode.
Metal housing.
Voltage range:5~35VDC
Auto recovery functionality, including online detection, and auto
redial.
Ethernet port: 1.5KV magnetic isolation protection
RS232: 15KV ESD protection
SIM port: 15KV ESD protection

Page - 9 -
Power port 2.5mm Barrel connector: reverse-voltage and
overvoltage protection
Antenna port SMA Female
Supports IP Stack Auto mode
IP / web based user interface for remote management,
maintenance and configuration.
Standard and Convenience
Supports standard RS232, Ethernet ports and Wi-Fi.
Supports standard WAN port and PPPOE protocol that can
connect to ADSL directly
Supports intellectual mode, establishes communication state
automatically when powered on
Provide management software for remote management
Convenient configuration and maintenance interface (WEB or CLI)
High-performance
Supports double link backup between two cellular networks
Supports triple link backup among cellular, cellular and
WAN(PPPOE, ADSL)
Supports VPN client(PPTP, L2TP, IPSEC and GRE)
Supports port mirror function
Supports WIFI AP, WIFI AP client and WDS
Supports multi online trigger ways, including SMS, ring and data.
Support slink disconnection when timeout
Supports APN/VPDN
Supports wireless video monitoring and dynamic picture transfer
Supports DHCP server and client, DDNS, firewall, NAT, DMZ host,
etc.
Supports TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP,
SNMP protocols
Router chart is as follows

Page - 10 -
Embedded processing
`system
Power
RS232
Indicator
lights
DATA Interface
User interface
4 ports
switch
WIFI
AP
10/100M
WAN
Cellular
Module

Page - 11 -
S p e c i f i c a t i o n s
Cellular Specification
Standard and Band
Bandwidth
TX
power
RX
sensitivity
MA100-1010 GPS+WCDMA ROUTER
UMTS/WCDMA/HSDPA/
HSUPA
850/1900/2100MHz,
850/900/1900/2100MHz
GSM850/900/1800/1900
MHz
GPRS/EDGE CLASS 12
HSUPA: 5.76Mbps
(Upload speed)
HSDPA: 7.2Mbps
(Download speed)
UMTS: 384Kbps
(DL/UL)
<24dBm
<-109dBm
WIFI Specifications
Standard
IEEE802.11b/g
IEEE802.11n (optional)
Bandwidth
IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 300Mbps (max)
Security
WEP, WPA, WPA2, etc.
WPS (optional)
TX power
16-17dBm(11g), 18-20dBm(11b)
RX sensitivity
<-72dBm@54Mpbs
Hardware System
CPU
Industrial 32bit CPU
FLASH
4MB(Extendable to 16MB)
SDRAM
32MB(Extendable to 64MB)
Interface Type
Ethernet
1x 10/100 Mbps Ethernet port(RJ45), auto MDI/MDIX,
1.5KV magnetic isolation protection
LAN
4 10/100 Mbps Ethernet ports(RJ45), auto MDI/MDIX,
1.5KV magnetic isolation protection
Serial
1 RS232 port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5, 2
Parity: none, even, odd, space, mark
Baud rate: 110~230400 bps
Indicator
"Power", "System", "Online", "GPS", " Local Network ",
"WAN", "WLAN"

Page - 12 -
Antenna
Cellular: 2 x Standard SMA female interface, 50 ohm,
WIFI: Standard SMA female interface, 50 ohm,
SIM
2 x Standard 3V/1.8V user card interface with 15KV
ESD protection
Power
Standard 3-PIN power jack, reverse-voltage and
overvoltage protection, 2.5mm barrel connector
Reset
Restores the router to its original factory default
settings
Power Input
Standard Power
DC 12V/1.5A
Voltage Range
DC 5~35V
Current
Consumption
Minimum current: 450mA (12VDC)
Maximum Current: 600mA (12VDC)
* The product needs to be supplied by a limited
power source or the power supply provided.
Otherwise, safety will not be ensured
Physical Characteristics
Housing
Metal
Dimensions
206x135x28 mm
Weight
805g
Environmental Limits
Operating Temperature
-25~+60ºC
Extended Operating Temperature
-30~+75ºC
Storage Temperature
-40~+85ºC
Operating Humidity
95% (Non condensing)

Page - 13 -
Dimension: (unit: mm)

Page - 14 -
I n s t a l l a t i o n I n t r o d u c t i o n
Accessories List
Name
Quantity
Router
1
Cellular Antenna
1
GPS Antenna
1
WIFI Antenna
1
Network cable
1
Serial cable
1
Power Lead
1
Stator
2
SIM card Installation
Power off the router, and press the eject button next to the SIM card tray
with a small sharp object. Upon doing so the SIM card tray will eject from
the face of the modem. Place the SIM card into the SIM card tray
(Ensure that the side of the SIM card with the metal connection points is
facing upwards), and then insert the SIM card tray back into the SIM
card outlet.
Antenna Installation
Attach the SMA male connector of the cellular antenna into the female
SMA interface on the router labeled “Antenna”.
Attach the SMA male connector of the WIFI antenna into the female
SMA interface on the router labeled “WIFI”.
The router supports an RS232 interface and a 10/100M Ethernet interface.
These two interfaces both utilize an RJ45 connector, with the RS232
interface labeled “Console” and the 10/100M Ethernet interface labeled
“ETH”.
Plug the RJ45 end of the serial cable into the RJ45 outlet of the router
labeled “console”, and plug the DB9F end of the serial cable into the
RS232 serial interface of the user’s device.

Page - 15 -
The pin out connections of the serial cable are as follows:
RJ45
DB9F
1
8
2
6
3
2
4
1
5
5
6
3
7
4
8
7
The signal definition of the DB9F serial communication interface is as
follows:
Power
The input supply voltage range is 5~35VDC. We recommend using the
standard DC 12VDC/1.5A power adaptor available from Maxon.
Indicator Lights
The router has five indicator lights and operates as follows:
Indicator
Light
State
Status Description
Power
ON
Router is powered on
OFF
Router is powered off
System
BLINK
System is up
OFF
System is down
Pin
RS232 signal
Direction
1
DCD
output
2
RXD
output
3
TXD
input
4
DTR
input
5
GND
6
DSR
output
7
RTS
input
8
CTS
output

Page - 16 -
Online-1
ON
The main link has logged onto the
network
OFF
The main link hasn’t logged onto the
network
GPS
ON
GPS is active
OFF
GPS is not active
Local
Network
1-4
OFF
The corresponding interface is not
connected
ON /
BLINK
The corresponding interface is
connected /Communicating
WAN
OFF
The WAN interface is not connected
ON /
BLINK
The WAN interface of is connected
/Communicating
WLAN
OFF
WLAN is not active
ON
WLAN is active
Reset Button
The modems “Reset” button is used to restore the modem to its
original factory default settings. To restore the router to factory default
settings, the user needs to press the “Reset” button and hold it in for 15s,
after which, the router will restore its original factory default settings and
restart automatically.

Page - 17 -
C o n f i g u r a t i o n a n d M a n a g e m e n t
Datamax is configured via a web interface. In order to access the
Datamax web interface you will need a computer with a spare Ethernet
LAN port. The LAN card configuration should have the Internet Protocol
TCP/IP set to obtain an IP Address automatically and obtain DNS server
address automatically.
To check these settings go to your LAN adaptor properties and check
your Interment Protocol TCP/IP settings, it should look as follows:
Connection Steps:
1. Connect the Ethernet cable supplied with your router to your
computer Ethernet LAN port
2. Your computer will get an IP address from the Datamax DHCP
range automatically.

Page - 18 -
3. In your web browser type 192.168.1.1 in the Address (URL) field (The
Default IP Address of the Ethernet port is 192.168.1.1). The router will
prompt you for login credentials the default username and
password are both “admin”.
WAN Settings
This page is used to configure the Internet access parameters
User Name
Username provided by the ISP
Password
Password provided by the ISP
Call Center
Telephone number to dial default *99#
APN Name
Select APN Name provided by the ISP is
Network
Select
Auto, GSM only and WCDMA only
Pin Verify
Enable
Enabling and entering the PIN no. will
disable the PIN code
WAN NAT
Enable/Disable

Page - 19 -
Internet IP Address
By default, the Internet IP Address of the router is allocated by the ISP
automatically. Should your connection require a static IP address you
can set the address if the ISP supports this feature.
Domain Name Server (DNS) Address
Normally, the Domain Name Server (DNS) Address of the router is
allocated by the ISP automatically. You can also use your own DNS
address.
If you want to use your own DNS, please make sure that the DNS address
is accessible.
Keep Online Detection
This function is used to detect whether the Internet connection is active.
Once enabled and the router detects that the connection is inactive, it
will redial automatically to re-establish a data connection.
Detection Method:
None
Detection is disabled
Ping
The router will send an ICMP packet to the primary

Page - 20 -
server, if it fails it will try the secondary detection server,
if the router does not receive ICMP response it will try to
reconnect to the network.
Route
Using the route method, the router will use a trace route
method for detecting the connection status by trying to
reach the primary and secondary detection servers.
PPP
Detects data connection status. With this method, the
router will monitor the PPP connection layer status.
Detection
Interval
Is the time interval between status checks, the value is
represented in seconds
Primary
Detection
Server IP
Is the address of the server used to respond to the
router’s detection packets. This item is only valid for
"Ping" and "Route" methods
Backup
Detection
Server IP
Is the address of the secondary server used to respond
to the router’s detection packets. This item is only valid
for "Ping" and "Route" methods
Note: with “Route” or “Ping” detection methods, it is quite important to
make sure that the “Primary Detection Server IP” and “Backup Detection
Server IP” are reachable, as they have to respond to the router.
