MAXSTAR INSTA MIX PB-01 User manual

PERSONAL BLENDER
INSTA MIX
MAXSTAR APPLIANCE LIMITED
1/7, West Patel Nagar, Opposite Pillar No. - 205, New Delhi - 110008
Tel: [phone]; e-mail: [e-mail]; Website: www.maxstar.in
USER MANUAL
Please read this book carefully before using this appliance.

1. BPA Free Tritan Bottle
2.Blade Cap with stainless steel blades
3.Pulse Button
4. 350W Motor Base
5. Secure Screw On Lid x 2
6. Additional BPA FREE Tritan Bottle
Note: there are rubber seals located under the screw-on lids and inside the blade capto
Prevent leakage. if these seals become loose and come out ,pls wash them in warm soapy
Water, rinse and then dry thoroughly ,please place them correctly backinto the screw-on lids
Or blade cap before using the Smoothie Maker. please contact After –Sales Support by using
The contact detail provided at the bottom of this page if further instructions are required .
Improtant safety instructions
When using el ectrical appliances, to reduce the risk of personal injury or damage to
Property, basic safety precautions must be observed, including the following:
Read carefully and save all instructions provided withthis appliance.
Always turn the power off at the power outlet before you insert or removethe plug
Remove by grasping the plug-do not pull on the cord.
This appliance is not intended for use by persons (including children )with reduced
Physcal , sensory or mental capabilities ,or lack of experience and knowledge,unless
They have been given supervision or instruction concerning the use of the appliance
By a person responsible for their safety.
Only connect the appliance to a power outlet of the same voltage (AC only) as that
Maked on the rating plate of the appliance.
Do not use your appliance with an extension cord unless this cord has been checked
And tested by a qualifled technician or service person.
To protect against risk of electric shock, do not immerse the cord, plug or base in water
Or any other liquid.
Never leave the appliance unattended whilein use.
Close supervision is necessary when any appliance is used by or near children.
Turn the power off and unplug from the power outlet when not in using , before putting
On or taking off parts, or before cleaning .
Do not use the appliance for any purpose other than itsintended use.
Do not place the appliance on or near flammable or hot objects.
Avoid contact with moving parts .
Do not operate any electrical appliance ifthe power cord is damaged or after the
Appliance has been dropped or damaged in any way .if damage is suspected .
Contact after –sales support .
Do not operate appliance with hands .
Do not palce hot or boiling liquids into the smoothie maker, all liquids should be at
Roomtemperature or cooler before placing into the bottle.
do not use outdoors.
do not let the power cord of appliance hang over the edge of a table or bench
Or touch any hot surfaces.
some appliances are sealed using tamperproof screws to avoid tampering /maintenance
By unskilled or unqualified persons and also for safety reasons.
Do not attenpt to repair ,disassemble or modify the appliance.
Do not use chemical ,steel wool or abrasive cleaners to cleanthe appliance.
Ascraper may be used ,however this can only be used when the smoothie maker is not running.
Blades are sharp.habdle carefully.
Never cover the appliance when it isin operation.
This appliance isintended for processing small quantities of food for immediate
Consumption ,this appliance is not inteded to prepate large quantities of food at
On time
To reduce the risk of injury ,never place the blade cap on the motor base without
Frist properly attaching the bottle.
The screw-on lid needs to be firmly screwed onto the bottle or there may be a risk
Of leakage.
Do not attempt totamper withthe cover interlock ,mechanism.
This appliance is for household, indoor use only.
Only use the appliance for domestic purpose .
This appliance should be used intermittently, do not allow the smoothie maker to
Run when it is empty or become overloaded.
Ashort power supply cord is provided to reduce the risk of becoming entangled or
Tripped over, which may occur with a long cord.
WARNING: the blade is very sharp,caution should be taken when cleaning and
Disassembling the smoothie maker.
The ingredients that are put inthe blending cup should not exceed 600ml.
Always operate the product on a flat, level, stable surface.

Do not submerge the unit in water or other liquids as this may cause electrical
Failure and damage tothe electrical components.
Do not place carbonated drinks into the smoothie maker as this may cause damage
To the bottle,blade cap and motor base.
Do not place any parts of the smoothie maker into a microwave.
Only place the bottle, drinking lid and blade capinthe top basket of a dishwasher
And run the dishwasher on a cool , gentle cycle only.
Do not place the motor base in a dishwasher.
WARNING : Do not over-tighteenthe blade cao onto the bottle. Over-tightening of the blade
Cap may cause damage tothe smoothie maker and will make the bottle difficult to remove
WARNING
To reduce the risk of electric shock , do not immerse or expose the products ,
Flexble cord or plug to rain, moisture or any liquid.
Do not use the product near baths, basins or other vessels containing water
Or other liquids, or when standing is or on damp or wet surfaces.
In the event that the appliance is dropped into water ,turn off the power at
The power outlet and removethe plug immediately.
DO NOT REACH INTO THE WATER TO RETRIEVE IT UNTIL IT HAS BEEN
DISSCONNECTED FROM THE POWER OUTLET.
It isimportant to note that the appliance will have to be inspected by a qualified
Technician before using it again
Instructions
Getting started
ensure the bottleis not filled with food or liquids past the maximum capactitylevel
Marking ,do not operate the smoothie maker when it is empty.
ensure close supervision when being used around chlidren
it is reommended to have all ingredients prepared before switching on the smoothie
Maker .
do not palce hot or boiling liquids into the smoothie maker, all liquids should be at
Roomtemperature or cooler before palcing into the bottle.
do not place carbonated drinksinto the smoothie maker as this may cause damage
To the bottle,blade cap and motor base.
Using the Smoothie Maker
1. palce the sommthie maker base onto a flat stable surface .
2. using the recipes provided (see page 11 or 12) or your own ,place the ingredients into
the sommthie maker ,ensure any solidingredients such as fruit or vegetables are
cute into small poeces ni larger than 2cm., it is recommended that any solidingredients are
added before adding liquid ,be careful not to fill past MAX line
3. once ingredients have been put in, screw the blade cap (2) on to bottle withthe
blade facing into the bottle,to lock,twist the blade cap (2) anti-cockwise, ensure not to
over-tighten the cap (fle.1)
WARNING: do not over –tighten the blade cap (2) onto the bottle. Over-tightening of
The blade cap may cause damage to the smoothie maker and will make the bottle diffcult to
remove
.
4. once the blade cap(2) is screwed into place,turn the bottle upside down and again
the arrow on the blade cap(2) with the arrow on the motor base (4). Twist bottle anti-clock
wise tolock into place (Flg.2)
5. plug the smoothie maker into a standard 220-240volt AC electrical outlet and turn
the power on at the wall stocket ,a blue light will illuminate around the pulse button 3
6. hold down the pulse button(3) for 30 second intervals, or until youringredients reach
the desired consistency . pulsing for 1 minute requires 2 minute rest period alternatively
once you have aligned the arrow on the blade cap(2) withthe arrow on the motor base(4)
press the bottle (1) down and hold down the pulse botton (3) to active blending.
7. when all ingredients are combined ,release the pulse button (3) on the until and turn
the smoothie maker off at the power outlet ,removethe bottle(1)from the motor base
(4) by turning it clockwise and tipit upside down, unscrew the blade cao(2) and set it
Aside ,(Flg.3)
8. to convent the smoothie maker bottle (1) to an on-the –go –bottle. Simply attachthe
included lid(5) and screw on totighten.your smoothie maker is now ready to drink but
is also portable and cantaken anywhere (Flg.4)

Note:if ingredients become stuck around the blade during pulsing ,unlock the bottle from
The notor base,shake it gently to dislodge the ingredients, then lock it back into the base
Before continuing pilsing
Crushing Ice
The smoothie maker can be used to crush small amounts of ice (2 to 3 cubes at atime).
Always add a small amount of liquid into the smoothie maker along withthe ice before
Pressing the pulse button, the liquid can be water or milk or one of the other liquids
Mentioned inthe recipes on page 11 and 12.
Cleaning and Maintenance
ensure that the unit it turned off and unplugged before attempting to cleanthe unit .
blades are sharp-handle with carel
some foods may discolour the plastic,this is perfectly normal and won’t harm the
Plastic or affect the flavour of the food .the discolouration may be removed with
vegetable oil
wash the blade cap.lid and bottles in warm soapy water.there parts are dishwasher
safe. As long as they are placed in the top basket and the dishwasher is run on a
cool. gentle cycle.
rinse well. Ensure that all parts are dried thoroughly before storing .
do not immerse the base unit,power cord or mains plug in water or any other liquids.
If cleaning of the base unit is required ,use a damp cloth an drt well.
NOTE: there are rubber seals located under the screw-on lids. And inside the blade capto
Prevent leakage.ifthese seals become loose and come out , please wash them in warm
Soapy water, rinse and then dry thoroughly, please palce them correctly backinto the
Screw –on lids or blade cap before using the smoothie maker, please contact After Sleas
Sipport by using the contact detail provided at the bottom of this page if further instructions
are required
Quick Cleaning Guide
fill the bottle half way with warm tap water and a drop of detergent.
screw the blade cap onto the bottle withthe blade facing into into the bottle
twist the cap anti-clockwise. Ensure not to over –tighten the cap.
once the motor base. Twist the bottle anti clock-wise to secure into place.
press and hold the pulse button for 10 seconds
removethe bottle, unscrew the blade cap and rinse both under running water.
dry thoroughkly before using again.
Recipes
Combine all ingredients as per “using the smoothie maker “(pge6), if one of the recipes
below is too thick for your liking just add additional liquid, but only add to the max level.
All measurements below should only be used as a guide,
Go Green Smoothie
250 grams spinachleaves
1 pear, cored and chopped into 1cm cubes
20 green or red graps
125 grams greek yoghurt
Mixed Berry Smoothie
250 grams mixed berries (either fresh or frozen)
125 grams plain or greek yoghurt
add enough soy milk,almond milk or
Skmmed milkto flii the bottletothe max level
honey totaste

1 tbsp peanut butter
250 grams spinach
1 banana, peeled and choppen into 1cm cubes
5 strawberries, chopped into 1cm cubes
add enough soy milk , almond milk or skimmed milkto fill the bottletothe max level
sprinkle cinnanmon on top to serve
Tropical Smoothie
pulp of 3passion fruits or 125 grams tinned passion fruit pulp
1 banana, peeled and chopped into 1cm cubes
1 smal mango,peeled and chopped into 1cm cubes
add enough orange juice to fill the bottletothe max level
serve with ice cubes and a mint leaf
Envrionment Friendly Disposal
Correct disposal of this product
This Wheeled Bin symbol indicates that this procucts should
Not be disposed of with other household wastes, to prevent
Possible harm tothe environment or human health from
Uncontrolled waste disposal, recycle it responsibly to promote
The sustainable recycling of material resources. Contact your
Local authortity for recycling failities in your area.
SPECIFICATIONS
TYPE PB-01
RATED VOLTAGE230 V
RATED FREQUENCY 50Hz
RATED POWER 350W

PERSONAL BLENDER
RATING : 230V,50 HZ
POWER : 350W
INSTA MIX
WARRANTY CARD

Please preserve the Warranty Card and Cash Memo and ensure that they are duly stamped and signed by the Company’s dealer.
The Warranty Card or a Cash Memo which is not stamped and signed by the dealer will be treated as invalid.
Max Star product that you have bought is of excellent quality and construction. However we \will correct, free of charge any defects in
material or workmanship for a period of one year* (the Warranty period) from date of purchase subject to the terms and conditions.
TERMS & CONDITIONS OF WARRANTY
1. Max Star products are warrantied solely against poor workmanship, manufacturing defect and use of faulty material only.
Consequential liabilities will not be entertained. All Max Star products are designed for domestic usage only.
2. In the event of a replacement of spares during the warranty period, this warranty card will be required along with the original tax
invoice/ Cash Memo to process the claim. The Company will not entertain a claim with incomplete warranty details.
3. This warranty is confined to the first purchaser of the product only & is not transferable.
4. Repair or replacement of spares will be carried out through the Company’s Authorized Service Centre or its Authorized Dealers.
5. Repairs during warranty period shall be carried on “Carry In” basis, wherein, for services, the purchaser shall bring the product to the
Company’s Authorized Service Center / Authorized Dealer for warranty service along with Tax Invoice / Cash Memo and Warranty
Card. The warranty does not cover cost of transportation of product from the customer’s place to the Company’s Authorized Service
Centre/ Authorized dealer. However, in case the customer located beyond the municipal limits of the jurisdiction of the Company’s
Authorized Service / Authorized Dealers, wishes the Company / its Authorized Service Center/ Authorized Dealer to collect the
product from his place for the purpose of servicing the product then all expenses incurred in collection and delivery back of the
product, as well as the expenses incurred in connection with deputing of service personnel / technicians towards to and for travel,
conveyance and other incidentals etc. will be borne by the customer.
6. In the event of repairs / replacement of any part/s of the product, this warranty will be thereafter continue and remain in force only for
the unexpired period of the warranty. Moreover, the time taken for repair/ replacement and in transit whether under the warranty or
otherwise shall not be excluded from the warranty period. The customer shall have to pay a visit charge towards inspection, as
applicable.
7. The Company / its Authorized Service Centre/ Authorized Dealer, reserves the right to retain any parts or component/s replaced at
its/their discretion in the event of a defect noticed in the equipment during the warranty period. The company shall have exclusive
right to replace the defective / unserviceable part/s or component/s with the part/s or component/s which may be new or refurbished.
8. The warranty does not cover accessories external to the product.
9. The warranty does not cover demonstration/installation of the product purchased.
10. In the event of any unforeseen circumstance, and spares not being available, the Company’s prevailing depreciation rules will be
binding onthe purchaser to accept as a commercial solution in lieu of repairs.
11. The warranty is issued at Delhi and Courts at Delhi shall have exclusive jurisdiction over matters covered or flowing from this
warranty.
12. The Company’s obligation under this warranty shall be limited to repairing or providing replacement of parts, which are found to be
defective.
13. In the event of repairs/replacement of specific parts on which warranty is more is more than product warranty, the specific parts will
be repaired /replaced free of the cost but customer needs to pay service charges in such cases.
THIS WARRANTY IS NOT APPLICABLE IN ANY OF THE FOLLOWING CASES:
1. The warranty card is not duly filled by the selling dealer.
2. The completed warranty card is not presented to the service personnel at the time of repair.
3. The product is not purchased from an Authorized MAX STAR dealer.
4. The product is not installed, used and maintained according to instruction given in the instruction manual.
5. Defect cause by improper use as determined by the company personnel.
6. Installation/ repair work is carried out by persons/agency other than Authorized by the company.
7. Defects have been caused by reasons beyond control of the Company, like act of God, during transit to Service Centre or
purchaser’s residence, poor maintenance, damage to the product caused by insects/ rodents.
8. The warranty does not apply to :
a. Surface coating, body aesthetics, plastic parts, neon lamps, bake light part, rubber/neon parts, cord wire, push button & bulb and
dursable parts viz. shaft, bush etc.
b. Normal wear and tears of parts.
c. Damages resulting from accidents, mishandling, improper use or negligence on the part of customer and fluctuation in supply
voltage.
d. Damages resulting due to usage of power supply other than specified 230 Volts AC 50 Hz. e.g. inverters, generator etc.
e. For humming noise generated due to usage of electronic fan regulators of any make.
f. Breakage of glass parts.
g. Heating tubes/rods for failure or breakage.
MAXSTAR APPLIANCE LIMITED
1/7, West Patel Nagar, Opposite Pillar No. - 205, New Delhi - 110008
Tel: [phone]; e-mail: [e-mail]; Website: www.maxstar.in
WA R R A NT Y
(As per terms and conditions overleaf)
Name of Purchaser :
Address : Phone No. Residence :
Office : Product Sl. No.: Date Of Purchase :
Customer’s Signature Dealer’s Stamp & Signature
