Maxtor MTC40 Series User manual

We reserves the right to improve the product's appearance, size and technology without prior notice.
All products sizes and colors are subject to the actual product
INSTALLATION MANUAL
MTC40 series

2 3
Preparation before installation
PRECAUTIONS
All vanities must be installed by a fully qualified plumber.
Vanities and tops must be installed onto finished surfaces.
It is imperative that all bathroom installations are ventilated to meet standards.
Failure to provide ventilation that meets these standards will void the
manufacturer's warranty.
It is important that the product is unpacked and inspected for any damage,
defects, and that the product supplied is correct. If any of the above is
apparent, Do not proceed with this installation and contact the water
bath immediately.
TOOLS REQUIRED FOR INSTALLATION
Electric/Battery Drill
Kitchen & Bathroom
Non-Acidic Silicone
Φ10mm & Φ6mm
Drill Bit
SCREW (x10) WALL PLUG (x10) WIRE CONNECTOR (x4)
Tape Measure (3m-5m)
Pencil
Spirit Level
Screw Driver Hammer
Installation of dierent walls
WOODEN WALL PREPARATION
SOLID WALL
[720mm]
Suggested
Height
Make sure the vanity and LED mirror (or Medicine cabinet) be mounted on the reinforcement plate.
[50x100mm]
Wood
Reinforcement
[50x200mm]
Wood
Reinforcement
[720mm]
Suggested Height
for counter top
[350mm]
Suggested Height
[350mm]
Suggested
Height
[25x100mm]
Wood
reinforcement
[50x200mm]
Wood
reinforcement
[720mm]
Suggested Height
for counter top

4 5
Specication & Installation Guide
Recommended Wall VanityMounting Height
[350mm]
[720mm]
IMPORTANT! Make sure that the reinforcemente holds your bathroom cabinet securely
before installing it.
STEP 2 STEP 3
Wall positioning perforation & Wall plug. Tighten the screws,adjust level.
M6 PA screws Screws cushion
Φ10mm Drill Bit
STEP 1
Locate cabinet & mark location
CABINET INSTALLATION
Suggested
Height
[720mm]

6 7
STEP 4 STEP 5
Adjust level. Twist screw cover.
STEP 6 STEP 7
Intall the basin and glue.
ELECTRIC CONNECTIONS
ALL WIRING SHOULD BE DONE BY A QUALIFIED LICENCED ELECTRICIAN
WARNING: Shut o power before wiring the mirror.
WARNING: An Electrical option mirror must be wired to a 20 Amp
GFl(Ground Fault Interrupter) protected circuit when used in bathrooms
andall other locations required by the National Electric Code.
WARNING: This mirror must be connected to a grounded, metalpermanent
wiring system or an equipment-grounding conductor must berun with the
circuit conductors and connected to the equipment groundingterminal or
lead on the mirror.
CAUTION: Requires 120 VAC 20 Amp GFl protected circuit.
Electric wiring: Be sure to provide enough
wire to make the proper and safe
connection to the Field/Power.
• 5mm copper free silver mirror
• Hiah output LED lighting:
• CRI 9O+,2700-640OK CCT,IP44
• Colour changing and dimmable touch
• switch for surface LED
• Vertical and horizontal mount options
• Defogger
MIRROR FEATURES
* Wire terminal plate is not included.

8 9
STEP 1 STEP 2
STEP 3 STEP 4
Placment Support location
Install screws Placement
MIRROR MOUNT
Select the desired position of the mirror.
Level and mark the location.
Measure the center of the holes and mark the
drilling locations ensure marking are leveled.
Place the mirror against the wall and slide
down as shown in image.
Using a drill,make holes and fill with supplied
plugsand screws.Leave a gap of 2 - 3mm
between thehead of the screw and the wall.
Φ6mm Drill Bit
M4 PA screws
[350mm]
STEP 1
STEP 3
STEP 5
STEP 2
STEP 4
STEP 6
Remove the mounting hardware from
themounting pipe.
Clean and wipe the countertop and check if it is
level.
Slide rubber washer,metal washer and
mounting bracket onto the thread shank.
Put the rubber O-ring into the bottom gap oaucets
then Insert faucet into faucet hole.
Adjust position of faucet body if necessary,
Then tighten the mounting nuts with phillips
screwdriver until snug.
Connect and tighten the supply hoses by using
twoadjustable wrenches ,Turnon the angle
valve and check for leaks.
FAUCET INSTALLATION
For first time install, flush the pipes first byopen the angel valve to run 60s.

10 11
STEP 1
lnstall Pop-up Waste
with over ow
POP-UP WASTE INSTALLATION
STEP 2
Connect the drain pipe
DRAWER ASSEMBLY
Removal with Locking Device
Lay the drawer bottom onto the
slide then push thedrawer into
the cabinet.
Drawer up & down
adjustment:0~+3mm.
For removal, hold the handle and pull out the drawer.

12 13
HINGE ADJUSTMENT AND REMOVAL INSTRUCTION
PIVOT-PRO side adjustment
PIVOT-PRO Depth Adjustment
PIVOT-PRO Height Adjustment
Side adjustment of the door is made by using the indicated screw.
Depth adjustment is made without loosening any screw.The door can be
moved in or outby rotating the cam adjuster on the hinge arm.
By loosening the two xing screws to allow the mounting plate to slide up or down
,the door can be adjusted vertically by ±2mm.After retightening the screws, the
depthadjustment is done.
Snap-on
cam-adjustable
DOOR INSTALL
DOOR REMOVE

14 15
TROUBLE SHOOTING
PLUMBING RECOMMENDATIONS
CLEANING & MAINTENANCE
What happens if my soft close drawer is not closing properly?
It means that your soft close drawer is not engaged correctly. Follow the instructions on page 03 to re-engage the
soft close mechanism.
Why is my soft close drawer making a noise on closing, and not closing smoothly?
If the release tabs on the drawer are not lifted properly, then this may cause the cog to strip on the soft close
mechanism. Please contact Bath Co Customer Services for a replacement. This is not covered under warranty.
What are the dimensions of the cabinets – internal and external?
All dimensions can be found on our website – www.aouasbath.com or in our brochures.
Can I get an extra tap hole in my vanity top?
Yes – most tops we can put an extra tap hole in. This can be done at an extra cost of $60.00+GST per tap hole.
How to cut out a sink hole in Kordura surfaces?
These hybrid solid surfaces hold colour throughout and can be easily cut or drilled with a router, jigsaw or holesaw
» Single drawer units are designed to be plumbed with a bottle trap.
» Waste is not to be over-tightened to avoid stress on basin or top.
» A Contoured waste complete with a washer set top and bottom must be used on all
basins so as not to void the warranty
» We do not recommend the use of silicone when installing the contoured waste.
» Basin overow must line up with waste opening.
» Waste overow hole opening must not be blocked by sealant.
» Basins with xing holes must be bolted back to the wall separately from the vanity unit.
» To maintain the nish on your unit and top, only use a soft cloth, or a weak solution of non-abrasive detergent.
Do not use cleaners that incorporate isopropyl alcohol. Polymarble tops should only be cleaned with soapy
water and a soft cloth.
Kordura Surfaces: Regular cleaning is recommended. Use soapy water and a soft cloth when cleaning surface.
Do not use product with high alkaline & ph levels. Contact Bath Co directly to provide guidelines to polish
scratched and heavy stains.
» To restore accidental scratches, burns etc. on gloss painted nishes, rub gently with a very light cutting
compound. On matt or timber nishes contact the manufacturer.
» Mirrors should be cleaned with diluted methylated spirits only (dilute 1:10).
Remove all moisture caused by splashes, wet hands, or steam with a chamois or soft cloth after use.
Do not wipe the exposed edge of the mirror.
» To avoid deterioration; it is important mirrors are kept dry of any moisture.
» Bath Co warranty on mirrors applies for one year from the date of purchase
Cleaning and Warranty
General Cleaning
Aquas Bath products are made from materials or sourced specically for bathroom and laundry spaces. Our
vanities and cabinetry are designed to be water resistant, not waterproof. Care must be taken to immediately
dry spillage as well as ventilate your bathroom to eliminate moisture build up or humidity which will lead to
deterioration of materials and is not covered by warranty.
For all surfaces use a soft cloth and a weak solution of a non-abrasive detergent. Do not use cleaners with
isopropyl alcohol, high alkaline, acidic or any abrasive based cleaners. A moist microbre cloth will give the best
results.
Cabinetry Finishes
Timber Veneer & Painted To clean
Aquas Bath timber veneer surfaces simply use a soft cloth and a weak olution of a non-abrasive detergent. Do not
use cleaners with isopropyl alcohol, high alkaline, acidic or any abrasive based cleaners.
Melamine
Melamine is low maintenance and easy to clean. Simply wipe down with a clean, damp cloth. With stubborn
grease and grime, use vinegar diluted with water or Selleys Sugar Soap. Always wipe with a damp cloth, then a
dry cloth after cleaning to remove moisture. Never use abrasive cleaners, cleaners with isopropyl alcohol, high
alkaline, acidic or any abrasive based cleaners.
Basins & Counter Top Vessels
Ceramic/Acrylic/Polymarble
Ceramic basin, just use water or clean soap to wipe with water is ok.
To clean acrylic surfaces use non-abrasive soap, It is recommended that the product surface is wiped dry after
each use to prevent the build up of soap and scum.
Polymarble
Mirrors
Keep your bathroom well ventilated to avoid condensation that can gather at the edges of your mirror. Always
protect from excessive moisture and ensure any moisture or condensation is wiped away immediately.
Wipe your mirrors with a slightly moist microbre cloth and then dry with a dry microbre cloth.
DO NOT use any ammonia-based cleaning products (including glass cleaners), as these could corrode the mirror’s
silver backing.
Warranty
Aquas Bath products carry a ve (5) year warranty from the date of purchase. Proof of
purchase needs to be supplied by the purchaser when making a claim.
Aquas Bath warrants that in the manufacture of its products only high-quality workmanship
and materials have been used. If within the warranty period there should be a fault with either
materials or workmanship Plumbline will either (at its sole discretion) repair or replace the
faulty product, but will not be responsible for removal and installation costs.
IMPORTANT NOTE: Under no circumstances are tile vanity cabinets and/or tops ‘into’ the wall.
Aquas Bath vanity cabinets & tops must be tted to nished wall coverings. The Warranty does not cover any vanity
and/or top that has been tiled ‘into’ a wall i.e., tting or xing a vanity to a wall and tiling into the side and around it,
and/or tiling down and/or around the vanity top.
This warranty does not cover damage by improper installation, abuse, accident, excessive wear, and tear, improper
care and maintenance, natural causes (sunlight and water), water temperatures above 55°C, humidity, and over
environmental conditions.
