Maytag MDB4621AWB - Full Console Dishwasher User manual

FRAME AND CONSOLE PARTS
1
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
2−07 Litho In U.S.A. (ebk) Part No. W10121819 Rev. A
UNDERCOUNTER
DISHWASHER
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8535436 Instructions,
Installation
3367007 Instructions,
Installation
(Supplement)
(Locating Your
Water Supply)
W10102584 Guide, Use & Care
8535431 Tech Sheet
English/French
W10102582 Guide, Energy
3
W10039780 Control,
Electronic
4 3376359 Fuse, Thermal
6 Console
(Includes Insert
& Active Overlay)
W10102617 Black
W10102618 White
W10102619 Stainless
8 Door Frame
9743028 Black
9 3380854 Bolt, Latch
10 Lever, Latch
3380778 Black
3380779 White
11 3369325 Switch, (2)
12 3368955 Pin, Switch (2)
13 8573190 Harness and
Protector
14 3376405 Elbow, Harness
15 3400892 Screw
16 8051304 Cover, Timer
17 3374501 Motor, Dual
19 Panel, Front
3379375 Black
3379376 White
22 3379358 Spring, Door Catch
23 3379357 Catch, Door
26 3373234 Bearing,
Spring (2)

INNER DOOR PARTS
2
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3371435 Door, Inner
(Includes Items
2 & 3)
2 3376066 Latch, Detergent
Dispenser
(Includes Item 3)
3 3369061 Snap, Detergent
Dispenser
(Includes Item 2)
4 3369505 Actuator Assembly
5 8052028 Wet Agent,
Dispenser
6 3379673 Seal, Door Vent
7 3369448 Draw Bar,
Electronic
8 3368999 Spring (Draw
Bar)
9 3378138 Lid Assembly
10 8066018 Spring, Lid
11 3372028 Pin (Lid Hinge)
12 3371710 Screen, Vent
13 3378134 Cap, Wet Agent
15 3400815 Screw (8)
16 3371569 Cover, Drip
19 3379674 Vent Assembly
(Includes Item 6)
20 8271325 Absorber, Sound

TUB ASSEMBLY PARTS
3
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819

TUB ASSEMBLY PARTS
4
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10082658 Tub Assembly
2 8528831 Tub, Wheel
Assembly (8)
3 3368933 Runner (2)
4 3374849 Leveler (2)
5 3370389 Screw,
Shoulder (2)
6 302819 Wheel (2)
7 343641 Screw,
10−16 x 1/2 (4)
8 3378149 Plate, Latch
9 3374720 Screw
10 3376927 Gasket
11 8573061 Strain Relief
12 8528862 Deflector (2)
13 8519830 Heater
(Includes Item 14)
14 717273 Washer, Rubber (2)
15 8268548 Nut (2)
(Heater Terminal)
16 8283345 Water Valve
17 304392 Screw, 8−18 x 1/2
18 661566 Thermostat,
Hi−Limit
20 301958 Clamp
23 3400935 Clip
25 304231 Screw, 8−18 x 1/2
28 3379383 Spring, Door (2)
29 8318218 Housing, Float
Switch
30 3369067 Switch, Float
31 8318219 Cover, Switch
Housing
32 8519587 Float & Washer
Assembly
33 717488 Nut
34 Panel, Toe
(Includes Item 26)
3368942 Black
9742861 White
8054181 Biscuit
35 Panel, Access
3379387 Black
3379388 White
9743560 Stainless
36 302868 Screw,
8−18 x 1/2 (4)
37 3369414 Hose, Inlet
40 8573243 Sound Shield, Tub
41 8573951 Terminal Box
42 300068 Cover Assembly,
Terminal Box
50 3378595 Bracket,
Thermostat
53 3379740 Support, Heater
54 3400014 Screw
55 3378128 Washer
57 3369138 Screw, 8−18
61 8052018 Friction Pad
62 3369816 Miscellaneous
Parts Bag
(Includes 2 Screws
& 2 Hose Clamps)

PUMP AND MOTOR PARTS
Note: The Pump Gasket
Must Be Replaced Anytime
The Pump Assembly Is
Removed And Reinstalled
In The Dishwasher.
Pump Centering Tool Required
For Pump Re−Assembling
Order Item 31.
5
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819

PUMP AND MOTOR PARTS
6
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9740982 Plate, Perforated
(Includes Item 5)
(Also Order
Item 30)
See Note A.
2 3367173 Base, Inlet
(Includes Items
1 & 5)
(Also Order
Item 30)
See Note A.
3 9741232 Screw, 8−18 x 5/8
4 302710 Seal, Inlet Base
5 302709 Ball, Check
6 95080 "O" Ring
7 719929 Ball, Check
9 3384593 Filter Assembly
(Includes Items
12, 13 & 22)
See Note A.
10 3400001 Screw
11 3378176 Impeller, Wash
(Includes Items
12 & 13)
12 3371152 Screw & Seal
10−32 x 3/4
13 302711 Seal, Pump Outlet
14 3376844 Outlet, Pump
(Includes Item 13)
15 3369482 Check Valve
(Includes Item 6)
16 661633 Gasket, Pump
17 8283498 Pump & Motor
Assembly
(Includes Item 16)
19 3378175 Chopper Kit
(Also Order
Item 30)
See Note A.
22 302704 Seal, Drain Cover
23 3376845 Cover, Drain
(Also Order
Item 30)
See Note A.
24 8274950 Impeller,
Drain Kit
(Also Order
Item 30)
See Note A.
25 3376157 Base, Pump
(Also Order
ITEM 30)
See Note A.
26 3367197 Support, Pump
Mounting (4)
27 3368270 Slinger
(See Note A.
28 8534971 Motor & Fan
Assembly
(Includes Item 27)
(Also Order
Item 30)
See Note A.
29 8281183 Screw (4)
30 675505 Pump Seal Kit
(Includes Items
4, 12, 13 & 22)
31 303918 Tool, Pump
Centering
32 356138 Clamp, Hose
33 3374077 Hose, Drain
34 3371748 Cap, Drain
37 3378083 Thermister
38 3376723 Seal, O−Ring
39 3376358 Retainer,
Thermostat
40 9740674 Gasket, Drain
Cover
NOTE A:
Pump Centering Tool Required
For Pump Re−Assembling
Order Item 31.

UPPER DISHRACK AND WATER FEED PARTS
7
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819
Illus. Part
No. No. DESCRIPTION
1 8268838 Support, Arm
(Also Order
Items 2 & 8)
2 303722 Clip
3 8268829 Spray Arm, Upper
(Also Order Item 8)
4 3385142 Bumper (2)
5 8268862 Tower, Pressure
6 8268645 Wheel & Transport
Assembly (4)
7 8539208 Dishrack, Lower
8 8268871 Support Lock,
Spray Arm
9 8539107 Basket, Silverware
10 8539093 Lid, Basket
11 3376846 Seal, Lower
Sprayarm
12 3385089 Track
13 8565920 Stop, Track (4)
14 8562003 Basket, Small
Item
17 8268848 Wheel Assembly
18 8539222 Dishrack, Upper
22 8268874 Sprayarm, Lower
23 3367910 Cap, Nozzle
24 719576 Bearing, Nozzle

OPTIONAL PARTS (NOT INCLUDED)
8
For Models: MDB4621AWB0, MDB4621AWW0, MDB4621AWS0
(Black) (White) (Stainless)
W10121819
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
ACCESSORIES
Side Panel Kits
4378867 White
4378868 Black
675788 Biscuit
4378869 Almond
Custom Trim & Panel Kits
675775 Black
675776 White
675809 Biscuit
Moisture Barrier Kit
4396277 Kit
Drain Hose
3385556 12 Ft.
Heavy Duty Spring Kit
4318050 Spring
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392899 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
285006 Superior Black
4392901 Biscuit
PAINT, TOUCH−UP (1 qt.)
799344 White (Uncut)
4392900 Biscuit
POWER CORD KIT
4317824 Power Cord Kit
(Includes Power
Cord & Misc.
Hardware)
ANTI−TIP KIT
4378968 Floor Mounting Kit
DISHRACK REPAIR
Tip Tine Repair Kit
(Enough for Two
Complete Dishracks)
4396838 White
4396840 Grey
4396854 Silver Atlantis
Vinyl Touch−Up (4 oz.)
676453 White
676455 Grey
4396853 Silver Atlantis
