Maytag MDB8951AWB - Jetclean II Series Fully Integrated... Manual

Repair
Parts
List
MODEL NUMBER
MDB8951AWB
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DISHWASHER
©2005 Maytag Services

Section: CONTROL PANEL & DOOR
DW12-88
Model: MDB8951AWB
1

CONTROL PANEL & DOOR
No. Part No. Description
Section:
Series Qty
- 99003097 PLATE, TOWEL BAR BACK 10 2
1 99003452 TOWEL BAR (BLACK) 10 1
- 99003154 SCREW-TRUSS HEAD 1/4-20 T20 Note: SCREW, TOWEL BAR 10 2
1 99003456 END CAP, HANDLE (SILVER) 10 2
2 99003090 PANEL, DECORATOR (BLK) Note: (ALSO ORDER 99003049) 10 1
3 99003093 PAD, FOAM 10 1
- 99002934 DAMPER (6"X 18") 10 1
4 99003094 SUPPORT, INNER DOOR (BLK) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, CONTROL PANEL 10 3
5 99003394 PANEL, CONTROL (BLK) 10 1
- 99003096 FASTENER, PANEL 10 2
- 99003096 FASTENER, PANEL 10 2
6 99003095 ANCHOR, PANEL FASTENER 10 2
- 99003049 WRAP, FOAM 10 2
7 99002930 BRACKET, HINGE (RT) Note: (NEED TO ORDER 99003049 & 99003051 WHEN REPLACING THIS
PART) 10 1
- 99001075 SCREW Note: SCREW, BRACKET 10 4
7 99002929 BRACKET, HINGE (LT) Note: (NEED TO ORDER 99003049 & 99003051 WHEN REPLACING THIS
PART) 10 1
- 99003046 BLOCK, FOAM (LT) 10 1
8 99003047 BLOCK, FOAM (RT) 10 1
9 99003048 BARRIER, FOAM 10 1
10 99003347 LATCH ASSEMBLY 10 1
- 99002751 SWITCH, DOOR 10 2
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 2
11 99002576 HOUSING, BOARD (BASE) 10 1
12 99003432 BOARD, CONTROL 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 1
13 99002575 HOUSING, BOARD (TOP) 10 1
14 99003044 INSULATION, DOOR 10 1
15 99003140 DOOR, INNER (W/DAMPER) 10 1
- Y912620 SCREW Note: SCREW, INNER DOOR 10 8
16 99003045 SEAL, DOOR (BTM) 10 1
- 99002270 SEAL, BASE 10 1
17 99003317 RINSE AID/DETERGENT DISPENSER 10 1
- 99003060 KNOB, RINSE AID (W/O-RING) 10 1
18 99002465 BRACKET, DISPENSER 10 2
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, BRACKET 10 6
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: RAIL & RACK ASSEMBLY
DW15-146
Model: MDB8951AWB
3

RAIL & RACK ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99003462 RACK ASSEMBLY (UPPR) 10 1
- 99003459 HANDLE, RACK (FRONT HALF) 10 1
- 99003460 HANDLE, RACK (BACK HALF) 10 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
- 99003069 CAGE, BALL BEARING 10 2
- 99003281 STOP, RAIL (GRAY) 10 4
2 99003066 RAIL, INNER SLIDE 10 2
- 99003068 BEARING, BALL 10 8
3 99002696 CLIP, CUP (BLUE) 10 2
4 99003485 TINE, FOLDING (DK GREY) 10 2
- 99002709 PIVOT, FOLD AWAY TINE 10 2
5 99003484 CLIP, FOLDING TINE (BLUE) 10 1
- 99003053 GUARD, RACK (LOW SIDE) 10 1
6 99003052 GUARD, RACK (HIGH SIDE) 10 1
7 99003011 COVER, RACK ADJUSTER (GRAY) 10 2
8 99003178 LEVER, ADJUSTER (BLUE) 10 2
9 99003199 RACK ADJUSTER ASSY (RT) 10 1
- 99003198 RACK ADJUSTER ASSY (LT) 10 1
- 99003010 SCREW (T15) 8-18 X .500 10 11
10 99003020 STABILIZER, RACK ADJUSTER 10 1
11 99002671 SHELF, CUP (UPR) 10 1
12 99002679 WASH MANIFOLD ASSY (UPR) 10 1
13 99002624 ARM, WASH (UPR) 10 1
14 99002670 CLIP, UPR WASH MANIFOLD (BACK) 10 1
15 99002669 CLIP, UPR WASH MANIFOLD (FRT) 10 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
16 99003494 RACK ASSEMBLY (LWR) DK GRAY 10 1
17 99003495 SHELF, CUP (HI SIDE) 10 1
18 99003149 WHEEL ASSEMBLY (LWR) 10 8
19 99003497 TINES, CONVERTABLE (REAR) 10 1
20 99003527 CLIP, ADJUSTABLE TINE (BLUE) 10 1
21 99003496 TINES, CONVERTABLE (FRT) 10 1
22 99002687 PIVOT, CONVERTIBLE TINE (BLUE) 10 2
- 99002697 COVER, SPLIT/FIT BASKET 10 2
23 99002683 SPLIT/FIT BSKT ASSY 10 1
- 99002684 BASKET, SILVERWARE (HALF) 10 2
24 99003117 BASKET, AUXILLARY 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-117
Model: MDB8951AWB
5

TUB
No. Part No. Description
Section:
Series Qty
1 99002629 BRACKET, WATER VALVE 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
2 99002975 VALVE, WATER 10 1
- 99002553 SCREW-#8X7/16 HEX WASHER HEAD Note: SCREW, WATER VALVE 10 2
3 911856 CLAMP, SPRING 10 2
4 99002852 HOSE, INJECTOR 10 1
5 99003028 INLET, AIR/WATER 10 1
6 99002150 SEAL, AIR/WATER INLET 10 1
7 99003029 GRILL, AIR/WATER INLET 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
8 99002636 BRACKET, SUPPORT (LT) 10 1
9 99003038 TRIM, CORNER EDGE (LWR-LT) 10 1
- 99003039 TRIM, CORNER EDGE (LWR-RT) 10 1
10 99003337 SEAL, DOOR 10 1
11 99002648 BRACKET, CABINET MOUNTING 10 2
12 99003152 FRT SUPPORT W/SOUND BOX (BLK) 10 1
- 912366 SCREW --++*** Note: SCREW, SUPPORT (BLK) 10 2
- 99003130 SEAL, SOUND TRAY (BLK) 10 1
- 99002640 FASTENER, INSULATION 10 2
13 99003127 INSULATION, TUB 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
14 99002610 BRACKET, SPRING ADJUSTMENT 10 2
15 99003118 SPRING, DOOR 10 2
16 99003446 DOOR CABLE ASSEMBLY 10 2
- 912366 SCREW --++*** Note: SCREW, PANEL (BLK) 10 2
17 99002765 PANEL, TOE (W/DAMPER-BLK) 10 1
- 99003087 BRACKET, REAR SUPPORT 10 1
- 99002694 SOUND SEAL, TOE PANEL (BLK) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
18 99002607 BRACKET, CABLE 10 2
19 99002609 SHOULDER BOLT, CABLE BRACKET 10 2
20 99002608 ROLLER, CABLE BRACKET 10 2
21 99002635 LEG, LEVELING 10 4
22 99002927 SUPPORT, HINGE (RT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, SUPPORT 10 4
22 99002928 SUPPORT, HINGE (LT) 10 1
23 99003150 BACKER, HINGE SEAL (RT) 10 1
- 99003151 BACKER, HINGE SEAL (LT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
24 99002637 BRACKET, JUNCTION BOX SUPPORT 10 1
25 99002638 COVER, JUNCTION BOX 10 1
- 912365 SCREW Note: SCREW, COVER 10 1
26 99003079 COVER, SWITCH 10 1
27 99002631 SWITCH, FLOAT 10 1
28 99003031 HOLDER, FLOAT SWITCH 10 1
29 99003040 SEAL, STANDPIPE 10 1
30 99003037 STANDPIPE, FLOAT 10 1
31 99002630 FLOAT 10 1
32 99002633 THERMOSTAT, LIMITING 10 1
33 99001008 CLIP, THERMOSTAT 10 1
34 99003041 TRIM, TUB EDGE (BTM) 10 1
- 99002973 GASKET, HEATER 10 1
35 99002971 HEATER (W/GASKET) 10 1
36 99003033 NUT, HEATER 10 2
- 99002692 SCREW, TRIM MOUNTING Note: SCREW, TRIM STRIP 10 4
37 99003128 STRIP, TRIM (LT) 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-117
Model: MDB8951AWB
7

TUB
No. Part No. Description
Section:
Series Qty
38 99003036 STRIP, TRIM (TOP) 10 1
- 99002692 SCREW, TRIM MOUNTING Note: SCREW, TRIM STRIP 10 4
39 99003129 STRIP, TRIM (RT) 10 1
40 99002701 GAP SEAL, TOE KICK (BLK) 10 2
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WATER DISTRIBUTION ASSEMBLY
DW14-78
Model: MDB8951AWB
9

WATER DISTRIBUTION ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99002642 MANIFOLD, MAIN 10 1
2 99002674 STATION, DOCKING (W/FLAPPER) 10 1
3 99002676 WASH ARM, TOP (W/RETAINER) 10 1
4 99002753 RETAINER, TOP WASH ARM 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: PUMP & MOTOR
DW14-80
Model: MDB8951AWB
11

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99002654 CAP, WASH ARM 10 1
2 99002678 WASH ARM, LOWER (W/SHIELDS) 10 1
3 99002653 SHIELD, RADIANT 10 2
- 99002666 SCREW Note: SCREW, GUARD 10 3
4 99002979 GUARD, FILTER (GRAY) 10 1
- 99002664 SCREW, DISCHARGE HOUSING 10 6
5 99002677 DISCHARGE HOUSING ASSY (UPR) 10 1
6 99002659 WASH IMPELLER ASSEMBLY 10 1
- 99002987 SCREW, IMPELLER 10 1
7 99003291 ASSY., FILTER/FLOWPLATE 10 1
- 99002668 SCREW, STAINLESS PAN HEAD Note: SCREW, FILTER/FLOWPLATE 10 3
8 99003427 CHOPPER 10 1
9 99003341 SEAL KIT, METAL CHOPPER SLEEVE 10 1
10 99003055 GASKET, MOTOR MOUNT 10 1
11 99003056 LEVER, MOTOR MOUNT 10 3
12 99003057 PLUNGER, MOTOR MOUNT 10 3
13 99002651 O-RING, TURBIDITY SENSOR 10 1
- 33002917 SCREW, #10-16 Note: SCREW, SENSOR 10 2
14 99002650 SENSOR, TURBIDITY 10 1
15 99003436 WASH MOTOR ASY (SEAL NOT INCL) 10 1
- 99002815 FLAPPER, DRAIN PUMP VALVE 10 1
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, DRAIN PUMP 10 3
16 99003141 DRAIN PUMP ASSEMBLY 10 1
17 99003309 FLAPPER, DRAIN PUMP INLET 10 1
18 99002857 O-RING, DRAIN PUMP 10 1
- 99003440 SHIELD, CAPACITOR 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, CAPACITOR 10 1
19 99002665 CAPACITOR, MOTOR 10 1
20 99002652 HOSE, DRAIN 10 1
- 99002656 CLAMP, DRAIN HOSE (1-3/8") 10 1
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

SUPPLEMENTAL INFORMATION
No. Part No. Description
Section:
Series Qty
- 6919559 MANUAL, USE & CARE 10 1
- Y6920186 MANUAL, USE & CARE 30 1
- 16026394 TECH SHT,DISHWASHER 10 1
- 16022783 MANUAL, SERVICE DW 10 1
- 99003349 GUIDE, ENERGY (REV C) 10 1
- 99002854 MISC. PARTS PACKAGE 10 1
- 99003308 HARNESS, WIRE 10 1
13
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15003743
Model: MDB8951AWB
14
