Maytag JDB4000AW User manual

Service
This manual is to be used by qualified appliance
technicians only. Maytag does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
16021814
Revison0
August2002
Jetclean II™
Dishwashers
Basemanualcoversgeneralinfomation.
Refertoindividual TechnicalSheetfor
informationonspecific models.
Thismanualincludes,butisnotlimitedto
thefollowing: JDB4000AW
MDB5600AW
MDB6600AW
MDB7600AW
MDB8600AW
MDB9600AW
MDBF550AW
MDBF750AW
MDBH950AW
MDBH970AW
MDBL540AW
MDBL740AW

216021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Important Information
Prideand workmanshipgo intoevery product to provideour customers with qualityproducts.It is possible, however,
that during its lifetime a product may require service. Products should be serviced only by a qualified service
technician who is familiar with the safety procedures required in the repair and who is equipped with the proper tools,
parts, testing instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE
APPROPRIATE SERVICE MANUAL BEFORE BEGINNING REPAIRS.
Important Notices for Consumers and Servicers
Toavoid risk ofserious injury or death,repairsshould not be attemptedby unauthorized persons, dangerous
conditions (such as exposure to electrical shock) may result.
Maytagwill notbe responsible forany injury orproperty damage fromimproper serviceprocedures. If performing
serviceon your own product, assumeresponsibility for any personal injuryor property damage which mayresult.
Recognize Safety Symbols, Words, and Labels
DANGER—Immediate hazards which WILL result in severe personal injury or death.
WARNING—HazardsorunsafepracticeswhichCOULDresultinseverepersonalinjuryordeath.
CAUTION—Hazardsor unsafepractices which COULDresultin minorpersonal injuryor productor property
damage.
To locate anauthorizedservicer, pleaseconsult your telephone book orthe dealer from whomyou purchased this
product. For further assistance please contact:
Customer Service Support Center
CAIRCenter
Web Site Telephone Number
WWW.AMANA.COM........................................................................... 1-800-843-0304
WWW.JENNAIR.COM......................................................................... 1-800-536-6247
WWW.MAYTAG.COM ......................................................................... 1-800-688-9900
CAIR Center in Canada ...................................................................... 1-800-688-2002
Amana Canada Product ...................................................................... 1-866-587-2002
WARNIN
G
!
CAUTIO
N
!
DANGER
!
WARNING
!
CAUTION
!

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 3
Table of Contents
Will Not Start or Program.................................... 4-18
Will Not Fill......................................................... 4-18
Will Not Wash ....................................................4-19
Will Not Drain ..................................................... 4-19
Will Not Dry ........................................................ 4-19
ManualFunctionTest ......................................... 4-19
FieldServiceTest ............................................... 4-19
Section5. Service and DisassemblyProcedures
FrontSupport andToe PanelRemoval ................ 5-20
InnerDoorPanelRemoval................................... 5-21
Detergent / RinseAid Disp..................................5-21
Wax Motor Detergent / RinseAid Disp................5-22
Vent .................................................................... 5-22
WireCover ..........................................................5-22
Door Latch & Switch HolderAssembly................5-23
PCBoard............................................................ 5-24
TechnicalSheet .................................................. 5-24
ControlPanel...................................................... 5-24
DoorLatch Strike ................................................ 5-24
DoorGasket .......................................................5-25
OuterDoor ..........................................................5-25
DoorHingeAnd Support .....................................5-26
DoorSpring......................................................... 5-26
DoorSpringAndComponent Replacement..........5-27
OverPressure Filter ............................................ 5-27
Top WashArm .................................................... 5-27
Manifold .............................................................. 5-28
DockingStation .................................................. 5-28
LowerWashArm ................................................ 5-28
Float ...................................................................5-29
HeatingElement .................................................5-30
Thermostats .......................................................5-31
WaterValve ........................................................ 5-31
Air Water Inlet ....................................................5-32
UpperRackRemoval .......................................... 5-33
TubWheels ........................................................ 5-33
TurbiditySensor.................................................. 5-33
DrainPump ........................................................ 5-34
Wash Motor Assembly ....................................... 5-34
AppendixA
InstallationInstructions ....................................... A-2
AppendixB
Jenn-AirUser’s Guide ......................................... B-2
AppendixC
MDB-3User’s Guide...........................................B-2
ImportantInformation
ImportantNotices forConsumers andServicers .... 2
Recognize Safety Symbols, Words, and Labels ... 2
Section1. ImportantSafety Information
GeneralInformation...............................................1-4
RelatedPublications .............................................1-4
GeneralPrecautions andWarnings.......................1-4
ProductWarning Labels
JunctionBox Warning...........................................1-5
SupportPanel Warning.........................................1-5
ControlCoverWarning ..........................................1-6
Section 2. Electrical Equipment & Testing
Electrical Test Equipment .....................................2-7
ApplianceTestMeter ............................................2-7
ContinuityTesting .................................................2-7
Digital Test Meter..................................................2-7
VoltageChecks ..............................................2-8
MotorTest Cord ....................................................2-8
GroundingPolarity ................................................2-8
Electrical Tests
WaterValve ..........................................................2-9
Detergent / RinseAid Disp Wax Mtr Check ..........2-9
Vent Wax Motor Check....................................... 2-10
Section 3. Cycles & Options
Cycles ................................................................ 3-11
Options............................................................... 3-12
Display ............................................................... 3-13
Control Style by Model........................................ 3-14
Control Style by Model........................................ 3-15
Section4. TroubleShooting
Will Not Fill......................................................... 4-16
Overflows ............................................................ 4-16
PoorWater Circulation........................................ 4-16
PoorWashability ................................................ 4-17
Will Not Drain ..................................................... 4-17
Continuesto Drain .............................................. 4-17
PoorDrying ........................................................ 4-17
Water Leaks ....................................................... 4-18
Noise .................................................................. 4-18
AppendixD
MDB-4User’s Guide...........................................D-2

1-4 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Important Safety Information
WARNING
!
To avoid personal injury or death from improper
servicing, make sure you read and understand the
descriptions and meaning of various safety symbols,
words and labels used in this manual, before
attempting any procedures described in the manual.
Failure to understand and comply with safety
information may result in severe personal injury or
death.
General Information
This Service Manual describes the operation,
disassembly,troubleshooting, and repairof Maytag®
Dishwashers.It is intended for useby authorized
servicer’swho troubleshoot andrepair these units.
NOTE: It is assumed that users of this manual are
familiar with the use of tools and equipment used
totroubleshoot and repairelectrical, and
mechanical systems; and understand the
terminology used to describe and discuss them.
Related Publications
This is a base service manual, covering a range of
similar models. It is intended to be used in conjunction
with the Parts Manual and Technical Sheet covering
specific model being serviced.
General Precautions and Warnings
•Disposeof discarded appliance and shipping or
packing material properly.
•Do not allow children to play in or on dishwasher.
•Do not abuse, sit, stand or play on door or racks of a
dishwasher.
•Useonly detergents and rinse agents recommendedfor
useina dishwasher.
•Store dishwasherdetergent and rinse agents out of the
reachof children.
•Ifthedishwasher drains into a food disposer, make
suredisposeris completely empty before running
dishwasher.
•Repairsshouldbe done by a qualified technician.
•Do not tamper with controls.
•Donottouch the heating element during or immediately
afteruse.
•Load sharp knives with the handles up to reduce the
risk of cut-type injuries or damaging seal.
To avoid risk of personal injury or death due to
electrical shock:
•Groundingwires andwires colored likegrounding
wires are NOT to be used as current carrying
conductors.
•Standardacceptedcolor coding forground wires
is green or green with a yellow stripe.
•Groundingwires shouldnot beremoved from
individualcomponents whileservicing, unless
componentis to beremoved and replaced.
•Replaceallremoved groundingwires before
completingservice.
WARNING
!
To avoid death, severe personal injury, fire or
electrical shock when using dishwasher observe
the following:
• Observe all local codes and ordinances.
•Disconnectelectrical powerto dishwasher before
servicing.
•Connectdishwasher to agrounded metal,
permanentwiring system.
•DONOT ground to gasline.
•DO NOT ground to cold water pipe if pipe is
interrupted by plastic, non-metallic gaskets, or
otherinsulating (non-conducting)materials.
•Check with a qualified electrician if you are not
surethis appliance isproperly grounded.
•Thisdishwasher is designedto operate on
regular house current (120 V, 60 Hz). Use a
circuit equipped with a 15 ampere fuse or circuit
breaker.Use a 20ampere fuse if dishwasheris
connectedwith a food wastedisposer.
•Undercertain conditions, hydrogen gasmay be
produced in a hot water system that has not
beenused for 2weeks or more.HYDROGEN
GAS IS EXPLOSIVE. If hot water system has
notbeen used for sucha period, before using
dishwasher, turn on all hot water faucets and let
waterflow from eachfor severalminutes. This will
releaseany accumulated hydrogengas.
HYDROGEN GAS IS FLAMMABLE. Do not
smoke or use an open flame during this time.
•Do not store or use combustible materials,
gasolineor otherflammable vapors andliquids in
the vicinity of this or any other appliance.
•Do not wash plastic items unless marked
"dishwashersafe" or theequivalent. Ifnot
marked,check with manufacturerfor
recommendations.Items that arenot dishwasher
safe may melt and create a potential fire hazard.
•Toavoidentrapment and/orsuffocation,remove
dooror door latch mechanismfrom any
dishwasher that is discarded or not in use.
WARNING
!

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 1-5
Important Safety Information
PRECAUCIÓN
:
Desconecte la
energía eléctrica
antes de darie
servicio.
ATENCIÓN:
Solamente use
conductores de
cobre. Use cables d
e
suministro adecuado
s
para 75° (167°F).
CAUTION: Disconnect electrical power
before servicing.
ATTENTION: Use copper conductors only.
Use supply wires suitable for 75°C (167°F).
ATTENTION: Débrancher de
l'alimentation électrique avant tout dépannage
.
ATTENTION: Utiliser des conducteurs en
cuivre uniquement. Utiliser des fils
d'alimentation pouvant supporter une
température de 75°C (167°F).
GROUNDING: This unit must
be grounded in accordance with local
and/or national electric codes.
WARNING: The heating
element, drain pump, harness clip,
dispenser mount, and water valve are
intentionally not grounded and may
present a risk of electrical shock only
during servicing. Discharge motor
capacitior before servicing. Failure to
follow these instructions can result in
death, serious injury, fire, or electrical
shock.
MISE Á LA TERRE: Cet appareil
doit être relié à la terre conformément aux
codes électriques locaux et/ou nationaux.
AVERTISSEMENT: La résistance,
la pompe de vidange, l'attache du hamais, la
monture de distributeur et l'électrovanne ne
sont pas reliés à la terre intentionnellement et
peuvent présenter des risques d'électrocution
uniquement en casd'intervention de service
aprés-vente. Décharger le condensateur
avant toute intervention. Le non-respect de
ces consignes peut entrainer la mort, des
blessures graves, l'incendie ou l'électrocution.
CONEXIÓN A TIERRA: Esta
unidad debe estarconectada a tierra de
acuerdo con los códigos eléctricos locales y
nacionales.
ADVERTENCIA: El elemento calentador,
la bomba de drenado, el sujetador del arnés,
el montaje del surtidor y la válvula de
agua están sin conectara tierra
intencionalmente podrían presentar un riesgo
de descargas eléctricas cuando se les da
servicio solamente. El no seguir estas
instrucciones podría causar la muerte, lesione
s
graves, incendios o descargas eléctricas.

1-6 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
WARNING:
Disconnectpowerbeforeservicing.Electroniccontroliseergizedatalltimesuntil
powerisdisconnected.Capacitorsoncontrolmayremainactiveafterelectricalpowerisdisconnected.
Failuretofo llowtheseintructionscanresultindeath,seriousinjury,fire,orelectricalshock.
ADVERTENCIA:
Desconectelaenergíantesdedarleservicio.Elcontrolelectrónicoestá
energizadotodoeltiempohastaquesedesconectalaenergía.Loscapacitoresdelcontrolpodrían
permaneceractivosdespuésdedesconectarlaenergíaeléctrica.Elnoseguirestasinstrucciones
podrícausarlamuer
te,lesionesgraves,incendiosodescargaseléctricas.
AVERTISSEMENT:
Débrancheravanttoutein terventio n.Lacommandeélectroniqueest
constammentsoustensionàmoinsquel'appareilnesoitdébranché.Lescondensateursdela
commandepeuventrestersoustensionunefoisl'appareildébranché.Lenon-respectdecesconsignes
peutentraînerla mort,desblessuresgraves,l'incendieoul'électrocution.
Important Safety Information
WARNING: Disconnect power before servicing. Electronic control is energized at all times until
power is disconnected. Capacitors on control may remain active after electrical power is disconnected.
Failure to follow these instructions can result in death, serious injury, fire, or electrical shock.
ADVERTENCIA: Desconecte la energí antes de darle servicio. El control electrónico está
energizado todo el tiempo hasta que se desconecta la energía. Los capacitores del control podrían
permanecer activos después de desconectar la energía eléctrica. El no seguir estas instrucciones
podrí causar la muerte, lesiones graves, incendios o descargas eléctricas.
AVERTISSEMENT: Débrancher avant toute intervention. La commande électronique est
constamment sous tension à moins que l'appareil ne soit débranché. Les condensateurs de la
commande peuvent rester sous tension une fois l'appareil débranché. Le non-respect de ces consignes
peut entraîner la mort, des blessures graves, l'incendie ou l' électrocution.

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 2-7
Section 2. Electrical Equipment & Testing
Electrical Test Equipment
Theequipment requiredto servicethese models depends
largelyupon the condition encountered. Locatinga
malfunctionwill often require the useof electrical testing
equipment such as:
ApplianceTest Meter
Clamp-OnAmmeter
MotorTestCord
Appliance Test Meter
AnAppliance Test Meter is a multi-purpose tester
combininganAC/DC voltagetester with amulti-range
ohmmeter.
The easiest means of testing electrical components is
"Continuity Testing" with an appliance meter. Continuity
is a complete or continuous path from one point in an
electrical circuit to another.
Theobvious advantagesof being ableto check electrical
componentsand circuits without power applied isone of
thefeatures of the Ohmmeter. Multipleranges allow
accuratedetermination of resistances ofboth single
components and entire circuit paths. Resistance is
measuredin "Ohms."
To avoid risk of personal injury or death due to
electrical shock:
Alwaysbe sure the power has been disconnected
beforemaking resistance measurements. Failure to
do so will also result in damage to your meter!
Internalbatteries provideall thepower neededto
make resistance checks. They should be checked
at least once a year and replaced as needed.
Continuity Testing: is a process of eliminating electrical
componentsinvolved ina givenfunction ofthe appliance,
until the inoperative part is found. By reviewing the list of
possibleelectrical problems undera given condition,and
thenperforming appropriate continuitychecksof the parts
involved,you should be abletolocate the electrical
componentwhich isinoperative.
NOTE: When checking components or circuit paths for
continuity, external wiring should be disconnected to
eliminatefalse readings throughexternal paths. Isolate
what you want to test.
Digital Test Meter
can be used to check for open
or closed circuits, measure
resistance,AC and DC volts,
andtemperature.
Analog Test Meter
can be used to check for
open or closed circuits,
measureresistance,AC and
DCvolts, andtemperature.
WARNING
!

2-8 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
VOLTAGE CHECKS
Generally, these checks will consist of taking readings
at the wall receptacle in order to determine the
availability of voltage to the product. Voltage checks on
individualcomponents ofa product arenot
recommended due to the possibility of electrical shock.
Componentpart testing is bestaccomplishedthrough
continuity checks with anAppliance Test Meter.
NOTE: Use of the meter on voltage higher than the
indicatedrange may cause permanentdamage to the
meter. To prevent damage, firstselect highest range and
thenlower the rangefor readings which fallwithin the
lowerscale.
Clamp-On Ammeter
can be used to detect shorts.
Overloadson thecircuit breaker
or fuse can be traced
toeither the appliance
or circuit breaker by
checking the current
draw.
Each circuit in an appliance has a "Normal" current
draw, which is an indicationof the performance of that
circuit. Current draw levels of less than or more than
normalgive clues to possible malfunctions. Theclamp-
onammeter measures these circuits withoutbreaking
the circuit by measuring the strength of the magnetic
fielddeveloped aroundeach conductor. Currentisread
by separating the conductors and clamping the jaws of
theammeter around each conductoronwhich current is
read. Lowamperage readings indicateproblems, such
asdamaged heating elements, etc. Highamperage
readingsindicate the unit beingtestedis operating under
anincreased mechanical or electrical load.
NOTE: Overloads on a circuit breaker or fuse can be
traced to the product being tested or the circuit breaker
(or fuse) by checking the products current draw. If the
amperagereading is less thanthe breaker reading,the
breaker or fuse box is at fault.
Use of Ammeter on dishwasher:
1. Motor Current - the reading can be taken at the
leads on the motor start relay or at the male connec-
tor.
2. Heating Element Current - The reading can be
taken using either lead to the element.
Motor Test Cord
A motor test cord may be used to electrically check
operationof thevarious electrical componentswithout
removing them from the unit. Testing in this manner
merelydetermines whether or notthe part will function
independentlyof other electrical components. Inorder to
make accurate tests, proper connection of the motor test
cord is important. With the aid of the drawings under
Drive MotorTest, installation of the motor test cord may
be done quickly and accurately.
Grounding and Polarity
Thereceptacle used forall Maytag products operatingon
120VAC must beproperly grounded andpolarized.
Thepower cord usedon the appliances shouldbe
equippedwith athree (3)prong polarizedgrounding plug
To avoid risk of personal injury or death due to
electrical shock:
•Disconnectelectrical powerto dishwasher before
servicing.
•Always plug test cord into a properly grounded
receptacle.
DANGER
!
To avoid risk of personal injury or death due to
electrical shock:
•Donot cut orremove the grounding prongfrom any
plug.
DANGER
!
•Alwaysmake connection to componentsbefore
plugging test cord into receptacle.
ELECTRICAL EQUIPMENT & TESTING

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 2-9
forprotection against shock hazardandshould be
pluggeddirectly intoa properly groundedand polarized
receptacle.
It is the responsibility of the person installing the
applianceto assure it isadequately grounded and
polarized at the point of installation, taking into
considerationlocal conditions and requirements. In
caseswhere only a two(2) prong receptacle is available,
it is the personal responsibility of the consumer to have it
replacedwith aproperly groundedthree (3)prong
receptacle. Allgrounding and wiring should bedone in
accordance with National, State, and Local codes. DO
NOT USE AN ADAPTER PLUG WITH THIS
APPLIANCE.
ELECTRICAL TESTS
To avoid risk of personal injury or death due to
electrical shock:
•Disconnectelectrical powerto dishwasher before
servicing.
•Always plug test cord into a properly grounded
receptacle.
•Alwaysmake connection to componentsbefore
plugging test cord into receptacle.
WATER VALVE TEST
TheWaterValvemay be checkedwithout removing it from
theDishwasher.
To check the Water Valve for operation, hook up the test
cordas follows:
Wax Motor Check
Detergent / Rinse Aid Dispenser
A single Wax Motor is used to activate both the release of
theDetergent Cup Coverand the rinseaid fromthe
reservoir.
To check the operationof the WaxMotor,removal from
theDispenser Retaineror Inner Dooris not necessary.
First, snap the Detergent Cup Door shut. Then, connect
a Power Test Cord across the two terminals of the Wax
Motor. Plug the Power Test Cord into a 120 VAC
receptacle. The plunger in the center of the Wax Motor
should "push out" and actuate the Dispenser in
approximately45-60 seconds. Removevoltage to the
Wax Motor and allow the plunger to retract into the Wax
Motor. Apply voltage to the Wax Motor again and observe
forproper liftingoftherinse aid plunger.
WARNING
!
Electrical Equipment & Testing

2-10 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Wax Motor Check- Vent
A single continuous duty wax motor is used to operate
thevent.
Connect a Power Test Cord across the two terminals of
the Wax Motor. Plug the Power Test Cord into a 120 VAC
receptacle.The pungershouldextend (pushout) and
force the Vent Flap tight against the vent opening in
approximately45-60 seconds.When power isremoved
from the Wax Motor, the plunger should retract along with
the Vent Flap, opening the vent.
WARNING
!
To avoid risk of personal injury or death due to
electrical shock:
•Disconnectelectrical powerto dishwasher before
servicing.
•Always plug test cord into a properly grounded
receptacle.
•Alwaysmake connection to componentsbefore
plugging test cord into receptacle.
Electrical Equipment & Testing

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 3-11
Section 3. Cycles & Options
Cycle Description
AutoClean Designed to auto select the number of fills and length of wash time based on soil level
of the dish load. Water usage ranges from 3 to 8 gallons.
HeavyWash Designed toprovide a longercycle for washingitemswith heavy
food soils. Water usage is 8 gallons.
NormalWash Designed to wash loads containing dishes with normal amounts of food soils.
Water usage ranges from 3 to 6 gallons.
Light Wash Designed to wash loads containing dishes that are lightly soiled. Water usage is 5
gallons.
Quick Wash Designed for light food soils. The cycle ends with a rinse and does not include drying.
Water usage is 4 gallons.
Rinse Only Rinses dishes being held until the dishwasher is full, and another
cycle is selected. This cycle helps reduce the potential for development of odors.
Water usage is 2 gallons.
SeeUser's Guide forspecific operation.
MDB9600Only
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
Coversall othermodels

3-12 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Option Description
ToughScrub™ This option adds fills, heat and/or wash time to the
ToughScrub Plus™ wash cycle.
Sanitize This option monitors cycles for sanitization.
Extra Rinse This option adds an extra rinse to the cycle which helps in hard water situations.
160° Wash This option raises temperature in the final rinse to 160° F.
HeatedDry This optionimproves drying resultsbyturning the heatingelement on and offduring
the dry portion of the cycle.
Delay Delays the start of the dishwasher based on user input.
ControlLock Lock's the control touch pads from unwanted usage. This option does not lock the
door.
MDB9600Only
SeeUser's Guide forspecific operation.
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Cycles & Options
Coversall othermodels

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 3-13
Display Description
Clean The "Clean" light illuminates at the end of the cycle and remains on until the door has
beenopen continuously for 30seconds.
Drying The "Drying" light illuminates until the cycle is complete.
Washing The "Wash" light illuminates through all the rinse and wash portions of the cycle.
HeatingDelay The "Heating Delay" light illuminates when the cycle is being extended to heat the
water.
Clean/Sanitized These two lights illuminate from the end of cycle until the next cycle is selected,
orthe door has been open continuously for 30 seconds.
Delay The "Delay" light will illuminate whenever a delay count down is in progress, or until
the "Delay" pad is pressed again.
MDB9600Only
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Cycles & Options
Coversall othermodels
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
QuietSeries300
START/
Cancel DELAY
1-9

3-14 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
MDB5600
Heavy
Wash Normal
Wash Light
Wash Rinse
Only START/
Cancel DELAY
2-4-6 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries 100 Sanitized
Washing
Drying Clean Options
Cycles
2
4
6
Heavy
Wash Normal
Wash Light
Wash Rinse
Only START/
Cancel DELAY
2-4-6 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
Sanitized
Washing
Drying Clean Options
Cycles
2
4
6
ENN-AIR
Heavy
Wash Normal
Wash Light
Wash Rinse
Only START/
Cancel DELAY
2-4-6 Sanitize
Extra
Rinse
Heated
Dry
3
QuietSeries 100 Sanitized
Washing
Drying Clean Options
Cycles
2
4
6
MDBH950
MDBF550
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
Washing
Drying Options
Cycles
DELAY
2-4-6
2
4
6
QuietSeries200 Sanitized
Clean
MDB6600
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
MDB7600
MDB8600
JDB4000
Cycles & Options

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 3-15
MDBH970
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough Extra
Rinse
Heated
Dry
3
QuietSeries200
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Scrub
Plus
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries200
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
MDBF750
Cycles & Options
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
QuietSeries300
START/
Cancel DELAY
1-9
MDB9600

4-16 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Section 4. Electrical-Mechanical
Troubleshooting
Will Not Fill
Water Access Valve
Checkto determine if the valve is turnedon and water is
availableto theDishwasher.Check waterpressure.
Circuit Breaker/Fuse
Checkfor tripped breakeror blown fuse.Reset or replace
as necessary.
Door Latch
Check door switches for continuity. With door switches
engaged,no continuity, replace switch.
Float
Check float position. If in the up position, check for
obstructionor disengagement from the FloatSwitchArm.
Float Switch
If the float is in the down position, check the switch for
continuity. If no continuity, replace the Float Switch.
Water Valve
Check Solenoid for continuity. No continuity, replace
Water Valve. Check Inlet Screen for restrictions. Clean
screen or replace Water Valve as necessary. (See section
5).
Wiring/Electrical Connections
Checkfor loose orfrayedwire terminal connections.
Checkfor broken wirewithin harness. Repair or replace
as necessary.
NOTE: Lowwater pressure can resultinfailure of the
Water Valve to close properly.
Float
Ensure that the Float isn't stuck in the down position.
Checkfor sediment buildup. Clean and/orreplace as
necessary.
Float Switch Actuator Lever
Check the actuator lever on the bracket. It must be able
to move freely. Repair or replace as necessary. (See
section 5).
Float Switch
Check Float Switch for continuity with the Float in the up
position. If continuity is present and Float moves up and
downfreely, replace Float Switch.
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000 ohmresistor before attempting toservice, unless test proceduresrequire power to be
connected.Ensure all groundwires are connectedbefore certifying unitas repairedand/oroperational.
CAUTION
!
Units covered in this manual are polarized. Reversing polarity of a unit or any of its components will cause
damage.To avoid reversing polarity, any wires disconnected orremoved during service must bereconnected to the
samelocation. To ensurewires are reconnected to the properlocation, tagor otherwise mark thewires before
disconnectingorremoving.
POOR WATER CIRCULATION
Water Level - Too Low
Normalwater fill should beat level depicted byarrows.
PumpAssembly
Checkassembly for obstructions orrestricted movement
of parts. Repair and/or replace parts as necessary.
Overflows
Water Valve
Checkthat water continues toflowwhen electrical power
is turned off. If the water continues to flow without
electricalpower, replaceWaterValve.

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 4-17
Filters
Checkfor blockageofStrainer,Over Pressure Filter.
Repairas necessary.
Poor Washability
Spray Arms
Check all Spray Arms for blockage of water ports or
cracks.Check for properrack loading toavoid interference
withSprayArms during washaction. Check for proper
sealing,fastening, andmovement of SprayArms.Repair
as necessary.
Filters
Checkfor blockage of Strainer, Primary Filter, andFilter
Support.Repairas necessary.
Detergent Cup Cover
Checkspringhingeoperationof DetergentCup Cover.
Repairas necessary.
Detergent Cup
Check operation of Detergent CupAssembly, Wax Motor,
Actuator,Linkage, and CoverLatch. Repairand/orreplace
parts as necessary. Note: For testing of Wax Motor, see
Section 2.
RinseDispenser
Checklevel of rinseaid in reservoir.Check rinse aid
dispensersetting.
Will Not Drain
Inadequate Drainage
CheckDrain Pumpforproper operation.Check the drain
pipeconnections and repairasneeded. If draininginto the
garbagedisposal, check forunprocessedfood waste at
drainhose connection to disposer. Cleanout as needed.
Drain Hose
Check drain hose for kink or restrictions. Reroute or
removeany restriction ofdrain hose asneeded.
PumpAssembly
Check pump assembly for obstructions or restricted
parts. Repair or replace parts as necessary.
Wiring/Electrical Connections
Checkfor loose orfrayedwire terminal connections.
Checkfor broken wirewithin harness. Repair or replace
as necessary.
Electrical-Mechanical Troubleshooting
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000 ohmresistor before attempting toservice, unless test proceduresrequire power to be
connected.Ensure all groundwires are connectedbefore certifying unitas repairedand/oroperational.
Continues To Drain
Control Board
CheckControl Boardfor properoperation.
Wash Delivery System
Checkmanifold and Docking Stationforgood seal and no
leaks.
Poor Drying
Water Temperature
Checkfor low watertemperature. Temperature shouldbe
between120 -150degrees Fahrenheit. Ifnot, advise
consumertoadjust water heater setting. Encourage
consumerto purge water linesto the dishwasher area
priorto starting the dishwasher.
CycleOptions
Adviseconsumer useof optionsavailable on dishwasher
thatimprove drying. Options thatimprove drying are
Heated Dry, and 160° Wash.
Detergent
Checkwater hardness. Instruct consumer ondetergent
usage,one teaspoonof detergent pergrain of water
hardness.
RinseDispenser
Checklevel of rinseaid in reservoir.Check dispenser
settingunder cap. Use "MAX"forhard water conditions.
Improper Rack Loading
Check how the consumer loads the dishes into the racks.
Improperloading of some typesof dishes can trap water
which causes dishes not to dry.
Heating Element
Check load readings listed on Technical Sheet located
behindToe Panel.

4-18 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Thermostat
Check mating surface of the High Limit Thermostat face
to surface of tub enclosure. Contact area must be flat.
Adjust the thermostat placement if necessary. See
Technical Sheet, locatedbehindToe Panel forthermostat
data.
Water Leaks
Installation
CheckDishwasher forproper levelingand squarenessin
cabinet.
Door Alignment
Checkproper alignment ofDoor Liner to DoorGasket.
Door Gasket
Checkfor torn ordamaged Door Gasket.Repair or
replace as necessary.
Hoses
Check for loose hose clamps or hoses that leak. Tighten
hose clamps or replace hoses as needed.
Spray Arms / Manifold
Check for cracks and replace as necessary.
Detergent / Rinse Aid Dispenser Seal
CheckRinseAid Dispenser Sealfor proper positioning or
cracking.Reposition or replace asneeded.
Water Valve
CheckWater Valvebody for damage andleaks. Replace if
necessary. Also, check plumbing connections to Water
Valve.
Wash Motor Assembly
Check for water leak between PumpAssembly and tub.
Drain Pump Assembly
Check PumpAssembly Housing for cracks. Check Drain
Pump "O" ring for leaks.
Electrical Mechanical Troubleshooting
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000 ohmresistor before attempting toservice, unless test proceduresrequire power to be
connected.Ensure all groundwires are connectedbefore certifying unitas repairedand/oroperational.
Noise
Banging
Checkfor loose SprayArms.Check for dishes interfering
withSprayArm rotation.See loadinginformation in the
User's Guide at the end of this manual.
Hammering/Chattering
CheckWater Valve for,noise, lowvoltage,or highvalve
coil resistance. Replace Water Valve if needed. Also,
check incoming water supply line for proper size and
pressure. Make sure the supply line is secured.
Grinding
Check for objects in PumpAssembly. If objects are
found, inspect PumpAssembly for damage. Repair as
needed.
Vibration
Checkcomponentsfor source of vibration. Adjustand/or
tightenas needed.
Will Not Start Or Program
Control Board
Checkincoming voltagetoControl Board.
Membrane Switch
Checkfor properoperation of MembraneSwitch. See
membranereadings on theTechnical Sheet located
behindtoe panel.
NOTE: Makesure the pin connectors aremaking proper
contact with pins on the Control Board. If the
voltageiscorrect into the Control Board, and the
boardwill not activate,replace board.
Will Not Fill
Water Valve
Check Water Valve circuit. See Technical Sheet for water
valvedata locatedbehind toepanel.
NOTE: Makesure the pin connectors aremaking proper
contact with pins on the Control Board.

©2002 Maytag Appliance Sales Company 16021814 Rev. 0 4-19
Will Not Wash
Wash Motor
Check Wash Motor circuit. See data listed on the
Technical Sheet, locatedbehind toe panel.
Electrical Mechanical Troubleshooting
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000 ohmresistor before attempting toservice, unless test proceduresrequire power to be
connected.Ensure all groundwires are connectedbefore certifying unitas repairedand/oroperational.
Will Not Drain
Drain Motor
Check Drain Motor circuit. See data listed on the
Technical Sheet, locatedbehindToe Panel.
Will Not Dry
Vent Assembly
Check VentAssembly for proper operation. Check Wax
Motor.
Heating Element
Check Heating Element circuit. See data listed on the
Technical Sheet, locatedbehindToe Panel.
Manual Function Test
SeeTechnical Sheet, locatedbehindToe Panel.
Field Service Test
SeeTechnical Sheet, locatedbehindToe Panel.

5-20 16021814 Rev. 0 ©2002 Maytag Appliance Sales Company
Section 5. Service and Disassembly Procedures
!
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000 ohmresistor before attempting toservice, unless test proceduresrequire power to be
connected.Ensure all groundwires are connectedbefore certifying unitas repairedand/oroperational.
Thefollowing paragraphsdescribe howto disassemble
unit under test. Disassembly to some extent is required
toinstall unit, toperform troubleshooting procedures, and
toremove andreplace failedcomponents.
Componentnames usedthroughout disassembly
procedures are the same as those used in Parts
Manuals.
For quicker reassembly, disassemble unit under test only
to extent necessary to troubleshoot and repair. Unless
noted, reassembly is opposite of disassembly.
WARNING
!
Front Support and Toe Panel Removal
Removalof Front SupportandToe Panelwill allow access
to the Water Valve, Float Switch Assembly, Electrical
Junction Box, hoses, thermostats, Start Capacitor and
Motor/PumpAssembly.
Removal
1. Disconnect power to the machine.
2. The Front Support Panel is held by 2 screws, one
eachside. Remove bothscrews.
3. The Toe Panel is held by 2 screws, one each side.
To avoid risk ofpersonal injury or deathdue to
electrical shock, ground wires and wires colored like
ground wiresare NOT tobe used as current carrying
conductors.The standard acceptedcolor coding for
ground wires is green or green with a yellow
stripe.Electrical components such asthe water valve
andmotorare groundedthrough anindividual wire
attached to the electrical component. Ground wires
shouldnotbe removedfrom individualcomponents
while servicing, unless the component is to be
removedand replaced. It isextremely important to
replaceallremoved groundwires beforecompleting
service.
