Maytag MEDE500VF0 User manual

TOP AND CONSOLE PARTS
1
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
3−09 Printed in U.S.A. (L.T)(bay) Part No. W10215172 Rev. B
29" ELECTRIC DRYER

TOP AND CONSOLE PARTS
2
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10057351 Use & Care Guide
W10057360 Tech Sheet
W10134980 Installation,
Diagnostic Guide
W10165147 Sheet, Steam Tip
W10057356 Guide,
Quick Start
2 Top
3980634 White
W10193965 Green
W10193964 Red
3
W10111017 Harness, Main
4 Panel, Console
(Includes Buttons
& Control Board
& Item 13 )
W10164452 White
W10191140 Green
W10237639 Red
5 3394427 Clip, Harness
6
W10006840 Bracket, Console
(Includes Items:
21.)
7 94614 Terminal
8 3936144 Plug, Terminal
9 3390647 Screw, 8−18 x 1/2
10
W10185550 Power Cable
User Interface
11
W10177245 Medallion
12 3395683 Connector,
(Motor)
13 98139 Screw, 8−32 x 1/32
14
W10164576 Knob, Assembly
15
W10170293 Guide, Light
Cycle Internal
16
W10171504 Foil−Display
17
W10112267 Foam−Seal
18
W10185548 Harness,
User−Interface
19
W10171502 Fram−Light
(Guide Display)
20
W10164578 Guide, Light
(3−Way Digital)
21
W10170295 Frame−Light Guide
22
W10164567 Cycle, Light Guide
23
W10172298 Bushing, Knob
24
W10164610 User−Interface
25 8572039 Seal,
User Interface
26 8540513 Screw
27 8540282 Screw

CABINET PARTS
3
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172

CABINET PARTS
4
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8576583 Cover,
Terminal Block
2 3390814 Screw, 8−18 x 3/8
3 8533974 Screw, 10−32 x 5/8
(Ground)
4 3397659 Block, Terminal
5
W10167612 Switch, Broken
Belt
6 8563727 Bracket, Control
7 Panel, Side (L.H.)
W10192435 White
W10193955 Green
W10193954 Red
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 Plug, Multivent
697750 White
W10151499 Midnight Grey
13 3388672 Pulley Assembly
14 279318 Terminal, Brass
& Tinned (3)
(Includes Illus. 33)
15 8066120 Lever, Snap
Switch
16 3394081 Wire, Belt Switch
17
W10128772 Sound Panel
18
W10121334 Washer
19
W10128087 Assembly,
Door Switch
20 690997 Tri Ring
21 8066115 Cover−Plate
22 8529053 Ramp, Door
23
W10181463 Harness,
Digital Interface
24 Panel, Side (R.H.)
W10192446 White
W10193958 Green
W10193957 Red
25
W10177388 Control Board
26 Trim−Ring
Assembly
(Includes
Item. 48 )
W10164746 White
W10190564 Green
W10221448 Red
27 8538263 Motor, Assembly
60 HZ.
28 3398948 Wire, Jumper
(Broken Belt
Switch)
29 8578220 Pulley 60 HZ.
30
W10112954 Belt, Drive
31 8541503 Kit,
Stack Assembly
32 3387118 Bracket, Motor
33 279393 Terminal Block
Screw Kit (For
Terminal Block)
34 49026 4" − 90 Elbow
35 62825 Clip, S−Type (3)
36 8563747 Exhaust Pipe
& Bracket
37 8563750 Exhaust Pipe
(Short)
38 8563749 Exhaust Pipe
(Long)
39 3388674 Idler Bracket
40 Panel, Toe
W10116271 White
W10193963 Green
W10193962 Red
41
W10181460 Panel, Rear
42 98129 Screw,
6−20 x 1 1/16
43 3390647 Screw, 8−18 x 1/2
44 3387242 Seal, Front Panel
45 3393008 Screw, 10−16 x 1/2
46 8519459 Clip, Toe Panel
47 343641 Screw, 10−16 x 1/2
48
W10129065 Trim−Clip
Metal
49 359625 Screw−Ground
50 8519207 Base, Cabinet
51 Front Panel
(Includes
Illus. 44 )
W10153275 White
W10193970 Green
W10193967 Red
52 696144 Strike, Door (2)
53 90767 Screw, 8−18 x 3/8
54 3357011 Screw, 10−16 x 1/2
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
55 279818 White
W10186596 Midnight Grey

BULKHEAD PARTS
5
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172

BULKHEAD PARTS
6
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3 3394984 Door, Lint
Screen
4 3406653 Harness, Sensor
5 697354 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
9 3392519 Thermal − Fuse
(91 C)
10 3402841 Lens,
Drum Light
11 489463 Screw, 8−18 x 5/8
12 8572105 Clip, Exhaust
Pipe
13 8533971 Screw, 8−18 x 5/16
14 8544771 Heater Element
15 279457 Terminal Wire
Kit (For Heater
Element Wiring
Harness Repair)
16
W10001120 Nut, 3/8−16 (L.H.)
17
W10133857 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8563745 Exhaust Pipe
23 3394985 Housing, Outlet
24 697693 Baffle, Drum
25
W10181466 Complete Drum
Assembly
26
W10109200 Screw, 11−16 x 3/4
27
W10166807 Seal, Drum
28 695240 Screw, 8−18 x 1/2
29 90767 Screw, 8−18 x 3/8
30 8519245 Bulkhead, Front
31 8299979 Grille, Outlet
32 359625 Screw, 8−18 x 1/2
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 8578825 Bracket,
Drum Light
36
W10136369 Socket Assembly
37 697772 Wheel, Blower
38 8066208 Clip, Spring
39 3394986 Spring, Lint
Screen Door
40
W10049370 Lint Screen
41 697770 Seal, Cover Plate
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 8544769 Housing−Slot
Heater Box
47 280148 Thermal Cut−Off
(Includes Illus.
No. 48)
48 8557403 Thermostat 295 F
(146 C)
49 8544770 Housing−Tab
Heater Box
50 8066099 Bracket,
Heater Box
51 3387230 Screw, 10−16 x 1
52 8544776 Flange,
Heater Box
53
W10044596 Valve, Water Inlet
(Includes Items,
29, 54, 60 & 61)
54
W10044597 Bracket, Valve
55
W10044606 Nozzle & Hose
Assembly
(Includes Items,
57, 59, 62 & 63)
56
W10044598 Hose,
(Not Servicable)
Includes With
Item 55.)
57
W10044629 Nozzle & Screen
Assembly
58
W10044615 Clip,
Push−To−Connect
59 3391018 Cable, Tie
60
W10044605 Coupling, Hose
61
W10184825 Cover, Inlet Valve
62
W10044579 Washer, Nozzle
63
W10044628 Nut, Brass
64
W10128629 Shield, Blower
Housing
(Includes,
Item 29 ).
65
W10128544 Caplug

DOOR PARTS
7
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Label,
Hinge Hole
W10085210 White
W10085230 Silver
2
W10139920 Door Hinge
Assembly
3
W10180119 Cover,
Door Hinge
4 9742177 Screw, 8−18 x 5/8
5
W10048910 Screw−Plug
6
W10180118 Door−Intermediate
7
W10193522 Handle Ring
8 690081 Door Catch
Assembly (Lower)
9
W10159996 Screw,
10−24 x 3/64
10 8578229 Door Assembly
(Inner)
(Includes
Illus. 8 & 14)
11 355515 Screw,
8−18 x 11/16
12
W10193530 Door, Outer
Assembly
13
W10180117 Door Mask
14 3398175 Door Catch
Assembly (Upper)
15 8580116 Pad−Handle
16
W10180120 Door−Shield
17 8519354 Retainer−Window
Lower
18 8519356 Retainer−Window
Upper
19 3393258 Screw,
20 8579662 Seal−Window
21 8566254 Glass−Window
22
W10139457 Seal−Door
23
W10171571 Screen, Door

OPTIONAL PARTS (NOT INCLUDED)
8
For Models: MEDE500VW0, MEDE500VP0, MEDE500VF0
(White) (Green) (Red)
W10215172
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
W10218248 Green Metallic
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
ACCESSORY PARTS
8529894 Hold Down Kit
8522199 Kit, Dryer
Vent Testing
80047 Kit,
Dryer Repair
8579666A Kit,
Door Reversing
Miscellaneous Parts Bag
W10044609 Bag Assembly
(Contains The
Following)
76314 (Hose Inlet)
6’Hose With Elbow
W10044603 (Hose Inlet)
1’Hose
W10194033 Washer
W10044604 Connector, Hose
