INSTALLATION INSTRUCTIONS
COMMERCIAL DRYER – Gas or Ele tri
INSTRUCTIONS POUR L’INSTALLATION D’UNE
SÉCHEUSE COMMERCIALE – À gaz ou éle trique
TableofContents/Tabledesmatières ........................................2
W10184578A
SP - W10184579A
www.maytagcommerciallaundry.com
MDE17PR
MD 17PR MDE17PD
MD 17PD

2
You can be killed or seriously injured if you don't immediately 
You can be killed or seriously injured if you don't follow 

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety 
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
TABLE OF CONTENTS
DRYER SAFETY............................................................................ 2
INSTA ATION REQUIREMENTS .............................................. 5
Tools and Parts .......................................................................... 5
Location Requirements.............................................................. 5
Electrical Requirements - as Dryer ........................................ 7
Electrical Requirements - Electric Dryer (U.S.A. Only) ............ 8
Electrical Requirements - Electric Dryer (Canada Only) .......... 9
as Supply Requirements .................................................... 10
Venting Requirements ............................................................ 11
INSTA ATION INSTRUCTIONS – MOVE DRYER INTO
POSITION ................................................................................ 12
INSTA ATION INSTRUCTIONS – GAS DRYER .................. 13
Make as Connection..............................................................13
Connect Vent ............................................................................13
Complete Installation ..............................................................13
INSTA ATION INSTRUCTIONS – E ECTRIC DRYER........ 14
Make Electrical Connection......................................................14
Connect Vent ............................................................................18
Complete Installation ..............................................................18
REVERSING THE DOOR SWING .......................................... 19
MAINTENANCE........................................................................19
E ECTRONIC CONTRO S SETUP........................................ 20
WARRANTY..............................................................................24
DRYER SAFETY
TABLE DES MATIÈRES
SÉCURITÉ DE A SÉCHEUSE ..............................................25
EXIGENCES D’INSTA ATION................................................27
Outillage et pièces ....................................................................28
Exigences d’emplacement ......................................................28
Spécifications électriques - sécheuse à gaz ...........................29
Spécifications électriques - Pour le Canada seulement ..........30
Spécifications de l’alimentation en gaz ..................................31
Exigences concernant l'évacuation ..........................................32
INSTRUCTIONS D'INSTA ATION - DÉP ACEMENT DE A
SÉCHEUSE À SON EMP ACEMENT FINA ..........................34
INSTRUCTIONS D’INSTA ATION – SÉCHEUSE À GAZ ....35
Raccordement à la canalisation de gaz ..................................35
Raccordement du conduit d'évacuation ................................35
Achever l’installation ................................................................35
INSTRUCTIONS D’INSTA ATION – SÉCHEUSE
É ECTRIQUE............................................................................36
Raccordement du conduit d'évacuation ................................36
Achever l’installation ................................................................36
INVERSION DU SENS D’OUVERTURE DE A PORTE............37
INSTRUCTIONS D’ENTRETIEN ............................................ 37
RÉG AGE DE A COMMANDE É ECTRONIQUE ................38
GARANTIE ................................................................................43

WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion, or to prevent property damage, personal injury, or death.
–Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
–WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
–Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
•Clear the room, building, or area of all occupants.
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the “What to do if you smell gas” instructions.
3
IMPORTANT: The gas installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54 or the Canadian Natural Gas and Propane Installation Code, CSA B149.1.
The dryer must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, CSA C22.1.

4
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
■It is recommended that the owner post, in a prominent location, instructions for the customer’s use in the event the customer smells
gas. This information should be obtained from your gas supplier.
■Post the following warning in a prominent location.
In the State of Massachusetts, the following installation instructions apply:
■Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
■If using a ball valve, it shall be a T-handle type.
■A flexible gas connector, when used, must not exceed 3 feet.

5
Lo ation Requirements
If installing a gas dryer:
IMPORTANT: Observe all governing codes and ordinances.
■Check code requirements: Some codes limit or do not permit
installation of clothes dryers in garages, closets, or sleeping
quarters. Contact your local building inspector.
■Make sure that lower edges of the cabinet, plus the back and
bottom sides of the dryer, are free of obstructions to permit
adequate clearance of air openings for combustion air. See
“Recessed Area and Closet Installation Instructions” below
for minimum spacing requirements.
NOTE: The dryer must not be installed in an area where it will
be exposed to water and/or weather.
INSTALLATION REQUIREMENTS
Recessed Area and Closet Installation Instructions
This dryer may be installed in a recessed area or closet.
For recessed area and closet installations, minimum clearances
can be found on the warning label on the rear of the dryer.
The installation spacing is in inches and is the minimum
allowable. Additional spacing should be considered for ease
of installation, servicing, and compliance with local codes
and ordinances.
If closet door is installed, the minimum unobstructed air opening
in the top and bottom is required. Louvered doors with equivalent
air openings are acceptable.
The dryer must be exhausted outdoors.
No other fuel-burning appliance may be installed in the same
closet as the dryer.
Tools and Parts
ather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools
listed here.
Tools needed
■8" (20 mm) or 10" (25 mm) Pipe wrench
■8" (20 mm) or 10" (25 mm) adjustable wrench
■Flat-blade screwdriver
■Phillips screwdriver
■Adjustable wrench that opens to 1" (25 mm) or 1" (25 mm)
hex-head socket wrench
■Level
■5⁄16" socket wrench
■Utility knife
■Vent clamps
■Pipe-joint compound resistant to LP gas
■Caulk gun and caulk (for installing new exhaust vent)
■Pliers
■Putty knife
Parts supplied
Remove parts bag from dryer drum. Check that all parts were
included.
■Foot boot (4)
■Dryer foot (4)
■Bezel kit (PR models only)

6
Recessed front view Closet side view
Minimum Installation Clearances
Additional clearances for wall, door, and floor moldings may be required or if
external exhaust elbow is used.
closet
door
Front
View
3" (76 mm)
3" (76 mm)
24 in2
(155 cm2)*
48 in2.
(310 cm2)*
*Opening is the minimum for a closet door.
Louvered doors with equivalent air openings are acceptable.
0" (0 mm)
Closet
door
14"
(356 mm)
max.
1" (25 mm)
0" (0 mm)
15"
(381 mm)*
0"
(0 mm)
Product Dimensions 27" (686 mm) dryer
27" (686 mm)
37"
(940 mm)
14"
(35.6 cm)
ELECTRIC
GAS
EXHAUST
LEFT OR
RIGHT SIDE
EXHAUST
43⁄4"
(121 mm)
13"
(330 mm)
11⁄4"
(32 mm)
BACK VIEW
41⁄4"
(108 mm)
63⁄4"
(152 mm) 4" (102 mm)
dia.
3⁄4"
(21 mm)
SIDE VIEW
BOTTO
EXHAUST
35"
(889 mm)
261⁄2"(673 mm)
291⁄4"(743 mm)
141⁄8"
(359 mm)
71⁄4"
(184 mm)
101⁄4"
(260 mm)
Non-coin-
operated models:
71⁄8" (181 mm)
Coin-operated
models:
77⁄8" (200 mm)

7
Ele tri al Requirements – Gas Dryer
IMPORTANT: The dryer must be electrically grounded in
accordance with local codes and ordinances or, in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70,
latest edition, or Canadian Electrical Code, CSA C22.1.
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrical installer determine that
the ground path is adequate.
A copy of the above code standards can be obtained from:
National Fire Protection Association
One Batterymarch Park, Quincy, MA 02269
CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
■A 120 volt, 60 Hz, AC only, 15- or 20-amp, fused electrical
circuit is required. A time-delay fuse or circuit breaker is also
recommended. It is recommended that a separate circuit
serving only this dryer be provided.
Recommended Ground Method
The dryer, when installed, must be electrically grounded in
accordance with local codes or, in the absence of local codes,
with the National Electrical Code, ANSI/NFPA 70, latest edition,
or Canadian Electrical Code, CSA C22.1, and all local codes
and ordinances.

8
Ele tri al Requirements – U.S.A. Only
It is your responsibility
■To contact a qualified electrical installer.
■To be sure that the electrical connection is adequate and in
conformance with the National Electrical Code, ANSI/NFPA
70-latest edition and all local codes and ordinances.
The National Electrical Code requires a 4-wire power supply
connection for homes built after 1996, dryer circuits involved
in remodeling after 1996, and all mobile home installations.
Acopy of the above code standards can be obtained from:
National Fire Protection Association, One Batterymarch Park,
Quincy, MA 02269.
■To supply the required 3 or 4 wire, single phase, 120/240 volt,
60 Hz., AC only electrical supply (or 3 or 4 wire, 120/208 volt
electrical supply, if specified on the serial/rating plate) on a
separate 30-amp circuit, fused on both sides of the line. A
time-delay fuse or circuit breaker is recommended. Connect
to an individual branch circuit. Do not have a fuse in the
neutral or grounding circuit.
■Do not use an extension cord.
■If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
Electrical Connection
To properly install your dryer, you must determine the type of
electrical connection you will be using and follow the instructions
provided for it here.
■This dryer is manufactured ready to install with a 3-wire
electrical supply connection. The neutral ground conductor is
permanently connected to the neutral conductor (white wire)
within the dryer. If the dryer is installed with a 4-wire electrical
supply connection, the neutral ground conductor must be
removed from the external ground connector (green screw),
and secured under the neutral terminal (center or white wire)
of the terminal block. When the neutral ground conductor is
secured under the neutral terminal (center or white wire) of the
terminal block, the dryer cabinet is isolated from the neutral
conductor.
■If local codes do not permit the connection of a neutral
ground wire to the neutral wire, see “Optional 3-wire
connection” section.
■A 4-wire power supply connection must be used when the
appliance is installed in a location where grounding through
the neutral conductor is prohibited. rounding through the
neutral is prohibited for (1) new branch-circuit installations,
(2) mobile homes, (3) recreational vehicles, and (4) areas
where local codes prohibit grounding through the neutral
conductor.
If using a power supply cord:
Use a UL listed power supply cord kit marked for use with
clothes dryers. The kit should contain:
■A UL listed 30-amp power supply cord, rated 120/240 volt
minimum. The cord should be type SRD or SRDT and be at
least 4 ft (1.22 m) long. The wires that connect to the dryer
must end in ring terminals or spade terminals with upturned
ends.
■A UL listed strain relief.
If your outlet looks like this:
Then choose a 4-wire power supply cord with
ring or spade terminals and UL listed strain
relief. The 4-wire power supply cord, at least
4 ft (1.22 m) long, must have four 10-gauge
copper wires and match a 4-wire receptacle of
NEMA Type 14-30R. The ground wire (ground
conductor) may be either green or bare. The
neutral conductor must be identified by a
white cover.
4-wire recept cle
(14-30R)
3-wire recept cle
(10-30R)
Then choose a 3-wire power supply cord with
ring or spade terminals and UL listed strain relief.
The 3-wire power supply cord, at least 4 ft (1.22
m) long, must have three 10-gauge copper wires
and match a 3-wire receptacle of NEMA Type
10-30R.
If your outlet looks like this:

9
Ele tri al Requirements – Canada Only
It is your responsibility
■To contact a qualified electrical installer.
■To be sure that the electrical connection is adequate and in
conformance with the Canadian Electrical Code, C22.1-latest
edition and all local codes. A copy of the above codes
standard may be obtained from: Canadian Standards
Association, 178 Rexdale Blvd., Toronto, ON M9W 1R3
CANADA.
4-wire recept cle (14-30R)
If connecting by direct wire:
Power supply cable must match power supply (4-wire or 3-wire)
and be:
■Flexible armored cable or nonmetallic sheathed copper cable
(with ground wire), protected with flexible metallic conduit. All
current-carrying wires must be insulated.
■10-gauge solid copper wire (do not use aluminum).
■At least 5 ft (1.52 m) long.
■Do not use an extension cord.
If you are using a replacement power supply cord, it is
recommended that you use Power Supply Cord Replacement
Part Number 9831317. For further information, please
reference the service numbers located in the “Assistance
or Service” section.
■To supply the required 4 wire, single phase, 120/240 volt, 60
Hz., AC only electrical supply on a separate 30-amp circuit,
fused on both sides of the line. A time-delay fuse or circuit
breaker is recommended. Connect to an individual branch
circuit.
■This dryer is equipped with a CSA International Certified
Power Cord intended to be plugged into a standard 14-30R
wall receptacle. The cord is 5 ft (1.52 m) in length. Be sure
wall receptacle is within reach of dryer’s final location.

10
Flexible metal appliance connector:
■It is recommended that a new flexible stainless steel gas line,
design-certified by CSA International, be used for connecting
the dryer to the gas supply line. (The gas pipe which extends
through the lower rear of the dryer is provided with 3⁄8" male
pipe thread.)
■Do not kink or damage the flexible stainless steel gas line
when moving the dryer.
Rigid pipe connection:
The rigid pipe connection requires a combination of pipe fittings
to obtain an in-line connection to the dryer.
■Must include a shutoff valve:
The supply line must be equipped with a manual shutoff
valve installed within 6 ft. (1.8 m) of dryer in accordance
with National Fuel as Code, ANSI Z223.1. In Canada,
an individual manual shutoff valve must be installed in
accordance with the B149 installation codes CAN/C A
B149.1 and CAN/C A B149.2. This valve should be located
in the same room as the dryer. It should be in a location that
allows ease of opening and closing. Do not block access to
shutoff valve. The valve is for turning on or shutting off gas
to the dryer.
D
B
C
A
Gas Supply ine
Recommended method
■Provide a gas supply line of 1⁄2" rigid (IPS) pipe to the dryer
location. Pipe joint compounds that resist the action of LP gas
must be used. Do not use TEFLON®† tape. With LP gas,
piping or tubing size can be 1⁄2" minimum. Usually, LP gas
suppliers determine the size and materials used in the system.
Alternate method
■The gas supply may also be connected using 3⁄8" approved
copper or aluminum tubing. If the total length of the supply
line is more than 20 ft. (6.1 m), larger tubing will be required.
If using natural gas, do not use copper tubing. Pipe joint
compounds that resist the action of LP gas must be used.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
Gas Supply Requirements
IMPORTANT: Observe all governing codes and ordinances.
This installation must conform with all local codes and
ordinances. In the absence of local codes, installation must
conform with American National Standard, National Fuel as
Code ANSI Z223.1/NFPA 54 or CAN/CSA B149.
A copy of the above code standards can be obtained from:
National Fire Protection Association
One Batterymarch Park, Quincy, MA 02269
CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
The design of this dryer has been certified by CSA International
for use at altitudes up to 10,000 feet (3048 m) above sea level at
the B.T.U. rating indicated on the model/serial plate. Burner input
adjustments are not required when the dryer is operated up to
this elevation.
When installed above 10,000 feet (3048 m), a four percent (4%)
reduction of the burner B.T.U. rating shown on the model/serial
plate is required for each 1,000 foot (305 m) increase in elevation.
For assistance when converting to other gas types and/or
installing above 10,000 feet (3048 m) elevation, contact your
local service company.
Type of Gas
This dryer is equipped for use with natural gas. It is design-
certified by CSA International for LP (propane and butane) gases
with appropriate conversion. No attempt shall be made to convert
the dryer from the gas specified on the serial/rating plate for use
with a different gas without consulting the serving gas supplier.
Conversion must be done by a qualified service technician.
as conversion kit part numbers are listed on the gas valve
burner base.
A. G s supply line
B. Shutoff v lve in “open” position
C. To dryer
D. NPT 1/8" min. plugged t pping

11
■Installed in a confined area:
If the dryer is installed in a confined area such as a bathroom
or closet, provision must be made for enough air for
combustion and ventilation. Check governing codes and
ordinances or refer to the “Recessed Area and Closet
Installation Instructions” in the “Location Requirements”
section.
Gas Supply Pressure Testing
A1⁄8" NPT minimum plugged tapping, accessible for gauge
testing, must be installed immediately upstream of the installed
shut-off valve to the dryer.
The dryer must be disconnected from the gas supply piping
system during any pressure testing of the system at test
pressures in excess of 1⁄2"psig.
Venting Requirements
WARNING: To reduce the risk of fire, this dryer MUST BE
EXHAUSTED OUTDOORS.
■The dryer vent must not be exhausted into any gas vent,
chimney, wall, ceiling, attic, crawlspace, or a concealed space
of a building.
■Only rigid or flexible metal duct shall be used for exhausting.
■Do not use an exhaust hood with a magnetic latch.
■4" (102 mm) heavy metal vent and clamps must be used. Do
not use plastic or metal foil vent.
■Use clamps to seal all joints. The duct shall not be assembled
with screws or other fastening means that extend into the
duct and catch lint. Do not use duct tape.
■The total length of flexible metal vent shall not exceed 73⁄4ft
(2.4 m).
IMPORTANT: Observe all governing codes and ordinances.
Rigid metal vent is recommended to prevent crushing and
kinking.
Flexible metal vent must be fully extended and supported when
the dryer is in its final position. Remove excess flexible metal vent
to avoid sagging and kinking that may result in reduced airflow
and poor performance.
An exhaust hood should cap the vent to prevent rodents and
insects from entering the home or business.
Exhaust hood must be at least 12" (305 mm) from the ground
or any object that may be in the path of the exhaust (such as
flowers, rocks, or bushes).
If using an existing vent system, clean lint from the entire length
of the system and make sure exhaust hood is not plugged with
lint. Replace any plastic or metal foil vent with rigid metal or
flexible metal vent.
Plan installation to use the fewest number of elbows and turns.
Allow as much room as possible when using elbows or making
turns. Bend vent gradually to avoid kinking.
Vent outlet is located at the back of the dryer, at bottom center.
The vent can be routed up, down, left, right, or straight out the
back of the dryer.
Vent System ength
Maximum length of vent system depends upon the type of
vent used, number of elbows, and type of exhaust hood.
The maximum length for rigid vent is shown in the chart.
For vent systems not covered by the vent specification chart,
see your parts distributor.
If dryer is installed in a confined area, such as a bedroom,
bathroom, or closet, provision must be made for enough air
for combustion and ventilation. (Check governing codes and
ordinances.) See “Recessed Area and Closet Installation
Instructions” in the “Location Requirements” section.
A 4" (102 mm) outlet hood is preferred. However, a 21⁄2" (64 mm)
outlet exhaust hood may be used. A 21⁄2" (64 mm) outlet creates
greater back pressure than other hood types. For permanent
installation, a stationary vent system is required.
AB
Exh ust Air Flow
A. Good
B. Better
Rigid Metal Vent
No. of 90° turns
4" (102 mm) Diameter Exhaust Hoods
Maximum Vent ength
0
1
2
3
4
Box Hood and Louvered Style Angled Hood Style
130 ft. (39.6 m)
125 ft. (38.1 m)
115 ft. (35.1 m)
106 ft. (32.3 m)
98 ft. (29.9 m)
129 ft. (39.3 m)
119 ft. (36.3 m)
109 ft. (33.2 m)
100 ft. (30.5 m)
92 ft. (28.0 m)

12
Multiple Dryer Venting
■A main vent can be used for venting a group of dryers. The
main vent should be sized to remove 200 CFM of air per
dryer. Large-capacity lint screens of proper design may be
used in the main vent if checked and cleaned frequently. The
room where the dryers are located should have make-up air
equal to or greater than the CFM of all the dryers in the room.
■Back-draft Damper Kit, Part No. 3391910, is available from
your dealer and should be installed in the vent of each dryer
to prevent exhausted air from returning into the dryers and
to keep the exhaust in balance within the main vent.
Unobstructed air openings are required.
Each vent should enter the main vent at an angle pointing in the
direction of the airflow. Vents entering from the opposite side
should be staggered to reduce the exhausted air from interfering
with the other vents.
The maximum angle of each vent entering the main vent should
be no more than 30°.
A. Individu l dryer vent
B. M in vent
air flow
30° max.
A
B
Keep air openings free of dry cleaning fluid fumes. Fumes create
acids which, when drawn through the dryer heating units, can
damage dryers and loads being dried.
A clean-out cover should be located on the main vent for periodic
cleaning of the vent system.
If an exhaust hood cannot be used:
The outside end of the main vent should have a sweep elbow
directed downward. If the main vent travels vertically through the
roof, rather than through the wall, install a 180° sweep elbow on
the end of the vent at least 2 ft. (610 mm) above the highest part
of the building. The opening in the wall or roof shall have a
diameter 1⁄2" (13 mm) larger than the vent diameter. The vent
should be centered in the opening.
Do not install screening or cap over the end of the vent.
A
A. Exh ust hood or elbow
B. W ll
C. M in collector vent
D. Horizont l vent
E. 180° sweep elbow
F. Vertic l vent
G. Roof
E
B
G
C
D
2 ft. (610 mm)
min. above
highest point
of building
F
C
Min. 12 "(300 mm) clearance
above any accumulation
of snow, ice, or debris such
as leaves.
The console houses the electronic control board. The board is
factory set for a dry time of 45 minutes. Consult the tech sheet
found inside the dryer toe panel to reset dry time and for other
options.
The card reading mechanism is not included, but is available from
your usual industry sources.
NOTE: Slide dryer onto cardboard or hardboard before moving to
avoid damaging floor covering.
1. Using two or more people, move dryer to desired installation
location.
2. Take tape off front corners of dryer. Open dryer and remove
the literature and parts packages. Wipe the interior of the
drum thoroughly with a damp cloth.
INSTALLATION INSTRUCTIONS – MOVE DRYER INTO POSITION
3. Take two of the cardboard corners from the carton and place
them on the floor in back of the dryer. Firmly grasp the body
of the dryer and gently lay it on its back on the cardboard
corners. Disconnect power before making electrical
connections.
4. With one of the legs in hand, check the ridges for a diamond
marking which indicates how far the leg is supposed to go
into the hole.
5. Start to screw the leveling legs into the holes by hand. (Use a
small amount of liquid detergent to lubricate the screw
threads so it is easier to turn the legs.) Use a 1" (25 mm)
wrench or socket wrench to finish turning the legs until you
reach the diamond mark.
6. Now stand the dryer up.
7. Remove cardboard or hardboard from under dryer. Adjust the
legs of the dryer up or down until the dryer is level.

13
INSTALLATION INSTRUCTIONS – GAS DRYER
Make Gas Conne tion
1. Remove red cap from gas pipe.
2. Connect gas supply to dryer. Use pipe-joint compound
resistant to the action of L.P. gas for gas connections. If
flexible metal tubing is used, be certain there are no kinks.
If necessary for service, open the toe panel. Use a putty knife
to press on the toe panel locks located near the two ends of
the toe panel. Pull downward on the toe panel to open. Toe
panel is hinged at the bottom.
3. Open the shutoff valve in the gas supply line.
4. Test all connections by brushing on an approved noncorrosive
leak-detection solution. Bubbles will show a leak. Correct any
leaks found.
Conne t Vent
1. Using a 4" (102 mm) clamp, connect vent to exhaust outlet
in dryer. If connecting to existing vent, make sure the vent is
clean. The dryer vent must fit over the dryer exhaust outlet
and inside the exhaust hood. Make sure the vent is secured
to exhaust hood with a 4" (102 mm) clamp.
2. Using two or more people, move dryer to desired installation
location. Do not crush or kink vent. Make sure dryer is level.
3. Check to be sure there are no kinks in the flexible gas line.
Complete Installation
1.With dryer in final position, place level on top of the dryer, first
side to side; then front to back. If the dryer is not level, adjust
the legs of the dryer up or down until the dryer is level.
2. Plug into a grounded 3 prong outlet.
3. Check dryer operation (some accumulated time may be on
the timer on mechanical timer models due to factory testing).
Push START/RESTART button. Using a high heat cycle (not
the air cycle), let the dryer run for at least five minutes. Dryer
will stop when time is used up. Make sure the dryer turns off.
NOTE: Dryer door must be closed for dryer to operate. When
door is open, dryer stops, but timer continues to run. To
restart dryer, close door and push START/RESTART button.
4. If the burner does not ignite and you can feel no heat inside
the dryer, shut off dryer for five minutes. Check that all supply
valve controls are in “ON” position and that the electrical cord
is plugged in. Repeat five-minute test.
5. If drying time is too long, make sure lint screen is clean.

14
Make Electrical Connection
Power Supply Cord Method – U.S. Only
This dryer is manufactured with the neutral ground wire
connected to the neutral (center) of the wiring harness at the
terminal block. If local codes do not permit this type of
connection, use “Four-wire connection” instructions.
Use a UL-listed power supply cord rated 240 volt min., 30-amp
and marked for use with a clothes dryer.
INSTALLATION INSTRUCTIONS – ELECTRIC DRYER
1. Disconnect power.
2. Remove hold-down screw and the terminal block cover.
3. Assemble 3⁄4" (19 mm) UL-listed strain relief (UL marking on
strain relief) into the hole below the terminal block opening.
Tighten strain relief screws just enough to hold the two clamp
sections together. Install power supply cord through the
strain relief.
4. Complete installation following instructions for your type of
electrical connection:
• Four-wire (recommended method)
• Three-wire (if four-wire is not available)
B
C
A
A. Strain relief clamp sections
B. Dryer cabinet
C. Strain relief screws
CD
B
A
A. External ground conductor screw
B. Tab
C. Terminal block cover
D. Hold-down screw

15
5. Remove the center terminal block screw.
6.Remove the appliance neutral ground wire
from the external ground conductor screw.
Fasten under center, silver-colored
terminal block screw.
7. Connect the ground wire of the power
supply cord to the external ground
conductor screw. Tighten screw.
8. Connect the neutral wire (white or center)
of the power supply cord under the center
screw of the terminal block. Tighten
screw.
9.Connect the other wires to outer terminal
block screws. Tighten screws.
10. Tighten strain relief screws.
11. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
Four-wire power supply cord must have four,
No. 10 copper wires and match a four-wire
receptacle of NE A Type 14-30R. The
fourth wire (ground conductor) must be
identified by a green cover and the neutral
conductor by a white cover.
BD
C
GF
E
A
A. Spade terminals wit upturned ends
B. Neutral
C.
3⁄4" (19 mm)
UL-listed strain relief
D. Neutral (w ite)
E. Ring terminals
F. Ground wire
G. Ground prong
A. External ground conductor screw
B. Appliance neutral ground wire
C. Center terminal block screw
D. Outer terminal block screws
E. Strain relief screw
F. Neutral (center wire)
G. Ground wire
Power Supply Cord,
Four-wire electrical connection:
C
B
A
F
G
E
D

16
A. Spade terminals wit upturned ends
B. Ring terminals
C. Neutral (w ite or center)
D.
3⁄4" (19 mm)
UL-listed strain relief
E. Neutral
A. External ground conductor screw
B. Center terminal block screw
C. Outer terminal block screws
D. Strain relief screw
E. Neutral (center wire)
F. Appliance neutral ground wire
A. Separate copper ground wire
B. External ground conductor screw
C. Appliance neutral ground wire
D. Center terminal block screw
E. Outer terminal block screws
F. Strain relief screw
G. Neutral (center wire)
G
F
E
Power Supply Cord,
Three-wire electrical connection:
B
A
E
F
D
C
Three-wire power supply cord must
have three, No. 10 copper wires and
match a three-wire receptacle of NE A
Type 10-30R.
EC
D
This blade connected to
this conductor. B
A
5. Loosen or remove the center terminal
block screw.
6. Connect the neutral wire (white or center)
of the power supply cord to the center,
silver-colored terminal screw of the
terminal block. Tighten screw.
7.Connect the other wires to outer terminal
block screws. Tighten screws.
8. Tighten strain relief screws.
9. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
D
AC
B
5. Remove the center terminal block screw.
6. Remove the appliance neutral ground wire
from the external ground conductor
screw. Connect the appliance neutral
ground wire and the neutral wire (white or
center) of the power supply cord under
the center, silver-colored terminal block
screw. Tighten screw.
7. Connect the other wires to outer terminal
block screws. Tighten screws.
8. Tighten strain relief screws.
9. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
10. After reattaching the terminal cover,
connect a separate copper ground wire
from the external ground conductor screw
to an adequate ground.
If codes permit and a separate ground wire is
used, it is recommended that a qualified
electrician determine that the ground path is
adequate.
Use this method where local codes permit connectin
neutral round wire to neutral wire:
Use this method where local codes do not permit
connectin neutral round wire to neutral wire:

17
Direct Wire Method – U.S. Only
Direct wire cable must match power supply (4-wire or 3-wire)
and be:
■Flexible armored cable or nonmetallic sheathed copper cable
(with ground wire), protected with flexible metallic conduit. All
current-carrying wires must be insulated.
■10-gauge solid copper wire (do not use aluminum).
■At least 5 ft. (1.52 m) long.
1. Disconnect power.
2.Remove hold-down screw and terminal block cover.
3. Install 3⁄4" conduit connector into the hole below the terminal
block opening. Connect flexible metallic conduit and tighten
connector screw. Install direct wire cable through the flexible
metallic conduit.
4. Complete installation following instructions for your type of
electrical connection:
• Four-wire (recommended method)
• Three-wire (if four-wire is not available)
CD
B
A
A. External ground conductor screw
B. Tab
C. Terminal block cover
D. Hold-down screw
A
to
disconnect
box B
D
5" (127 mm)
31⁄2" (89 mm)
1" (25 mm)
of wires
stripped of
insulation
C
Strip 5" (127 mm) of outer covering
from end of cable. Leave green or bare
ground wire at 5" (127 mm). Cut 11⁄2"
(38 mm) from 3 remaining wires. Strip
insulation back 1" (25 mm).
Shape ends
of wires into
a hook.
C
B
A
E
D
F
5. Remove the center terminal block screw.
6. Remove the appliance neutral ground
wire from the external ground conductor
screw. Fasten under center, silver-
colored terminal block screw.
7. Connect the ground wire (green or bare)
of the direct wire cable to the external
ground conductor screw. Tighten screw.
8. Place the hooked end of the neutral wire
(white or center) of the direct wire cable
under the center screw of the terminal
block (hook facing right). Squeeze hook
end together. Tighten screw.
9. Place the hooked ends of the other
direct wire cable wires under the outer
terminal block screws (hook facing right).
Squeeze hooked ends together. Tighten
screws.
10. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
Direct Wire,
Four-wire electrical connection:
A.
3⁄4" (19 mm)
conduit connector
B. Neutral (w ite or center)
C. Ground wire (green or bare)
D. 10-gauge, 3 wire wit ground wire in
flexible metallic conduit
A. External ground conductor screw
B. Appliance neutral ground wire
C. Center terminal block screw
D. Outer terminal block screws
E. Neutral (center wire)
F. Green or bare ground wire
B
C
A
A. Conduit connector
B. Dryer cabinet
C. Connector screw

18
Connect Vent
1. Using a 4" (102 mm) clamp, connect vent to exhaust outlet in
dryer. If connecting to existing vent, make sure the vent is
clean. The dryer vent must fit over the dryer exhaust outlet
and inside the exhaust hood. ake sure the vent is secured to
exhaust hood with a 4" (102 mm) clamp.
2. ove dryer into final position. Do not crush or kink vent.
ake sure dryer is level.
Complete Installation
1. With dryer in final position place level on top of the dryer, first
side to side; then front to back. If the dryer is not level, adjust
the legs of the dryer up or down until the dryer is level.
2. Plug in dryer or reconnect power.
3. Check dryer operation (some accumulated time may be on
the timer on mechanical timer models due to factory testing).
Push START/RESTART button. Using a high heat cycle (not
the air cycle), let the dryer run for at least five minutes. Dryer
will stop when time is used up. Make sure the dryer turns off.
NOTE: Dryer door must be closed for dryer to operate. When
door is open, dryer stops, but timer continues to run. To
restart dryer, close door and push START/RESTART button.
4. If drying time is too long, make sure lint screen is clean.
5. Now start the dryer and allow it to complete a full heat cycle
(not air cycle) to make sure it is working properly.
A.
3⁄4" (19 mm)
conduit connector
B. Neutral (w ite or center)
C. 10-gauge, 3 wire wit ground wire in
flexible metallic conduit
A. External ground conductor screw
B. Center terminal block screw
C. Outer terminal block screws
D. Neutral (center wire)
E. Appliance neutral ground wire
Shape ends
of wires into
a hook.
Strip 31⁄2" (89 mm) of outer
covering from end of cable.
Strip insulation back 1" (25 mm).
If using 3 wire cable with ground
wire, cut green or bare wire even
with outer covering.
Three wire with ground wire: green or bare
wire cut short. Wire is not used. Dryer is
grounded through neutral conductor.
to
disconnect
box
1" (25 mm)
of wires
stripped of
insulation
31⁄2" (89 mm)
5. Loosen or remove the center terminal
block screw.
6. Place the hooked end of the neutral wire
(white or center) of the direct wire cable
under the center screw of the terminal
block (hook facing right). Squeeze
hooked end together. Tighten screw.
7.Place the hooked ends of the other
direct wire cable wires under the outer
terminal block screws (hook facing right).
Squeeze hooked ends together. Tighten
screws.
8. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
5. Remove the center terminal block screw.
6. Remove the appliance neutral ground wire
from the external ground conductor screw.
Connect the appliance neutral ground wire
and the neutral wire (white or center) of the
direct wire cable under the center, silver-
colored terminal block screw. Tighten
screw.
7. Connect the other wires to outer terminal
block screws. Tighten screws.
8. Insert tab of the terminal block cover into
slot of the dryer rear panel. Secure cover
with hold-down screw.
9. After reattaching the terminal cover,
connect a separate copper ground wire
from the external ground connector screw
to an adequate ground.
If codes permit and a separate ground wire is
used, it is recommended that a qualified
electrician determine that the ground path is
adequate.
Direct Wire,
Three-wire electrical connection: Use this method where local codes permit
connectin neutral round wire to
neutral wire:
Use this method where local codes do
not permit connectin neutral round
wire to neutral wire:
A
B
C
A
B
C
D
E
A. Separate copper ground wire
B. External ground conductor screw
C. Appliance neutral ground wire
D. Center terminal block screw
E. Outer terminal block screws
F. Neutral (center wire)
F
E
D
AC
B

19
You can change your door swing from a right-side opening to a
left-side opening, if desired.
1. Place towel (A) on top of dryer to protect surface.
2. Open dryer door. Remove bottom screws from cabinet side of
hinges (B). Loosen (do not remove) top screws from cabinet
side of hinges.
3. Lift door until top screws in cabinet are in large part of hinge
slot. Pull door forward off screws. Set door (handle side up)
on top of dryer. Remove top hinge screws from cabinet.
4. Remove screws attaching hinges to door.
5. Remove screws from all sides of door (5 screws). Holding
door over towel on dryer, grasp sides of outer door and gently
lift to separate it from inner door (do not pry apart). Do not pull
on door seal or plastic door catch.
REVERSING THE DOOR SWING (OPTIONAL)
A
B
D
C
6.Be certain to keep cardboard
spacer centered between doors.
Reattach outer door panel to
inner door panel so handle
is on the side where hinges
were just removed.
7. Attach door hinges to dryer door so that the larger hole is
at the bottom of the hinge and the hinge pin is toward the
door front.
8. Remove the 4 screws that attach 2 plugs (C) on the handle
side. Attach plugs to opposite side using the same 4 screws.
9. Insert screws into bottom holes on left
side of cabinet. Tighten screws halfway.
Position door so large end of door hinge
slot is over screws. Slide door up so
screws are in bottom of slots. Tighten
screws. Insert and tighten top screws in
hinges.
10. Close door and check that door strike aligns with door
catch (D).
Maintenance instructions:
■Clean lint screen after each cycle.
■Removing accumulated lint:
•From inside the dryer cabinet:
Lint should be removed every 2 years or more often,
depending on dryer usage. Cleaning should be done
by a qualified person.
•From the exhaust vent:
Lint should be removed every 2 years, or more often,
depending on dryer usage.
■Keep area around dryer clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
■Keep dryer area clear and free from items that would obstruct
the flow of combustion and ventilation air.
If dryer does not operate, check the following:
■Electric supply is connected.
■Circuit breaker is not tripped or house fuse is not blown.
■Door is closed.
■Controls are set in a running or “ON” position.
■START button has been pushed firmly.
■For gas dryers, check that gas supply shutoff valves are set
in open position.
If you need assistance:
The Commercial Laundry Support Center will answer any
questions about operating or maintaining your dryer not
covered in the Installation Instructions. Just dial 1-800 NO BELTS
(1-800-662-3587) — the call is toll free.
When you call, you will need the dryer model number and serial
number. Both numbers can be found on the serial-rating plate
located in the dryer door well.
MAINTENANCE INSTRUCTIONS

20
ELECTRONIC CONTROL SETUP
IMPORTANT
Electrostatic Disc arge (ESD)
Sensitive Electronics
ESD problems are present everywhere. ESD may damage
or weaken the electronic control assembly. The new control
assembly may appear to work well after repair is finished,
but failure may occur at a later date due to ESD stress.
■Use an anti-static wrist strap. Connect wrist strap to green
ground connection point or unpainted metal in the appliance.
-OR-
Touch your finger repeatedly to a green ground connection point
or unpainted metal in the appliance.
■Before removing the part from its package, touch the anti-
static bag to a green ground connection point or unpainted
metal in the appliance.
■Avoid touching electronic parts or terminal contacts; handle
electronic control assembly by edges only.
■When repackaging failed electronic control assembly in anti-
static bag, observe above instructions.
GENERAL USER INFORMATION
Blank display
This condition indicates the appliance is inoperative. Enter set-up
mode to view diagnostic code.
‘0 Minutes’ showing in display
This condition indicates the appliance cannot be operated. Coins
dropped or debit inputs during this condition will be stored in escrow
but cannot be used until normal operation is restored by opening
and closing the door. If a door switch fails, it must be replaced before
normal operation can be restored.
Cold Start (initial first use)
Appliance is programmed at the factory as follows:
■5 minutes dry time/quarter (coin 1).
■$1.50 dry price (fixed cycle with top off - PD Models).
■$0.00 dry price (fixed cycle - PR Models).
Warm Start (after power failure)
A few seconds after power is restored, if a cycle was in progress
at the time of the power failure, ‘RESELECT CYCLE’ will flash
in the display. This is to indicate the need for a fabric setting
key pad to be pressed to restart dryer.
Pricing
After the door is opened following the completion of a cycle, the
display indicates the cycle price (unless set for free operation). As
coins or debit inputs arrive, the display will change to lead the user
through the initiation of a cycle.
There are four (4) types of pricing:
Fixed ‘Vend’ Pricing
A dryer set up for ‘Fixed Cycle’ operation can only accept additional
time accumulated by increments equal to the length of a complete
dry cycle. A maximum of 99 minutes may be purchased; no
additional credit is given when 99 minutes is in the display.
Accumulator Pricing
If the price is set to one coin 1, then accumulator mode is in effect.
Cycle time can be purchased one coin at a time (PD models) up to
the maximum time of 99 minutes. Stacked PD machines will credit
all money to a cycle with a single button press while in accumulator
pricing.
Fixed Cycle With Top Off Pricing
A dryer set to offer ‘Top Off’ capability will allow time to be added to
an existing dry cycle in increments equal to the number of minutes
of dry time per quarter (coin 1), up to 99 minutes, regardless of the
cost required to start the machine. No credit is given for coins or
debit inputs entered when the control is displaying 99 minutes. PR
Models: In Enhanced Debit Mode, the top off price can be set
independently. (See VALUE OF COIN 2), and the top off time is
calculated according to the following equation:
top off price =top off time
full cycle price full cycle length
Penny increment offset is not applied to top off purchases.
Free Cycles
This is established by setting the cycle price to zero. When this
happens ‘SELECT CYCLE’ will appear rather than a cycle price.
Debit Card Ready
This appliance is debit card ‘cable’ ready. It will accept a variety of
debit card systems; but, does NOT come with a debit card reader.
Refer to the debit card reader manufacturer for proper machine
set-up. In models converted to a eneration 1 debit card system,
debit pulses represent the equivalent of one coin (coin 1).
