Maytag MDG52PN User manual

LEGENDARY MAYTAG DEPENDABILITY
Maximizing your equipment investment for over a half-century.
ENERGY-SAVING SOLUTIONS
Maytag built the first appliance ever to receive the ENERGY STAR®label. Today,
we offer energy-saving laundry solutions for all commercial laundry needs—
from highly efficient ENERGY STAR®-qualified washers to the most energy-
efficient dryers ever from Maytag—to help you save money and build profits.
ADVANCED CONTROLS
Includes Maytag®Accu Trac®audit system that uses a PDA to communicate
with the microprocessor controls— so you can set up, monitor and audit your
equipment in seconds.
CAPACITY:
• 50-Lb. Capacity
FOR YOUR CUSTOMERS:
• Extra-Large Door Opening with Dual-Pane Door Glass
• Time Remaining Digital Display
• Self-Diagnostic Microprocessor Controls
FOR YOUR OPERATION:
• Owner-Programmable Single-Phase Reversing Cylinder
• Low BTU and Fast Dry
• Enhanced Insulation For Greater Efficiency
• Front Serviceable
• Accu Trac® Audit System With Two-Way Data Communication
• Large-Capacity Lint Drawer
BUILT-TO-LAST™FEATURES:
• Maytag® Exclusive Waterless Fire Suppression System
• Heavy-Duty Motors
• Permanently Lubricated Bearings
• Four-Point Roller Support System
• 3-Year Limited Warranty—All Parts Covered
MDG52PN
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
MULTI-LOAD DRYER
MY130080
visit maytagcommerciallaundry.com
or call 800-662-3587

DRYER SPECIFICATIONS
MODEL MDG52PN
CAPACITY
Lbs. (kg)
50 (22.68)
Cu. ft. (cu. m) 16.02 (.453)
TUMBLER
Diameter—in. (mm)
37 (940)
Depth—in. (mm) 25.75 (654)
MOTOR
Single-phase, thermoprotected against overload, auto-reset

HP (kw) tumbler/blower .75 (.56) /.50 (.37)
Tumble speed—RPM 40 ± 1.5
AIRFLOW
Cfm (cmm)
600 (17.00)
GAS RATING
BTU/hr. (kcal/hr.)
110,000 (27,720)
GAS INLET
M.N.P.T. in. (mm)
1 inlet, 0.50 (12.7)
VOLTAGE/BREAKER/FUSE REQUIREMENTS
Volts (Hz)
120 (60)
Amps 25
Export models—options available 220–480V/50–60Hz/1PH or 3PH
COLOR
White

Stainless Steel

APPROXIMATE WEIGHT
Crated—lbs. (kg)
640 (290)
Uncrated—lbs. (kg) 610 (277)
DIMENSIONS
Height—in. (mm)
70.5 (1,791)
Width—in. (mm) 38.25 (972)
Depth—in. (mm) 40.13 (1,019)
Exhaust duct diameter—in. (mm) 8 (203)*
Door opening diameter—in. (mm) 27.38 (695)
*Requires 8" (203 mm) material if venting horizontally; 10" (254 mm) if venting vertically.
See specific instructions for proper installation.
Because of continuous product improvement, Maytag reserves the right to change specifications without notice.
At Maytag, we believe durable goods should remain just that.
That’s why every Maytag®product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship. It’s also why we stand behind our equipment
with solid service and support from our professional Maytag
laundry suppliers. Simply put, when you choose Maytag®
products, you ensure your peace of mind.
OUR COMMITMENT
TO DEPENDABLE QUALITY
2/13
MDG52PN
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
MULTI-LOAD DRYER
Maytag®Commercial Energy Advantage™
Multi-Load Dryer
MICROPROCESSOR NON-COIN
MAYTAG®LIMITED WARRANTY
3 YEARS — ALL PARTS
For a period from the date of original purchase through the time
listed above, the designated parts that fail in normal commercial
use will be repaired or replaced free of charge for the part itself,
with the owner paying all other costs, including labor, transportation
and customs duty. Chemical damage is excluded from all warranty
coverage. See complete warranty for details.
