Maytag MEW5527DDB User guide

24"
Penetration into cabinet:
Cutout height:
Recommended cutout location from floor :
Distance from face of cabinet to
front of closed door handle:
Cutout width:
Minimum cabinet width:
Distance from face of cabinet to
outer edge of open door (Door swing):
Minimum cabinet depth:
Overall unit width:
Overall unit height: 23 1/2" 28 1/4"
26 3/4"
15/16"
20 1/2"
4" - 33"
27 7/8"
25 1/2"
27"
Overall Dimensions
(not to scale)
28 1/4"
26 3/4"
Cabinet Opening
(not to scale)
4" - 33"
27 7/8"
25 1/2"
27"
24"
15/16"
23 1/2"
Electrical box
• Approved for undercounter installation.
• Do Not block air intake slots along bottom of oven.
• IMPORTANT: nylon grip nuts that hold crate bottom
must be removed before installation.
• A three-wire, single phase, A.C. 120/208-240 volt,
60Hz cycle electrical system protected by a 20 amp
fuse or comparable circuit breaker must be provided .
7/8" O.D. flexible cable 4 feet long is furnished by
manufacturer. Mount junction box in area under
plywood floor if adequate lower cabinet space is
available. Locate 1 1/4" conduit access hole in the
back right hand side of the plywood floor.
SEE PAGE 2 FOR UNDERCOUNTER INSTALLATION
www.dexpress.com DIMENSION EXPRESS Fax on Demand [phone]
• Dimensions (Actual Size) •
• NEVER reuse Data Sheets. Data Sheets are subject to change without • Call Dimension Express if you have any questions at [phone] •
notice. Dimension Express is a FREE service bureau and is updated daily, • Always refer to a current Code at a Glance or manufacturer directory •
it makes far more sense to spend the time necessary to request new Data • Data Sheet codes change on the first of odd numbered months at 12:01am •
Sheets for each project, as opposed to the problems, time, costs, and risks
associated with reusing old Data Sheets.
27" Wall Ovens:
MEW5527DDB and MEW5527DDW
• Product Model Number (s): •
Subject to change without notice. This system is designed to
be updated daily if necessary. Dimension Express is not
responsible for use of superseded, voided, or outdated data
sheets. Because of the difficulty or impracticability of deter-
mining actual damages, liability of Dimension Express shall
not exceed $50.00.
Copyright © Dimension Express, 2003.
This Data Sheet Includes Information On
Top overlap:
Bottom overlap:
Right side overlap:
Left side overlap: 5/8"
5/8"
0"
3/8"
Oven overlap distances when using
cutout dimensions listed above:
BN207.5 • A214 • • 031211 • 890 • 45012
• Additional Information •
214
Maytag
