Maytag MGS5875BDW - Slide in Gas Range Manual

Repair
Parts
List
MODEL NUMBER
MGS5875BDW
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
RANGE
©2005 Maytag Services

Section: CONTROL PANEL/TOP ASSEMBLY
C15-622
Model: MGS5875BDW
1

CONTROL PANEL/TOP ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 74011127 PANEL, CONTROL (WHT) 10 1
2 74010826 SUPPORT, CONTROL PANEL 10 1
3 74004821 CAP, END (WHT-RT) 10 1
3 74004822 CAP, END (WHT-LT) 10 1
4 74010975 KNOB (WHT) 10 4
5 74010687 CLOCK/OVERLAY (WHT) 10 1
- 74010979 BRACKET, CLOCK MTG 10 1
6 3601F221-45 BAFFLE, VENT COVER 10 1
7 74011136 TOP, MAIN (WHT) 10 1
8 74004005 SCREW, 6-32 X 5/16" 10 4
9 74010947 COVER, VENT (ALUM ALLOY) 10 1
10 7201P061-60 GASKET 10 1
11 74009121 GRATE, DOUBLE (GRY) 10 2
12 74004290 END CAP, VENT (RT-GRY) 10 1
12 74004291 END CAP, VENT (LT-GRY) 10 1
13 74010846 SHIELD, CONTROL 10 1
14 74007356 BUMPER, GRATE BOTTOM 10 4
- M0275597 SEALER, RTV CLEAR 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: GAS CONTROLS
C13-275
Model: MGS5875BDW
3

GAS CONTROLS
No. Part No. Description
Section:
Series Qty
1 74010965 MANIFOLD PIPE ASY. 10 1
2 74007420 CAP, BURNER (LRG-GRY) 10 1
3 74007413 BASE, BURNER (16K) Note: BASE, BURNER (RF) 10 1
- Y700502 SCREW 10 2
4 74010915 SWITCH/HARNESS ASSEMBLY 10 1
5 74009453 VALVE, 16K (MUELLER) Note: VALVE, BURNER (RF) 10 1
5 74009452 VALVE, 9K (MUELLER) Note: VALVE, BURNER (RR/LF) 10 2
5 74009451 VALVE, 5K (MUELLER) Note: VALVE, BURNER (LR) 10 1
6 74009416 SCREW 10 4
7 74004076 BURNER, BROIL 10 1
8 74007498 IGNITER, OVEN --W 10 2
9 3601F217-47 BAFFLE, BROIL BURNER 10 1
10 7103P030-60 NUT, WING 10 1
11 74004307 PLATE, BROIL FITTING 10 1
12 74010901 FITTING, BROIL 10 1
- 3807F446-45 SUPPORT, BURNER 10 1
13 74003960 BURNER, BAKE 10 1
14 74011133 TUBING, BURNER (RR) 10 1
14 74011134 TUBING, BURNER (LR) 10 1
14 74011132 TUBING, BURNER (LF) 10 1
14 74011131 TUBING, BURNER (RF) 10 1
15 74010908 HOLDER, ORIFICE (5K) Note: HOLDER, ORIFICE (5K-LR) 10 1
15 74010907 HOLDER, ORIFICE (16K) Note: HOLDER, ORIFICE (16K-RF) 10 1
15 74010909 HOLDER, ORIFICE (9.2K) Note: HOLDER, ORIFICE (9.2K-LF/RR) 10 2
- 74011755 IGNITER/BRACKET ASY 10 4
16 Y74010900 OVEN VALVE/REG ASSEMBLY 10 1
17 74004408 TUBING (3/8") 10 1
18 74004283 MODULE, SPARK (4+0) 10 1
19 7101P282-60 SCREW (10-24X5/16-NI) 10 4
20 74007020 SUPPORT, SPARK MODULE 10 1
21 74010944 TUBING, SUPPLY 10 1
- Y700502 SCREW 10 2
22 74007411 BASE, BURNER (5K) Note: BASE, BURNER (LR) 10 1
23 74007698 BASE, BURNER (LRG/BLK) Note: BASE, BURNER (RR/LF) 10 2
- Y700502 SCREW 10 4
24 74007422 CAP, BURNER (SMR-GRY) 10 1
25 74007752 CAP, BURNER (MED-GRY) 10 2
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: BODY
C14-924
Model: MGS5875BDW
5

BODY
No. Part No. Description
Section:
Series Qty
1 74010949 BACK, MAIN 10 1
2 74010987 INSULATION, WRAPPER 10 1
3 74010815 EXTENSION, MAIN BACK 10 1
4 74011142 HINGE, OVEN DOOR 10 2
5 74010959 VENT 10 1
6 74010904 SWITCH, LIMIT 10 1
7 74008263 SWITCH, DOOR LOCK 10 1
8 74004438 CORD, POWER 10 1
9 74011146 BOTTOM, BURNER BOX 10 1
10 74010832 TRIM, SIDE (WHT) 10 2
11 74006096 COVER, WIRE (REAR) 10 1
12 74005264 COVER, TERMINAL BLOCK 10 1
13 7101P112-60 SCREW 10 4
14 74010819 LATCH ASY 10 1
15 74010905 SHEILD, LOWER SIDE 10 2
16 74010822 PANEL, SHIELD (RT) 10 1
16 74010821 PANEL, SHIELD (LT) 10 1
17 74010823 FAN, COOLING 10 1
18 74010845 COVER, DOOR LATCH 10 1
19 74003976 SCREW, SHOULDER 10 4
20 74008264 INSULATOR 10 1
21 74001632 BRACKET, SWITCH ACTUATOR 10 1
22 22002368 SCREW----NA 10 2
23 74001629 SPRING, DOOR SWITCH 10 1
24 74003562 ROD, DOOR LIGHT SWITCH 10 1
25 74001631 BUMPER, ROD 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: OVEN/BASE
C12-543
Model: MGS5875BDW
7

OVEN/BASE
No. Part No. Description
Section:
Series Qty
1 74010805 SCREW, LEVELING LEG 10 4
2 74010899 BOTTOM, PEDESTAL 10 2
3 74010882 PEDESTAL, FRONT 10 2
4 74006591 SHIELD, WARMING DRAWER 10 1
5 74007129 SUPPORT, VALVE REGULATOR 10 1
6 74003565 RUNNER, DRAWER 10 2
7 74004078 ROLLER, DRAWER 10 2
8 74005231 SHAFT, STORAGE DRAWER ROLLER 10 2
9 74005230 NUT, LOCK (8-32) 10 2
10 74004465 PAN, BAKE BURNER 10 1
11 74005465 COVER, VALVE/REGULATOR 10 1
12 74001219 BAFFLE, OVEN FRONT 10 1
13 74006574 SHIELD, HEAT POUCH 10 1
14 74005564 BRACKET, ANTI-TIP 10 1
15 74010885 LAMP ASSEMBLY 10 1
- 7407P103-60 BULB, OVEN 10 1
16 74004944 SENSOR, OVEN (SHORT) 10 1
17 74009480 RETAINER, BOTTOM INSULATION 10 1
- 74010986 INSULATION, OVEN BOTTOM 10 1
18 74003976 SCREW, SHOULDER 10 2
19 74010812 SUPPORT, OVEN BOTTOM 10 2
20 74010948 BOTTOM, OVEN 10 1
21 74001757 RACK, OVEN 10 2
22 7101P124-60 SCREW W/WASHER 10 22
23 74009589 RACK, CREATE A SPACE HALF 30" 10 1
24 74009587 INSERT, HALF RACK 30" 10 1
25 74010902 FAN, CONVECTION 10 1
26 74008315 COVER, CONVECT FAN 10 1
27 74010814 RETAINER, CONV INSULATION 10 1
28 7101P124-60 SCREW W/WASHER 10 6
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR/DRAWER
C11-871
Model: MGS5875BDW
9

DOOR/DRAWER
No. Part No. Description
Section:
Series Qty
1 74003642 LINING, DOOR 10 1
2 74004224 TAPE, SINGLE SIDED (WHT) 10 2
3 74001574 NUT, SNAP (ROUND-BLK) 10 4
4 7201P046-60 GASKET, DOOR 10 1
5 74005546 SPACER, RUBBER 10 2
6 74003644 FRAME, GLASS 10 1
7 74003645 GLASS, INNER 10 2
8 74003647 INSULATION, OVEN DOOR 10 2
9 74009502 BAFFLE, OVEN DOOR 10 1
10 74004857 GLASS W/TAPE ASSY 10 1
11 74003650 RETAINER, GLASS 10 2
12 74009690 TRIM, DOOR TOP (WHT) 10 1
13 74009699 BRACKET, DOOR HANDLE (LT) 10 1
13 74009698 BRACKET, DOOR HANDLE (RT) 10 1
14 74010972 HANDLE, DOOR (WHT) 10 1
15 74006635 SCREW W/WASHER (HANDLE MTG) 10 2
16 12002358 KIT, DOOR TRIM (WHT) 10 1
17 74009687 SUPPORT, GLASS (WHT) 10 1
18 74009540 SCREW (WHT) 10 9
19 12002396 KIT, DOOR GLASS (WHT) 10 1
20 74008333 DRAWER, STORAGE 10 1
21 74010896 BRACKET, DRAWER 10 2
22 74004078 ROLLER, DRAWER 10 2
23 74005231 SHAFT, STORAGE DRAWER ROLLER 10 2
24 7103P082-60 NUT 10 2
25 2404F030-51 LINING, DRAWER PANEL 10 1
26 74003407 PANEL, DRAWER (WHT) 10 1
27 74004310 SCREW, PANEL 10 2
28 74005230 NUT, LOCK (8-32) 10 2
29 74009540 SCREW (WHT) 10 2
30 74005546 SPACER, RUBBER 10 2
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

SUPPLEMENTAL INFORMATION
No. Part No. Description
Section:
Series Qty
- 8113P581-60 MANUAL, USE & CARE 12 1
- 8113P496-60 MANUAL, USE & CARE 10 1
- 74011352 WIRE (WHT/2)/2 CURCUIT PLUG 11 1
- 74011350 WIRE (18G WHT/2) 10 1
- 74011351 HARNESS, MAIN 11 1
- 74010943 HARNESS, MAIN 10 1
- 74010914 HARNESS, SPARK 10 1
- 74010849 HARNESS, SENSOR/LATCH 10 1
- 74011053 KIT, LP ORIFICE 10 1
- 12002708 ORIFICE KIT (NAT) 10 1
- K71FILLW KIT, EXTRUSION FILLER (WHT) 10 1
- W10124350 NOT REQUIRED PART OR SEE NOTE Note: ACCESSORY FILLER KITS 10 0
- UXA1100AAW KIT, SIDE PANEL (WHT) 10 1
- W10124350 NOT REQUIRED PART OR SEE NOTE Note: ACCESSORY SIDE PANEL KITS 10 0
- 74011435 PLUG, SIDE TRIM (WHT) 10 8
- W10124350 NOT REQUIRED PART OR SEE NOTE Note: ACCESSORY SIDE TRIM PLUGS 10 0
11
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15003735
Model: MGS5875BDW
12
