CABINET PARTS
1
For Model: MBB1952HEW14
(White)
Part No. W10201417 Rev. A
REFRIGERATOR
4−08 Litho In U.S.A. (pl) (eeb)

CABINET PARTS
2
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10137641 Use & Care Guide
67003882 Energy Guide
W10169671 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310729 White
4 67005064 Label, Fill Tube
5 67006118 Roller Assy. (2)
6 12627302 Clip, Grille
7 67006744 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
10 67001098 Cover, Fill Tube
11 67006380 Screw
12 67005822 Screw
13 A3076901 Plug−Button
14 67006303 Screw (3)
15 Hinge, Center
67006960 White
16 67003868 Foot Brake
17 Cover, Corner
67003484 White
18
12566604ED Hinge, Top
19 12479901 Plate, Cover
20 67006564 Screw (4)
21 Cover Hinge
67001014 White
22 Grille, Toe
(Includes Clips)
67003849 White
23 67007018 Pin, Bottom Hinge
24 67006662 Screw
25 67006425 Screw
26 Hinge, Bottom
67001069 White
27 67001173 Cover, Water Valve
28 67006101 Cover, Unit
29 Cover, LW Hinge
12561901W White
30 67001066 Tube, Drain
31 67001067 Clip, Drain Tube
32 M0274057 Shim
33 B5759649 Gasket
34 67006715 Screw (2)

FREEZER LINER PARTS
3
For Model: MBB1952HEW14
(White)
W10201417

FREEZER LINER PARTS
4
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 67005874 Guide, Fill Tube
4 67001285 Cover, Light
5 67003636 Motor, Evaporator
6
Y12570701 Socket, Light
7 67001045 Panel Control
8 67001046 Control,FZ Temp.
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005868 Cover, Evaporator
12 67006425 Screw
13
W10121318 Grommet
14 67001286 Module, Freezer
Control
15
W10167028 Clip, Evap. Motor
16 67005653 Switch, Light
17 67006530 Screw
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 67002286 Gasket, Bottom
21 B8381501 Gasket
22 13024802 Grille, Fz Air
23
W10167023 Shroud, Evap.Fan
24 2169142 Blade, Fan
(Evaporator)
25 67003420 Knob, FZ Control
Following Parts Not Illustrated
W10130480 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Model: MBB1952HEW14
(White)
W10201417

FREEZER DOOR PARTS
6
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION
1 Door, Freezer
W10176974 White
2 Handle, Door
67005140 White
3 Gasket, Door
W10130150 White
4 67006831 Screw, Handle
5 Plug, Button (2)
10712401 White
6 Plug−Handle Hole
12246601 White
7 67004977 Bushing (4)
8 Stop, Door
67003779 White
9 67006287 Screw
10 67003397 Retainer,
Door Shelf

REFRIGERATOR LINER PARTS
7
For Model: MBB1952HEW14
(White)
W10201417

REFRIGERATOR LINER PARTS
8
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67002083 Module, Light
3 67001040 Belt, Damper
4 67001034 Tensioner, Belt
5 67001036 Timer, Defrost
6 C3680310 Switch, Light
7 67002512 Knob, Front
8 67001035 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67002301 Cover, Light
12 12990514 Screw
13 67003878 Cover, Damper
14 67003803 Insulation
15 67003410 Damper/Gear
Assembly
16 67001033 Knob, Gear
17 M0310343 Plug Button
White
18 67001038 Gasket, Damper
19 67002085 Pan, Timer
Light Housing
Following Parts Not Illustrated
67001043 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
9
For Model: MBB1952HEW14
(White)
W10201417

REFRIGERATOR DOOR PARTS
10
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION
1 Door, Refrigerator
67001138 White
2 67006682 Screw−Handle (2)
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 Bucket, Door
67001141 Small (2)
67001021 Medium (2)
6 Plug−Handle Hole
12246601 White
7 Plug, Button (2)
10712401 White
8 Gasket, Door
W10130148 White
9 Handle, Door
67003129 White
10 67006287 Screw
11 Stop, Door
67003779 White
12 67006439 Nameplate
13 67002505 Retainer, Ref Door
14 Bushing (4)
67004977 White
15 Trim, Handle−Top
67005131 White
16 12248201 Screw
17 Trim−Handle,
Bottom
67005137 White

UNIT PARTS
11
For Model: MBB1952HEW14
(White)
W10201417

UNIT PARTS
12
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67006914 Basepan
4 67006425 Screw
5 67005491 Block, Condenser
6
W10174591 Tube, Discharge
7
W10119856 Harness, Evap.
Heater
8 67004713 Pan, Drain
9 61004743 Grommet (3)
10 67002135 Heater, Defrost
11
W10131991 Clip, Capacitor
12
W10174592 Start Device
13 61003210 Gasket
14 67003426 Thermostat,
Defrost
15 67005680 Grommet (2)
16 67006573 Screw
17
W10169124 Grommet (4)
18 67006133 Condenser
19 67006432 Screw
20 67001133 Tray, Drip
21 67006737 Screw
22 12002051 Evaporator Kit
(Incl. Evap., Heat
Shield, & Instr.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060301 Harness, Unit
with Power Cord
27 2317845 Drier
28
W10130129 Compressor
(Includes items
11,12,17,27,29)
29 67005562 Capacitor
30 67006434 Axle, Roller (2)
31
W10158508 Shroud
32 67004953 Bracket, Fan Motor
33 67004954 Screw
34 10547003 Clip, Drier
35 67005149 Roller (2)
36
W10137529 Grommet, Cond. (4)
37 10623002 Clip, Evaporator
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
4.25 ozs.
(R−134A)

SHELF PARTS
13
For Model: MBB1952HEW14
(White)
W10201417

SHELF PARTS
14
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION
1 67001057 Rail, Center
Crisper
2 67003879 Trim, Crisper
3 67006608 Screw
4 67006231 Shelf−Freezer
5 12754803 Basket, Freezer
(Lower)
6 12204808 Glass Shelf
7 67006360 Screw
8 67005864 Slide, Humidity
Control
9 67004127 Divider, Basket
(Upper)
10 67003400 Frame, Shelf
11 67006400 Screw
12 67001308 Pan, Deli
13 67001054 Glide, Left
14 67001053 Glide, Right
15 67006626 Screw, Glide (4)
16 67002569 Pan, Crisper
17 67001155 Brace, Crisper
18 67001153 Frame, Crisper
19 67006877 Glass, Crisper Cover
20 67001073 Ladder, Center
21 67001302 Ladder, Side
22 10459930 Trim, Front Shelf
23 10946012 Trim, Rear Shelf
24 61002140 Tray, Ice (2)
25 61002267 Pan, Ice

OPTIONAL PARTS
15
For Model: MBB1952HEW14
(White)
W10201417
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392901 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
4392901 Biscuit
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
4392900 Biscuit (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
31462 Cleaner, 10 oz.
Stainless Steel
FIELD INSTALLABLE
ICE MAKER
67001740 Complete Icemaker
