1
CABINET PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
04−08 Litho In U.S.A. (mat) Part No. W10197413 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10153840 Use & Care Guide
W10158909 Service & Wiring
Sheet
W10153841 Energy Label
W10154390 Instruction Sheet,
Door Removal
628370 Modular Icemaker
Service Sheet
2 2174748 Front Roller (2)
3 3400517 Screw
4 2196236 Roller (Rear) (2)
5 489427 Screw
6 2155013 Clip, Grille
7 2304249 Screw Plate (2)
8 2260507 Housing, Water
Filter
9 2209697 Shim (2)
10 489500 Screw (2)
11 4396841 Water Filter
12 2203770 Hinge Top (FC)
13 2203771 Hinge, Top (RC)
14 488500 Screw
15 Hinge Cover
2203407W White
2203407B Black
16 2217075 Hinge Bottom (2)
17 Cap, Water
Filter
2260518W White
2260518B Black
18 3400113 Screw (4)
19 2260519 Block, Housing
Support
20 3400858 Screw
21 Filler, Wrapper
2201014 White
2201017 Black
22 Grille
2260500W White
2260500B Black
23 489497 Screw
24 Button, Water
Filter
2260503W White
2260503B Black
25 3400103 Screw (2)
26 489290 Screw
27 489464 Screw
28 2304697 Tube, Filter
Inlet
29 2255012 Tube, Filter
Outlet
30 940139 Drain Fitting
31 1108438 Extension Tube
32 1108439 Clip, Drain Tube
33 2252035 Cover, Unit
34 Cabinet (Not A
Serviceable Part)
35 Hinge Cover
2203408W White
2203408B Black
36 8281227 Screw
37 549193 Clamp, Service
Cord
38 489084 Screw
39 2155311 Door Closer,
Lower Cam (2)
40 489483 Screw (2)

REFRIGERATOR LINER PARTS
3
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2257741 Louver
3 2256035 Bracket, Dual
Crisper Light
4 489084 Screw
5 2311637 Wire Harness,
Crisper Light
6 2311612 Clip, Control
Box (2)
7 2209753 Air Diffuser
Assembly
8 2152019 Air Diffuser
Cover
9 2150331 Cover, Conduit
10 486298 Screw
11 2162085 Socket
12 2217199 Reservoir
13 527949 Light Bulb
14 2209769 Light Lens
15 488280 Screw (2)

REFRIGERATOR SHELF PARTS
4
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 2309518 Snack Pan
2 2174150 Glass, Cover
3 2311726 Cover, Pan
4 2255593 Trim, Pan
5 2179259 Glass, Cover
7 2255592 Trim, Meat Pan
9 2179342 Slide, Humidity
Control
10 2188652 Crisper Pan
11 2188724 Meat Pan
12 2196485 Stud Assembly
13 3400894 Screw
14 2179343 Housing, Humidity
Control
15 2196483 Stud Assembly
16 8281158 Screw
17 2309561 Shelf Assembly,
Spillguard
18 2309523 Shelf Assembly,
Slide−Out
19 2311722 Egg Bin

5
FREEZER LINER PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

6
FREEZER LINER PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 2163762 Cup, Shelf
Mounting (12)
3 2171713 Door, Ice
Compartment
4 2309597 Shelf, Wire
5 842534 Clip, Air Duct (2)
6 2196206 Support, Stud (4)
7 2309757 Freezer Bin
8 1115373 Switch, Rocker Arm
9 8281158 Screw (4)
10 2196483 Stud Assembly (4)
11 2309596 Shelf, Wire
12 2171714 Shelf, Top
Compartment
13 2171705 Light Lens
14 527949 Light Bulb
15 2162085 Light Socket
16 Slide, Container
1119237 Left Side
1119293 Right Side
17 489100 Screw (4)
18 3400893 Screw
19 2309522 Shelf, Wire

MOTOR AND ICE CONTAINER PARTS
7
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

MOTOR AND ICE CONTAINER PARTS
8
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 2183726 Bracket, Motor
2 2188385 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Solenoid
5 489355 Screw (2)
6 2311639 Wiring Assembly,
Ice Dispenser
7 489399 Screw (6)
8 2205716 Coupling, Motor
9 489478 Screw
10 2162085 Socket, Light
11 2196091 Ice Container
12 1119005 Spacer, Step (3)
13 1119007 Spacer, Flat (2)
14 2257022 Blade, Rotary
15 2257023 Blade, Rotary
16 2257024 Blade, Rotary
17 489235 Washer, Plain
18 1119009 Blade, Fixed (2)
19 2157405 Block, Blade
20 489229 Roll Pin
21 2196295 Auger
22 2209781 Drum
23 2171682 Floating Baffle
24 1119018 Nut, Bearing
25 2155231 Control Arm
26 1119020 Spring, Return
27 1119021 Retainer Clip, Rod
28 488886 Screw
29 2180348 Housing, Crusher
30 1119017 Deflector, Ice
31 489234 Washer, Plain
32 489236 Retainer Ring
33 2204321 Front Cover,
Ice Container
34 527949 Light Bulb
35 2171706 Light Lens,
Dispenser
100 2209780 Ice Container
(Complete)

9
REFRIGERATOR DOOR PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

REFRIGERATOR DOOR PARTS
10
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes Item 6)
W10153847 White
W10159873 Black
W10150583 Stainless−VCM
W10170585 Stainless Steel
2 2256101 Door, Compartment
4 2187172 Door Bin (3)
6 Door Gasket,
Magnetic
2309528 Mist Beige
2309529 Black
7 Handle
12743701W White
12743701B Black
8 2308091 Thimble−Top
9 13067101 Clip
10 12990203 Screw
11 2182178 Door Closer,
Upper Cam
12 489420 Screw
13 Bracket, Door Stop
2206629 Chrome
2206629B Black
14 Accent, Handle
12834803W White
12834803B Black
15 2324038 Nameplate
16 489491 Screw (4)
17 2177962 Trivet, Shelf
18 3400012 Screw

11
FREEZER DOOR PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

12
FREEZER DOOR PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(Includes Item 8
And Dispenser
Front Parts)
W10153844 White
W10159876 Black
W10170562 Stainless−VCM
W10170570 Stainless Steel
2 Handle
12743701W White
12743701B Black
3 2182181 Thimble−Top
4 2326016 Screw
5 2309718 Trivet (4)
6 3400012 Screw
7 Door Gasket,
Magnetic
2309532 Mist Beige
2309533 Black
8 2209681 Trim, Door Shelf
9 488500 Screw
10 2311641 Wire Harness
11 2182179 Door Closer,
Upper Cam
12 489420 Screw
13 Bracket, Door Stop
2206629 Chrome
2206629B Black
14 Accent, Handle
12834803W White
12834803B Black
15 12990203 Screw
16 13067101 Clip
17 2154473 Connector

13
DISPENSER FRONT PARTS
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

DISPENSER FRONT PARTS
14
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2 3196537 Screw
3 2194719 Retainer, Levers
4 2304772 Spring, Torsion
5 2196195 Pin
6 2180353 Door, Ice
7 2304355 Door Mechanism
Assembly
8 2205686 Mechanism Delay
9 Grille, Overflow
2206670W White
2206670B Black
10 2304317 Water Fitting
Assembly (Includes
Water Tube)
11 Lever, Ice
Dispenser
2203562W White
2203562B Black
12 2180224 Guide, Ice
13 2180200 Lamp Holder
14 2162361 Switch (2)
15 2183771 Bracket, Control
16 3406124 Bulb, Light
17 Lever, Water
Dispenser
2203561W White
2203561B Black
18 Switch Assembly
(Not Available
Order #23)
19 Overlay, Front
Cover
(Not Available
Order #23)
20 2180236 Wire Assembly
21 Front Cover,
Housing
(Not Available,
Order #23)
22 489000 Screw
23 Front Cover
Assembly
(Includes Items
18, 19, 20 & 21)
W10153855 White
W10159864 Black
24 625834 Spacer, Switch (2)
25 2195051 Strain Relief
26 2304673 Bracket, Dispenser
27 2252127 Sleeve, Delay
Mechanism

UNIT PARTS
15
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

UNIT PARTS
16
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 12825802 Fan, Blade
3 2223953 Condenser
Assembly
4 489464 Screw
5 2208280 Clip, Wire
6 8533993 Screw
7 2255199 Clip, Retaining
8 2161302 Sleeve
10 4387765 Wire, Capacitor
(Service Only)
12 4387731 Cover, Terminal
(Service Only)
13 2154697 Overload
(Service Only)
14 2205765 Tube Suction
15 2311725 Clip, Condenser(2)
16 2319793 Start Device,
Combination
(Start Relay and
overload) for
production
compressor only
17 Capacitor
2169373 Production
1118576 Service
18 2261599 Tube, Condenser to
Heat Loop
19 2183454 Relay
(Service Only)
21 489478 Screw
22 2188823 Evaporator
23 2161324 Clamp
24 2188874 Fan, Motor
25 1105523 Tray, Evaporator
26 2217194 Heat Shield
27 Drier
2319825 Production
2317845 Service
28
W10120459 Compressor
(Includes Items
10, 12, 13, 17,
19, 27 & 39)
(Also Order
876765 Tube Kit)
30 2157397 Unit Mounting
Frame
31 2187783 Unit, Harness
(Includes Power
Cord)
32 2181929 Fan, Motor Bracket
33 2188175 Heater, Defrost
34 489373 Screw
35 Grommet (4)
1100826 (Production)
4387558 (Service)
36 489340 Screw (5)
37 2196202 Air Baffle
38 2155547 Clip, Heat Shield
39 2206281 Unit Cover, Bottom
40 489396 Clip
41 2305374 Unit Mounting
Rail
42 8281232 Screw
43 2260517 Guard, Fan
44 2263990 Strap
45 489427 Screw
46 2209709 Union
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 oz.
(R−134A)

AIR FLOW PARTS
17
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 2182120 Fan Scroll
2 2155590 Retainer,
Fan Motor
3 2161231 Air Scoop
4 2319914 Bi−Metal, Defrost
5 2203593 Air Duct Freezer
7 2315549 Fan Motor
8 2169142 Fan Blade
9 2304241 Gasket, Evaporator
Cover (2)
10 2176759 Fan Grommet (2)
11 2182146 Duct, Icemaker
12 2310114 Harness, Fan
Evaporator
(Includes #4)
13 2155789 Gasket, Fan Scroll
14 2203876 Gasket
15 2203841 Cover, Evaporator
16 8281159 Screw (6)
17 489478 Screw
18 2203595 Support, R.S
19 2203596 Support, L.S

CONTROL PARTS
18
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10159858 Control Box
2 2311611 Mounting Bracket
3 2219875 Light Switch
4 2200096 Cover, Light Lens
5 2303824 Electronic
Control
6 489398 Screw (2)
7 2213462 Led Assembly
8 2198202 Thermostat
9 3196537 Screw
10 2182195 Cam Assembly
11 1110560 Bearing Body
12 2196062 Damper Control
13 1110559 Pivot Arm
14 487869 Screw (2)
15 2162085 Light Socket
16 2196001 Tube Barrier,
Thermostat
17 2311792 Light Bulb
18 2311632 Control Box
Harness
19 1115374 Clip, Wiring
20 1115375 Clip, Wiring
21 2311631 Connecting Rod
22 489285 Fastener, Push−On
23 2311614 Thermostat Knob
24 2311615 Control Knob
25 627068 Screw
26 489203 Spring Washer

ICEMAKER PARTS
19
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413

ICEMAKER PARTS
20
For Models: MSD2542VEW00, MSD2542VEB00, MSD2542VEU00, MSD2542VES00
(White) (Black) (Stainless−VCM) (Stainless Steel)
W10197413
Illus. Part
No. No. DESCRIPTION
1 489084 Screw
2 2209774 Chute, Water
3 628379 Clip, Fuse
4 2223137 Tube, Water
5 489478 Screw
6 2304757 Filter Valve Asm
7 489385 Tube Clip
8 2174155 Cover
9 488649 Screw
10 628228 Mold & Heater
Assembly (Also
Order 542638
11 628356 Cup, Water Fill
12 627843 Ejector
13 2182124 Ice Striper
14 2194712 Support
15 2315522 Retainer,
Thermostat
16 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
17 8533917 Screw
18 489276 Screw
19 2304354 Shut Off Arm
20 628320 Bracket
21 626678 Module Assembly
(Includes #23)
22 488208 Screw
23 Motor
(Not Serviced,
Order #21)
100 626662 Complete Icemaker
Assembly
