Maytag FRONT-LOADING AUTOMATIC WASHER User manual

www.maytag.com
www.maytag.ca
www.maytag.ca
W10326417A
W10336732A - SP
Para una versión de estas instrucciones en español, visite: www.whirlpool.com
FRONT-LOADING
AUTOMATIC WASHER
Use & Care Guide
For questions about features, operation/performance,
parts, accessories, or service, call: 1-800-688-9900
or visit our website at...
In Canada, call: 1-800-807-6777
or visit our website at...
LAVEUSE AUTOMATIQUE À
CHARGEMENT FRONTAL
Guide d'utilisation et d'entretien
Pour assistance, installation, ou service, composez le :
1-800-807-6777
ou visitez notre site internet à..

2
TABLE OF CONTENTS
WASHER SAFETY........................................................................................... 2
INSTALLATION REQUIREMENTS................................................................. 3
Tools and Parts........................................................................................... 3
Options...................................................................................................... 4
Location Requirements .............................................................................. 4
Drain System.............................................................................................. 5
Electrical Requirements.............................................................................. 6
INSTALLATION INSTRUCTIONS.................................................................. 7
Remove Transport System.......................................................................... 7
Connect the Inlet Hoses.............................................................................7
Connect the Drain Hose ............................................................................ 8
Secure the Drain Hose............................................................................... 9
Level the Washer ....................................................................................... 9
Complete Installation ................................................................................. 9
FEATURES AND BENEFITS..........................................................................10
WASHER USE ..............................................................................................11
Starting Your Washer ...............................................................................11
Using the Proper Detergent...................................................................... 11
Using the Dispenser.................................................................................12
Pausing or Restarting................................................................................12
Changing Cycles and Options..................................................................13
Status Lights .............................................................................................13
Cycles ...................................................................................................... 14
Normal Sounds ........................................................................................15
Options & Modifiers ................................................................................15
Laundry Guide.........................................................................................16
LAUNDRY TIPS ...........................................................................................17
Loading....................................................................................................17
Stain Removal Guide ............................................................................... 18
WASHER CARE............................................................................................19
Cleaning Your Washer.............................................................................19
Water Inlet Hoses.....................................................................................19
Vacation, Storage, and Moving Care........................................................ 20
TROUBLESHOOTING................................................................................. 21
WARRANTY................................................................................................. 25
ASSISTANCE OR SERVICE.........................................................BACK COVER
TABLE DES MATIÈRES
SÉCURITÉ DE LA LAVEUSE ......................................................................... 26
EXIGENCES D'INSTALLATION................................................................... 27
Outillage et pièces................................................................................... 27
Options.................................................................................................... 27
Exigences d'emplacement........................................................................ 27
Système de vidange ................................................................................. 29
Spécifications électriques......................................................................... 30
INSTRUCTIONS D'INSTALLATION ........................................................... 31
Élimination des accessoires de transport.................................................. 31
Raccordement des tuyaux d'alimentation................................................ 31
Raccordement du tuyau de vidange......................................................... 32
Immobilisation du tuyau de vidange........................................................ 33
Réglage de l'aplomb de la laveuse........................................................... 33
Achever l'installation ............................................................................... 33
CARACTÉRISTIQUES ET AVANTAGES ....................................................... 34
UTILISATION DE LA LAVEUSE................................................................... 35
Mise en marche de la laveuse.................................................................. 35
Utilisation du détergent approprié ........................................................... 35
Utilisation du distributeur ........................................................................ 36
Pause ou remise en marche..................................................................... 37
Modification des programmes et options................................................. 37
Témoins lumineux................................................................................... 37
Programmes............................................................................................. 38
Sons normaux.......................................................................................... 40
Options et Modificateurs ......................................................................... 40
Guide de lessivage................................................................................... 41
CONSEILS DE LESSIVAGE........................................................................... 42
Chargement ............................................................................................. 42
Guide pour l'élimination des taches ........................................................ 43
ENTRETIEN DE LA LAVEUSE....................................................................... 44
Nettoyage de la laveuse........................................................................... 44
Tuyaux d'arrivée d'eau ............................................................................ 45
Précautions à prendre avant les vacances,
un entreposage ou un déménagement..................................................... 45
DÉPANNAGE .............................................................................................. 46
GARANTIE................................................................................................... 50
ASSISTANCE OU SERVICE....................................... COUVERTURE ARRIÉRE
WASHER SAFETY

3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. The
parts supplied are in the washer drum.
Tools needed for connecting the water inlet hoses
■Pliers (that open to 19/16" [39.5 mm])
■Flashlight (optional)
Tools needed for connecting the drain hose
■Locking pliers (that open to 19/16" [39.5 mm])
Tools needed for installation
■Open end wrenches 14 mm and 13 mm
■Level
■Wood block
■Ruler or measuring tape
Parts supplied
AB
F
G
C
DE
A. Drain hose form
B. Inlet hose (2)
C. Inlet hose washer (4)
D. Drain hose
E. Transport bolt hole plug (4)
F. Beaded strap
G. Hose clamp

4
Alternate Parts
Your installation may require additional parts. If you are interested
in purchasing one of the items listed here, call the toll-free number
on the cover or in the “Assistance or Service” section.
If You Have You Will Need to Buy
Laundry tub or
standpipe taller
than 96" (2.4 m)
Sump pump system (if not already
available)
Overhead sewer Standard 20 gal. (76 L), 30" (762 mm) tall
drain tub or utility sink and sump pump
(available from local plumbing suppliers)
Floor drain Siphon break, Part Number 285834;
additional drain hose
Part Number 8318155; and connector kit,
Part Number 2858835
Drain hose too
short 4 ft. (1.2 m) drain hose extension kit,
Part Number 2858863
Water faucets
beyond reach of fill
hoses
2 longer inlet hoses:
5ft ( 1.5 m) Black EPDM (2 pack)
8212641RP, 10 ft ( 3.0 m) Black EPDM
(2 pack) 8212656RP
Options
Pedestal
You have the option of purchasing pedestals of different heights
separately for this washer. You may select a 10" (254 mm) or a
15.5" (394 mm) pedestal. The pedestal will add to the total height
of the washer.
Optional pedestal
Pedestal
Height Approximate Height with
Washer
Color Model
Number
10" (254 mm) 46" (1168 mm) White WHP1000SQ
15.5" (394 mm) 51.5" (1308 mm) White WHP1500SQ
15.5" (394 mm) 51.5" (1308 mm) Lunar
Silver XHP1550WL
Stack Kit
Are you planning to stack your washer and dryer? To do so you will
need to purchase a Stack Kit.
To order, call the dealer from whom you purchased your washer or
refer to the “Assistance or Service” section. Ask for Part Number
8572546.
Location Requirements
Selecting the proper location for your washer improves
performance and minimizes noise and possible washer “walk.”
Your washer can be installed under a custom counter, or in a
basement, laundry room, closet, or recessed area. See “Drain
System.”
Companion appliance location requirements should also be
considered. Proper installation is your responsibility.
You will need:
■A water heater set to deliver 120°F (49°C) water to the washer.
■A grounded electrical outlet located within 6 ft. (1.8 m) of where
the power cord is attached to the back of the washer. See
“Electrical Requirements.”
■Hot and cold water faucets located within 4 ft. (1.2 m) of the hot
and cold water fill valves, and water pressure of 20-100 psi
(137.9-689.6 kPa).
■A level floor with a maximum slope of 1" (25 mm) under entire
washer. Installing the washer on soft floor surfaces, such as
carpets or surfaces with foam backing, is not recommended.
■A sturdy and solid floor to support the washer with a total weight
(water and load) of 400 lbs (180 kg).
Do not operate your washer in temperatures below 32°F (0°C).
Some water can remain in the washer and can cause damage in low
temperatures.
Installation clearances
■The location must be large enough to allow the washer door
to be fully opened.
■Additional spacing should be considered for ease of installation
and servicing. The door opens more than 90°, and it is not
reversible.
■Additional clearances might be required for wall, door, and floor
moldings.
■Additional spacing of 1" (25 mm) on all sides of the washer
is recommended to reduce noise transfer.
■Companion appliance spacing should also be considered.
Washer Dimensions
5 0
1
/ 4 "
(1276 mm)
27 "
(686 mm)
36 "
(914 mm)
30
1
/ 2 "
(775 mm)

5
Recommended spacing for custom undercounter installation
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
27 "
(686 mm)
1 "
(25 mm)
1 "
(25 mm)
2 " (50 mm)
36 " min.
(914 mm)
Recommended spacing for recessed or closet installation, with or
without a pedestal
The dimensions shown are for the recommended spacing.
Recessed area or closet installation
3 "
(76 mm)
3 "
(76 mm)
34 " min.
(864 mm)
48 in.
2
*
(310 cm
2
)
24 in.
2
*
(155 cm
2
)
1 "
(25 mm)
4 "
(102 mm)
32 "
(813mm)
A. Side view - closet or confined area
B. Closet door with vents
Recessed or closet installation - Washer on pedestal
1 "
(25 mm)
4 "
(102 mm)
18 " min.
(457 mm)
32 "
(813mm)
1 "
(25 mm)
27 "
(686 mm)
A. Recessed area
B. Side view - closet or confined area
Recommended spacing for recessed or closet installation, with
stacked washer and dryer
The dimensions shown are for the recommended spacing.
3"
(76 mm)
3"
(76 mm)
48 in.
2
*
(310 cm
2
)
24 in.
2
*
(155 cm
2
)
27 "
(686 mm)
1 "***
(25 mm)
1 " (25 mm)
12 " (305 mm)
1 "***
(25 mm)
5
1
/ 4 "**
(133 mm)
72 "
(1829 mm)
*Min. top and bottom air openings for closet door.
**External exhaust elbow requires additional space.
***Wall, door, and floor molding may require additional spacing.
Recommended spacing for cabinet installation
The dimensions shown are for the recommended spacing.
For cabinet installation, with a door, the minimum ventilation
openings in the top are required.
1 "
(25 mm)
(178 mm)
7
(178 mm)
7 "
(22
9
(102 mm)
4 "
(25
m
1
"
(686 mm)
27 "
(800 mm)
31
1/2
"
Drain System
The washer can be installed using the standpipe drain system (floor
or wall), the laundry tub drain system, or the floor drain system.
Select the drain hose installation method you need. See “Tools and
Parts.”
Standpipe drain system - wall or floor (views A & B)
The standpipe drain requires a minimum diameter standpipe of
2" (50 mm). The minimum carry-away capacity can be no less than
17 gal. (64 L) per minute.

6
The top of the standpipe must be at least 30" (762 mm) high and no
higher than 96" (2.4 m) from the bottom of the washer.
30 " min.
(762 mm)
A B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L) capacity. The top
of the laundry tub must be at least 30" (762 mm) above the floor.
Floor drain system (view D)
The floor drain system requires a siphon break that may be
purchased separately. See “Tools and Parts.”
The siphon break must be a minimum of 28" (710 mm) from the
bottom of the washer. Additional hoses might be needed.
30 " min.
(762 mm)
28 " min.
(710 mm)
C D
Electrical Requirements
■A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical
supply is required. A time-delay fuse or circuit breaker is
recommended. It is recommended that a separate circuit serving
only this appliance be provided.
■This washer is equipped with a power supply cord having a
3 prong grounding plug.
■To minimize possible shock hazard, the cord must be plugged
into a mating, 3 prong, grounding-type outlet, grounded in
accordance with local codes and ordinances. If a mating outlet
is not available, it is the personal responsibility and obligation of
the customer to have the properly grounded outlet installed by a
qualified electrician.
■If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
■Do not ground to a gas pipe.
■Check with a qualified electrician if you are not sure the washer
is properly grounded.
■Do not have a fuse in the neutral or ground circuit.

7
INSTALLATION INSTRUCTIONS
Remove Transport System
IMPORTANT: Position the washer so that the rear of the washer is
within approximately 3 ft. (900 mm) of its final location.
There are 4 transport bolts in the rear panel of the washer that
support the suspension system during transportation. These bolts
also retain the power cord inside the washer until the bolts are
removed.
1. On the back of the washer, loosen the 4 transport bolts using a
13 mm wrench.
2. Once the bolt is loose, move it to the center of the hole and
completely pull out the bolt, including the plastic spacer
covering the bolt.
3. Once all 4 bolts are removed, discard the bolts and spacers.
Then pull the power cord through the opening of the rear panel
and close the hole with the attached cap.
4. Cover the bolt holes with the 4 transport bolt hole plugs.
NOTE: If the washer is to be transported at a later date, call your
local service center. To avoid suspension and structural damage,
your machine must be properly set up for relocation by a certified
technician.
Connect the Inlet Hoses
Insert new flat washers (supplied) into each end of the inlet hoses.
Firmly seat the washers in the couplings.
A B
A. Coupling
B. Washer
Connect the inlet hoses to the water faucets
Make sure washer drum is empty and flat washers have been placed
into hose couplings. Both hoses must be used for the washer to
work properly.
1. Attach a hose to the hot water faucet. Screw on coupling by
hand until it is seated on the washer.
2. Attach a hose to the cold water faucet. Screw on coupling by
hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten. Damage to the coupling or water faucet
can result. Both faucets must be turned on for the washer to work
properly.
Clear the water lines
■Run water through both faucets and inlet hoses, into a laundry
tub, drainpipe or bucket, to get rid of particles in the water lines
that might clog the inlet valve screens.
■Check the temperature of the water to make sure that the hot
water hose is connected to the hot water faucet and that the cold
water hose is connected to the cold water faucet.

8
Connect the inlet hoses to the washer
IMPORTANT: Make sure that the flat washers have been placed into
the hose couplings.
C H
C. Cold water inlet
H. Hot water inlet
1. Attach the hot water hose to the washer’s hot (H) water inlet
valve. Screw on coupling by hand until it is seated on the
washer.
2. Attach the cold water hose to the washer’s cold (C) water faucet.
Screw on coupling by hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the valve.
Damage to the valves can result.
4. Turn on the water faucets completely and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the risk
of hose failure. Record hose installation or replacement dates on
the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
Connect the Drain Hose
Remove drain hose from washer drum
1. Use locking pliers, squeeze hose clamp tabs together and insert
over the end of drain hose.
2. Slide drain hose onto washer connection.
3. Once drain hose is in place, release pliers.
4. Washer drain system can be installed using a floor drain, wall
standpipe, floor standpipe, or laundry tub.
Laundry tub drain or standpipe drain
A B
Connect the drain hose form to the corrugated drain hose.
A. Snap either end of the drain hose form to the drain hose at the point where
the corrugation begins.
B. Bend drain hose over drain hose form and snap into place.
To keep drain water from going back into the washer:
■Use the drain hose form, and do not force excess drain hose into
standpipe. Hose should be secure, but loose enough to provide
a gap for air.
■Do not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See Floor drain under “Tools and
Parts.”

9
Secure the Drain Hose
Drain hose must be secured to stop the hose from moving when
water is pumped out. If the drain hose moves, water may end up on
the floor.
1. Drape the power cord over the washer top.
2. Move the washer to its final location.
3. Place the drain hose in the laundry tub or standpipe as shown.
See illustrations A and B.
A B C
NOTES:
■Do not force excess drain hose back into the rear of the washer.
■To avoid siphoning, do not seal or put more than 4½"
(114 mm) of the drain hose into drainpipe or standpipe.
4. If the washer faucets and the drain standpipe are recessed, put
the hooked end of the drain hose in the standpipe as shown. See
illustration C.
Level the Washer
Proper foot to floor contact and leveling your washer avoids
excessive noise and vibration.
NOTE: Installing washer on soft floor surfaces, such as carpets or
surfaces with foam backing, is not recommended.
1. Slide the washer to its final location.
2. Check that all four feet are in firm contact with the floor.
3. Check the levelness of the washer by placing a level on the top
edge of the washer, first side to side then front to back.
If the washer is against a wall, move the washer out slightly
before tipping back. If the washer is not level, first prop the front
with a wooden block and adjust the front feet height moving the
hexagonal plastic part as necessary. Repeat to adjust back feet.
4. Make sure all four feet are in firm contact with the floor. Then
check that the washer is perfectly level (use a level). Repeat steps
1-3 until washer is level.
5. After the washer is level, and all four feet are in firm contact with
the floor, use a 9/16" (14 mm) open-end wrench to turn the
locknuts on the feet, tightly against the washer cabinet.
IMPORTANT: All four locknuts on the feet must be tightened. If
the locknuts are not tight against the washer cabinet, the washer
may vibrate.
6. The washer should not move front to back, side to side, or
diagonally when pushed on its top edges.
7. Confirm the levelness of the washer.
Complete Installation
1. Check the electrical requirements. Be sure that you have the
correct electrical supply and the recommended grounding
method. See “Electrical Requirements.”
2. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
3. Check that you have all of your tools.
4. Dispose of/recycle all packaging materials.
5. Check that both water faucets are on.
6. Check for leaks around faucets and inlet hoses.
7. Plug into a grounded 3 prong outlet.
8. Read “Washer Use.”
9. To test and to clean your washer, measure 1/2 the detergent
manufacturer’s recommended amount of High Efficiency (HE)
detergent for a medium-size load. Pour the detergent into the
detergent dispenser. Select NORMAL and then press START/
PAUSE. Allow the washer to complete one whole cycle.
Use only HE High Efficiency detergent.

10
FEATURES AND BENEFITS
Your new front-loading high efficiency washer, was designed to
conserve resources and lower your water and energy bills. The
washer is designed to determine and then provide the amount of
water needed for the best performance. The time of operation may
be greater for this new system than for a conventional washer.
Electronic Controls
Flexible electronic controls are easy to use whether you are a
beginner or an expert.
Auto Water Level
Adjusting to the size of the load, this feature allows the washer to
use the minimal amount of water needed to clean and rinse the
clothes. With a low water level, you can obtain the same results.
Because only the required amount of water is used, the washer
saves energy, too. You can obtain the same washing results for
small and large load sizes.
Larger Load Size
Since there is no agitator, you can wash larger, bulkier items such
as an average size sleeping bag. You are also able to wash more
clothes at one time, which means fewer loads. You can wash a
pillow or a large stuffed teddy bear.
Suspension System
To reduce washer “walk” and “off-balance” conditions, your new
washer combines:
■2 Springs to isolate vibration
■3 Shock absorbers at the washer base to minimize movement
Stainless Steel Drum
The stainless steel drum eliminates corrosion and enables higher
spin speeds for more water extraction, reducing drying time.
Adaptive Variable Speed Motor
The motor adapts to the load size and to the cycle selected to give
the optimum cleaning, rinsing, and spinning conditions. The motor
can handle slow speeds needed for delicate items and is powerful
enough to drive an average clothes load up to high-speed spin.
Spin Speeds
This washer automatically selects the spin speed based on the cycle
selected. For some cycles, the default spin speed can be changed if
desired. This washer offers up to three different spin speed choices.
Add Clothes
This option is available in all wash cycles except Rinse, Drain &
Spin, and Clean Washer with AFFRESH™ cycle. When this option is
available at the beginning of the cycle, the Add Clothes status light
will illuminate for the first 7 minutes. This washer allows a 7-minute
period in which other garments may be added to a load.
Dynamic Balance
A precision balancing system allows the washer to reach high-
speed spins. The washer spins faster so that clothes coming out of
the washer will have less moisture than with traditional top load
machines. In addition, if the Dynamic Balance system detects off-
balance loads during spinning, it redistributes the clothes so that
they are evenly balanced.
Smart Dispensers
The three compartments in the dispenser allow loading of all
laundry products before the washer is started. The products
will be dispensed into the wash at the optimal time for high-
performance cleaning. The bleach release system is included
in the detergent advantage system. The detergent is added at
the beginning of the cycle, and the bleach is added after the
enzymes have had a chance to do their cleaning. The fabric
softener is dispensed in the rinse cycle or in the 2nd Rinse, if
selected. The Detergent Advantage System Dispenser tray is
easily removed for cleaning.
Use only HE High Efficiency detergent.

11
WASHER USE
cycle signal
dryness level
temperatures
Starting Your Washer
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
The following is a guide to using your washer. Please refer to
specific sections of this manual for more detailed information.
Do not store laundry products on the top surface of this washer.
Vibration is normal during operation.
Using the Proper Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE” or “High Efficiency.” This wash system,
along with less water, will create too much sudsing with a regular
non-HE detergent. Using regular detergent will likely result in washer
errors, longer cycle times, and reduced rinsing performance. It may
also result in component failures and noticeable mold or mildew. HE
detergents are made to produce the right amount of suds for the best
performance. Follow the manufacturer’s instructions to determine the
amount of detergent to use.
Use only HE High Efficiency detergent.
First Wash Cycle Without Laundry
Before washing clothes for the first time, if not completed during
the final installation step, choose the Normal cycle and run it
without clothes. Use only HE High Efficiency detergent. Use 1/2
the manufacturer’s recommended amount for a medium-size load.
This initial cycle serves to ensure the interior is clean before
washing clothes.
For All Wash Cycles
1. To load washer
Open the washer door by pulling on the handle. Sort laundry
according to color and type of fabric. Place a load of sorted
clothes in the washer. Do not tightly pack the washer. Tightly
packed items can cause poor cleaning.
■Always empty pockets. Small items can be caught within
the washer resulting in noise or plugging the pump.
■The washer can be fully loaded, but not tightly packed.
Washer door should close easily.
■Mix large and small items. Avoid washing a single item.
Load evenly.
■Wash small items such as infant socks in mesh garment bags.
It is recommended that more than one garment bag be used
and that each garment bag be filled with equal amounts of
material.
■When unloading garments, occasionally check under the
rubber rim at the front of the tub for small items.
2. Close the washer door by pushing it firmly until the lock clicks.
After a lock check at the beginning of the cycle, the washer door
will remain locked during the wash cycle.
NOTE: After any wash cycle is completed, the door must be
opened and then closed before a new cycle can begin. The
door can be opened only if Start/Pause is selected while the
Add Clothes light is illuminated or if the cycle has been
canceled. See “To cancel a cycle” in the “Changing Cycles
and Options” section.
3. Open the dispenser drawer and add laundry products to the
detergent, bleach, or fabric softener compartments. Close drawer
slowly to avoid spills. See “Using the Dispenser.”
4. Turn on the washer by pressing POWER/CANCEL or by turning
the cycle selector. The indicator light for the selected cycle will
illuminate. When selecting a Wash Cycle, the preset Wash Temp
and Spin Speed for the selected cycle will illuminate. These
settings provide the recommended fabric care for the selected
cycle. See “Cycles.”
5. Select the desired Options. Not all Options are available with all
cycles. See “Options.”
6. If desired, select the Cycle Signal button. The signal is helpful
when you are washing items that should be removed from the
washer as soon as it stops. Press Cycle Signal On, if no signal is
desired, Press Cycle Signal Off. Light will not be illuminated.

12
7. To begin the wash cycle immediately
Press and hold START/PAUSE (for approximately 1 second).
■You will hear the door locking, unlocking, and locking
again. This is normal.
■If you do not press START/PAUSE within 5 minutes of
choosing a cycle, the washer automatically shuts off.
■When the wash cycle is complete, the DONE status light
illuminates, the door unlocks, and the wash load can be
removed from the washer. The washer powers down
automatically 5 minutes after the cycle is complete and the
DONE light goes off until door is opened. To power down
the washer manually after the wash cycle is complete, press
POWER/CANCEL once.
8. To begin the wash cycle later
Press DELAY START until the desired delay time (in hours) is
displayed. Press START/PAUSE. The indicator will remain
illuminated during the desired time selected.
IMPORTANT: When delaying a cycle, use only powdered
detergents in the main wash compartment since liquid
detergents may seep out of the compartment during Delay,
before the wash cycle begins.
Using the Dispenser
Your new washer has a dispenser drawer with three separate
compartments for your laundry products—detergent, liquid chlorine
bleach, and liquid fabric softener. Laundry products are diluted and
dispensed automatically at the proper time during the wash cycle,
making it unnecessary for you to return to the washer during the
cycle to add them.
It is normal for small amounts of water to remain in the dispensers
when the wash cycle is complete.
Do not put laundry products directly into the wash tub. Always use
the proper dispensers when adding laundry products.
Choosing the Right Detergent
Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE” or “High Efficiency.” This wash
system, along with less water, will create too much sudsing with a
regular non-HE detergent. Using regular detergent will likely result in
washer errors, longer cycle times, and reduced rinsing performance. It
may also result in component failures and noticeable mold or mildew.
HE detergents are made to produce the right amount of suds for the
best performance. Follow the manufacturer's instructions to
determine the amount of detergent to use.
Use only HE High Efficiency detergent.
To fill dispenser compartments
1. Pull out the dispenser drawer.
2. Add the desired laundry products to the proper compartment.
3. Push in the dispenser drawer slowly and completely (to avoid a
spill).
A
B
C
D
Dispenser
A. Dispenser release lever
B. Main Wash detergent compartment
C. Liquid chlorine bleach compartment
D. Fabric softener compartment
Main Wash detergent compartment
(Letter B in Dispenser Illustration)
Add liquid or powdered HE detergent to this compartment for your
main wash cycle.
■Liquid color-safe bleach or oxi products may be added to the
Main Wash compartment along with liquid detergent.
■Powdered color-safe bleach or oxi products may be added to the
Main Wash compartment along with the powdered detergent.
■Do not mix powdered and liquid products in the Main Wash
compartment.
■Use the measurement device which comes with the detergent.
Add no more than the manufacturer's recommended amount.
NOTE: Overfilling could cause an oversudsing condition.
Chlorine bleach compartment
(Letter C in Dispenser Illustration)
Add NO MORE THAN 2/3 cup (160 mL) liquid chlorine bleach to
this compartment. The bleach will be automatically diluted and
dispensed at the best time during the first rinse after the wash cycle.
This compartment cannot dilute powdered bleach.
■Use only liquid chlorine bleach in this dispenser. Do not use this
dispenser to add powdered chlorine or any form of color-safe
bleach or oxi products to your load.
■Always measure liquid chlorine bleach. Use a measuring cup
with a pour spout; do not guess. Follow the manufacturer’s
directions for proper use.
■Do not fill beyond the “MAX” level.
NOTE: Overfilling could cause garment damage.
Fabric softener compartment
(Letter D in Dispenser Illustration)
Follow the manufacturer's instructions to determine the amount of
fabric softener to use. Fabric softener will be automatically
dispensed in the final rinse or in the 2nd Rinse, if selected.
■Do not fill beyond the “MAX” level.
Pausing or Restarting
1. To pause the washer at any time, press START/PAUSE.
2. To continue the cycle, press and hold START/PAUSE (for
approximately 1 second).

13
Changing Cycles and Options
Not all Options are available with all Cycles.
Cycles and Options can be changed anytime before START/PAUSE
is pressed.
To cancel a cycle
1. Press POWER/CANCEL.
2. The washer powers down, the door unlocks, and clothes can be
removed.
NOTE: If the water level or the temperature is too high, the washer
will drain automatically before the door unlocks.
To change Options after the cycle has started
1. Press START/PAUSE once.
2. Press the desired OPTIONS. If the option is not available,
the machine will beep.
3. Press and hold START/PAUSE (for approximately 1 second)
to continue the cycle.
NOTE: Press and hold FRESH SPIN™ option button (approx.
1 second) to add periodic tumbling. See “Options” for complete
cycle description. The light will glow when selected and will
remain flashing for up to 6 hours or until the washer is stopped by
either pressing POWER/CANCEL or opening the door.
To drain the washer manually
1. Press START/PAUSE.
2. Press RINSE, DRAIN & SPIN.
3. Deselect 2ND RINSE Option.
4. Press and hold START/PAUSE (for approximately 1 second)
to begin the drain.
5. When the spin is complete, the door unlocks. Items can be
removed from the washer.
Status Lights
These lights show which portion of the cycle the washer is
operating. They also indicate when you can add an additional
item to the wash cycle and when the controls are locked.
Add Clothes
You can add items to the washer after the wash cycle has started,
if the Add Clothes status light is illuminated. All cycles have this
feature except Rinse, Drain & Spin and Clean Washer with
AFFRESH™ cycle.
To add items
1. Press START/PAUSE. The washer door unlocks, and items can
be added.
2. To continue the cycle, close the door and press and hold
START/PAUSE (for approximately 1 second).
NOTE: To add garments after the Add Clothes period is over,
the wash cycle needs to be canceled, the items added, and a
new wash cycle started.
Done
The Done light comes on after the cycle is complete. The light will
stay on until door is opened.
Controls Locked
Lock/Unlock Controls
This feature avoids unintended use of the washer and cycle or
option changes during a cycle. When this light is illuminated, all
buttons are disabled except for START/PAUSE and POWER/
CANCEL. You can lock the controls while the washer is in
operation.
To lock the controls
Press and hold CYCLE SIGNAL option for 3 seconds.
The Controls Locked status light illuminates.
To unlock the controls
Press and hold CYCLE SIGNAL option for 3 seconds until the
CONTROLS LOCKED Status light turns off.
Door Locked
Depending on the stage of the wash cycle, the door locks and
unlocks automatically. The status light indicates when the door is
locked. To unlock, press START/PAUSE.

14
Cycles
Wash Cycles
Choose Wash Cycles by rotating the Cycle selector knob to the
desired cycle. Each cycle is designed for different types of fabric and
soil levels.
■Each cycle has a preset cycle time, WASH TEMP, SPIN SPEED,
and may have preset Options. The preset settings provide the
recommended fabric care for the selected cycle.
■The preset settings can be changed anytime before START/
PAUSE is pressed. Not all Options (WASH TEMP, SPIN SPEED)
are available with all Cycles. To change settings after the cycle
has started, press START/PAUSE, then select the desired settings.
Press and hold START/PAUSE (for approximately 1 second) to
continue the cycle.
Preset Cycle Settings
Each cycle has a preset Cycle Time, WASH TEMP, and SPIN SPEED.
These settings provide the recommended fabric care for the selected
cycle. See chart.
Cycle Estimated
Time*
(hr:min)
Temp Spin
Speed
Power Wash 2:30 Hot/Cold Max
Extract™
Whites 1:39 Hot/Cold Ex High
Heavy Duty 1:24 Hot/Cold Max
Extract™
Normal 0:59 Warm/
Cold Max Extract™
Comforters 1:06 Warm/
Cold Low
Rapid Wash 0:30 Warm/
Cold Max Extract™
Delicate 0:34 Cold/
Cold Low
Silk 0:37 Cold/
Cold Low
Rinse,
Drain & Spin 0:26
0:14 Cold NA Ex High Ex High
Soak 0:30 Warm/
Cold No Spin
Clean Washer with
AFFRESH™ 0:56 N/A High
*The cycle times vary automatically based on your water pressure,
water temperature, detergent, and clothes load. The cycle time will
be extended if oversudsing occurs or the load is unbalanced.
My Cycle
This convenient feature allows you to save your most commonly
used cycle and any option and modifiers you may use frequently.
Simply select your cycle; make your option/modifier selections and
press and hold the My Cycle button until you hear a tone that
indicates your selection has been saved and the My Cycle light will
illuminate. To use this combination again, simply press POWER/
CANCEL, press MY CYCLE, then press START/PAUSE. The cycle,
option and modifier lights saved should also illuminate. To change
cycles, rotate cycle knob to another setting or press any other
buttons besides the Power/Cancel or Start/Pause.
NOTE: This cycle only retains the last settings saved and will not
indicate other than the initial tone that the button was pressed long
enough to save selections.
Power Wash
Use this cycle for overly soiled garments and household items that
need additional cleaning effort. This cycle combines high and
medium tumbling action, with MaxExtract™ spin speed and
additional water in last rinse to flush excess dirt from the load. For
better results, use this cycle combined with the stain treat option.
Whites
This cycle is especially designed for cleaning loads of soiled
white fabrics with the addition of chlorine bleach. Hot washing
temperatures assure optimal bleach activity. An additional rinse
provides optimal rinse performance to avoid chlorine residues on
your laundry. This cycle combines fast-speed tumbling, longer wash
time, and ex high spin speed to shorten drying time. It also includes
an 2nd Rinse option, which is automatic with Whites cycle.
Heavy Duty
Use this cycle to wash loads of sturdy, colorfast fabrics and heavily
soiled garments. This cycle combines fast-speed tumbling, longer
wash time, and MaxExtract™ spin speed to shorten drying times.
Normal
Use this cycle to wash loads of no-iron fabrics such as sport shirts,
blouses, casual business clothes, permanent press blends, cottons
and linens, and synthetic fabrics. This cycle combines medium-
speed tumbling, MaxExtract™ spin speed, and a load cooling
process to reduce wrinkling.
Comforters
Use this cycle to wash normally soiled blankets and comforters.
This cycle starts with a soak to thoroughly saturate your large load.
This is followed by medium wash action and low spin speeds to
maintain load balance.
Cycle Estimated
Time*
(hr:min)
Temp Spin
Speed

15
Rapid Wash
Use this cycle to wash small loads of 2-3 lightly soiled garments that
are needed in a hurry. This cycle combines fast-speed tumbling, a
shortened wash time, and high-speed spin to shorten drying time.
Large wash loads will result in the machine increasing the wash
time.
Delicate
Use this cycle to wash sheer fabrics and lingerie. This cycle
combines low-speed tumbling and low-speed spin for gentle fabric
care.
■Use mesh garment bags to wash undergarments such as
underwire bras, items with strings, and small items such as
socks.
Silk
Use this cycle to clean washable silk and ultra delicate garments
(check label instructions to make sure the garment is washable.)
This cycle gently tumbles and drains with the lowest spinning to
gently clean garments and minimize wrinkling. Garments will
contain a higher amount of water at the end of this cycle because of
the low spin action.
Rinse, Drain & Spin
Use this cycle to get a rinse and spin only. This cycle combines fast-
speed tumbling and ex high spin speed. If desired, you can reduce
the spin speed by selecting the speed you want from the SPIN
SPEED option.
Rinse is useful for:
■Loads that need rinsing only.
■Adding fabric softener to a load using the fabric softener
dispenser.
Using Drain & Spin:
1. Select Rinse, Drain & Spin cycle.
2. Deselect 2nd Rinse option.
Soak
Use the Soak cycle to help remove set-in stains on fabrics. This
cycle provides a soak time with warm or cold water followed by
drain. Extra water, a short tumbling phase for equal distribution of
the laundry, and a soaking time without drum movement improve
the removal of set-in stains. Drain without spin assures gentle
treatment, even for delicate articles.
Clean Washer with AFFRESH™ cycle
Use the Clean Washer with AFFRESH™ cycle once a month to keep
the inside of your washer fresh and clean. This cycle uses a higher
water level in combination with AFFRESH®washer cleaner tablet or
chlorine bleach to thoroughly clean the inside of your washing
machine. See “Cleaning Your Washer.”
IMPORTANT: Do not place garments or other items in the washer
during the Clean Washer with AFFRESH™ cycle. Use this cycle
with an empty wash drum.
Normal Sounds
As with any new product, you will hear sounds that you are not
accustomed to. You may hear various sounds when the door is
locked or unlocked, and during the washing, rinsing, or spinning
process. Between changes in wash actions, there will be
momentary pauses. You will hear water spraying and splashing
during the wash and rinse cycles. These new sounds and pauses
are part of normal washer operation. See “Troubleshooting.”
Options & Modifiers
You can customize your wash by adding options to your cycle
selections. You can add or change an option after starting a cycle
anytime before the selected option begins. Not all Options are
available with all cycles.
cycle signal
dryness level
temperatures
■See the “Laundry Guide” section for an overview of possible
options for each Wash Cycle selection.
■If an option is available with a selected cycle, the light for that
option will illuminate when selected.
■If an option is unavailable with a selected cycle, there will be a
short tone and the light for that option will not illuminate when
selected.
FRESH SPIN™option
Use this option when you are not able to unload your clothes, soon
after the wash cycle ends. This option provides periodic tumbling
for up to 6 hours to help freshen your clothes. During this time, the
“Done” indicator remains activated, the door remains locked, and
the FRESH SPIN™ option indicator light will flash. The FRESH
SPIN™ option will automatically stop and the door lock will be
released after this time expires, or if you press POWER/CANCEL at
anytime to unload your laundry.
Delay Start
Use this to begin the wash cycle later.
■Press DELAY START until the desired time (in hours) shows in the
estimated time remaining display.
■Press START/PAUSE. The countdown to the wash cycle will show
in the display window.
2nd Rinse
A 2nd rinse can be used to aid in the removal of detergent residue
from garments. This option provides an additional rinse with the
same water temperature as in the normal rinse. It is automatic for
the Whites cycle. You may select or deselect by pressing 2ND
RINSE.
MaxExtract™
Use this option to improve drying times for heavy fabrics or special
care items. This options final spin increases to the highest speed and
reduces excess water to save energy.
Wash Temp
Each cycle has a preset water temperature setting. To change the
water temperature, press the WASH TEMP button until the desired
setting is illuminated.
Select a water temperature based on the type of load you are
washing. Use the warmest wash water safe for fabrics. Follow
garment label instructions.
The water temperature for all rinses are cold, which save energy.

16
Temperature Guide
Wash Temp Suggested Fabrics
HOT Whites and pastels
Heavy soils
WARM Bright colors
Moderate to light soils
COLD Colors that bleed or fade
Light soils
In wash water temperatures colder than 60°F (15.6°C), detergents
do not dissolve well. Soils may be difficult to remove.
Controlled Temperature
Warm and cold wash temperatures are sensed and maintained by
regulating the amount of hot and cold water from your faucet. This
provided excellent cleaning while saving energy.
ATC (Auto Temp Control) electronically senses and maintains a
uniform water temperature. ATC regulates incoming hot and cold
water.
■Cold rinse is not controlled and will be the same as your cold
faucet.
Spin Speed
Each cycle has a preset spin speed. To change the spin speed, press
the SPIN SPEED button until the desired setting is illuminated.
Cycle Signal
This signal is helpful when you are removing items from the washer
as soon as it stops. Press Cycle Signal button Signal On or Signal
Off.
Prewash
Use this option for loads of heavily soiled items that need
pretreatment.
■Add detergent to Main Wash compartment of the dispenser
drawer.
■This option adds tumbling time prior to the selected main cycle.
The washer continues automatically from prewash into the main
wash cycle.
Stain Treat
Use this option for heavily soiled loads that need improved stain
treatment. When Stain Treat is selected, the water temperature of
the selected wash cycle is automatically set to warm and provides
additional time of medium and high speed tumbling. This option
will provide optimal removal of organic stains such as blood.
Laundry Guide
Refer to this chart for suggested load types and their corresponding cycles. Listed to the right are the options available to each of these washer
cycles.
CYCLE SUGGESTED LOAD TYPE AVAILABLE OPTIONS
Delay
Start 2nd
Rinse Cycle Signal Fresh Spin™Prewash Stain Treat
Power Wash Soiled garments and household items ✔ ✔ ✔ ✔ ✔ ✔
Whites Soiled white fabrics ✔ ✔ ✔ ✔ ✔ ✔
Heavy Duty Heavily soiled underwear, towels, shirts, etc.,
made of cotton
✔ ✔ ✔ ✔ ✔ ✔
Normal Normally soiled blouses, shirts, overalls, etc., made
of polyester, nylon, cotton, linen, or cotton blends
✔ ✔ ✔ ✔ ✔
Comforters Normally soiled blankets and comforters ✔ ✔ ✔ ✔ ✔
Rapid Wash Small loads of 2-3 lightly soiled cotton, polyester,
nylon, and cotton blends.
✔ ✔ ✔ ✔
Delicate Curtains and delicateclothing, dresses, skirts, shirts,
and blouses.
✔ ✔ ✔ ✔
Silk Silk or ultra delicate fabrics labeled as machine
washable
✔ ✔ ✔
Rinse,
Drain & Spin All loads ✔ ✔ ✔ ✔
Soak Fabrics made of cotton, linen, polyester, or nylon ✔ ✔ ✔
Clean Washer with
AFFRESH™ No clothes, use AFFRESH®washer cleaner tablet
or chlorine bleach
✔✔

17
LAUNDRY TIPS
Preparing clothes for washing
Follow these recommendations to help you prolong the life of your
garments.
■Use only High Efficiency detergents. The package for this type of
detergent will be marked “HE” or “High Efficiency.” This wash
system, along with less water, will create too much sudsing with
a regular non-HE detergent. Using regular detergent will likely
result in washer errors, longer cycle times and reduced rinsing
performance. It may also result in component failures and
noticeable mold or mildew. HE detergents are made to produce
the right amount of suds for the best performance. Follow the
manufacturer's instructions to determine the amount of
detergent to use.
Use only HE High Efficiency detergent.
■Close zippers, snaps, and hooks to avoid snagging other items.
Remove pins, buckles, and other hard objects to avoid
scratching the washer interior. Remove non-washable trim and
ornaments.
■Empty pockets. Small items can be caught with the washer
resulting in noise or plugging the pump.
■Turn down cuffs; brush away lint and dirt.
■Turn wool and synthetic knits inside out to avoid pilling.
■Tie strings and sashes so they will not tangle.
■Mend tears, loose hems, and seams.
■Treat spots and stains.
■Stained or wet garments should be washed promptly for best
results.
■Mix large and small items, avoid washing single items, and load
evenly.
■Wash small items, such as infant socks, in a mesh garment bag.
To create a balanced load it is recommended that more than one
garment bag be used, and that each garment bag be filled with
equal amounts of material.
NOTE: If you are washing only small items, it is recommended
that more than one mesh garment bag be used, and that each
garment bag be filled with equal amounts of material.
Sorting
■Separate heavily soiled items from lightly soiled ones, even if
they would normally be washed together. Separate lint-givers
(towels, chenille) from lint-takers (corduroy, synthetics,
permanent press). When possible, turn lint-givers inside out.
■Separate dark colors from light colors, colorfast items from
noncolorfast items.
■Sort by fabric and construction (sturdy cottons, knits, delicate
items).
Unloading
■Remove clothes from washer after the cycle is completed. Metal
objects such as zippers, snaps, and buckles may rust if left in the
washer basket for a long time.
■When unloading garments, occasionally check under the
colored seal at the front of the tub for small items.
Loading
Loading suggestions
Heavy Work Clothes
2 pair pants
3shirts
3 pair jeans
1 coverall
Mixed Load
2 double sheets or
1 king size sheet(s)
4 pillowcases
6 T-shirts
6pairshorts
2shirts
2blouses
6 handkerchiefs
Towels
8 bath towels
8 hand towels
10 washcloths
1bathmat
Delicates
3 camisoles
4 slips
4 panties
2bras
2 nighties
Small Load cycle
(2-3 garments)
2 dress shirts
1 pair dress pants

18
Stain Removal Guide
Stain Use Liquid Chlorine or
Color-Safe Bleach Use suggested Wash Cycle Stain Use Liquid Chlorine or Color-Safe Bleach Use suggested Wash Cycle
Ink
✔Power Wash
Grass
✔Power Wash
Blood
✔Cold or Warm
Normal
Tomato
Products
✔Power Wash
Coffee/
Chocolate
✔Warm
Whites
Mud
✔Warm
Power Wash
Cosmetics
Heavy Duty
Deodorants
Heavy Duty
Dirty
Motor Oil
Warm
Heavy Duty
Ring around
the Collar
✔Normal
Do not tumble dry soiled or stained items. Heat may permanently set stains.

19
WASHER CARE
Cleaning Your Washer
Cleaning the Door Seal/Bellow
1. Open the washer door and remove any clothing or items from
the washer.
2. Inspect the colored seal/bellow between the door opening and
the basket for stained areas. Pull back the seal/bellow to inspect
all areas under the seal/bellow and to check for foreign objects.
A. Seal/Bellow
3. If stained areas are found, wipe down these areas of the seal/
bellow, using the procedure that follows.
a) Mix a dilute solution, using 3/4 cup (177 mL) of liquid
chlorine bleach, and 1 gal. (3.8 L) of warm tap water.
b) Wipe the seal/bellow area with the dilute solution, using a
damp cloth.
c) Let stand 5 minutes.
d) Wipe down area thoroughly with a dry cloth and let the
washer interior air dry with door open.
IMPORTANT:
■Wear rubber gloves when cleaning for prolonged periods.
■Refer to the bleach manufacturer’s instructions for proper use.
Washer Maintenance Procedure
This washer has a special cycle that uses higher water volumes in
combination with AFFRESH®washer cleaner or liquid chlorine
bleach to thoroughly clean the inside of the washer.
NOTES:
■Read these instructions completely before beginning the
cleaning process.
■If necessary, the cleaning cycle may be interrupted by pressing
the POWER/CANCEL button twice. However, this will not
immediately stop the cycle. The machine will continue with
several rinse and drain steps to ensure that all remaining
AFFRESH®washer cleaner or liquid chlorine bleach is rinsed
from the washer.
Begin procedure
1. Open the washer door and remove any clothing or items from
the washer.
2. Using the AFFRESH®washer cleaner (Recommended):
Add one AFFRESH®washer cleaner tablet to the washer drum.
If using liquid chlorine bleach:
3. Open the dispenser drawer and immediately add 2/3 cup
(160 mL) of liquid chlorine bleach to the bleach compartment.
NOTE: Do not add any detergent to this cycle. Use of more than
2/3 cup (160 mL) of bleach will cause product damage over
time.
4. Close the washer door and dispenser drawer.
5. Select the CLEAN WASHER with AFFRESH™ cycle.
6. Press START/PAUSE.
NOTE: The basket will rotate, then the door will unlock, lock
again, and then the cycle will continue.
■The machine will not fill, but the basket will rotate while the
washer runs a short sensing cycle. This will take
approximately 3 minutes.
7. The cycle will determine whether clothing or other items are in
the washer.
a)
b)
If no items are detected in the washer, it will proceed to
Step 8.
If the Wash LED light flashes, the door will unlock. Remove
clothing or items in the washer.
■Press POWER/CANCEL to cancel the flashing LED light.
Then repeat steps 1, 2, and 6 to start the cycle again.
8. Once the cycle has begun, allow the cycle to complete.
9. After the cycle is complete, leave the door open slightly, to allow
for better ventilation and drying of washer interior.
Always do the following to maintain washer freshness
■Use only HE High Efficiency detergent.
■Leave the door slightly open after each cycle to allow for better
ventilation and drying of washer interior.
■Repeat the cleaning procedure monthly.
■If the procedure does not sufficiently improve the machine
freshness, please evaluate your installation and usage conditions
for other causes.
Cleaning the exterior
Use a soft damp cloth or sponge to wipe up any spills. Occasionally
wipe the outside of your washer to keep it looking new. Use mild
soap and water. Do not use abrasive products.
Cleaning the dispenser drawer
The dispenser drawer is removable for easy cleaning.
1. Unlock the dispenser drawer by pressing the Release Lever. See
“Using the Dispenser.” Remove the drawer.
2. Remove the inserts (the siphon from the softener and bleach
compartments).
3. Wash the parts under running water.
NOTE: Do not wash components in the dishwasher.
4. Replace the inserts and return the dispenser to the drawer.
Water Inlet Hoses
Replace inlet hoses after 5 years of use to reduce the risk of hose
failure. Periodically inspect and replace inlet hoses if bulges, kinks,
cuts, wear or leaks are found.
When replacing your inlet hoses, record the date of replacement.

20
Vacation, Storage, and Moving Care
Install and store your washer where it will not freeze. Because some
water may stay in the hoses, freezing can damage your washer. If
storing or moving your washer during freezing weather, winterize it.
Non-use or vacation care:
Operate your washer only when you are at home. If you will be on
vacation or not using your washer for an extended period of time,
you should:
■Unplug washer or disconnect power.
■Turn off the water supply to the washer. This helps avoid
unintended flooding (due to a water pressure surge) while you
are away.
■Slightly open door to provide ventilation.
To winterize washer:
1. Put 1 qt (1 L) of R.V.-type antifreeze in the drum.
2. Run washer on a Rinse, Drain & Spin cycle.
3. Unplug washer or disconnect power.
4. Shut off both water faucets.
5. Disconnect water inlet hoses from faucets and drain.
To use washer again:
1. Flush water pipes.
2. Reconnect water inlet hoses to faucets.
3. Turn on both water faucets.
4. Plug in washer or reconnect power.
5. Run the washer through the Normal cycle with 1/2 the
manufacturer’s recommended amount of HE detergent for a
medium-size load, to clean the washer and remove the
antifreeze, if used.
To transport the washer:
1. If washer will be moved during freezing weather, put in 1 qt (1 L)
of R.V.-type antifreeze in the drum. Run washer on a Rinse,
Drain & Spin cycle.
2. Unplug the power cord.
3. Disconnect the drain hose from the drain system and attach to
rear panel clips.
4. Shut off both water faucets.
5. Disconnect the water inlet hoses from faucets, then drain the
hoses and clip them to the rear panel of the washer.
IMPORTANT: Call service. Do not reuse transport bolts. Washer
must be transported in the upright position. To avoid suspension
and structural damage, your machine must be properly set up for
relocation by a certified technician.
Reinstalling the washer
1. Follow the “Installation Instructions” to locate, level and connect
the washer.
2. Run the washer through the Normal cycle with 1/2 the
manufacturer’s recommended amount of HE detergent for a
medium-size load, to clean the washer and remove the
antifreeze, if used.
