Smart Start Guide
2013 M{zd{3

1
Key
NOTE: Refer to your Owner’s Manual for additional details about
“Personalization Features”.
KEYLESS ENTRY SYSTEM
Unlock
• Push once to
unlock driver’s
door or all
the doors
(depending on
personalization).
• Push twice
(within three
seconds) to
unlock all doors
and liftgate.
Panic Alarm
• Push for one
second or more
to activate alarm.
• Push Lock,
Unlock, or Panic
Alarm to turn
alarm off.
Retractable Key
Trunk (Sedan Only)
• Push and hold to open trunk.
Release Button
• Push to extend key.
• Push & fold to retract key.
Lock
• Push once to
lock all doors
and liftgate.
• Push twice
(within ve
seconds) for horn
sound verication
that all doors
are locked.

2
www.MazdaUSA.com
Advanced Key
Trunk
(sedan only)
Lock
Unlock
Panic Alarm
Trunk Lid Opener Switch
Liftgate Opener Switch
Liftgate Request Switch
ADVANCED KEYLESS
ENTRY SYSTEM
• Thissystemallowsyoutolock
and unlock the doors, and even
start the engine without taking
the key out.
While Carrying the
Advanced Key…
• Unlock the driver’s door by
pushing the driver’s door request
switch once.
• Unlock all doors (and liftgate)
by pushing the driver’s door
request switch once or twice
(depending on personalization)
OR by pushing the passenger’s
door request switch once.
• Lock all doors (and liftgate) by
pushing any request switch once.
• Open the trunk/liftgate by
pushing the electric trunk lid/
liftgate opener switch when
ignition is OFF. With ignition ON,
vehiclemustbeinPark(A/T)or
haveparkingbrakeset(M/T).
NOTE: When the liftgate opener switch
is pushed, the liftgate will open slightly. If
the liftgate is not opened within 1.5
seconds, the liftgate latch locks (you will
hear it lock) and the liftgate cannot be
opened or closed from this slightly raised
position.Toopen/closetheliftgate,push
the liftgate opener switch, open the liftgate
within1.5seconds,thencloseit.The
door/liftgate ajar warning light will be on
if the liftgate is not fully closed.
Door Request Switch

ACCELERATED WARM-UP SYSTEM (AWS) –
MAZDA3 SKYACTIV ONLY
Vehicle Starting (e.g., First start of the day on cold mornings):
YourvehicleisequippedwithSKYACTIVcombustiontechnology.This
technology includes AWS (Accelerated Warm-up System) for optimal
emission performance during cold starting conditions.
Cold Start (First start of the day on cold mornings):
Depressthebrake(AutomaticTrans.)orclutch(ManualTrans.),thenstart
the engine.
What you will notice: On start-up, the engine speed and sound are
higher (1500 RPM) for 30 seconds to 1 minute to quickly bring the catalyst
toefcientoperatingtemperature.TheRPMwillreducetoidleoncethe
temperatureisachieved.Thisisnormalengineoperationundercold
start conditions.
NOTE: You can drive the vehicle during AWS activation, no need to wait.
Normal Start (Emission components within optimal
temperature range):
Depressthebrake(AutomaticTrans.)orclutch(ManualTrans.),thenstart
the engine.
NOTE: RED Key Indicator Light may ash if the key is placed in the cup
holder.Thekey may not be detected in the cup holder.
3
Key
STARTING THE ENGINE WITH
ADVANCED KEYLESS ENTRY SYSTEM
While Carrying the Advanced Key…
• Start the enginebypushingtheSTART/STOPbutton,while
pushing the clutch pedal (manual transmission) or the brake pedal
(automatic transmission).
• Shut the engine OFFbypushingtheSTART/STOPbuttonagain.
• Activate Accessories (ACC)bypushingtheSTART/STOPbutton
once without pushing the clutch or brake pedal.
• Thekeyindicatorlight will show GREEN (engine ready to start)
whentheadvancedkeyisdetectedandtheclutchpedal(M/T)orthe
brakepedal(A/T)ispushed.TheindicatorblinksRED (3 sec) with
the ignition ON and the key is not detected or the advanced keyless
transmitter battery is dead. If illuminated RED,theSTART/STOP
button may not start the engine, unless the auxiliary key is used
(see “Starting the Engine with the Auxiliary Key”).

4
www.MazdaUSA.com
Engine Ready to Start
Indicator Light
ACC
Indicator
Light
Ignition ON
Indicator Light
NOTE:
• Emergency Engine Stop:
ContinuouslypushingtheSTART/STOPbuttonorpushingthebuttonseveral
times while the engine is running will turn the engine OFF. Use only in case
of an emergency.
• Vehicle Entry/Engine Start:
If the advanced key cannot be used due to a malfunction or dead advanced
key battery, use the auxiliary key to lock or unlock the doors and to start
the engine.
With the Auxiliary Key…
1Tostartengine,locatethekeyslotcoveronthesteeringcolumnand
remove the cover.
2Inserttheauxiliarykeyintothekeyslot,thenpushtheSTART/STOP
buttonwiththeclutchpedal(M/T)orthebrakepedal(A/T)pushed
down to start the engine.
Key Release
Auxiliary Key
(for opening the doors
and starting the engine)
Advanced Key (Rear)

5
Slide/Tilt Switch
Seat can be moved back and forth,
raised, lowered, or tilted with this control.
Recline Switch
Push forward or backward
to adjust seatback angle.
ELECTRONICALLY OPERATED DRIVER SEAT CONTROLS
FRONT SEAT WARMER
Thedriverandfrontpassengerseatscan
be warmed by rotating the applicable
seat warmer dial while the ignition is ON.
• Seat temperature increases as the
number on the dial increases.
• When the seat warmers are not
needed, rotate the dials to 0.
MANUAL SEAT CONTROLS
Height Adjustment Lever
Raise or lower seat height by
repeatedly pulling up or pushing
down on the lever.
Recline Lever
Pull up to adjust seatback angle.
Slide Release Lever
Pull lever up to move seat backward
or forward.
Seats
NOTE:Therearseatsonthe5-doorareequippedwithfoldableheadrestraints.To
fold the head restraint, pull the strap on the back of the head restraint and fold the head
restraintdownward.Toreturntheheadrestrainttoitsuprightposition,liftitupward.

6
FUEL DOOR RELEASE
(located on oor in front of driver’s seat)
Toopen,pullthefueldoorrelease.
Fuel
•MAZDA3: Regular Unleaded Fuel
– 87 Octane
•MAZDASPEED3: Premium Fuel
– 91-93 Octane
Trunk
Release
(sedan only)
Fuel Door
Release
www.MazdaUSA.com
FUEL DOOR
Toavoidscratching
the paint during
refueling, secure
the fuel ller cap
tether over the
hook as shown.
FUEL ECONOMY
To achieve the best fuel economy:
 • Drive sensibly. Speeding, rapid acceleration and excessive braking will
lower fuel economy.
 • Observe the speed limit. Fuel economy can decrease rapidly at speeds
above 60 mph.
 • Keep tires properly inflated. Under-inated tires will lower fuel economy.
 • Use the recommended grade of oil specified in the owner’s manual
and keep the engine properly maintained. Visit your Authorized
Mazda Dealer who specializes in the servicing of Mazda engines.
 • Monitor the Current Fuel Economy on the MID (if equipped).The
current fuel economy is calculated every 2 seconds.
Additional items that also help increase fuel economy:
 • Remove excess weight. Heavy items in the vehicle will lower fuel economy.
 • Avoid excessive idling. Idling for long periods will waste gas.
 • Use cruise control. Using cruise control on the highway helps to maintain
a constant speed and saves gas.
 • Use overdrive gears. Using overdrive gearing reduces the vehicle’s engine
speed, which saves gas and reduces engine wear.
 • Use a quality gasoline with the recommended octane. Use of higher
octane gasoline will not improve your fuel economy.
Visitwww.ecodrivingusa.com or www.fueleconomy.gov for more information.
Seats Fuel

Driver’s View
7
MULTI-INFORMATION
DISPLAY CONTROLS
( PP. 2 5 -2 6 )
LIGHTING/
TURN SIGNALS
(P. 11)
BLUETOOTH®
HANDS-FREE/
AUDIO
(PP. 21-24, 29)
CRUISE
CONTROL
HOOD
RELEASE
DSC
AFS
(P. 17 )
PUSH BUTTON
START
(P. 3)
BSM
(P. 14)
TILT/TELESCOPING
STEERING WHEEL
LEVER

Driver’s View
8
WIPER/
WASHER
(P. 12 )
HAZARD
WARNING
INFORMATION
DISPLAY
( PP. 19 -2 0 )
CLIMATE
CONTROL
( PP. 19 -2 0 )
SEAT
WARMERS
(P. 5)
ACCESSORY
SOCKET
PASSENGER
AIRBAG OFF
INDICATOR1
1Thisindicatorlightilluminatestoremindyouthatthefrontpassenger’sfront/sideairbagsand
seatbeltpretensionerwillnotdeployduringacollision.Thereasonforthisisthattheweightinthe
seat is less than approximately 66 lbs. Always wear your seat belt and secure children in the rear seats
in appropriate child restraints. See the Owner’s Manual for important information on this safety feature.
PASS
AIRBAG
OFF
NOTE: When closing
the glovebox, push in the
middle to securely close it.
www.MazdaUSA.com
CLOCK
(P. 21)
NAVIGATION
(PP. 27-2 8 )
AUDIO
(PP. 21-24 )

9
TACHOMETER
DASHBOARD
ILLUMINATION1
1•Rotatetheknobtoadjustthebrightnessoftheinstrumentclusterandotherdashboardilluminations.
Vehicles with Multi-Information Display:
Theinstrumentclusterhasadimmerfunctionthatcanbecancelledtomaketheilluminationbrighter
during the day when the headlights are on. If the illumination is too dim during the day, push the knob,
or if the illumination does not dim when turning on the headlights at night, push the knob. When
dimmed, rotate the knob to adjust the brightness of the illumination.
Instrument Cluster
Check Fuel Cap (p. 6)
Low Engine Oil Pressure
Dynamic Stability Control
(DSC)/Traction Control
System (TCS) Off
Indicator Light
DSC OFF switch pushed and
TCS/DSCturnedoff.
Check Engine Light
Security Indicator Light
Lights On (Exterior)
Power Steering Malfunction
ABS (Antilock Brake
System) Malfunction
Air Bag/Front Seat Belt
Pretensioner System
Malfunction
Low Fuel Level
Turn Signals/Hazard
Warning Indicator Lights
Headlight High Beams On
Automatic Transaxle
Warning Light
Cruise Main Indicator Light
On (AMBER)/Cruise Set
Indicator Light On (GREEN)
Shift Position Indicator Light
Malfunction Warning Light
Charging System Malfunction
Door/Liftgate Ajar
AFS
OFF
Adaptive Front Lighting
System (AFS) OFF (p. 17)
FUEL
GAUGE
ODOMETER/
TRIP METER
OFF
GLOSSARY OF WARNING AND INDICATOR LIGHTS
NOTE: See Owner’s Manual for more details and explanations.

Tire Pressure
Monitoring System
(TPMS) Warning Light
On/Warning Beep: Low tire
pressure in one or more tires.
Flashing:TPMSMalfunction
Seat Belt
Unbuckled/Malfunction
BSM
OFF
BSM OFF
(Blind Spot Monitoring) (p. 14)
KEY Warning Light RED (pp. 3-4)
KEY Indicator Light GREEN
(pp. 3-4)
Brake Warning Light
Parking brake on/low brake
uid/malfunction
Traction Control System
(TCS)/Dynamic Stability
Control (DSC)
On:TCS/DSCmalfunction
Flashing:TCS/DSCoperating
Low Washer Fluid Level
Warning Light
10
SPEEDOMETER TRIP METER
SELECTOR2
2•Pushtotogglebetweentripmeter(A&B).
 •Whenatripmeterisselected,pushand
hold to reset to zero.
www.MazdaUSA.com
SHIFT LEVER
POSITION INDICATOR
ENGINE COOLANT TEMP LIGHTS
Since this vehicle does not use an engine
coolant temperature gauge, red and blue
engine coolant temperature lights are used
to indicate high and low coolant temperature.
Red Coolant Temp Light
Flashing: Engine is starting to run hot.
Drive slowly to reduce engine load.
On: Engine is overheating. Safely
pull over to the side of the road and
turn the engine off.
Refer to the Owner’s Manual for
more information.
Blue Coolant Temp Light
On: Engine coolant is cold and no warm
air is available for heater/defroster.
Off: Engine coolant is warm and warm
air is available for heater/defroster.
Thelightmaystayonforafew
minutes after start-up when the
engine is cold, but the vehicle can
be driven with the light on or off.
TPMS NOTE: Low ambient temperature and/or high altitude causes tire pressures to drop
andmayturntheTPMSwarninglighton.Ifthewarninglightcomeson,checkthetirepressure
and ll the tires as soon as possible, preferably before moving the vehicle and warming up the
tires.Tirepressureshouldbecheckedwhenthetiresarecold.

Lights
11
LIGHTING CONTROL/TURN SIGNAL LEVER
AUTO:Thelightsensor
automatically determines
when to turn the headlights
on or off.
:Turnstail,parking,dashboard,
and headlights on.
:Turnsfoglights
on only when
headlights
are on.
:Turnstail,
parking, and
dashboard
lights on.
Pull
to Flash
High Beams
Push for
High Beams

12
www.MazdaUSA.com
Wipers
CAUTION: WhentheignitionisON,turntheAUTOwipersOFFwhen
going through a car wash, or while cleaning or touching the windshield.
WINDSHIELD/REAR WINDOW WIPER/WASHER CONTROL LEVER
AUTO:Therainsensorsensestheamountofrainfallandturnsthewipers
on or off. Rotate inner ring away from you (clockwise) for less sensitivity
(requires more rain to turn wipers on) and toward you (counterclockwise)
for more sensitivity (requires less rain to turn wipers on).
NOTE:VehiclesnotequippedwithAUTO
wiperswillhaveINTwipers.SetthelevertoINT
and choose an interval timing by rotating the
ring between fast and slow.
Pull lever to dispense
windshield washer uid
More sensitive
Less sensitive
1
2
3
HI
LO
AUTO
OFF
MIST
Rear Window
Wiper/Washer
INT:Intermittent
ON: Normal speed
:Washer/wiper
(hold as desired)

13
Transmission
Lower
Gear
Higher
Gear
SPORT A/T MANUAL SHIFT MODE
The Sport A/T Manual Shift Mode gives you the
feel of driving a manual transmission by allowing
you to manually shift to control engine rpm and
torque when more control is desired.
To Use Manual Shift Mode:
• Shift the lever from D to M.
NOTE: Changing to manual mode
can be done while driving the vehicle.
To Shift Up To A Higher Gear:
• Tapshiftleverback(+)once.
To Shift Down To A Lower Gear:
• Tapshiftleverforward(-)once.
Thetransmissionwillautomaticallyadjusthowandwhenitshiftsgears
basedonroadconditionsandyourdrivingstyle.Thetransmissionmaystay
in a lower gear longer than usual when going up or down hills or driving
aroundcorners.Thisfeaturegivesyoubettercontrolandamoreconnected
driving experience.
6-SPEED MANUAL TRANSMISSION
 • Pushtheclutchpedalcompletelydown
to start the engine and to shift gears.
 • ToplacethetransmissioninReverse,
place shifter in the neutral position, push
the shifter knob down, move to the left
and push forward.

14
Blind Spot Monitoring (BSM)
Your Vehicle
Detection Areas
BLIND SPOT MONITORING (BSM) (if equipped)
The Blind Spot Monitoring (BSM) system is designed to assist the driver
by monitoring blind spots on both sides of the vehicle to the rear in
certain situations such as when changing lanes on roads and freeways or
reversing the vehicle from a parking garage.
Turning BSM System Off
TurningtheBSMsystemoffwillturnoffboththelightandsound
indicators.TomanuallyturntheBSMsystemoff,pushtheBSM
OFFswitchonthedash.TheBSMOFFindicatorwillilluminate
intheinstrumentclusterwhentheBSMsystemisoff.TheBSM
system will automatically turn on the next time the vehicle is started.
 • Ifyourvehiclespeedis6.7mph(10.8km/h)ormore,theBSMwillwarn
you of vehicles in the detection area by illuminating the BSM warning
lights located on the left and right door mirrors.
 • IfyouoperateaturnsignalinthedirectionofanilluminatedBSMwarning
light, the system will also warn you with a beep and warning light ash.
 • BSMsensorsarelocatedundertheleftandrightrearbumperareas.The
BSM system may not operate properly if the rear bumper gets too dirty,
so keep the rear bumper area clean.
NOTE: Do not rely completely on the BSM system and be sure to look over your
shoulder before changing lanes:
•TheBSMcanassistthedriverinconrmingthesafetyofthesurroundings,but
is not a complete substitute.
•Thedriverisresponsibleforensuringsafelanechangesandothermaneuvers.
•Alwayspayattentiontothedirectioninwhichthevehicleistravelingandthe
vehicle’s surroundings.
•TheBSMdoesnotoperatewhenthevehiclespeedislowerthanabout6.7mph
(10.8 km/h).

Feature Highlights
15
Auxiliary Jack
NOTE: You will need an audio cable with an 1/8 inch
(3.5 mm) mini stereo plug (available as a Genuine Mazda
accessory) to connect your portable audio player into the
aux jack.
Refer to the Owner’s Manual for additional information.
1Plug 1/8 inch mini stereo cable into the portable audio player and the
AUX jack.
2 • Audio Controls (without navigation): Push the AUX button on the
audio unit to switch to the AUX mode.
•Audio Controls (with navigation): Push AUDIO button on audio
system, then touch AUX on-screen button.
3Use the portable audio player controls to play music.
PORTABLE AUDIO PLAYER INTEGRATION USING THE USB
PORT OR AUX JACK
Your vehicle is equipped with a USB port (some models) and auxiliary AUX
jacklocatedinthecenterconsole.ThiswillallowyoutoplayyouriPod,USB
device, or portable audio player through the vehicle’s audio system. Learn
the system when parked and do not let it distract you while driving.
IMPORTANT:
 • Setthevolumelevelonyourportableaudioplayertothehighestlevel
before distortion starts, then use the vehicle’s audio system to adjust
the volume.
 • UnpluganydevicefromtheUSBportandaccessorysocketbefore
turning off the vehicle. Leaving devices plugged in can drain the battery
and cause issues during the Bluetooth pairing process at startup. Wait
about 15 seconds after starting the vehicle before plugging anything
into the USB port.

16
www.MazdaUSA.com
USB Port
Refer to the Owner’s Manual for additional information.
1Connect the cable into the portable audio player and the USB port.
2 • Audio Controls (without navigation): Push the AUX button on
the audio unit to switch to the USB mode and start playback.
•Audio Controls (with navigation): Push AUDIO button on audio
system, then touch the USB on-screen button.
NOTE: When the iPod®is connected to the USB port, the USB on-screen tab
changes to the iPod on-screen tab. Do not remove the iPod while in the iPod
mode. Otherwise, the data could be damaged.
3Use the vehicle’s audio system or steering wheel controls to control
the USB device connected.
NOTE: TheiPodfunctionsontheiPodcannotbeoperatedwhileitisconnected
to the vehicle’s audio system because it controls the iPod functions.
ALUMINUM WHEEL CARE
Your aluminum wheels have a protective
coating on them. Only use a mild soap
or neutral detergent with a sponge or
soft cloth to clean them.
CAUTION: Using a wire brush,
polishing compound, solvent, or any
type of abrasive cleaner may damage
the protective coating.
Genuine Mazda Accessory Wheel
Locks are available at your
Authorized Mazda Dealer

Feature Highlights
17
TURBOCHARGER TIPS (MAZDASPEED3 only)
After driving at freeway speeds or up a long hill, idle engine at least
30 seconds in order to cool turbocharger. Avoid shutting the engine off
abruptly after a hard or long drive as turbocharger damage may result.
 • DoNOTraceorover-revANYenginewhenstarting,particularlya
turbocharged engine.
 • DoNOTaddaftermarketdevicestoaltertheengine’signition,fuel
delivery, or turbo boost pressure, as this may lead to serious engine
damage and void your warranty.
NOTE:
• With AFS, it is normal to see the
headlights move and hear the sound of
the headlight leveling motors at the front
of the vehicle when the ignition is ON.
• Thesystemwillneedtoberesetifthe
vehicle battery has been disconnected
or the system fuse has been replaced.
Please refer to your Owner’s Manual for
easy to follow resetting instructions.
With AFS
Without AFS
ADAPTIVE FRONT-LIGHTING SYSTEM (AFS)
The adaptive front-lighting system (AFS) automatically turns the
headlight beam to the right or left in conjunction with the direction of
the steering wheel.
TheAFSimprovesthedirectionofheadlightilluminationwhilecornering,and
only works when the vehicle is moving.
Push AFS OFF to turn
system off or on. When off,
AFS OFF illuminates in the
instrument panel.

PERSONALIZE YOUR MAZDA3 WITH
GENUINE MAZDA ACCESSORIES:
Go to www.MyMazda.com, then select “Accessories” below the MyMazda Home
header for a complete listing of available accessories for your Mazda3.
18
www.MazdaUSA.com
BLUETOOTH®FEATURES
See your Owner’s Manual for more information.
Push the PHONE button, then select the
“Setup” tab.
SMS TEXT AUDIO DELIVERY/VOICE
REPLY: Play (read) text from a Bluetooth
connected phone and respond back.
NOTE: If “Message” is grayed out, your phone does not support this
feature. See your Owner’s Manual for more information.
DON’T DISTURB ME: You will not receive phone calls and messages.
DOWNLOAD PHONEBOOK: Use this feature and “All Contacts” to
download and update your phonebook in the vehicle. Some PHONEBOOKS may
not automatically update if changes are made on your phone.
AUTOMATIC 911 CALL: Calls 911 after certain moderate to severe collisions.
ThiscanbeturnedONorOFF.
NOTE:
• Phone must be paired and connected.
• Some phone models do not support all features.
Go to www.MazdaUSA.com/bluetooth or contact [phone] for
further assistance or to report a phone/MP3 device concern.
• See your Owner’s Manual for more information.

Manual Climate Control
INFORMATION DISPLAY
19
Dial
Temperature
Control Dial
Rotate the dial for
temperature control.
NOTE: When set
to MAX A/C with
dashboard vents or
dashboard and oor
vents, the A/C will
turn on, and
recirculated air will
be selected for
maximum cooling.
Fan Control Dial
Rotate the dial to set desired
fan speed (1-4).
Push to defrost the
rear window.
Push to manually turn
air conditioning on or off.
Push to recirculate
cabin air to reduce
outside odors and
improve cooling
(indicator on) or receive
fresh air (indicator off).
Mode Selector Dial
Rotate the dial to
select airow mode.
Dashboard
vents
Dashboard
and oor vents
Floor vents
Defroster and
oor vents
Windshield
defroster
: Best Cooling
Settings
: Best Heating
Settings
FRONT VENT SYSTEM AIRFLOW OPERATION
When the “Windshield Defroster” or “Defroster and Floor”
or “Floor” mode is selected, air will not only blow from the
defroster vents on top of the dash or the oor vents, but
also a small amount from the dashboard vents. If air is not
desired from the dashboard vents, they can be closed
using the dials or vent louvers.
• Todefrostthewindshieldfaster,closethe
dashboard vents.
• Todefrostthesidewindowsfaster,pointtheside
dashboard vents toward the side windows.
• Towarmthepassengers’upperbodiesfaster,point
the side and/or center dashboard vents toward the
inside of the vehicle.
Push
Audio
Outside
Temperature
Clock
