2016 – MX-5 – Body and Accessories
DOOR TRIM REMOVAL/INSTALLATION
1. Disconnect the negative battery cable. (See NEGATIVE
BATTERY CABLE DISCONNECTION/CONNECTION.)
2. Remove the inner handle cover while detach tabs, pin.
3. Remove the recess cover.
4. Remove the screw.
Search here..

2/25/2020 DOOR TRIM REMOVAL/INSTALLATION | 2016 ND Shop Manual
https://www.hexorcism.com/16ND/sm356212/ 2/4
5. Move the door trim in the order of arrows (1), (2), (3), (4),(5)
and (6) shown in the gure and detach the clips.
6. Remove the door trim in the direction of the arrow shown in
the gure.

2/25/2020 DOOR TRIM REMOVAL/INSTALLATION | 2016 ND Shop Manual
https://www.hexorcism.com/16ND/sm356212/ 3/4
7. Remove tab A in the direction of the arrow (1) shown in the
gure.
8. Remove the inner handle in the direction of the arrow (2)
shown in the gure while detaching tab B.
9. Disconnect the connector.
10. Install in the reverse order of removal.
