Thank you for choosing a Mazda. We at Mazda design and build vehicles with complete
customer satisfaction in mind.
To help ensure enjoyable and trouble-free operation of your Mazda, read this manual
carefully and follow its recommendations.
An Authorized Mazda Dealer knows your vehicle best. So when maintenance or service is
necessary, that's the place to go.
Our nationwide network of Mazda professionals is dedicated to providing you with the best
possible service.
We assure you that all of us at Mazda have an ongoing interest in your motoring pleasure
and in your full satisfaction with your Mazda product.
Mazda Motor Corporation
HIROSHIMA, JAPAN
Important Notes About This Manual
Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you
resell the vehicle, leave this manual with it for the next owner.
All specifications and descriptions are accurate at the time of printing. Because improvement is a constant goal at
Mazda, we reserve the right to make changes in specifications at any time without notice and without obligation.
Air Conditioning and the Environment
Your Mazda's genuine air conditioner is filled with a refrigerant that has been found not to damage the earth's
ozone layer. If the air conditioner does not operate properly, consult an Authorized Mazda Dealer.
Perchlorate
Certain components of this vehicle such as [air bag modules, seat belt pretensioners, lithium batteries, ···] may contain Perchlorate Material- - Special handling
may apply for service or vehicle end of life disposal. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
Please be aware that this manual applies to all models, equipment and options. As a result, you may find
some explanations for equipment not installed on your vehicle.
©2014 Mazda Motor Corporation
Printed in Japan Aug. 2014 (Print1)
A Word to Mazda Owners
Mazda5_8DW3-EA-14H_Edition1 Page3
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (4,1)
We want to help you get the most driving
pleasure from your vehicle. Your owner's
manual, when read from cover to cover,
can do that in many ways.
Illustrations complement the words of the
manual to best explain how to enjoy your
Mazda. By reading your manual, you can
find out about the features, important
safety information, and driving under
various road conditions.
The symbol below in this manual means
“Do not do this”or “Do not let this
happen”.
Index: A good place to start is the Index,
an alphabetical listing of all information
in your manual.
You'll find several WARNINGs,
CAUTIONs, and NOTEs in the manual.
WARNING
A WARNING indicates a situation in
which serious injury or death could
result if the warning is ignored.
CAUTION
A CAUTION indicates a situation in
which bodily injury or damage to
your vehicle, or both, could result if
the caution is ignored.
NOTE
A NOTE provides information and sometimes
suggests how to make better use of your
vehicle.
The symbol below, located on some parts
of the vehicle, indicates that this manual
contains information related to the part.
Please refer to the manual for a detailed
explanation.
How to Use This Manual
Mazda5_8DW3-EA-14H_Edition1 Page4
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (5,1)
Mazda5_8DW3-EA-14H_Edition1 Page5
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H
Table of Contents
Your Vehicle at a Glance
Interior, exterior views and part identification of your Mazda. 1
Essential Safety Equipment
Use of safety equipment, including seats, seat belt system, child-restraint
systems and SRS air bags.
2
Knowing Your Mazda
Explanation of basic operations and controls; opening/closing and adjustment
of various parts.
3
Before Driving Your Mazda
Important information about driving your Mazda. 4
Driving Your Mazda
Explanation of instruments and controls. 5
Interior Comfort
Use of various features for drive comfort, including air-conditioning and audio
system.
6
In Case of an Emergency
Helpful information on what to do in an emergency. 7
Maintenance and Care
How to keep your Mazda in top condition. 8
Customer Information and Reporting Safety Defects
Important consumer information including warranties and add-on equipment. 9
Specifications
Technical information about your Mazda. 10
Index 11

Black plate (6,1)
Mazda5_8DW3-EA-14H_Edition1 Page6
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (7,1)
1Your Vehicle at a Glance
Interior, exterior views and part identification of your Mazda.
Interior Overview .......................................................................... 1-2
Interior Equipment (View A) .................................................... 1-2
Interior Equipment (View B) .................................................... 1-3
Interior Equipment (View C) .................................................... 1-4
Exterior Overview ......................................................................... 1-5
Front .......................................................................................... 1-5
Rear ........................................................................................... 1-6
1-1
Mazda5_8DW3-EA-14H_Edition1 Page7
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (8,1)
Interior Equipment (View A)
Door-lock knob .................................................................................................. page 3-10
Power door lock switch ..................................................................................... page 3-11
DSC OFF switch ............................................................................................... page 5-26
Lighting control ................................................................................................. page 5-59
Turn and lane-change signal .............................................................................. page 5-63
Dashboard illumination knob ............................................................................ page 5-43
Instrument cluster .............................................................................................. page 5-40
Wiper and washer lever ..................................................................................... page 5-64
Lock release lever .............................................................................................. page 3-32
Headlight leveling switch .................................................................................. page 5-62
Outside mirror switch ........................................................................................ page 3-32
Power window switches .................................................................................... page 3-16
Power window lock switch ................................................................................ page 3-19
1-2
Your Vehicle at a Glance
The equipment and installation position varies by vehicle
Interior Overview
Mazda5_8DW3-EA-14H_Edition1 Page8
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (9,1)
Interior Equipment (View B)
Audio control switches ...................................................................................... page 6-47
SRS air bags ...................................................................................................... page 2-46
Cruise control switches ...................................................................................... page 5-21
Climate control system ........................................................................................ page 6-2
Hazard warning flasher switch .......................................................................... page 5-70
Information display ............................................................................................ page 6-95
Audio system ..................................................................................................... page 6-12
Glove compartment ......................................................................................... page 6-104
Accessory socket ............................................................................................. page 6-109
Manual transaxle shift lever ............................................................................... page 5-10
Automatic transaxle selector lever ..................................................................... page 5-12
Ignition switch ..................................................................................................... page 5-2
Hood release handle .......................................................................................... page 3-21
Your Vehicle at a Glance
Interior Overview
1-3The equipment and installation position varies by vehicle
Mazda5_8DW3-EA-14H_Edition1 Page9
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (10,1)
Interior Equipment (View C)
Seat belts ............................................................................................................ page 2-18
SRS air bags ...................................................................................................... page 2-46
Remote fuel-filler lid release ............................................................................. page 3-20
Bottle holder .................................................................................................... page 6-101
Vanity mirror ...................................................................................................... page 6-93
Overhead light ................................................................................................... page 6-94
Rearview mirror ................................................................................................. page 3-33
Sunvisor ............................................................................................................. page 6-93
Parking brake ....................................................................................................... page 5-6
Seat warmer switches ........................................................................................ page 2-16
Front seat ............................................................................................................. page 2-2
Cup holders ...................................................................................................... page 6-100
Rear ventilation system ....................................................................................... page 6-9
Second-row seat ................................................................................................... page 2-5
Third-row seat ................................................................................................... page 2-10
1-4
Your Vehicle at a Glance
The equipment and installation position varies by vehicle
Interior Overview
Mazda5_8DW3-EA-14H_Edition1 Page10
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (11,1)
Front
Hood .................................................................................................................. page 3-21
Windshield wiper blades .................................................................................... page 8-28
Moonroof ........................................................................................................... page 3-22
Outside mirror .................................................................................................... page 3-32
Child safety locks .............................................................................................. page 3-13
Tires ................................................................................................................... page 8-36
Light bulbs ......................................................................................................... page 8-42
Your Vehicle at a Glance
Exterior Overview
1-5The equipment and installation position varies by vehicle
Mazda5_8DW3-EA-14H_Edition1 Page11
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (12,1)
Rear
Rear wiper blade ................................................................................................ page 8-29
Liftgate .............................................................................................................. page 3-13
Antenna .............................................................................................................. page 6-11
Sliding doors ...................................................................................................... page 3-11
Door lock ............................................................................................................. page 3-9
Tires ................................................................................................................... page 8-36
Fuel-filler lid ...................................................................................................... page 3-19
Light bulbs ......................................................................................................... page 8-42
1-6
Your Vehicle at a Glance
The equipment and installation position varies by vehicle
Exterior Overview
Mazda5_8DW3-EA-14H_Edition1 Page12
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (13,1)
2Essential Safety Equipment
Use of safety equipment, including seats, seat belt system, child-restraint
systems and SRS air bags.
Seats ............................................................................................... 2-2
Front Seats ................................................................................ 2-2
Second-Row Seats .................................................................... 2-5
Third-Row Seat ....................................................................... 2-10
Seat Arrangements .................................................................. 2-12
Head Restraints ....................................................................... 2-14
Seat Warmer
í
......................................................................... 2-16
Seat Belt Systems ........................................................................ 2-18
Seat Belt Precautions .............................................................. 2-18
Seat Belt .................................................................................. 2-22
Front Seat Belt Pretensioner and Load Limiting Systems ....... 2-24
Seat Belt Extender ................................................................... 2-27
Seat Belt Warning Light .......................................................... 2-28
Seat Belt Reminder ................................................................. 2-29
Child Restraint ............................................................................ 2-30
Child Restraint Precautions ..................................................... 2-30
Child-Restraint System Installation Position .......................... 2-35
Installing Child-Restraint Systems .......................................... 2-36
LATCH Child-Restraint Systems ............................................ 2-43
SRS Air Bags ............................................................................... 2-46
Supplemental Restraint System (SRS) Precautions ................ 2-46
Supplemental Restraint System Components ......................... 2-52
How the SRS Air Bags Work .................................................. 2-54
SRS Air Bag Deployment Criteria .......................................... 2-58
Limitations to SRS Air Bag .................................................... 2-59
Driver and Front Passenger Occupant Classification
System
í
.................................................................................. 2-61
Monitoring and Maintenance .................................................. 2-66
2-1
í
Some models.
Mazda5_8DW3-EA-14H_Edition1 Page13
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (14,1)
Front Seats
WARNING
Do not modify or replace the front
seats:
Modifying or replacing the front seats
such as replacing the upholstery or
loosening any bolts is dangerous. The
front seats contain air bag
components essential to the
supplemental restraint system. Such
modifications could damage the
supplemental restraint system and
result in serious injury. Consult an
Authorized Mazda Dealer if there is
any need to remove or reinstall the
front seats.
Do not drive with damaged front seats:
Driving with damaged front seats is
dangerous. A collision, even one not
strong enough to inflate the air bags,
could damage the front seats which
contain essential air bag
components. If there was a
subsequent collision, an air bag may
not deploy which could lead to
injuries. Always have an Authorized
Mazda Dealer inspect the front seats,
front seat belt pretensioners and air
bags after a collision.
Make sure the adjustable components
of a seat are locked in place:
Adjustable seats and seatbacks that
are not securely locked are
dangerous. In a sudden stop or
collision, the seat or seatback could
move, causing injury. Make sure the
adjustable components of the seat
are locked in place by attempting to
slide the seat forward and backward
and rocking the seatback.
Never allow children to adjust a seat:
Allowing children to adjust a seat is
dangerous as it could result in
serious injury if a child's hands or
feet become caught in the seat.
Adjust the driver's seat only when the
vehicle is stopped:
Adjusting the driver's seat while the
vehicle is moving is dangerous. The
driver could lose control of the vehicle
and have an accident.
CAUTION
Be careful not to place your hands
and fingers around moving parts of
the front seat when adjusting the
seat positions to prevent injury.
qSeat Slide
To move a seat forward or backward, raise
the lever and slide the seat to the desired
position and release the lever.
Make sure the lever returns to its original
position and the seat is locked in place by
attempting to push it forward and
backward.
2-2
Essential Safety Equipment
Seats
Mazda5_8DW3-EA-14H_Edition1 Page14
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (15,1)
qSeat Recline
WARNING
Do not drive with either front seat
reclined:
Sitting in a reclined position while the
vehicle is moving is dangerous
because you do not get the full
protection from seat belts. During
sudden braking or a collision, you
can slide under the lap belt and
suffer serious internal injuries. For
maximum protection, sit well back
and upright.
Always sit in the front passenger seat
properly with the seatback upright and
feet on the floor (With Driver and Front
Passenger Occupant Classification
System):
Your front passenger seat has weight
sensors, sitting in the front passenger
seat improperly out of position or
with the seatback reclined too far
while the vehicle is moving is
dangerous as it can take off weight
from the seat bottom and affect the
weight determination of the front
passenger sensing system. As a result
the front passenger will not have the
supplementary protection of the air
bag and seat belt pretensioner, which
could result in serious injury. Always
sit upright against the seatback with
your feet on the floor.
Do not drive with the seatback
unlocked:
All of the seatbacks play an
important role in your protection in a
vehicle. Leaving the seatback
unlocked is dangerous as it can allow
passengers to be ejected or thrown
around and baggage to strike
occupants in a sudden stop or
collision, resulting in severe injury.
After adjusting the seatback at any
time, even when there are no other
passengers, rock the seatback to
make sure it is locked in place.
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position and
release the lever.
Make sure the lever returns to its original
position and the seatback is locked in
place by attempting to push it forward and
backward.
Essential Safety Equipment
Seats
2-3
Mazda5_8DW3-EA-14H_Edition1 Page15
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (16,1)
CAUTION
When returning a rear-reclined
seatback to its upright position,
make sure you hold onto the
seatback with your other hand while
operating the lever. If the seatback is
not supported, it will flip forward
suddenly and could cause injury.
q Height Adjustment (Driver's Seat)
To adjust the seat height, move the lever
up or down.
qLumbar Support Adjustment
(Driver's Seat)
í
Move the lever forwards to adjust the
lumbar support as required.
qArmrest
The armrest can be used or placed upright.
WARNING
Never position the shoulder portion of
a front seat belt over the armrest:
Positioning the shoulder portion of a
front seat belt over the armrest is
dangerous as it cannot provide
adequate protection in a collision
and could result in serious injuries.
Never put your hands and fingers
around the moving parts of the seat
and armrest:
Putting your hands and fingers
around the moving parts of the seat
and armrest is dangerous as they
could get injured.
2-4
Essential Safety Equipment
í
Some models.
Seats
Mazda5_8DW3-EA-14H_Edition1 Page16
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (17,1)
Second-Row Seats
WARNING
Do not stack cargo higher than the
seatbacks:
Stacking luggage or other cargo
higher than the seatbacks is
dangerous. During a sudden stop or
collision, objects can fly around and
become projectiles that could hit and
injure passengers.
Make sure luggage and cargo are
secured before driving:
Not securing cargo while driving is
dangerous as it could move or be
crushed during sudden braking or a
collision and cause injury.
Make sure the adjustable components
of a seat are locked in place by
attempting to slide the seat forward
and backward and rocking the
seatback:
Adjustable seats that are not securely
latched are dangerous. In a sudden
stop or collision, the seat or seatback
could move, causing injury.
Never allow children to adjust a seat:
Allowing children to adjust a seat is
dangerous as it could result in
serious injury if a child's hands or
feet become caught in the seat.
Adjust the seat only when the vehicle is
stopped:
Adjusting the seat while the vehicle is
moving is dangerous. Sudden
braking or a collision could cause
serious injury.
Do not drive with the seatback
unlocked:
All of the seatbacks play an
important role in your protection in a
vehicle. Leaving the seatback
unlocked is dangerous as it can allow
passengers to be ejected or thrown
around and baggage to strike
occupants in a sudden stop or
collision, resulting in severe injury.
After adjusting the seatback at any
time, even when there are no other
passengers, rock the seatback to
make sure it is locked in place.
Never allow a passenger to sit or stand
on the folded seatback while the
vehicle is moving:
Driving with a passenger on the
folded seatback is dangerous.
Allowing a child to sit up on the
folded seatback while the vehicle is
moving is particularly dangerous. In
a sudden stop or even a minor
collision, a child not in a proper seat
or child-restraint system and seat
belt could be thrown forward, back
or even out of the vehicle resulting in
serious injuries or death. The child in
the baggage area could be thrown
into other occupants and cause
serious injury.
CAUTION
Be careful not to place your hands
and fingers around moving parts of
the second-row seat when adjusting
the seat positions to prevent injury.
NOTE
The second-row seats cannot be removed.
Essential Safety Equipment
Seats
2-5
Mazda5_8DW3-EA-14H_Edition1 Page17
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (18,1)
qSeat Slide
To move the seat forward or backward,
raise the lever and slide the seat to the
desired position and release the lever.
Make sure the lever returns to its original
position and the seat is locked in place by
attempting to push it forward and
backward.
qSeat Recline
WARNING
Do not drive with the seats reclined:
Sitting in a reclined position while the
vehicle is moving is dangerous
because you do not get the full
protection from the seat belts. During
sudden braking or a collision, you
can slide under the lap belt and
suffer serious internal injuries. For
maximum protection, sit well back
and upright.
Do not recline a second-row seatback
when the third row seat is occupied:
Reclining the second-row seatback
when the third-row seat is occupied
is dangerous.Because the clearance
in the third-row seat is limited,
occupants in the third-row seat could
be hurt seriously on a reclined
second-row seatback.
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position and
release the lever.
Make sure the lever returns to its original
position and the seatback is locked in
place by attempting to push it forward and
backward.
2-6
Essential Safety Equipment
Seats
Mazda5_8DW3-EA-14H_Edition1 Page18
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (19,1)
CAUTION
When returning a rear-reclined
seatback to its upright position,
make sure you hold onto the
seatback with your other hand while
operating the lever. If the seatback is
not supported, it will flip forward
suddenly and could cause injury.
qArmrest
The armrest can be used or placed upright.
WARNING
Never position the shoulder portion of
a second-row seat belt over the
armrest:
Positioning the shoulder portion of a
second-row seat belt over the
armrest is dangerous as it cannot
provide adequate protection in a
collision and could result in serious
injuries.
Never put your hands and fingers
around the moving parts of the seat
and armrest:
Putting your hands and fingers
around the moving parts of the seat
and armrest is dangerous as they
could get injured.
qThird-Row Seat Access
After folding the second-row seat
seatback and sliding the seat forward, you
can access the third-row seat easily.
Entering/exiting the third-row seat area
Raise the lever on the side of the second-
row seat or pull the strap behind the
second-row seat to fold the seatback
forward and slide the seat forward.
After entering/exiting the third-row
seat area
Return the second-row seatback to its
upright position and lock it after sliding it
backward. Make sure it is locked by
attempting to lightly move it forward and
backward.
Essential Safety Equipment
Seats
2-7
Mazda5_8DW3-EA-14H_Edition1 Page19
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H

Black plate (20,1)
CAUTION
ØWhen folding a seatback, always
hold onto the seatback with your
other hand while operating the
lever. If the seatback is not
supported, it will flip forward
suddenly and could cause injury.
ØAfter entering/exiting the third-
row seat area, return the seatback
to its upright position. Otherwise,
it could move unexpectedly and
cause injury.
qFolding the Second-Row Seats
To create a flat luggage compartment
space, lift the seat-bottoms of the second-
row seats and fold the seatbacks forward.
Folding the seatbacks
1. Insert the second-row outboard seat
belts in the retainers.
2. Move the seat all the way back.
3. Fold the head restraint all the way
down (page 2-14).
4. Pull the strap and lift the end of the
seat-bottom up and forward.
5. If the armrest and storage box are in
the position for use, store them.
Refer to Storage Box on page 6-105.
6. Raise the lever and fold the seatback
forward. Make sure the seatback is
secured by attempting to lightly move
it up and down.
2-8
Essential Safety Equipment
Seats
Mazda5_8DW3-EA-14H_Edition1 Page20
Tuesday, June 3 2014 12:33 AM
Form No.8DW3-EA-14H
