Mazda Tribute (j14) User manual

Introduction 4
Instrument Cluster 14
Warning and control lights 14
Gauges 19
Entertainment Systems 21
AM/FM stereo with single CD 21
AM/FM stereo with in-dash six CD 25
Climate Controls 31
Manual heating and air conditioning 31
Lights 33
Headlamps 33
Turn signal control 35
Bulb replacement 37
Driver Controls 42
Windshield wiper/washer control 42
Steering wheel adjustment 44
Power windows 47
Mirrors 48
Speed control 49
Locks and Security 57
Keys 57
Locks 57
Anti-theft system 62
Table of Contents
1

Seating and Safety Restraints 67
Seating 67
Safety restraints 75
Air bags 91
Child restraints 102
Driving 114
Starting 114
Brakes 118
Transmission operation 123
Vehicle loading 140
Trailer towing 144
Recreational towing 149
Roadside Emergencies 150
Hazard flasher switch 150
Fuses and relays 151
Overheating 157
Changing tires 158
Jump starting 168
Wrecker towing 174
Customer Assistance 176
Reporting safety defects (U.S. only) 186
Cleaning 187
Table of Contents
2

Maintenance and Specifications 193
Engine compartment 201
Engine oil 203
Battery 207
Fuel information 215
Air filter(s) 228
Tire Information 231
Refill capacities 243
Engine data 245
Accessories 248
Index 249
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from MNAO. MNAO may change the contents without notice and
without incurring obligation.
Copyright © 2003 MNAO
Table of Contents
3

CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to
the State of California to cause cancer and birth defects or
other reproductive harm. In addition, certain fluids contained in
vehicles and certain products of component wear contain or
emit chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
CONGRATULATIONS
Congratulations on acquiring your new Mazda product. Please take the
time to get well acquainted with your vehicle by reading this handbook.
The more you know and understand about your vehicle, the greater the
safety and pleasure you will derive from driving it.
For more information on Mazda and its products visit the following
website:
•In the United States: www.mazdausa.com
•In Canada: www.mazda.ca
Additional owner information is given in separate publications.
This Owner’s Guide describes every option and model variant available
and therefore some of the items covered may not apply to your
particular vehicle. Furthermore, due to printing cycles it may describe
options before they are generally available.
Remember to pass on the Owner’s Guide when reselling the vehicle. It is
an integral part of the vehicle.
WARNING: In the event of an accident the Fuel pump shut-off
switch will automatically cut off the fuel supply to the engine.
The switch can also be activated through sudden vibration (e.g.
collision when parking). To reset the switch, refer to the Fuel
pump shut-off switch in the Roadside Emergencies chapter.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
Introduction
4

SAFETY AND ENVIRONMENT PROTECTION
Warning symbols in this guide
How can you reduce the risk of
personal injury and prevent possible
damage to others, your vehicle and
its equipment? In this guide,
answers to such questions are
contained in comments highlighted by a bold WARNING statement.
These comments should be read and observed.
Warning symbols on your vehicle
When you see this symbol, it is
imperative that you consult the
relevant section of this guide before
touching or attempting adjustment
of any kind.
Protecting the environment
We must all play our part in
protecting the environment. Correct
vehicle usage and the authorized
disposal of waste, cleaning and
lubrication materials are significant
steps towards this aim. Information in this respect is highlighted in this
guide with the tree symbol.
Always dispose of used automotive fluids in a responsible manner. Follow
your community’s regulations and standards for recycling and disposing
of automotive fluids.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
5

BREAKING-IN YOUR VEHICLE
There are no particular breaking-in rules for your vehicle. During the
first 1,600 km (1,000 miles) of driving, vary speeds frequently. This is
necessary to give the moving parts a chance to break in.
SPECIAL NOTICES
Event Data Recorder
The computer in your vehicle is capable of recording detailed data
potentially including but not limited to information such as:
•the use of restraint systems including seat belts by the driver and
passengers,
•information about the performance of various systems and modules in
the vehicle, and
•information related to engine, throttle, steering, brake or other system
status potentially including information related to how the driver
operates the vehicle including but not limited to vehicle speed.
This information may be stored during regular operation or in a crash or
near crash event. This stored information may be read out and used by:
•service and repair facilities.
•law enforcement or government agencies.
•the Manufacturer and Distributor.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
6

Emission warranty
The New Vehicle Limited Warranty includes Bumper to Bumper
Coverage, Safety Restraint Coverage and Corrosion Coverage. In addition,
your vehicle is eligible for Emissions Defect and Emissions Performance
Warranties. For a detailed description of what is covered and what is not
covered, refer to the Warranty Guide that is provided to you along with
your Owner’s Guide.
Using your vehicle as an ambulance
WARNING: Do not use this vehicle as an ambulance.
Your vehicle is not equipped with an ambulance preparation package.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
7

These are some of the symbols you may see on your vehicle.
Vehicle Symbol Glossary
Safety Alert See Owner’s Guide
Protecting the
Environment Fasten Safety Belt
Air Bag-Front Air Bag-Side
Passenger Airbag Off Child Seat
Child Seat Installation
Warning
Child Seat Lower
Anchor
Child Seat Tether
Anchor Brake System
Anti-Lock Brake System Brake Fluid -
Non-Petroleum Based
Master Lighting Switch Hazard Warning Flasher
Fog Lamps-Front Fuse Compartment
Fuel Pump Reset Windshield Wash/Wipe
Windshield
Defrost/Demist
Rear Window
Defrost/Demist
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
8

Vehicle Symbol Glossary
Power Windows Power Window Lockout
Personal Alarm System
Feature Engine Oil
Engine Coolant Engine Coolant
Temperature
Do Not Open When Hot Battery
Avoid Smoking, Flames,
or Sparks Battery Acid
Explosive Gas Fan Warning
Power Steering Fluid Maintain Correct Fluid
Level
MAX
MIN
Emission System Engine Air Filter
Traction Control Passenger Compartment
Air Filter
Jack Check Fuel Cap
Dynamic Stability
Control Low Tire Warning
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
9

INFORMATION ABOUT THIS GUIDE
The information found in this guide was accurate at the time of printing.
Mazda may change the contents without notice.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Introduction
10

2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
Instrument Cluster
11

Instrument cluster
(pg. 14)
Windshield wiper/washer
control
(pg. 42)
Driver air bag
(pg. 91)
Speed controls*
(pg. 49)
Instrument panel
dimmer/dome light
control
(pg. 35)
Hood release handle
(pg. 199)
Power mirror control*
(pg. 48)
Headlamp and turn
signal control
(pg. 33)
Manual tilt steering
column lever
(pg. 44)
* if equipped
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
Instrument Cluster
12

Passenger airbag off
indicator
(pg. 96)
Hazard flasher control
(pg. 150)
Audio system
(pg. 21)
Cigarette lighter
Fog lamp control*
(pg. 33)
Climate controls
(pg. 31)
Rear window defroster
control
(pg. 31)
Auxiliary power point
(pg. 46)
Air conditioning control
(pg. 31)
*if equipped
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
13

WARNING LIGHTS AND CHIMES
Warning lights and gauges can alert you to a vehicle condition that may
become serious enough to cause expensive repairs. A warning light may
illuminate when a problem exists with one of your vehicle’s functions.
Many lights will illuminate when you start your vehicle to make sure the
bulb works. If any light remains on after starting the vehicle, have the
respective system inspected immediately.
Service engine soon: Your vehicle
is equipped with a computer that
monitors the engine’s emission
control system. This system is
commonly known as the On Board Diagnostics System (OBD II). The
OBD II system protects the environment by ensuring that your vehicle
continues to meet government emission standards. The OBD II system
also assists the service technician in properly servicing your vehicle.
The indicator light illuminates when the ignition is first turned to
the RUN position to check the bulb. If it comes on after the engine is
started, one of the engine’s emission control systems may be
malfunctioning. The light may illuminate without a driveability concern
being noted. The vehicle will usually be drivable and will not require
towing.
What you should do if the light illuminates
Light turns on (without blinking):
This means that the OBD II system has detected a malfunction.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
14

Temporary malfunctions may cause your light to illuminate.
Examples are:
1. The vehicle has run out of fuel. (The engine may misfire or run
poorly.)
2. Poor fuel quality or water in the fuel.
3. The fuel cap may not have been properly installed and securely
tightened.
These temporary malfunctions can be corrected by filling the fuel tank
with high quality fuel of the recommended octane and/or properly
installing and securely tightening the fuel cap. After three driving cycles
without these or any other temporary malfunctions present, the
light should turn off. (A driving cycle consists of a cold engine startup
followed by mixed city/highway driving.) No additional vehicle service is
required.
If the light remains on, have your vehicle serviced at the first
available opportunity.
Note: The light will illuminate if vehicle refueling is conducted
with the engine running.
WARNING: Never refuel vehicle with the engine running.
Light is blinking:
Engine misfire is occurring which could damage your catalytic converter.
You should drive in a moderate fashion (avoid heavy acceleration and
deceleration) and have your vehicle serviced at the first available
opportunity.
WARNING: Under engine misfire conditions, excessive exhaust
temperatures could damage the catalytic converter, the fuel
system, interior floor coverings or other vehicle components,
possibly causing a fire.
Check fuel cap: Momentarily
illuminates when the ignition is
turned to the ON position to ensure
your bulb is working. When the light
CHECK
FUEL CAP
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
15

stays on, check the fuel filler cap. Continuing to operate the vehicle with
the check fuel cap light on, can activate the warning light. When
the fuel filler cap is properly re-installed, the light(s) will turn off after a
period of normal driving. This period will vary depending on driving
conditions.
It may take a long period of time for the system to detect an
improperly installed fuel filler cap.
For more information, refer to Fuel filler cap in the Maintenance and
specifications chapter.
Brake system warning light: To
confirm the brake system warning
light is functional, it will
momentarily illuminate when the
ignition is turned to the ON position
when the engine is not running, or in a position between ON and START,
or by applying the parking brake when the ignition is turned to the ON
position. If the brake system warning light does not illuminate at this
time, seek service immediately from an authorized Mazda dealer.
Illumination after releasing the parking brake indicates low brake fluid
level and the brake system should be inspected immediately by an
authorized Mazda dealer.
WARNING: Driving a vehicle with the brake system warning
light on is dangerous. A significant decrease in braking
performance may occur. It will take you longer to stop the
vehicle. Have the vehicle checked immediately by an authorized
Mazda dealer.
Anti-lock brake system (ABS): If
the ABS light stays illuminated or
continues to flash, a malfunction has
been detected, have the system
serviced immediately by an
authorized Mazda dealer. Normal braking is still functional unless the
brake system warning light also is illuminated.
!
BRAKE
ABS
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
16

WARNING: If the light remains on, continues to flash or fails
to illuminate, have the system serviced immediately by an
authorized Mazda dealer. With the ABS light on, the anti-lock
brake system is disabled but normal braking is still effective
unless the brake warning light also remains illuminated with
the parking brake released.
Air bag readiness: If this light fails
to illuminate when ignition is turned
to ON, continues to flash or remains
on, have the system serviced
immediately by an authorized Mazda dealer. A chime will also sound
when a malfunction in the supplemental restraint system has been
detected.
Safety belt: Reminds you to fasten
your safety belt. A chime will also
sound to remind you to fasten your
safety belt.
Charging system: Illuminates when
the battery is not charging properly.
Engine oil pressure: Illuminates
when the oil pressure falls below the
normal range, refer to Engine oil in
the Maintenance and
specifications chapter.
Low fuel: Illuminates when the fuel
level in the fuel tank is at or near
empty (refer to Fuel gauge in this
chapter).
Overdrive off: Illuminates when
the overdrive function of the
transmission has been turned off,
refer to the Driving chapter. If the
light flashes steadily or does not illuminate, have the
transmission serviced soon, or damage may occur.
O/D
OFF
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
17

Four wheel drive indicator (if
equipped): Illuminates when
ignition is first turned ON to check
bulb. Solid illumination indicates
4WD system is in the heat protection mode. Blinking indicator indicates
system has been disabled or requires service, refer to the Driving
chapter.
Note: If the light continues to flash, have the system serviced by an
authorized Mazda dealer.
Anti-theft system: Flashes when
the Securilock娂Passive Anti-theft
System has been activated. Refer to
SecuriLock娂passive anti-theft
system in the Locks and Security chapter.
Speed control: Illuminates when
the speed control is activated. Turns
off when the speed control system
is deactivated, refer to the Driver Controls chapter.
Door ajar: Illuminates when the
ignition is in the ON position and
any door, liftgate, or liftgate window
is open.
Turn signals: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators stay on or flash faster, check for a burned out bulb.
High beams: Illuminates when the
high beam headlamps are turned on.
Safety belt warning chime: Sounds to remind you to fasten your
safety belts.
Key-in-ignition warning chime: Sounds when the key is left in the
ignition in the OFF/LOCK or ACCESSORY position and the driver’s door
is opened.
Headlamps on warning chime: Sounds when the headlamps or parking
lamps are on, the ignition is off (the key is not in the ignition) and the
driver’s door is opened.
CRUISE
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
18

GAUGES
Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H”and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool. Refer to
Engine coolant in the Maintenance and Specifications chapter.
WARNING: When the engine and radiator are hot, scalding
coolant and steam may shoot out under pressure and cause
serious injury. Do not remove the cooling system cap when the
engine and radiator are hot.
NOTE: This gauge indicates the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level the gauge
indication will not be accurate.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
19

Odometer: Registers the total
kilometers (miles) of the vehicle.
Trip odometer: Registers the
kilometers (miles) of individual
journeys. Press and hold the button
for 1 or more seconds to reset.
Press and release the button in less
than 1 second to toggle between
odometer and trip odometer.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.
Fuel gauge: Displays approximately
how much fuel is in the fuel tank.
The fuel gauge may vary slightly
when the vehicle is in motion or on
a grade.
When refueling the vehicle from
empty indication, the amount of fuel
that can be added will be less than
the advertised capacity due to the reserve fuel.
Note: The fuel filler door is located on the driver’s side of the vehicle.
2005 Mazda Tribute (j14)
Owners Guide (post-2002-fmt)
USA English (fus)
Instrument Cluster
20
This manual suits for next models
1
Table of contents
Other Mazda Automobile manuals

Mazda
Mazda CX-9 User manual

Mazda
Mazda 323 Protege 1992 Instruction manual

Mazda
Mazda 2010 CX-9 Guide

Mazda
Mazda Tribute Guide

Mazda
Mazda 2004 6 User manual

Mazda
Mazda 2003 B2300 User manual

Mazda
Mazda 5 2006 User manual

Mazda
Mazda 2003 Tribute User manual

Mazda
Mazda 2007 Mazdaspeed 3 User manual

Mazda
Mazda 2010 MX-5 Miata Guide

Mazda
Mazda 323 Protege User manual

Mazda
Mazda 2010 Tribute User manual

Mazda
Mazda 3 2018 User manual

Mazda
Mazda 2005 B2300 Truck User manual

Mazda
Mazda 1979-1984 RX7 Reference manual

Mazda
Mazda CX-9 2016 User manual

Mazda
Mazda 2008 MX-5 Miata User manual

Mazda
Mazda 2014 MX-5 Miata Guide

Mazda
Mazda 2012 CX-9 Guide

Mazda
Mazda 2002 Miata MX-5 User manual
