Mazda Tribute User manual

Introduction 4
Instrument Cluster 14
Warning and control lights 14
Gauges 19
Entertainment Systems 21
AM/FM stereo with single CD 21
AM/FM stereo with in-dash six CD 25
Climate Controls 32
Manual heating and air conditioning 32
Lights 34
Headlamps 34
Turn signal control 37
Bulb replacement 39
Driver Controls 45
Windshield wiper/washer control 45
Steering wheel adjustment 46
Power windows 49
Mirrors 50
Traction control 51
Locks and Security 58
Keys 58
Locks 58
Anti-theft system 65
Table of Contents
1
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)

Seating and Safety Restraints 70
Seating 70
Safety restraints 79
Airbags 95
Child restraints 111
Tires, Wheels and Loading 123
Tire Information 126
Tire Inflation 127
Tire Pressure Monitoring System (TPMS) 140
Vehicle loading 146
Trailer towing 153
Recreational towing 158
Driving 159
Starting 159
Brakes 163
Transmission operation 168
Roadside Emergencies 184
Hazard flasher switch 184
Fuses and relays 185
Changing tires 191
Lug Nut Torque 203
Overheating 203
Jump starting 204
Wrecker towing 210
Customer Assistance 212
Cleaning 223
Table of Contents
2
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)

Maintenance and Specifications 229
Engine compartment 238
Engine oil 241
Battery 245
Engine Coolant 247
Fuel information 253
Air filter(s) 267
Refill capacities 269
Engine data 271
Accessories 276
Index 277
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from MNAO. MNAO may change the contents without notice and
without incurring obligation.
Copyright © 2005 MNAO
Table of Contents
3
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)

CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to
the State of California to cause cancer and birth defects or
other reproductive harm. In addition, certain fluids contained in
vehicles and certain products of component wear contain or
emit chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
CONGRATULATIONS
Congratulations on acquiring your new Mazda product. Please take the
time to get well acquainted with your vehicle by reading this handbook.
The more you know and understand about your vehicle, the greater the
safety and pleasure you will derive from driving it.
For more information on Mazda and its products visit the following
website:
•In the United States: www.mazdausa.com
•In Canada: www.mazda.ca
Additional owner information is given in separate publications.
This Owner’s Guide describes every option and model variant available
and therefore some of the items covered may not apply to your
particular vehicle. Furthermore, due to printing cycles it may describe
options before they are generally available.
Remember to pass on the Owner’s Guide when reselling the vehicle. It is
an integral part of the vehicle.
WARNING: In the event of an accident the Fuel pump shut-off
switch will automatically cut off the fuel supply to the engine.
The switch can also be activated through sudden vibration (e.g.
collision when parking). To reset the switch, refer to the Fuel
pump shut-off switch in the Roadside Emergencies chapter.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
4

SAFETY AND ENVIRONMENT PROTECTION
Warning symbols in this guide
How can you reduce the risk of
personal injury to yourself or
others? In this guide, answers to
such questions are contained in
comments highlighted by a bold
WARNING statement. These comments should be read and observed.
Warning symbols on your vehicle
When you see this symbol, it is
imperative that you consult the
relevant section of this guide before
touching or attempting adjustment
of any kind.
Protecting the environment
We must all play our part in
protecting the environment. Correct
vehicle usage and the authorized
disposal of waste, cleaning and
lubrication materials are significant
steps towards this aim. Information in this respect is highlighted in this
guide with the tree symbol.
Always dispose of used automotive fluids in a responsible manner. Follow
your community’s regulations and standards for recycling and disposing
of automotive fluids.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
5

BREAKING-IN YOUR VEHICLE
There are no particular breaking-in rules for your vehicle. During the
first 1,000 miles (1,600 km) of driving, vary speeds frequently. This is
necessary to give the moving parts a chance to break in.
SPECIAL NOTICES
Event Data Recorder
The computer in your vehicle is capable of recording detailed data
potentially including but not limited to information such as:
•the use of restraint systems including seat belts by the driver and
passengers,
•information about the performance of various systems and modules in
the vehicle, and
•information related to engine, throttle, steering, brake or other system
status potentially including information related to how the driver
operates the vehicle including but not limited to vehicle speed.
This information may be stored during regular operation or in a crash or
near crash event. This stored information may be read out and used by:
•service and repair facilities.
•law enforcement or government agencies.
•the Manufacturer and Distributor.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
6

Emission warranty
The New Vehicle Limited Warranty includes Bumper to Bumper
Coverage, Safety Restraint Coverage and Corrosion Coverage. In addition,
your vehicle is eligible for Emissions Defect and Emissions Performance
Warranties. For a detailed description of what is covered and what is not
covered, refer to the Warranty Guide that is provided to you along with
your Owner’s Guide.
Using your vehicle as an ambulance
WARNING: Do not use this vehicle as an ambulance.
Your vehicle is not equipped with an ambulance preparation package.
Using your vehicle with a snowplow
WARNING: Do not use this vehicle for snowplowing.
Your vehicle is not equipped with a snowplowing package.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
7

These are some of the symbols you may see on your vehicle.
Vehicle Symbol Glossary
Safety Alert See Owner’s Guide
Protecting the
Environment Fasten Safety Belt
Airbag - Front Airbag - Side
Passenger Airbag Off Child Seat
Child Seat Installation
Warning
Child Seat Lower
Anchor
Child Seat Tether
Anchor Brake System
Anti-Lock Brake System Brake Fluid -
Non-Petroleum Based
Master Lighting Switch Hazard Warning Flasher
Fog Lamps-Front Fuse Compartment
Fuel Pump Reset Windshield Wash/Wipe
Windshield
Defrost/Demist
Rear Window
Defrost/Demist
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
8

Vehicle Symbol Glossary
Power Windows Power Window Lockout
Personal Alarm System
Feature Engine Oil
Engine Coolant Engine Coolant
Temperature
Do Not Open When Hot Battery
Avoid Smoking, Flames,
or Sparks Battery Acid
Explosive Gas Fan Warning
Power Steering Fluid Maintain Correct Fluid
Level
MAX
MIN
Emission System Engine Air Filter
Powertrain Malfunction Speed Control
Passenger Compartment
Air Filter Jack
Check Fuel Cap Low Tire Pressure
Warning
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
9

INFORMATION ABOUT THIS GUIDE
The information found in this guide was accurate at the time of printing.
Mazda may change the contents without notice.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
10

2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
11

Instrument cluster
(pg. 14)
Windshield wiper/washer
control
(pg. 45)
Driver air bag
(pg. 95)
Speed controls*
(pg. 51)
Instrument panel
dimmer/dome light
control
(pg. 36)
Hood release handle
(pg. 236)
Power mirror control*
(pg. 50)
Headlamp and turn
signal control
(pg. 34)
Manual tilt steering
column lever
(pg. 46)
* if equipped
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
12

Passenger airbag off
indicator
(pg. 99)
Hazard flasher control
(pg. 184)
Audio system
(pg. 21)
Cigarette lighter*
(pg. 48)
Fog lamp control*
(pg. 35)
Climate controls
(pg. 32)
Rear window defroster
control
(pg. 32)
Auxiliary power point
(pg. 48)
Air conditioning control
(pg. 32)
*if equipped
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
13

WARNING LIGHTS AND CHIMES
Warning lights and gauges can alert you to a vehicle condition that may
become serious enough to cause expensive repairs. A warning light may
illuminate when a problem exists with one of your vehicle’s functions.
Many lights will illuminate when you start your vehicle to make sure the
bulb works. If any light remains on after starting the vehicle, refer to the
respective system warning light for additional information.
Service engine soon: Your vehicle
is equipped with a computer that
monitors the engine’s emission
control system. This system is
commonly known as the On Board Diagnostics System (OBD II). The
OBD II system protects the environment by ensuring that your vehicle
continues to meet government emission standards. The OBD II system
also assists the service technician in properly servicing your vehicle.
The indicator light illuminates when the ignition is first turned to
the RUN position to check the bulb. If it comes on after the engine is
started, one of the engine’s emission control systems may be
malfunctioning. The light may illuminate without a driveability concern
being noted. The vehicle will usually be drivable and will not require
towing.
What you should do if the light illuminates
Light turns on (without blinking):
This means that the OBD II system has detected a malfunction.
Temporary malfunctions may cause your light to illuminate.
Examples are:
1. The vehicle has run out of fuel. (The engine may misfire or run
poorly.)
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
14

2. Poor fuel quality or water in the fuel.
3. The fuel cap may not have been properly installed and securely
tightened.
These temporary malfunctions can be corrected by filling the fuel tank
with high quality fuel of the recommended octane and/or properly
installing and securely tightening the fuel cap. After three driving cycles
without these or any other temporary malfunctions present, the
light should turn off. (A driving cycle consists of a cold engine startup
followed by mixed city/highway driving.) No additional vehicle service is
required.
If the light remains on, have your vehicle serviced at the first
available opportunity.
Note: The light will illuminate if vehicle refueling is conducted
with the engine running.
WARNING: Never refuel vehicle with the engine running.
Light is blinking:
Engine misfire is occurring which could damage your catalytic converter.
You should drive in a moderate fashion (avoid heavy acceleration and
deceleration) and have your vehicle serviced at the first available
opportunity.
WARNING: Under engine misfire conditions, excessive exhaust
temperatures could damage the catalytic converter, the fuel
system, interior floor coverings or other vehicle components,
possibly causing a fire.
Check fuel cap: Momentarily
illuminates when the ignition is
turned to the ON position to ensure
your bulb is working. When the light
stays on, check the fuel filler cap. Continuing to operate the vehicle with
the check fuel cap light on, can activate the warning light. When
the fuel filler cap is properly re-installed, the light(s) will turn off after a
period of normal driving. This period will vary depending on driving
conditions.
CHECK
FUEL CAP
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
15

It may take a long period of time for the system to detect an
improperly installed fuel filler cap.
For more information, refer to Fuel filler cap in the Maintenance and
Specifications chapter.
Brake system warning light: To
confirm the brake system warning
light is functional, it will
momentarily illuminate when the
ignition is turned to the ON position
when the engine is not running, or in a position between ON and START,
or by applying the parking brake when the ignition is turned to the ON
position. If the brake system warning light does not illuminate at this
time, seek service immediately from an authorized Mazda dealer.
Illumination after releasing the parking brake indicates low brake fluid
level and the brake system should be inspected immediately by an
authorized Mazda dealer.
WARNING: Driving a vehicle with the brake system warning
light on is dangerous. A significant decrease in braking
performance may occur. It will take you longer to stop the
vehicle. Have the vehicle checked immediately by an authorized
Mazda dealer.
Anti-lock brake system (ABS): If
the ABS light stays illuminated or
continues to flash, a malfunction has
been detected, have the system
serviced immediately by an
authorized Mazda dealer. Normal braking is still functional unless the
brake system warning light also is illuminated.
WARNING: If the light remains on, continues to flash or fails
to illuminate, have the system serviced immediately by an
authorized Mazda dealer. With the ABS light on, the anti-lock
brake system is disabled but normal braking is still effective
unless the brake warning light also remains illuminated with
the parking brake released.
!
BRAKE
ABS
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
16

Airbag readiness: If this light fails
to illuminate when ignition is turned
to ON, continues to flash or remains
on, have the system serviced
immediately by an authorized Mazda dealer. A chime will also sound when
a malfunction in the supplemental restraint system has been detected.
Safety belt: Reminds you to fasten
your safety belt. A chime will also
sound to remind you to fasten your
safety belt.
Charging system: Illuminates when
the battery is not charging properly.
Engine oil pressure: Illuminates
when the oil pressure falls below the
normal range, refer to Engine oil in
the Maintenance and
Specifications chapter.
Low fuel: Illuminates when the fuel
level in the fuel tank is at or near
empty (refer to Fuel gauge in this
chapter).
Overdrive off: Illuminates when
the overdrive function of the
transmission has been turned off,
refer to the Driving chapter. If the
light flashes steadily or does not illuminate, have the
transmission serviced soon, or damage may occur.
Low tire pressure warning:
Illuminates when your tire pressure
is low. If the light remains ON at
start up or while driving, the tire
pressure should be checked. Refer
to Inflating Your Tires in the Tires, Wheels and Loading chapter.
When the ignition is first turned to ON, the light will illuminate for 3
seconds to ensure the bulb is working. If the light does not turn ON,
have the system inspected by your authorized dealer. For more
information on this system, refer to Understanding Your Tire Pressure
Monitoring System in the Tires, Wheels and Loading chapter.
O/D
OFF
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
17

Four wheel drive indicator (if
equipped): Illuminates when
ignition is first turned ON to check
bulb. Blinking indicator indicates
system has been disabled, refer to the Driving chapter.
Note: If the light remains on, have the system serviced by an authorized
Mazda dealer.
Anti-theft system: Flashes when
the Securilock娂Passive Anti-theft
System has been activated. Refer to
SecuriLock娂passive anti-theft
system in the Locks and Security chapter.
Cruise control/Speed control:
Illuminates when the cruise
control/speed control is activated.
Turns off when the cruise control/speed control system is deactivated,
refer to the Driver Controls chapter.
Door ajar: Illuminates when the
ignition is in the ON position and
any door, liftgate, or liftgate window
is open.
Turn signals: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators stay on or flash faster, check for a burned out bulb.
High beams: Illuminates when the
high beam headlamps are turned on.
Safety belt warning chime: Sounds to remind you to fasten your
safety belts.
Key-in-ignition warning chime: Sounds when the key is left in the
ignition in the OFF/LOCK or ACCESSORY position and the driver’s door
is opened.
Headlamps on warning chime: Sounds when the headlamps or parking
lamps are on, the ignition is off (the key is not in the ignition) and the
driver’s door is opened.
CRUISE
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
18

GAUGES
Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool. Refer to
Engine coolant in the Maintenance and Specifications chapter.
WARNING: When the engine and radiator are hot, scalding
coolant and steam may shoot out under pressure and cause
serious injury. Do not remove the cooling system cap when the
engine and radiator are hot.
NOTE: This gauge indicates the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level the gauge
indication will not be accurate.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
19

Odometer: Registers the total miles
(kilometers) of the vehicle.
Trip odometer: Registers the miles
(kilometers) of individual journeys.
Press and hold the button for 1 or
more seconds to reset. Press and
release the button in less than 1
second to toggle between odometer
and trip odometer.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.
Fuel gauge: Displays approximately
how much fuel is in the fuel tank.
The fuel gauge may vary slightly
when the vehicle is in motion or on
a grade.
When refueling the vehicle from
empty indication, the amount of fuel
that can be added will be less than
the advertised capacity due to the reserve fuel.
Note: The fuel filler door is located on the driver’s side of the vehicle.
2006 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
20
