Mazda BT-50 2020 User manual

BLACK
BTAUDIO-IE-2001_5103404_Cover.indd 1-2 2020/07/08 9:28:49

BLACK
• We recommend that you also read the separate instructions for the
equipment on your vehicle that was installed by your Mazda Dealer.
• Your Mazda Dealer will be glad to answer any questions you may have
about the information in this manual.
• Please leave this manual in the vehicle when you resell it – the next owner
will need it.
Keep this Owner's Manual in the vehicle for handy reference
whenever needed.
• Please read this manual carefully, especially the information identified by
the following symbol/letter combinations: CAUTION , ADVICE and
NOTE .
Among them, CAUTION is reminders to be especially careful. Failure
to follow or wrongly following the associated instructions could result in
personal injury or accidents. Please read them thoroughly.
• Due to differences in vehicle specifications, the illustration used for
description may not match your vehicle.
• The contents of this manual are current at the date of issue, but may
differ slightly from your vehicle due to specification changes or other
modifications made thereafter.
• The equipment that is mentioned in this manual may not be equipped
depending on the vehicle specifications. Please check your vehicle
specifications and read this manual.
• This manual is applicable for vehicle in all countries except the USA and
Canada.
• All rights reserved. This manual may not be reproduced in whole or in
part, without the permission in writing of Mazda Motor Corporation.
Notes on Reading This Manual
Published: Jul., 2020
Printed: Jul., 2020
First Edition
Issued by Mazda Motor Corporation
HIROSHIMA, JAPAN
All rights reserved.
202007-01K-x
AUDIO OWNER'S MANUAL
BTAUDIO-IE-2001_5103404_Cover.indd 3-4 2020/07/08 9:28:51

Symbols Used in This Manual
CAUTION
Failure to follow these instructions identified by this symbol could result in injuries
or an accident.
ADVICE
Failure to follow these instructions identified by this symbol could cause
malfunction or damage to your vehicle.
NOTE
This symbol identifies information that you need to know.

HOW TO USE THIS MANUAL AND
HOW TO FIND A SPECIFIC TOPIC
●HOW TO USE THIS MANUAL 0-2
●HOW TO FIND A SPECIFIC TOPIC 0-3
●CHAPTER DESCRIPTION 0-5
0

0-2
1-2 RADIO AND CD/USB PLAYER
Control Panel
The CD/USB player can be used when the starter switch is in the "ACC" or "ON"
position.
No. Name
1 Eject button
2FLD/CHbutton
3CDslot
4 TUNE/TRACK button
5 Volume control button
No. Name
6USBterminal
7Minijack
8 FUNC/DISP button
9MODE/Powerbutton
1 2 3 4
9 8 7 6 5
Precautions
CAUTION
Operate the player only while the vehicle is stationary. Operating them while the
vehicle is moving could cause an accident.
Adjust the volume so that sound outside of the vehicle can be heard. If outside
sound cannot be heard, accidents may be harder to avoid.
Do not install a radio equipment antenna near the vehicle's radio antenna. This
could cause unwanted noise on the radio or while playing a CD.
•
•
•
ADVICE
Do not allow water to come into contact with the player. It may cause damage to
the player.
•
Chapter index tab
Use this for quick access to
your desired chapter.
Chapter/section titles
These titles are useful for getting the gist of
the content at a glance.
Symbols
See the preceding page for the meanings of these symbols.
ADVICE NOTECAUTION
Note: This page is shown only as an example. It is not intended to give you information on your particular
audio.
All values in this manual are indicated primarily according to the International System of Units (or in SI
units) with the conventional metric values and American units indicated in parentheses.
HOW TO USE THIS MANUAL

0-3
Use chapter/section titles as keys
Page 0-5
Search for the page describing the specific
topic by using the general table of contents
under CHAPTER DESCRIPTION, the
CHAPTER INDEX, and/or the TABLE
OF CONTENTS on the first page of each
chapter.
HOW TO FIND A SPECIFIC TOPIC

0-4

0-5
RADIO AND CD/USB PLAYER················ 1
HOW TO USE THIS MANUAL AND
HOW TO FIND A SPECIFIC TOPIC ·········· 0
CHAPTER DESCRIPTION

0-6

●Precautions 1-2
●Control Panel 1-2
●Using the Audio System 1-18
●Trademarks 1-26
1
RADIO AND CD/USB PLAYER

1-2 RADIO AND CD/USB PLAYER
Control Panel
The CD/USB player can be used when the starter switch is in the "ACC" or "ON"
position.
No. Name
1Ejectbutton
2 FLD/CH button
3CDslot
4TUNE/TRACKbutton
5 Volume control button
No. Name
6 USB terminal
7Minijack
8FUNC/DISPbutton
9MODE/Powerbutton
1 2 3 4
9 8 7 6 5
Precautions
CAUTION
Operate the player only while the vehicle is stationary. Operating them while the
vehicle is moving could cause an accident.
Adjust the volume so that sound outside of the vehicle can be heard. If outside
sound cannot be heard, accidents may be harder to avoid.
Do not install a radio equipment antenna near the vehicle's radio antenna. This
could cause unwanted noise on the radio or while playing a CD.
•
•
•
ADVICE
Do not allow water to come into contact with the player. It may cause damage to
the player.
•

1-3
RADIO AND CD/USB PLAYER
Turning the Power On
Press the "MODE/Power" button to turn the power on. Press and
hold it for 1 second or more to turn the power off.
Volume Adjustment
Press the "Volume control" button to adjust the volume.
: Volume will increase 1 step every time the button is pressed.
Volume will continuously increase when the button is pressed
continuously.
: Volume will decrease 1 step every time the button is pressed.
Volume will continuously decrease when the button is pressed
continuously.
It can be adjusted between 63 (maximum) and 0.
Default setting is 19.
ADVICE
Turning the power on or off with the volume set to maximum will damage the
equipment and your hearing. Set the volume to a moderate level.
•
Adjustment of bass, treble, fader, and balance, and setting of sound effect, clock
display and time can be performed.
Adjustment of Bass Level
1. Press the "FUNC" button to display "BAS".
2. Press the "TUNE/TRACK" button (" ") while "BAS" is
displayed to adjust the bass level.
: Level will increase every time the button is pressed.
: Level will decrease every time the button is pressed.
It can be adjusted in the range of -5 ↔-4 ↔-3 ↔-2 ↔-1 ↔
0 ↔1 ↔2 ↔3 ↔4 ↔5.
Default setting is 0.
Function Setting Mode

1-4 RADIO AND CD/USB PLAYER
NOTE
Adjustment of rear speaker volume is not possible if there are no rear speakers
installed.
•
Adjusting Treble
1. Press the "FUNC" button to display "TRE".
2. Press the "TUNE/TRACK" button (" ") while "TRE" is
displayed to adjust the treble level.
: Level will increase every time the button is pressed.
: Level will decrease every time the button is pressed.
It can be adjusted in the range of -5 ↔-4 ↔-3 ↔-2 ↔-1 ↔
0 ↔1 ↔2 ↔3 ↔4 ↔5.
Default setting is 0.
Adjusting Fader
1. Press the "FUNC" button to display "FAD".
2. Press the "TUNE/TRACK" button (" ") while "FAD" is
displayed to adjust the front and rear speaker volume.
: Front speaker volume will increase every time the button
is pressed.
: Rear speaker volume will increase every time the button is
pressed.
It can be adjusted in the range of R7 ↔R6 ↔R5 ↔R4 ↔
R3 ↔R2 ↔R1 ↔0 ↔F1 ↔F2 ↔F3 ↔F4 ↔F5 ↔F6 ↔
F7.
Default setting is 0.

1-5
RADIO AND CD/USB PLAYER
Adjusting Balance
1. Press the "FUNC" button to display "BAL".
2. Press the "TUNE/TRACK" button (" ") while "BAL" is
displayed to adjust the balance of volume from the left and
right speakers.
: Right speaker volume will increase every time the button
is pressed.
: Left speaker volume will increase every time the button is
pressed.
It can be adjusted in the range of L7 ↔L6 ↔L5 ↔L4 ↔L3
↔L2 ↔L1 ↔0 ↔R1 ↔R2 ↔R3 ↔R4 ↔R5 ↔R6 ↔R7.
Default setting is 0.
Switching the Time Display
1. Press the "FUNC" button to display "CLK".
2. Press the "TUNE/TRACK" button (" ") while "CLK" is
displayed and select "ON"/"OFF".
"ON": Clock is displayed.
"OFF": Clock is not displayed.
Setting Sound Effect
"Sound Effect (SE) " enhances the natural sound image, and
rich bass from any size speaker system.
1. Press the "FUNC" button to display "SE".
NOTE
Not operated during the AM mode.•
2. Press the "TUNE/TRACK" button (" ") while "SE" is
displayed and select "ON"/"OFF".

1-6 RADIO AND CD/USB PLAYER
Setting the Hour
1. Press the "FUNC" button to display "CLK" and make the
clock display (hours) blink.
2. Press the "TUNE/TRACK" button (" ") while the clock
display (hours) is blinking to adjust the time (hours).
: Time (hours) will increase every time the button is
pressed.
: Time (hours) will decrease every time the button is
pressed.
Setting the Minutes
1. Press the "FUNC" button to display "CLK" and make the
clock display (minutes) blink.
2. Press the "TUNE/TRACK" button (" ") while the clock
display (minutes) is blinking to adjust the time (minutes).
: Time (minutes) will increase every time the button is
pressed.
: Time (minutes) will decrease every time the button is
pressed.
NOTE
When the clock display is "ON", it is displayed prioritized over the audio display
(radio frequency, song number, or elapsed time).
When the power source is interrupted by battery disconnection, the time of the
clock will be reset.
•
•

1-7
RADIO AND CD/USB PLAYER
NOTE
When the displayed frequency reaches the highest frequency, it will return to the
lowest frequency. When the lowest frequency has been reached, it will return to
the highest frequency.
Program your preferred radio stations to the "Preset" buttons in advance to
conveniently use them during driving.
•
•
Reception frequency
AM 522 - 1629 kHz (9 kHz step)
FM 87.5 - 108.0 MHz (0.05 MHz step)
Tuner Mode Operations
Tuning
1. Press the "MODE" button when the power is on to select
either AM radio or FM radio.
It is switched to AM radio when "AM" is displayed, and FM
radio when "FM" is displayed.
2. Press the "TUNE" button (" ") for less than 2 seconds
to select a radio station manually.
Each time the button is pressed, the frequency steps up
(or down) to select the station of your choice.
Press the "TUNE" button (" ") for 2 seconds or longer to
select a radio station automatically. The automatic tuning will
stop after detecting a receivable station. Press the "TUNE"
button (" ") again to cancel this function.
Calling Out Preset Channels
A maximum of 6 stations can be programmed and called out in the "Preset" channels
for each of the FM radio and AM radio.
1. Press the "CH" button for less than 2 seconds.
2. Press the "TUNE" button (" ") and select the station
programmed in the preset channels.
As an example, "CH1" is displayed.

1-8 RADIO AND CD/USB PLAYER
Programming Preset Channels
1. Display the channel number you wish to program.
2. Press the "CH" button for 2 seconds or longer.
The frequency display will blink.
3. Press the "TUNE" button (" ") to select the frequency you
wish to program.
4. Press the "CH" button for 2 seconds or longer.
Once it has been set as a preset channel, the frequency
display will stop blinking.
NOTE
The radio stations in memory are erased when the power supply is interrupted
to replace the battery or fuses.
•

1-9
RADIO AND CD/USB PLAYER
ADVICE
Check that there is no CD in the player before inserting a CD. Forcibly inserting
a CD could damage the CD or cause the player to malfunction.
•
Playing CDs (When There is No CD Inserted)
Insert a CD into the CD slot with the label side (printed side) facing up. The power will
switch on and playback will start automatically.
CD Operations
NOTE
Gently push the CD into the player and it will automatically load.
At the start of the playback of a CD, track (music file) number will be indicated
on the display.
The first session on a disc containing both CD-DA data and MP3/WMA data is a
CD-DA file, only CD-DA files will be playback.
Files protected by DRM (Digital Rights Management), cannot be playback on
this unit.
•
•
•
•
Playing CDs (When There is a CD Inserted)
Press the "MODE" button when the power is on. "DISC" will appear
and playback will resume from where it was stopped.
Switching the Displayed Items on the Display
Every time the "DISP" button is pressed for 1 second or more, the
track (file) number and elapsed time is switched.
ADVICE
Use 12cm disc. Do not use 8cm disc or an adapter for 8cm disc.•

1-10 RADIO AND CD/USB PLAYER
Replaying the Same Track
Press the "TRACK" button (" ") for less than 1 second to start
playback of the current track from the beginning.
Selecting a Song in a Folder
For CD (MP3/WMA):
1. Press the "FLD" button for less than 1 second.
Folder number is displayed.
As an example, "F100" for folder number 100.
Track Selection
Press the "TRACK" button (" ") for less than 1 second to select
the desired track number.
: Advance to the next track.
(press twice or more): Return to a previous track.
2. Press the "TRACK" button (" ") to select a folder number.
: Increase folder number
: Decrease folder number
Fast Forwarding/Fast Reversing
Press and hold the "TRACK" button (" ") during playback to
advance the music forward or backward quickly.
Fast forward or fast reverse is stopped and the music is played
back when the "TRACK" button (" ") is released.
: Fast forward
: Fast reverse
