Quick Guide
MC SW5
Industrial Switch
MC Technologies GmbH ‐ Kabelkamp 2 ‐ D‐30179 Hannover
Telefon [phone] ‐ 0 ‐ Fax [phone]
www.mc‐technologies.net ‐ www.mct‐shop.net
sales@mc‐technologies.net
Frontview
4. Status LEDs
LED State Indicaon
LINK/ACT Steady A valid network connecon established. LINK stands for LINK.
Flashing Transming or receiving data.
ACT stands for ACTIVITY.
100
Steady The port is transferring at 100Mbps.
Off The port is transferring at 10Mbps if this LED
is dark.
Depending on the usage of the switch and the supply voltage,
power consumpon differs from 7mA to 70mA.
Please see table below.
5. Power Consumpon
State Current @24V Current @12V
power up 20mA 41mA
idle 7mA 16mA
1 port connected 14mA 29mA
2 ports connected 19mA 39mA
3 ports connected 24mA 51mA
4 ports connected 28mA 60mA
5 ports connected 35mA 70mA
MCT 07.2015

Quick Guide
The MC SW5 is an Industrial Ethernet switch with 5 Ethernet ports
and Auto‐negoaon 10/100 Mbps.
The switch is a plug‐and‐play Fast Ethernet Switch in compact size.
It doesn't have any complicated soware to set up.
1. Power Supply
The Switch is powered by DC Power which has to be supplied at
the DC Terminal Block. The input voltage range can be 12‐48V DC.
You can check the correct power supply at the PWR‐LED at the
frontside of the Switch.
Label Comment
PWR +12‐48V DC
GND Ground
PE (Ground)
• 100Base‐FX: Mul mode SC or ST type, Single mode SC or ST
type.
• 100Base‐BX: WDM Mul mode or Single mode SC type.
• Supports 1024 MAC addresses, 448K bits buffer memory.
• IEEE802.3x Flow control for Full‐duplex, Back pressure for
Half‐duplex.
• None‐blocking architecture and full wire‐speed forwarding
rate.
• Supports IEEE802.1p QoS with two priority queues.
• Supports IEEE802.3az Energy Efficient Ethernet (EEE).
• Supports max. length of frame up to 1552 Bytes.
• Power consumpon: 2.12W max.
• Power Supply: DC Terminal Block power input, 12‐48V DC.
• Operang temperature ranges from ‐10°C to 60°C.
• Plasc compact DIN‐Rail industrial case design.
• Startup: Connect the supply voltage to start up the device via
the terminal block.
2 Assembly
3 DIN Rail Mounng
2. Funconal Descripon
• Complies with EN61000‐6‐2 & EN61000‐6‐4 Generic
standard immunity for industrial environment.
• Supports IEEE802.3az 10Base‐Te only. 10Base‐T is not supported.
10Base‐Te is fully interoperable with 10Base‐T over 100m of
class D (Category 5) or beer cabling as specified in ISO/IEC
11801:1995.
• Supports 802.3az/802.3u/802.3x. Auto‐negoaon:
10/100Mbps, Full/Half‐duplex. Auto MDI/MDIX.
• Dismantling: Pull out the lower edge and then remove the
device from the DIN rail.
4 Dismantling
1 Power Supply Terminal Block
3. Assembly, Startup and Dismantling
• Assembly: Place the device on the DIN rail from above. Push
the front of the device towards the mounng surface unl it
audibly snaps into place.
