REACH-IN
Quick Reference Gui e
America's Quality Choice
in Refrigeration
Reach-in Coolers & Freezers • Prep Tables
Merchan isers • Pizza Tables
Narrow Body Reach-in Wide Body Reach-in Pass-thru Refrigerators
Base MountDual-temp
Roll-in Parts and Labor Warranty
McCall warrants to the original Purchaser-User
its product as per the following schedule:
All Parts: One year from original installation.
abor: One year from original installation.
Compressor: Five years from original installation.
The obligation of McCall under this warranty is limited to McCall
repairing or replacing, free of cost to Purchaser-User, any part or parts,
that in the judgement of McCall show evidence of defect, and provided
that upon McCall authorization, said part or parts to be returned to
McCall, transportation prepaid, for inspection and judgement. This
warranty covers only McCall manufactured self-contained cabinets.
This warranty is issued only to the original Purchaser-User, is not
transferable, applies only to a unit installed within the United States of
America, its territories and Canada and is in lieu of all other warranties
expressed or implied. McCall neither assumes nor authorizes any other
person to assume for McCall any liability not herein stated.
McCall shall not be liable for any damage or delays occurring in transit,
for any default or delays in performance caused by any contingency
beyond its contract including wars, government restrictions or restraints,
strikes, short or reduced supply of raw materials, fire, flood or other acts
of God, nor for damage or loss of any products, property, loss of income
or profit due to malfunctioning of sold unit.
Bakery CabinetsHeated Holding Cabinets
Refrigerators & Freezers only
available in one section model.
Three quality levels offered.
Models Section
1-1020N (F) 1
2-2020N (F) 1
4-4020N (F) 1
Freezers are ordered with
(F) model numbers.
Refrigerators & Freezers only
available in one section model.
Three quality levels offered.
Models Section
1-1024 (F) 1
2-2024 (F) 1
4-4024 (F) 1
Freezers are ordered with
(F) model numbers.
Available in one and two
sections and as narrow
body model. Three quality
levels offered.
Models Section
1020-H 1
1045-H 2
1020N-H 1 Narrow
Available in one, two,
and three sections with
retarder and proofer
options. 1000 Series
quality level only.
Models
H5-5001
H5-5002
H5-5003
P5-5001
P5-5002
P5-5003
Available in one, two
and three section.
Three quality levels
offered. Also available in
a Dual-temp pass thru
2 & 3 section.
Models Section
DT1-102001 1
DT1-1045 2
DT1-1070 3
Two sided access for
maximum flexibility.
Available in one, two,
and three sections
and three quality levels.
Models Section
1-1020P 1
1-1045P 2
1-1070P 3
(Glass door model shown)
Refrigerators and Freezers
available in one or two
sections and three
quality levels.
Models Section
1-1014 (F) 1
1-1018 (F) 1
1-1036 (F) 2
Freezers are ordered with
(F) model numbers.
Refrigerators & Freezers
available in one, two, and
three sections, three quality
levels. 65" or 72" cart
capacity.
Models Section
1-1001 (FE) 1
1-1002 (FE) 2
1-1003 3
Freezers are ordered with
(FE) model numbers.
DR-3 Drop-in/R-10E
Undercounter Super
Prep Table.
One through six full-size pan
capacity models. All metal
welded construction with
cold wall technology.
Number
Models of Pans
DR-1 1
DR-2 2
DR-3 3
DR-4 4
DR-5 5
DR-6 6
45" and 48" wide models
with frozen storage and two
temperature condiment pans.
Available in 1000 Series
quality level only.
Models
FST-45-2EN
FST-48-3EN
Refrigerator
Only available in one
section model. Three
quality levels offered.
Models Section
1-1010 1
2-2010 1
4-4010 1
-10°F Reach-in Freezers
Available in one, and
two sections and three
quality levels.
Models Section
1-1024UF 1
1-1045UF 2
Only 24" Wide! 33.5" Wide!
I O Certification
McCall has acquired certification to the ISO 9001
Quality Systems Standard. ISO, the International
Organization for Standardization maintains a series
of five international standards that provide guidance in
the development and implementation of an effective quality
management system. ISO certification benefits restaurant operators
worldwide by assuring them of consistent quality in all of McCall’s
product lines.
alad Bar Drop-inDrop-in Refrigerationmoothie TablesCounter Top Reach-in
2322C ©200 7 McCall 9/07
MCCALL REFRIGERATION, INC.
81 West Holly Street
Parsons, TN 38363, USA
Ph: 888-732-2446 • Fax: [phone]
Visit us online at www.mccallrefrigeration.com
High quality, inn vative s luti ns that fulfill all y ur “c ld-side” needs.
The Manit w c F dservice Gr up is c mprised f
three divisi ns and eight brand names.
The three divisi ns are Manit w c Beverage,
Manit w c Ice, and Manit w c Refrigerati n.
Within the Beverage Divisi n are brand names
Servend, Multiplex, and McCann's;
within the Ice Divisi n is Manit w c Ice;
and within the Refrigerati n Divisi n
are K lpak, McCall, Harf rd, and K laire.
Visit us t day at www.manitowocfsg.com
ISO 9001: 2000
Quality System
Certified
EnergyMizerTM
ook for the EnergyMizer™mark and you’ll
know you’re getting the most from every
energy dollar spent on foodservice equipment.
www.energymizer.com

1 ection Refrigerators
Models Series
1-1020 1000
2-2020 2000
4-4020 4000
1 ection Freezers
Models Series
1-1020F 1000
2-2020F 2000
4-4020F 4000
PRESERVATION Reach-in Refrigerators and Freezers
PREPARATION
PRESENTATION Display Cases and Revolving Merchandiser
2 ection Refrigerators
Models Series
1-1045 1000
2-2045 2000
4-4045 4000
2 ection Freezers
Models Series
1-1045F 1000
2-2045F 2000
4-4045F 4000
3 ection Refrigerators
Models Series
1-1070 1000
2-2070 2000
4-4070 4000
3 ection Freezers
Models Series
1-1070F 1000
2-2070F 2000
4-4070F 4000
1000, 2000, and 4000 eries
1000 eries
Exclusive 1000 Series Features
• Stainless steel cabinet interior and exterior front, sides, and doors.
2000 eries
Exclusive 2000 Series Features
• Stainless steel cabinet exterior front, sides, and doors.
• Heavy gauge aluminum cabinet interior with stainless steel floors.
4000 eries
Exclusive 4000 Series Features
• Heavy gauge anodized aluminum cabinet exterior sides.
• Stainless steel cabinet fronts and doors except for aluminum ends
that wrap around front.
• Heavy gauge aluminum cabinet interior with stainless steel floors.
tandard Features
•Windrunner®cools more evenly and efficiently
(see Windrunner®side bar).
•Expansion Valve Refrigeration system provides fast, efficient response
to load changes, cooling food quickly.
•Hot Gas Evaporator uses heat by-product to eliminate condensation
saving you money.
•tainless teel Heavy Duty helf upports. Adjustable every inch
to maximize your storage possibilities.
•Clean urfaces free of fasteners and light switches.
•Heavy Duty Chrome-plated Camlift Hinges are warranted for IFE,
and have built in light switch. Adjustable door stop allows door swing
of 120º or 180º.
•Rigid and Durable All Metal Door.
Available in one, two, and three
sections.
7000 eries Refrigerator
Models Section
7-7020T 1
7-7045T 2
7-7070T 3
7000 eries Freezers
Models Section
7-7020FT 1
7-7045FT 2
7-7070FT 3
7000 eries Features
Cabinet Exterior: heavy gauge anodized aluminum. Stainless steel door
and hatch cover.
Cabinet Interior: mill finish aluminum.
tandard Features:
Features:
• 27", 45", and 59" wide
models with 10", 12",
or 17", full-width
removable/reversible
synthetic cutting board
respectively.
Features:
• One, two, and three section
can accomidate from one
to four-12" x 20" inserts.
• Pans can be up to
6" deep.
• Drawers available on two
and three section models.
Features:
• 27", 45", and 59" wide models.
• Available in one or two section
refrigerator or freezer models.
Features:
• One, two, and three section
refrigerator or freezer models.
• Available with aluminum or
stainless steel interior.
• Remote refrigeration system
option on some models.
Low Boy and
Compact Low Boy Models
Self-contained and remote
refrigeration system models
available with stainless steel top
with “V” edge or sub-top, flat
galvanized.
Glass Door Reach-in Refrigerator Only.
Available in one, two, and three sections
with two pane glass door and three quality
levels.
Models Section
1-1020GD 1
1-1045GD 2
1-1070GD 3
Display Merchandiser
DM115
• 48" Wide
• Stainless steel exterior and interior
with white baked enamel interior
air duct.
• Convenient 36" countertop height.
MGM Revolving Merchandisers
MGM-25-2 (two door)
MGM-25-3 (three door)
• Show off your best products with this rugged,
solid oak merchandiser
• An attractive showcase and compelling focal
point for products ranging from desserts
to wine.
• Place the completely self-contained and mobile
MGM anywhere on your floor and watch the
impulse purchases follow!
Refrigerated Cabinets
•Uniform Temperatures. There is an average variance
of less than 2º F throughout the cabinet.
•Reduced Pulldown Time. Food remains fresher
longer and waste is reduced while meeting Health
Department requirements.
•Reduced Compressor Running Time. Since the cooling
process is more efficient, the motor runs less often for
shorter periods, saving electrical costs and extending the
life of the equipment.
•Decreased Outside Air Intrusion. Uniformity of air flow
and temperature works to prevent low pressure spots
where outside air can enter more easily when the door
is opened.
McCall Quality tatement
At McCall Refrigeration, we strive to make the best and most affordable
Reach-in Cabinets available in the industry. Examine our full line of
Reach-ins and you'll find premium quality and unsurpassed value
everywhere you look. Featuring stainless steel and aluminum construction,
our units are built to last. Doors and heavy-duty hardware can withstand
years of use. Plus, all McCall products go through an unprecedented 100%
run test to ensure product quality.
Prep Tables Pizza Tables Undercounter Work Tables Work Tables Chef tands
McCall Partner with Energy tar
McCall Refrigeration has been an Energy Star Partner since the introduction
of the Commercial Refrigeration Energy Star Program.
Energy Star is a broad partnership designed to promote
buildings, products and homes that use less energy
while providing better performance than conventional
designs. Manufacturers in the Energy Star Program
must meet certain identified criteria and energy
efficiency specifications. McCall has joined with Energy Star to help protect
the environment as well as save money on consumer utility bills. McCall has
qualified over 130 models, including two section refrigerators, one section
refrigerators, -10°F freezers, three section freezers, and two section freezers.
Contact your local sales representative for an explanation of
model numbers and additional quality features, or visit us online at:
www.mccallrefrigeration.com
Windrunner®Technology — No warm spots! No dead spots! —
Pizza Prep Table
•N F tandard 7 Compliant. U approved and meets or exceeds FDA and
HACCP program standards for sanitation and safety use by operators.
•Maximum Pan Flexibility and Capacity. Use up to (18) 6" deep 1/6 pans
to save motion, time and money. No fixtures or mullions to block flexibility.
You set them how you want them.
•eparated torage Compartments. This design eliminates cross
contamination issues. Food cannot fall from the pans into the storage area
below. Windrunner®manages and cools air within the storage unit with
carefully directed air streams.
•Cold Wall Rail. Windrunner®technology uses a refrigerated, wrap around,
insulated rail that keeps products cool and fresh. Internal air movement has
been redirected within the upper unit to prevent dead spots no matter how
you arrange your pans. A managed air flow gives you the temperature you
want and reduced energy costs.
• Top mounted compressor and evaporator coil.
• Windrunner®gradient air displacement process.
• Thermostatic temperature control.
• Hot gas condensate evaporator.
• Automatic defrost.
• Cord and plug attached.
• Master power switch.
• R-13A Refrigerant.
• Automatic interior light.
• Dial Thermometer.
• Adjustable doorstops.
