No. STK
CODE Parts No. Description Q No. STK
CODE Parts No. Description Q No. STK
CODE Parts No. Description Q
1 C MC-9228-320106 MAIN BODY 1 1-11 C CONNECTING ROD 1 1-46-1 B INSERT 1
1-1 C COVER ,CYL 1 1-12 B BEARING 2 1-46-2 C OUTER HOUSING 1
1-2 B HUS/HANDLE ASS'Y 1 1-13 B GASKET, CYL 1 1-46-3 C COVER , FAN 1
1-2-1 C HUS ASS'Y 1 1-14 C GASKET , MANIFOLD 1 1-46-4 B SCREW 1
1-2-1-1 B SCREW 3 1-15 B SPACER , RUBBER 2 1-46-5 B SCREW 1
1-2-1-2 A PLATE 1 1-16 B NUT 3 1-46-6 B SPRING , TORSIONAL 1
1-2-1-3 A PULLET STARTER 1 1-17 C MANIFOLD 1 1-46-7 B PIN 1
1-2-1-4 B SPRING ASS'Y 1 1-18 B GASKET 1 1-46-8 B SPRING 1
1-2-1-5 B KIT , STARTER HUS ASS'Y 1 1-19 B SCREW 1 1-46-9 B SCREW 2
1-2-1-6 A ROPE 1 1-20 C CARBURETOR ASS'Y 1 1-47 C HANDLE 1
1-2-1-7 A ROPE GUIDE 1 1-21 C BOX, AIR FILTER 1 1-48 B WASHER 1
1-2-2 C HUS ASS'Y 1 1-22 C PLATE , AIR BOX 1 1-49 B CABLE 1
1-2-2-1 C HOUSING 1 1-23 B SCREW 2 1-50 A THROTTLE TRIGGER 1
1-2-2-2 C INSERT , BRASS 3 1-24 B FILTER , AIR 1 1-51 A SWITCH 1
1-2-2-3 B ROPE GUIDE 1 1-25 C COVER , AIR BOX 1 1-52 B ISOLATOR 1
1-2-3 C COVER , ROPE 2 1-26 B SCREW 11 1-53 A PLATE 1
1-2-4 A HANDLE 1 1-27 B SCREW 3 1-54 B RETAINER RING 2
1-2-5 B WASHER 1 1-28 C WIRE ASS'Y , GROUD 1 1-55 B FUEL TANK ASS'Y 1
1-2-6 B SCREW 7 1-29 C WIRE ASS'Y , STOP SWITCH 1 1-55-1 B FUEL TANK 1
1-2-7 C LOCK 1 1-30 B IGNITION ASS'Y 1 1-55-2 B HOSE 1
1-2-8 B SPRING 1 1-31 B SCREW 3 1-55-3 B HOSE 1
1-2-9 B RING , RETAINING 1 1-32 B CRANKSHAFT PLUG 1 1-55-4 B FILTER 1
1-2-10 B HARNESS LINK 2 1-33 B GASKET 1 1-56 B FUEL CAP ASS'Y 1
1-2-11 C ISOLATOR RUBBER 3 1-34 C SHIELD , MUFFLER 1 1-57 C SIDE HANDLE ASS'Y 1
1-2-12 B SPACER 3 1-35 C C'CASE/C'SHAFT ASS'Y 1 1-57-1 C SIDE HANDLE 1
1-2-13 B WASHER 6 1-36 B KEY 1 1-57-2 B RETAINER , NUT 2
1-2-14 B SCREW 3 1-37 B SHROUD , ENGINE 1 1-57-3 B NUT 2
1-2-15 C HANDLE , LEFT 1 1-38 B SCREW 7 2 C MC-9186-320102 TUBE , SUCTION 1
1-3 B MUFFLER ASS'Y 1 1-39 B FLYWHEEL ASS'Y 1 3 C MC-9186-320101 TUBE , OUTER 1
1-4 C PLATE , MUFFLER 1 1-40 B WASHER 1 4 C MC-9129-320102 TUBE , BLOWER 90 DEG 1
1-5 A SPARK PLUG 1 1-41 B NUT 1 5 C MC-9186-320001 NOZZLE , FISHTAIL 1
1-6 C CYLINDER 1 1-42 C DISC-FIXED 1 6 C MC-9186-320002 TUBE 1
1-7 B RING , PISTON 11-43 B IMPELLER 1 7 C MC-9279-320103 BAG 1
1-8 B PISTON 11-44 C DISC-DRIVE 1 8 A MC-9149-320101 HARNESS 1
1-9 B PISTON PIN 11-45 B NUT 1 9 B MC-9SGABA3.5-07 SCREW 1
1-10 B RING , RETAINING 11-46 C COVER ASS'Y 1
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED DATE PAGE
Date
Mar-02
32cc Blower / Vac 1/14/2004 N/A 1/2
MODEL NO. MB3201 / 41BS321G077
SERVICE SPARE PARTS LIST
