McCulloch MCM2011 Guide

SERVICE SPARE PARTS LIST
DATE
6/6/2007
V2
REVISED DATE
6/6/2007
SPECIFY MODEL NO. WHEN ORDERING PARTS
16" Reel Mower
MODEL NO. MCM2011
SERVICE SPARE PARTS LISTSERVICE SPARE PARTS LISTSERVICE SPARE PARTS LISTSERVICE SPARE PARTS LISTSERVICE SPARE PARTS LIST

MCM2011
6/2/2009
No. Parts No. Description Q P Code
1 6199-201001 FOAM-RUBBER COVER 1 160
2 6068-201006 UPPER HANDLE 1 160
3 6068-201007 MIDDLE HANDLE 2 160
4 6SHDB-06-35 SQUARE SCREW 6 160
5 6WFE-06 FLAT WASHER 8 160
6 6134-201001 KNOB 8 160
7 6068-201004 LOWER HANDLE A 1 160
8 6CE-09 E CLIP 2 160
9 6122-201001 ROLLER WHEEL 5 160
10 6059-201101 TUBE 4 160
11 6021-201002 HEIGHT ADJUSTMENT BRACKET 2 160
12 6043-201001 HEIGHT ADJUSTMENT FIXED WASHER 2 160
13 6SHDB-06-30 SQUARE SCREW 2 160
14 6111-201101 SHAFT 1 160
15 6250-201101 CUTTER 1 160
16 6SFDZ-3/8-30 HEX SCREW 2 160
17 6SXAB-5/16-15 HEX SCREW 4 160
18 6SRCB-5/16-30 HEX SCREW 2 160
19 6CE-13 E CLIP 2 160
20 6122-201002 METAL WHEEL 2 160
21 6073-201001 GEAR 2 160
22 6004-201005 BRACKET (L) 1 160
23 6059-201002 FIXED TUBE 2 160
24 6017-201101 COVER 1 160
25 6155-201001 BEARING 2 160
26 6130-201001 SHAFT HOLDER 2 160
27 6115-201001 PIN 2 160
28 6250-201102 CUTTER 1 160
29 6131-201001 IRON RING 1 160
30 6198-201001 SPRING COVER 1 160
31 6024-201001 SPRING 1 160
32 6004-201006 BRACKET (R) 1 160
33 6WFZ-16 WASHER 2 160
16" Reel Mower
PARTS LIST

34 6068-201005 LOW HANDLE B 1 160
35 6SRCB-5/16-25 HEX SCREW 2 160
36 6NAZ-5/16 NUT 4 160
37 6014-201001 WASHER 2 160
