No. STK CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 MC-6059-203A01 TUBE 1 17 MC-6159-203A01 BRUSH HOLDER 2
2 MC-6010-203A02 WIRE 1 18 MC-6038-203A02 HOUSING (R) 1
3 MC-6028-203A02 TRIGGER 1 19 MC-6041-840001 TERMINAL BLOCK 2
4 MC-6022-203A01 SWITCH 2 20 MC-6SDABB04-14 SCREW 2
5 MC-6010-203A01 WIRE 1 21 MC-6043-982002 STRAIN RELIEF 1
6 MC-6024-203A01 SPRING 1 22 MC-6199-203A01 CORD GUARD 1
7 MC-6038-203A01 HOUSING (L) 1 23 MC-6011-203A01 POWER CORD 1
8 MC-6028-203A01 TRIGGER 1 24 MC-6SDABB04-20 SCREW 12
9 MC-6261-203A03 FIELD ASS'Y 1 25 MC-6017-203A04 BLADE COVER 1
10 MC-6MB-608-01 BEARING 4 26 MC-6260-203A03 ARMATURE 1
11 MC-6073-203A01 GEAR 1 27 MC-6262-203A01 COVER 1
12 MC-6250-203A04 20" BLADE 1 28 MC-6SVABB04-10 SCREW 2
13 MC-6115-203A01 PIN 2 29 MC-6252-203A02 GASKET 2
14 MC-6112-203A01 ECCENTRIC SHAFT 1 30 MC-6252-203A01 GASKET 1
15 MC-6111-203A01 OUTPUT SHAFT 1 31 MC-6097-203A14 LABEL (R) 1
16 MC-6216-203A01 BRUSH 2 32 MC-6097-203A07 LABEL (L) 1
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
REVISED
DATE
SPECIFY MODEL NO. WHEN ORDERING PARTS
20" Hedge Trimmer
MODEL NO. MT203A20 / 41AFA20K977
DATE
9/30/2003
SERVICE SPARE PARTS LIST
