McLAREN SPORTS SERIES
PRODUCT GUIDE

2 SPORTS SERIES PRODUCT GUIDE /
INTRODUCTION
The McLaren Sports Series breaks new ground into a
segment not previously occupied by McLaren, bringing our
technological advances to a new audience.
Styling is immediately recognisable as part of the McLaren
family. The distinctive design plays a key role in delivering a
pure McLaren driving experience, from aerodynamic
performance through to great visibility.
The McLaren Sports Series has been designed around an all
new carbon fibre MonoCell II. As with every McLaren this
forms the core of our cars.
The McLaren Sports Series is available as either a 540C, 570S
or 570GT specification. Striking design features such as the
Flying Buttress aid aerodynamics and concave rear window
both feature on Coupé. P1™inspired doors are a feature
across the Sports Series family and provide excellent cooling
performance whilst keeping drag to a minimum.
The McLaren Sports Series is fitted with a 3.8 litre twin-
turbocharged V8, producing 540PS and 540Nm within the
540C and 570PS and 600Nm within the 570S and 570GT
models. Power is transferred through to the road via our
McLaren 7-speed Seamless Shift Gearbox, incorporating
dual clutches to deliver instantaneous gear changes. The
powertrain system and incredibly capable vehicle
architecture combine to deliver class leading performance.
A suite of new optional content is available for the
McLaren Sports Series. The interior trim choices provide a
wide range of personalisation opportunities, including
Carbon fibre components that reduce weight and create a
sporty ambience, while a raft of technology based options
improve day to day usability. Additionally, a luxury
direction can be achieved with options such as the Bowers
and Wilkinson audio system and the ‘By McLaren’ designer
range of interiors. All combined, the vast array of options
allow for a car to be tailored to the customer’s individual
needs and wants.
Lightweight styling power
luxury comfort efficiency
technology performance

3 SPORTS SERIES PRODUCT GUIDE /
CONTENTS
1.0 INTRODUCTION
2.0 AT A GLANCE
Product Positioning 06
USP’s 07
Variant Visualisation 09
Technical Highlights 10
Standard & Optional Content 11
3.0 SHORT STORY
Exterior Features 16
Interior Features 19
4.0 LONG STORY
Exterior Design / Structure / Doors 22
Aerodynamics 25
CF Exterior Options 27
Exterior Colours 28
Chassis
Chris Goodwin 29
Cooling 30
Suspension 31
Steering 32
Wheels 33
Tyres 35
Brakes 36
ESC 37
Powertrain
Engine 39
Controls –Engine and Gearbox 40
Exhaust 43
Fuel System 44
Interior
Design 45
Digital Instrument Cluster 46
McLaren Track Telemetry 47
Interior Trim 48
Seats 72
Brightwork 75
Carbon Fibre Interior Components 76
Carbon Fibre Interior Options 77
Carbon Fibre Interior Upgrade Pack 78
Heating and Ventilation 79
Audio Systems 80
Technical Specification
Performance and Technical Specification 83
Performance vs. Competitors 85
Core Sales Arguments
Core Sales Arguments 570S 86
Sports Series vs. Competitors 87
Sports Series vs. Super Series 95
Aftersales
Warranty & Service 96

4 SPORTS SERIES PRODUCT GUIDE /
570GT CONTENTS
570GT INTRODUCTION 98
4.0 570GT AT A GLANCE
Product Positioning 100
Purchase Motivations 101
Technical Highlights 102
Standard & Optional Content 103
5.0 THE SHORT STORY
Exterior Features 105
Interior Features 107
6.0 THE LONG STORY
Panoramic Roof 109
Touring Deck & Bulkhead 110
The Drive 111
Core Sales Arguments vs. Competitors 112
Performance vs. Competitors 116
Full Performance & Tech Spec 118
Change Log 119

5 SPORTS SERIES PRODUCT GUIDE /
1.0
SPORTS SERIES COUPÉ:
AT A GLANCE

6 SPORTS SERIES PRODUCT GUIDE /
PRODUCT POSITIONING
Introduces the only true Sportscar in the Sportscar segment
The most exclusive option in its class, by far
Designed and hand-crafted in the same facility as the award winning McLaren P1™ and our Formula 1 race team
The most attainable and useable McLaren to date
Pure McLaren DNA throughout
Classic Sportscar layout: rear wheel drive; mid-engine
Ultra light chassis: Carbon Fibre MonoCell II
Breathtaking Performance –Equalled only in the class above
The most rewarding and engaging driving experience in class
McLaren Design Language: Sculpted by air
A useable car to drive every day

7 SPORTS SERIES PRODUCT GUIDE /
McLAREN SPORTS SERIES USP’S
Sports Series offers the most exclusive choice in the segment, by far
A Pure McLaren, designed and hand-built in the same facility as the award winning P1™and our Formula 1 race team
The only true Sportscar in the Sportscar market: Mid engine, Rear Wheel Drive with an extremely stiff, strong and light
carbon fibre Monocell II chassis
Double wishbones, adaptive dampers, Brake Steer (developed for Formula 1, utilised by P1™and lighter than a
conventional limited slip differential), electro-hydraulic power steering and a perfectly balanced lightweight chassis
come together to deliver the purest, most rewarding and engaging driving experience in its class, on both road and
track
The only car in the segment with dihedral doors: inspired by P1™and optimised for efficient cooling and aerodynamics
Sports Series’ design is the result of McLaren design philosophy where, as in nature, beauty is a by-product of function
Designed around the driver and the optimised technical package, a shrink-wrapped aerodynamic body delivers class
leading visibility and driving ergonomics making the car easy to position on the road or track whilst still being relaxing to
drive
A wealth of exterior and interior options offer unrivalled opportunity to tailor and personalise the car to your own
tastes and requirements:
‘By McLaren’ designer interiors coupled with the most powerful high end audio system in the segment
(1,280W) deliver a luxurious and sumptuous interior experience
Alternatively lightweight carbon fibre body panels and interior trim, P-Zero Corsa Tyres, super lightweight
forged wheels, Alcantara Race seats and the McLaren Track Telemetry system (with three integrated track
cameras) deliver a race ready specification
As with all McLaren's, MSO Defined and MSO Bespoke provide the most discerning of customers the
opportunity to create a truly bespoke version of their Sports Series, ensuring their car is one of a kind

8 SPORTS SERIES PRODUCT GUIDE /
McLAREN SPORTS SERIES USP’S
570S SPECIFIC
McLaren’s obsession with weight delivers a Sportscar which is 115 kg (254 lb) lighter than the nearest competitor, and
with all lightweight options fitted, 146 kg (322 lb) lighter
Coupled with McLaren’s award winning fully exposed V8 engine, delivers the highest power to weight ratio (434 PS /
428 BHP per tonne) in the segment
Sports Series delivers breathtaking performance, equaled only in the class above
Fastest in its class to 100 mph
Fastest in its class and faster than the Lamborghini Huracan to 200 kph by 0.4 seconds

9 SPORTS SERIES PRODUCT GUIDE /
VISUALISATION 540C VS. 570S
FEATURE
STANDARD
OPTION
540C CLUB AERO PACK
•Front Aero Aero Blades
•Side Skirts
•Rear Diffuser
Unpainted finish
N/A
570S SPORT AERO PACK
•Front Aero Aero Blades
•Side Skirts
•Rear Diffuser
Painted Dark Palladium
Unique geometry for increased aero
performance
Carbon Fibre

10 SPORTS SERIES PRODUCT GUIDE /
TECHNICAL HIGHLIGHTS
01 0-100 kph (0-62mph)
3.2 SECONDS
McLAREN 570S
03 Top Speed
328KPH
204MPH
McLAREN 570S
02 0-200 kph (0-124mph)
9.5 SECONDS
McLAREN 570S
05 Power & Torque
570 PS 600 Nm
McLAREN 570S
06 CO2
249G/KM
EU - Sports Series
04 Dry Weight
1,313 KG / 2,895LB
McLAREN 570S (Lightest)
07 Weight Distribution
42 : 58
% Front :% Rear
Sports Series

11 SPORTS SERIES PRODUCT GUIDE /
STANDARD SPECIFICATION
540C
New Carbon Fibre MonoCell II
3.8-litre V8 Twin Turbo (with Start-Stop Technology)
7-Speed Seamless Shift Gearbox
Power, 540PS (533bhp)
Torque, 540Nm (398lb-ft)
Active Dynamics Panel (Handling + Powertrain Modes)
Launch Control
McLaren Brake-Steer
Floating Rear Body Panels
Two-Tone Layered Dihedral Doors
Lightweight Composite Brake System with
Aluminium Hubs and Iron Discs
Cast Alloy 19” Front and 20” Rear Wheels
Pirelli P Zero™ Tyres
Full LED Lighting
Leather Interior
IRIS 7-inch touch screen infotainment system
Satellite Navigation
4-Speaker Audio System
Bluetooth Telephony and Media Streaming
iPod and iPhone connectivity
3x USB and 1x Auxiliary Input
Wi-Fi and tethering support
DAB or SIRIUS Satellite Radio
IRIS Electronic Owners Manual
McLaren Keyless Entry + Start
570S*
Power, 570PS (562bhp)
Torque, 600Nm (443lb-ft)
Active Damping S tune
Up rated standard exhaust
Carbon Ceramic Brakes
Forged 570S Wheels
Pirelli P Zero Corsa™ Tyres
Unique and enhanced Aero Blades
Unique Side Skirts
Unique and enhanced Rear Diffuser
570S Side Skirt Branding
Extended Leather Interior
* in addition to 540C Coupé
The standard specification for the McLaren Sports Series includes a number of unique features & inclusive content:

12 SPORTS SERIES PRODUCT GUIDE /
OPTIONAL CONTENT
01 Powertrain
540C Sports Exhaust
570S Sports Exhaust
Stealth Effect Exhaust Finishers
02 Chassis
Front Nose Lift
5-Spoke Lightweight Forged Alloy Wheels
Super-Lightweight Forged Alloy Wheels
Stealth Wheel Finish
Diamond Cut Wheel Finish
Pirelli P Zero Corsa™ Tyres (standard on 570S)
Pirelli SottoZero Winter Tyres
Brake Calliper Colour
Carbon Ceramic Brakes (standard on 570S)
03 Safety & Convenience
Front and Rear Parking Sensors
Rear Parking Camera
Vehicle Tracking System
Volumetric Alarm Upgrade
Branded Matt Set
Car Cover
04 Body
Special and Elite Paint
Carbon Fibre Door Mirrors
Carbon Fibre Wheel Arch Covers
Carbon Fibre Engine Covers (Rear Deck & Plenum)
Carbon Fibre Side Intakes
Stealth Badges
Carbon Fibre Aero Blades (570S only)
Carbon Fibre Side Skirts (570S only)
Carbon Fibre Diffuser (570S only)
Soft-Close Latches
05 Infotainment
McLaren 8 Speaker Audio System
Bowers & Wilkins Surround Sound Audio System
McLaren Track Telemetry Display
McLaren Track Telemetry Display & Three Camera
Recording System

13 SPORTS SERIES PRODUCT GUIDE /
OPTIONAL CONTENT
06 Interior
Extended Leather Interior (Standard on 570S)
Nappa Sport Leather Interior
Nappa Design Leather Interior
Nappa Alcantara Interior
‘By McLaren’ Designer Interior
Contrast Colour Stitching (Dependant on trim)
Full Electric Seats with Heating and Memory
Electrically Adjustable Steering Column
Fixed-Back Carbon Fibre Racing Seats (two sizes)
Alcantara Steering Wheel
Smoked Chrome Interior Brightwork (Available MY17
Coupé)
Light Colour Carpets and Headlining (Areia)
Leather Branded Sill Finishers (Standard with ‘By McLaren’
interiors)
Carbon Fibre Branded Sill Finishers
Carbon Fibre Seat Backs
Carbon Fibre Interior Components including;
Steering wheel clasp
IRIS surround bezel
Centre console and door switch backs
Carbon Fibre Door Insert
Carbon Fibre Tunnel Side
Premium Headlining (Standard on Nappa / ‘By McLaren’
interiors)
07 Option Packs
Carbon Fibre Exterior Upgrade 1
Mirrors
Side Intake
Carbon Fibre Exterior Upgrade 2 (570S Only)
Aero Blades
Side Skirts
Diffuser
Carbon Fibre Interior Upgrade
Interior Components
Door Insert
Tunnel Side
Security Pack
Nose Lift
Front and Rear Parking Sensors
Rear View Camera
Car Cover
Volumetric Alarm Upgrade
Lux Pack
Electric and Heated Seats
Electric Steering Column
B&W 12-speaker Surround Sound System
Soft Close Latches
Branded Matt Set

14 SPORTS SERIES PRODUCT GUIDE /
MSO CONTENT
01 Exterior
MSO Defined Exterior Carbon Fibre Upgrade Pack (Front
Splitter / Rear Bumper / Rear Spoiler)
MSO Defined Carbon Fibre Front Splitter
MSO Defined Carbon Fibre Rear Bumper
MSO Defined Carbon Fibre Rear Spoiler
MSO Defined Carbon Fibre Roof
MSO Defined Carbon Fibre Mirror Arms
MSO Defined Exterior Paint Colour
MSO Bespoke Paint Finish
MSO Defined Exterior Door Insert
02 Interior
MSO Defined coloured Seatbelts: McLaren Orange / Red /
Yellow
MSO Defined Carbon Fibre Interior Air Vents
Unique Stitch Colour
Unique Leather Colours
Unique Alcantara Colours
Embroidered Headrests: Standard and Bespoke Logos
Unique Coloured Carpets
Alcantara Carpets
Alcantara Floor Mats
Above: Car pictured features the MSO Carbon Fibre front splitter and MSO Carbon
Fibre roof. Below: Car pictured features the MSO Carbon Fibre rear bumper and
Rear Spoiler

15 SPORTS SERIES PRODUCT GUIDE /
2.0
SPORTS SERIES COUPÉ:
THE SHORT STORY

16 SPORTS SERIES PRODUCT GUIDE /
EXTERIOR –STANDARD FEATURES
Flying Buttress
Form follows function; this aerodynamic aid
primarily cancels out lift created by the
roof. In addition, this also improves engine
cooling.
McLaren M838TE
540PS (533BHP) / 570PS (562BHP)
3.8-litre Twin Turbo variants of the
M838T family of engines. Quick
engine response, good efficiency and
a superb soundtrack are all Sports
Series trademarks. ‘E’ is for evolution.
Adaptive Dampers
Adaptive dampers mean the Sports
Series is equally at home in urban or
on track environments. 570S models
receive further tuning with the
emphasis on performance.
Aluminium Body Panels
Aluminium has been utilised for its
low weight but also the intricate
designs that can be achieved. The
complex rear deck is achieved by a
process called Superforming.
New Carbon Fibre MonoCell II
A carbon fibre chassis weighing 75KG
(165lb) provides exceptional strength.
A low sill height and optimised door
sweep makes getting in and out easy.
LED Headlights / Rear Lights
Automatic LED lights with overseas
tourist function and Follow Me Home
function are standard across the
range.

17 SPORTS SERIES PRODUCT GUIDE /
Door Design
The intricate P1™inspired door
design plays a significant part in
cooling the powertrain and also
conceals the door button.
Rear Diffuser
For all models a flat under-floor
maximises the effect of the diffuser.
For 570S models only there are more
fences for a further performance
enhancement (available in CF as an
option).
Floating rear body panels
Surrounding the L.E.D rear lights, the
fenders on the Sports Series give the
illusion of floating as they meet the
rear deck and built in rear spoiler.
Superforming Rear Deck / Rear Window / Engine Bay
Intricate detailing on the rear deck is achieved as a result of
a process called Superform (hot aluminium blown into
shape over a mould). A striking concave rear window
features as does an exposed engine bay for efficient heat
evacuation.
EXTERIOR –STANDARD FEATURES
Wheels
For all Sports Series wheel size is 19”
front and 20”rear. 540C has cast
wheels as standard and 570S benefits
from forged wheels (offering a weight
saving) and a different design.
Pirelli Tyres
540C models come with Pirelli P
Zero™ Tyres as standard while 570S
models receive the performance
focused Pirelli P Zero Corsa™ Tyres.

18 SPORTS SERIES PRODUCT GUIDE /
Carbon Fibre Exterior Options
CF options include; side intakes,
mirror casing, front aero blades, rear
diffuser and side skirts (most of which
offer a 50% weight saving vs. the
original component). These can be
selected individually or as part of a
pack (see below for packs and
availability)
Lightweight Wheels
Optional 5-spoke Lightweight Forged
and Super Lightweight Forged wheel
designs are available in either a Silver,
Stealth or Diamond Cut finish. (See
specific section for availability).
EXTERIOR –OPTIONAL FEATURES
4 New Optional Colours
3 new Elite colours (Vermillion Red,
Ventura Orange, Bourbon) and 1
Special colours (Blade Silver).
Exhaust
Both 540C and 570S have their own
unique Sportscar sound as standard.
An optional Sport Exhaust on 540C
provide standard 570S noise levels (+3
dB). The optional Sports Exhaust on
570S takes things yet further (+2 dB).
CF Exterior Upgrade 1
Mirror Casings and Side Intake
(Available on 540C and 570S)
CF Exterior Upgrade 2
Aero Blades, Side Skirts and Rear
Diffuser (Available on 570S only)

19 SPORTS SERIES PRODUCT GUIDE /
INTERIOR –STANDARD FEATURES
Enhanced Visibility
The driver can only get the maximum
from the car once they feel confident
and visibility is key to this. The A-
pillars have been moved further
outboard while compressed B pillars
improve rear visibility as does mirror
position.
IRIS
For Sports Series IRIS is revised and
now features integrated heating and
ventilation controls as per P1™. The 7
inch interface controls the standard
DAB or SIRIUS radio, Satellite
Navigation, Bluetooth and Audio
Media player with Auxiliary and USB
(x3) connections.
TFT LCD Instrument Cluster
This new digital instrument cluster
provides super clear information and
includes features such as ‘Turn-by-
turn’ navigation information and a
race car type display when in Track
mode similar to that found in P1™.
Interior Trim
540C has a standard Leather Interior that is
available in three colour themes. The 570S
benefits from an Extended Leather Interior
available in four colour themes.
Stowage Space
Sports Series benefits from concealed in-door stowage,
glove box (excluding federal) and a stowage bin under
the armrest. The new centre console provides
enhanced stowage for loose items and a cup holder.

20 SPORTS SERIES PRODUCT GUIDE /
INTERIOR –OPTIONAL FEATURES
Interior Brightwork
The brightwork of the interior comes
in a Satin Chrome finish or optional
Smoked Chrome (available MY17
Coupé). The main components in this
pack are; air vent bezels, centre
console surround (upper and lower),
handling and powertrain controls,
seatbelt escutcheon and interior light
surround.
Tailored Interiors Options
In addition to 540C Leather Interior
and 570S Extended Leather Interior
(optional on 540C) there are four
further optional trim levels. All
feature Nappa Leather or Nappa
Leather and Alcantara. The range
culminates in the ‘By McLaren’
designer interiors. These 10 unique
interiors showcase the very best
Sports Series has to offer.
Carbon Fibre Interior Components
The CF interior components pack includes the
steering wheel spokes, extended paddles and
switch pack surrounds replacing the Black
Sparkle metallic finish. As separate items the
door insert and transmission tunnel can also be
specified in Carbon Fibre. A full Carbon Fibre
upgrade pack encompasses all of the above.
Racing Seats
Carbon Fibre Racing Seats based on
those featured in P1™are available as
an option in two sizes. These fixed
back manually adjustable seats offer a
substantial 15Kg (34lb) weight saving
and the provision for harnesses.
In Car Entertainment
The standard audio system provides four speakers.
As an option, an 8-speaker plus audio system and
top of the range Bowers & Wilkins system are
available. The Bowers and Wilkins system features
a distinctive Nautilus tweeter mounted centrally
on top of the facia offering class leading power
and precision.
