mcmurdo SMARTFIND GMDSS NAVTEX Guide

SMARTFIND GMDSS NAVTEX
GMDSS TRI-
CHANNEL
NAVTEX RECEIVER
USER & INSTALLATION MANUAL
VESSEL IDENTIFICATION INFORMATION
Name
Call Sign
MMSI
SMARTFIND GMDSS
NAVTEX S/N
Antenna Type
RX frequencies
supported by antenna
518 kHz
490 kHz
4209.5 kHz
 2015 Orolia Ltd
Part No: 93-204
Disclaimer
The information and illustrations contained in this publication are to the best of our
knowledge correct at the time of going to print. We reserve the right to change
specifications, equipment, installation and maintenance instructions without notice as
part of our policy of continuous product development and improvement. No part of this
publication may be reproduced, stored in a retrieval system or transmitted in any form,
electronic or otherwise without permission in writing from Orolia Ltd. No liability can be
accepted for any inaccuracies or omissions in the publication, although every care
has been taken to make it as complete and accurate as possible.

Contents
SAFETY NOTICES ........................................................................................... 4
QUICK START ................................................................................................. 5
ABOUT SMARTFIND GMDSS NAVTEX ......................................................... 6
INTRODUCTION .............................................................................................. 7
SMARTFIND GMDSS NAVTEX CONTROLS ................................................. 8
OPERATION ..................................................................................................... 9
SETUP MODE ................................................................................................ 14
SYSTEM ALARMS ......................................................................................... 22
ADJUSTING THE DISPLAY .......................................................................... 24
ANTENNA INSTALLATION ........................................................................... 34
OPTIONS ........................................................................................................ 39
EXTERNAL RECEIVER ................................................................................. 39
MAINTENANCE GUIDE ................................................................................. 39
TROUBLESHOOTING GUIDE ....................................................................... 40
NAVTEX STATIONS LIST ............................................................................. 43
END OF LIFE STATEMENT .......................................................................... 47
PRODUCT WARRANTY ................................................................................ 48
EU DECLARATION OF CONFORMITY ........................................................ 49
SOFTWARE REVISIONS ............................................................................... 50
Page 4
SAFETY NOTICES
WARNING: Do not connect the SMARTFIND GMDSS NAVTEX main unit directly to an AC
electrical supply, as an electric shock or fire hazard could result.
WARNING: Do not connect the SMARTFIND GMDSS NAVTEX system to a DC supply
exceeding 31 V or reverse the supply polarity.
CAUTION: Do not bypass the built in fuse
CAUTION: The SMARTFIND GMDSS NAVTEX system is designed for operation in the
temperature range -15 C to +55 C. Do not use the system in environments which exceed this
range.
CAUTION: The SMARTFIND GMDSS NAVTEX unit is not water-proof. Consequently it must
be located in a dry place and must be protected from direct contact with water.
CAUTION: Do not locate the SMARTFIND GMDSS NAVTEX unit in a position where;
a) the controls of the vessel may be obstructed.
b) it may obstruct normal movement around the vessel.
c) it may cause bodily injury.
CAUTION: Unauthorised opening of the SMARTFIND GMDSS NAVTEX unit or antenna
units will invalidate the warranty.
CAUTION: NAVTEX is for use as an aid to navigation and should not lead to a reduction in
the level of good seamanship required at all times.
CAUTION: Reception of NAVTEX messages cannot always be guaranteed and is
dependent on the quality of radio propagation at the time. No liability can be accepted for the non
transmission or non reception of NAVTEX messages.
CAUTION: Compass Safe Distances
SMARTFIND GMDSS NAVTEX main unit compass safe distance 0.87m
Compass deviation; 0.3º at 0.65m
1º at 0.41m.
Recommendation
Connection of a source of UTC data to either COM 1 or 2 is strongly
recommended for best operation of the SMARTFIND GMDSS NAVTEX.

Page 5
QUICK START
SMARTFIND GMDSS NAVTEX is extremely easy to operate:
 Apply equipment connections (page 25)
 Apply power at the vessels power switch panel
 The SMARTFIND GMDSS NAVTEX will start up after a few seconds delay
 Set UTC time and date (automatic when connected to GNSS / GPS)
 Select antenna configuration as passive or active (page 18)
 The SMARTFIND GMDSS NAVTEX will now start to receive and display
NAVTEX messages dependent on the transmission schedule of the NAVTEX
stations within the vessels current region.
Note: It may be several hours before the first message is received; this is dependent
on NAVTEX transmission coverage provided locally.
Take the time to read this manual carefully as it contains essential information
regarding the operation and maintenance of the SMARTFIND GMDSS NAVTEX and
a useful background to the NAVTEX system.
Should you have any questions, or require advice regarding Orolia products our
website ‘frequently asked questions’ is a good place to start. From the web site you
can also leave a message for our customer service team, visit;
www.mcmurdomarine.com
Page 6
ABOUT SMARTFIND GMDSS NAVTEX
The SMARTFIND GMDSS NAVTEX has been designed to meet the requirements of
IMO (International Maritime Organisation) MSC.148 (77) and IEC technical standard
61097-6 (Ed 2.1).
The SMARTFIND GMDSS NAVTEX has three separate receiver channels, one each
tuned to 490 kHz, 518 kHz and 4209.5 kHz. The SMARTFIND GMDSS NAVTEX will
receive on all three frequencies simultaneously in those parts of the world where
transmissions are available (refer to page 43).
The SMARTFIND GMDSS NAVTEX can be set up to filter out stations and/or
message categories that are not required by the User.
The SMARTFIND GMDSS NAVTEX is capable of being connected to an Integrated
Bridge System (IBS), transferring NAVTEX messages to other navigational aids if
required. Note that the IBS must be compliant with the serial port requirements of
IEC 61097-6 (Ed 2.1).
The SMARTFIND GMDSS NAVTEX will accept UTC time & date information via
either COM port if available. UTC time & date will be used to timestamp received
NAVTEX messages.
Permanent installation of the SMARTFIND GMDSS NAVTEX can be made with either
the bulkhead-mounting bracket or the flush panel mounting kit provided.
The NAVTEX antenna should be mounted where it is elevated clear of metal objects
in a location where it cannot easily be damaged.

Page 7
INTRODUCTION
NAVTEX is a method of transmitting navigational warnings and weather forecasts
from designated coast radio stations. All English language transmissions are made on
the 518 kHz NAVTEX channel. Each NAVTEX station is allocated several time slots
during the day when it is permitted to transmit, normally at four hourly intervals. The
exceptions to this are gale warnings and search and rescue messages which may be
transmitted at any time.
Reception of 518 kHz NAVTEX transmissions is normally limited to an area of 200 -
300 miles radius around each transmitting station, although considerably greater
ranges are possible at night. Subject to IMO approval, additional local language
transmissions are sent on 490 kHz and on 4209.5 kHz, SMARTFIND GMDSS
NAVTEX supports simultaneous reception of all three NAVTEX channels.
Designed to the latest International specifications, SMARTFIND GMDSS NAVTEX
meets IMO requirements under GMDSS and is designed for simplicity of operation. It
will provide up to date MSI (Marine Safety Information) and weather forecasts and is
suitable for use by all classes of commercial vessels and large pleasure craft. It will
display and store NAVTEX messages without manual intervention within designated
areas of NAVTEX service coverage.
If the vessel is located within the coverage area of several NAVTEX stations
(particularly at night), the SMARTFIND GMDSS NAVTEX may overwhelm you with
information. It can therefore be set up to display only those stations and message
categories you want to receive and which are applicable to the area in which the
vessel is currently sailing.
Normally, routine NAVTEX messages are repeated at four hourly intervals. Provided
that the SMARTFIND GMDSS NAVTEX is left running, repeated messages are not
displayed more than once. Each message is retained for three days (72 hours) after
its last reception before being automatically deleted, unless the message has been
marked as locked.
Full detail of the GMDSS NAVTEX service can be found in the Admiralty List of Radio
Signals Volume 5, Global Maritime Distress and Safety System (GMDSS) published
by the United Kingdom Hydrographic Office.
The IMO and various national coastguards also have informative websites; see the
links page at www.mcmurdomarine.com
Page 8
SMARTFIND GMDSS NAVTEX CONTROLS
The SMARTFIND GMDSS NAVTEX has been designed to be easy to use with an
intuitive user interface and softkeys.
Backlight key
Softkey labels
UTC (if available)
Status icons
Position (if available)
Main display area
Scroll bar
Softkeys
Indicator LED
Tracker pad
Enter key

Page 9
Display Icons
The SMARTFIND GMDSS NAVTEX displays various icons in the status bar at the top
of the display.
SAR, warning alarm
Unread message indicator
The antenna or antenna cable is faulty
The 518 kHz receiver is receiving
The 490 kHz receiver is receiving
The 4209.5 kHz receiver is receiving
The external receiver is receiving
OPERATION
Switch on the SMARTFIND GMDSS NAVTEX by applying power via a circuit breaker
or switched fuse.
There will be a few seconds delay whilst the software loads the contents of the
NAVTEX message store during which time the front panel red LED will blink.
The SMARTFIND GMDSS NAVTEX start-up screen will now be shown.
This screen disappears after 30 seconds; it may be removed sooner by pressing any
key.
Page 10
The SMARTFIND GMDSS NAVTEX is now ready to receive NAVTEX messages.
Receiving NAVTEX messages
When the SMARTFIND GMDSS NAVTEX begins to receive a signal, one or more of
the receiver icons at the top of the screen will appear to indicate which of the
receivers is active.
When a complete message has been received, a pop-up appears on the display
indicating that a new message is available and the "unread message" icon flashes.
The message can be read by pressing the Enter key, or the popup can be removed
without reading the message by pressing the Right key. As each new message is
received, the SMARTFIND GMDSS NAVTEX may also generate a single short beep
to attract attention to the new message. This audible alert can be disabled on the
Setup mode: System options page if it is not required.
Any messages that are not read immediately will be marked with the "unread
message" symbol in both the Index and Summary modes. The "unread message"
icon at the top of the display continues to flash until all messages have been read.
Note that while the popup Navtex message box is on display only the Enter or Right
buttons have any effect; all other keys are disabled until the popup box is removed.

Page 11
Alarms
The message category is used to classify the nature of each NAVTEX message. Of
particular note are message types 'D' (search and rescue), 'A' and 'L' (navigational
warnings) and 'E', 'B' and 'C' (meteorological warnings). When a message with any of
these message categories is received the SMARTFIND GMDSS NAVTEX operates
its alarm relay contacts and transmits an NMEA "ALR" sentence to the currently
selected alarm port. The alarm relay continues to operate until the alarm is
acknowledged either by removing the popup or by reception of an appropriate NMEA
"ACK" sentence from another connected device. Search and rescue messages
(category 'D') cannot be read later; the popup box can only be cleared by pressing the
Enter key and reading the message.
Finding and viewing NAVTEX messages
The SMARTFIND GMDSS NAVTEX displays NAVTEX messages in several ways
designed to make finding and viewing particular message categories or an individual
message easy and convenient.
Full Message
Message Summary
Message Index
Page 12
Message displays
view first lines
of each message
select another
message group
move cursor to
required message
select time frame
for messages
view selected message
select next
(newer) message
Go to next group
(see text)
go to previous group
(see text)
select previous
(older) message
scroll display up
select next
(newer) message
select previous
(older) message
scroll display down
view first lines
of each message
newest message
selected message
oldest message
Message index display
Message summary display
Full message display

Page 13
Message index display
The Message index display shows the identifiers of messages from a specific
receiver. Unread messages have an “envelope” () mark; locked messages (see Full
message display) have a “key” () mark.
Message identifiers can be expanded to show either the first two lines or the full
message by selecting the desired message and pushing the appropriate softkey.
Messages from another receiver can be displayed using the View softkey, which
cycles through the available sources.
Messages are grouped by time interval. The Show softkey cycles through the set
intervals.
Message summary display
The Message summary display shows the first two lines of each message, selected
by various criteria.
Selection criteria are time, station identity and message type. The Sort by softkey
cycles through these criteria.
Depending on the selection, the “group” is a 4-hour period, a station or a message
type.
The Show softkey controls the total number of messages displayed by suppressing
messages which are older than the selected time frame.
A message can be shown in full by selecting it and pushing the View softkey.
Full message display
Because messages are automatically erased 72 hours after they are received, it is
necessary to take action to retain an important message beyond this time. Displaying
the message and pressing the Lock softkey causes the message to be retained
indefinitely. A locked message is identified by a “key” () mark in the Index display.
A locked message is unlocked by displaying it (in this view) and pressing the Unlock
softkey.
Up to 250 messages can be saved for long term retention; once the limit has been
reached, operating the Lock softkey will not lock any more messages until some are
unlocked again.
Minimising the number of messages displayed
After the SMARTFIND GMDSS NAVTEX has been switched on for a while there will
be a large number of NAVTEX messages stored in memory. These can be quite
overwhelming if the user is looking for particular message categories or an individual
message.
Several design features have been incorporated into the SMARTFIND GMDSS
NAVTEX to make day to day operation easier:
 Separate frequency channel pages
Page 14
 Station filtering
 Message category filtering
 Time-limited display of messages
Separate frequency channel pages
A separate NAVTEX message display is provided for each of the 3 receiver channels.
All 518 kHz messages appear together, all 490 kHz messages appear together and
all 4209.5 kHz messages appear together. Switch between these displays by using
the View softkey.
Station filtering
NAVTEX transmitting stations that are not required can be de-selected by making the
appropriate selections in the Setup screens.
Message category filtering
NAVTEX message categories that are not required can be de-selected by making the
appropriate selections in the Setup screens.
Time-limited display of messages
In order to access recent messages quickly the Show softkey can be used to show
only NAVTEX messages that have been received in the selected time period (last
4 hours, last 12 hours etc)
SETUP MODE
To enter Setup mode, press and hold the ENTER key for 3 seconds.
All of the user-editable setup parameters are stored in non-volatile memory and will
be unchanged after a power cycle, unless otherwise stated in the descriptions of each
individual page.
To exit from Setup mode and return to normal operating mode, press and hold the
ENTER key for 3 seconds until the display returns to normal operating mode, or press
the top softkey to select the next main page.
Note that message pop-ups do not appear while in Setup mode to ensure they do not
interrupt the editing of a configuration field. Always exit from Setup mode when you
have finished configuring the SMARTFIND GMDSS NAVTEX and return to normal
mode before leaving the SMARTFIND GMDSS NAVTEX unattended.

Page 15
NAVTEX message headers
At the beginning of each NAVTEX message there is a message header which
identifies the source and nature of message, time and date of reception, received
frequency and error rate.
For example:
KA59 14:16 19-Jul 518 0%
In the Message Index display only the message identifier is visible.
It is recommended that the user takes time to set up the SMARTFIND GMDSS
NAVTEX to filter out those stations and message categories that are not required. In
this way the display is kept uncluttered; only those messages that are required will be
visible.
Messages are selected for display by the SMARTFIND GMDSS NAVTEX’s software
comparing the Station and Message Category information encoded into the message
identifier (e.g. KA in the diagram above) with the filter settings entered by the user
during setup.
Serial number
Message category
Transmitting Station
Receiv
er error rate
Received frequency
UTC date
UTC time
Message identifier
KA59
Page 16
Colour coding of NAVTEX message headers
The NAVTEX message information bars are colour coded for each type of message
as defined in the table below.
ID Message category Colour
A Navigational warnings CYAN
B Meteorological warnings GREEN
C Ice reports GREEN
D Search and rescue information and pirate warnings RED
E Meteorological forecasts GREEN
F Pilot service messages MAGENTA
G AIS, DECCA messages BROWN
H LORAN messages BROWN
I Not currently used BROWN
J SATNAV messages (GPS, GLONASS) BROWN
K Other electronic navaid system messages BROWN
L Navigational warnings (additional) CYAN
M to U Not currently used BROWN
V Notice to fishermen (US only) BROWN
W Environmental (US only) BROWN
X, Y Not currently used BROWN
Z No message on hand BROWN
Message filters
To enter setup mode, press and hold the ENTER key. After a few seconds the
Message filters page will be displayed.

Page 17
This page can be used to indicate that messages from specified Transmitting Stations
or of specified Message Categories should NOT be displayed, stored or output as
required.
Each receiver has its own separate set of message filters; pressing the
Select
XXXX kHz RECEIVER softkey cycles round the available receivers. The message
filter settings are all non-volatile and will be unchanged after a power cycle.
By default only message categories ‘A’ to ‘F’, ‘H’, ‘J’ to ‘L’, ‘V’ and ‘Z’ are enabled for
all Transmitting Stations. This is indicated by the check boxes for categories ‘G’, ‘I’,
‘M’ to ‘U’ and ‘W’ to ‘Y’ all being marked to indicate that they are being filtered out.
In order to deselect a Transmitting Station or Message Category, navigate to the
relevant checkbox using the pad (, ,  and  keys) and press ENTER. The
checkbox will then be marked to indicate that the Transmitting Station (or Message
Category, as appropriate) is now deselected and will not appear on the display.
Note that deselecting a Message Category (say ‘I’) in the top row (labelled ‘All’) will
remove Message Category ‘I’ from all Transmitting Stations. To disable message
categories from a specific station identity (e.g. ‘K’), scroll down until the selection
panel for ‘K’ is displayed, then select the appropriate check box. Deselecting the first
message category (labelled ‘*’) will toggle the state of all Message Categories from
the selected Station.
Message categories ‘A’, ‘B’, ‘D’ and ‘L’ cannot be individually controlled. A
Transmitting Station cannot be completely deselected but message types can be
deselected with the exception of types ‘A’, ‘B’, ‘D’ and ‘L’.
There are three sets of message filter options for every Transmitting Station and
Message Category. The ‘STORE’ filter indicates that the selected message shall be
neither displayed nor stored in the non-volatile memory. The ‘NRX’ filter indicates that
the message shall not be sent to either COM 1 or 2 on reception (if output of NRX
sentences to either COM 1 or 2 is enabled). The ‘PRINT’ filter indicates that the
selected message should not be sent to the printer on reception (if printer output is
enabled).
Note that the ENTER key toggles the value of any check box from checked to
unchecked and back again. Similarly, toggling any check box in the ‘All’ row, or in the
column headed ‘*’ will toggle the other entries in the row or column as appropriate.
Page 18
Setup mode: Receiver options
The
Setup mode: Receiver options page contains diagnostics to assist with
installing and fault finding the SMARTFIND GMDSS NAVTEX.
The lower part of the display is a monitor area which shows all received NAVTEX
characters in real time from the receiver selected as the monitor source, including the
phasing character (Ф) and receive character error symbol (), regardless of
transmitting station and message category filter settings.
Setup parameter
Comment
Antenna power Enabled for active antenna
or Disabled for passive antenna
Antenna status Unknown: see Troubleshooting guide
Active: an active antenna is connected
Passive: a passive antenna is connected
Overload: excessive current; see Troubleshooting guide
Error: see Troubleshooting guide
Signal strength
The size of the bar indicates the highest signal strength being
currently received by any of the three receivers
Monitor source Selects which receiver to monitor. This parameter is always reset
to ‘None’ after a power cycle.

Page 19
Checking the antenna:
You may wish to check that the NAVTEX antenna position is suitable by inspecting
the signal strength during a known NAVTEX transmission from a local station.
Interpreting the diagnostics aids:
When a NAVTEX signal is being received, the appropriate receiver frequency icon
appears at the top of the display. If the Monitor source is set to this frequency then the
received data will appear in the Monitor window.
Use the Receive icon, Signal strength bar and Monitor window to help diagnose
installation problems and/or as a check that your SMARTFIND GMDSS NAVTEX is
working correctly.
Receive
icon
Signal strength
bar
Monitor
window
Comments
OFF No new chars
being received
No current NAVTEX transmission
OFF No new chars
being received
Local in-band interference
present, or NAVTEX station
transmitting un-modulated RF
Set monitor source
to 518 kHz
Correct operation, NAVTEX data
will be shown in monitor window
Setup mode: System options
The
Setup mode: System options
page contains general information about the
SMARTFIND GMDSS NAVTEX and allows control over several aspects of the user
interface.
Page 20
Setup
parameter
Description
Software version
Display model
Serial no
These parameters show the software version, hardware model and
the individual serial number of the SMARTFIND GMDSS NAVTEX.
These values cannot be edited
Operating Mode Normal – normal use aboard vessel
Shore Station – displays all messages including repeats, ignoring
filters and 72-hour limit
Demonstration – for use at exhibitions, etc
Time
Date
These parameters allow the time and date to be set manually in
installations where there is no source of ZDA sentences
LED function Selects whether the LED on the front of the SMARTFIND GMDSS
NAVTEX is used to indicate a new message or an active alarm
Key click Allows key click sound to be disabled
Audible alarm Allows the internal audible alarm to be disabled in installations
where the SMARTFIND GMDSS NAVTEX is not located at the main
navigation position of the vessel. Note that this setting does not
affect the operation of the integral alarm relay or the generation of
alarm sentences.
Message pop-up Allows message popups to be disabled
or confined to SAR messages only
Full font size Offers three choices of message font size in Full Message view
NMEA checksums Controls if incoming NMEA sentences require checksums (for
compatibility with older equipment)
Screen timeout This setting allows the display to be automatically blanked after a
certain period of time. While the display is blanked, pressing any
key, or the receipt of a new message will turn it on again. Note that
this setting only affects the display screen; all the receivers in the
SMARTFIND GMDSS NAVTEX continue to work normally even
while the display is blanked.
Skip 4209 index
Skip ext index
These fields allow the 4209.5 kHz or external receiver index pages
to be skipped in installations where the 4209.5 kHz receiver or the
external receiver are not used
WARNING: Because messages are automatically deleted after 72 hours, changing
the time or date may cause stored messages to be lost.

Page 21
Setup mode: Serial options
The
Setup mode: Serial options page contains setup and configuration
parameters for the two serial ports on the SMARTFIND GMDSS NAVTEX unit. The
lower section of the display provides a monitoring facility for incoming messages on
the selected port.
Setup parameter Description
COM 1 port speed
COM 2 port speed
Selects the baud rate for each serial port
Print delay Specifies a number of seconds to pause between printing each
message. This may be used to restrict the output of the
SMARTFIND GMDSS NAVTEX when using a slow printer
Printer width Specifies the number of characters to output on each line when
printing messages. This must be at least 40 characters
Printer mode Selects between ‘On receipt’ printing where the SMARTFIND
GMDSS NAVTEX prints all messages as they are received and
‘On demand’ printing where the SMARTFIND GMDSS NAVTEX
only prints selected messages when requested by the user
Monitor source Selects serial interface for monitoring. This parameter is always
reset to ‘none’ after a power cycle
Printer output Selects which serial port is used for printing
NRX output Selects which serial port is used for the output of NRX sentences
when a message is received
ALR output Selects which serial port is used for the output of ALR sentences
Page 22
SYSTEM ALARMS
An alarm event state will always generate a message for sending to an IBS or remote
alarm panel as well as actuating the SMARTFIND GMDSS NAVTEX’s remote alarm
relay contacts.
The front panel LED and the buzzer are programmable – see Setup mode:
System options. Consequently, these indicators may or may not activate to
indicate an alarm. For bridge operation an IMO compliant external alarm should be
fitted – see page 32
The SMARTFIND GMDSS NAVTEX may generate alarms with the following alarm
numbers:
Alarm
number Alarm text
001 NAVTEX: Navigational warning
002 NAVTEX: Meteorological warning
003 NAVTEX: Search and rescue information
004 NAVTEX: Receiver (x) malfunction
005 NAVTEX: Self test error
006 NAVTEX: General failure
051 NAVTEX: Memory full
052 NAVTEX: Antenna error
053 NAVTEX: Antenna overload
RECEIVER MONITORING
The SMARTFIND GMDSS NAVTEX continuously monitors the signals being
received, and generates a “Receiver (x) malfunction” alarm (ID code 004) should any
receiver appear to be operating incorrectly. The “x” in the alarm message is 1 for the
490 KHz receiver; 2 for the 518 kHz receiver and 3 for the 4209.5 kHz receiver.
Serial interfaces
The SMARTFIND GMDSS NAVTEX has an IEC 61162-2 compatible serial interface
which can be used to connect the SMARTFIND GMDSS NAVTEX to other equipment
such as an integrated bridge system or a PC running charting software. The IEC
61162-2 serial interface also allows for the connection of a serial printer. The
integrated bridge system should be connected to the COM port of the SMARTFIND
GMDSS NAVTEX (using the 15-way D-type socket at the rear).
Printer Operation (option)
When the ‘Printer mode’ setting on the Setup mode : Serial options page is
set to ‘On Receipt’, the SMARTFIND GMDSS NAVTEX outputs every message to the
printer as it is received, subject to the control of the message filters. In this mode, the

Page 23
SMARTFIND GMDSS NAVTEX operates in a similar manner to a traditional ‘paper-
based’ NAVTEX receiver.
However, in order to conserve paper, when the ‘Printer mode’ setting on the
Setup mode : Serial options page is set to ‘On Demand’, the SMARTFIND
GMDSS NAVTEX will only print messages when instructed to do so.
To print all messages as they are received:
Set the ‘Printer mode’ setting to ‘On receipt’
Ensure all the ‘PRINT’ checkboxes for all stations and message categories on the
message filters page for each receiver are not checked
To print all stored messages from a specified receiver:
Ensure all the ‘PRINT’ checkboxes for all stations and message categories on the
message filters page for each receiver are not checked
Press the ‘Print Messages’ softkey on each of the Message filters pages to
print out all the messages for the corresponding receiver
To print messages from selected stations and message categories as they are
received:
Set the ‘Printer mode’ setting to ‘On receipt’
Use the message filters to filter out the unwanted stations and message categories
To print individual messages only on demand:
Set the ‘Printer mode’ setting to ‘On demand’
While viewing the full text of a message, press the ‘Print Message’ soft key
Note that this will always print the current message, irrespective of the settings of
the message filters
To print all messages from specified locations or specified message categories
only on demand:
Set the ‘Printer mode’ setting to ‘On demand’
Set the ‘PRINT’ checkboxes on the Message filters page to filter out the
unwanted stations and message categories
Press the ‘Print Messages’ softkey to print out all the messages which are not to be
filtered out.
Note that this will only print out the messages for the current receiver. To print all
the messages for each receiver it is necessary to operate the ‘Print Messages’
softkey on each of the Message filters pages in turn.
Page 24
ADJUSTING THE DISPLAY
LCD setup day & night modes
To enter LCD setup mode, press and hold the illumination key for 3 seconds the
LCD
setup: Day mode page will be displayed.
Use the left and right ( and ) keys to adjust the LCD contrast.
Use the up and down ( and ) keys to adjust the LCD brightness.
To change the night mode settings, briefly press the illumination key. The
LCD setup: night mode page will be displayed.
Note: These settings are non-volatile and will be unchanged after a power cycle.

Page 25
INSTALLATION
SMARTFIND GMDSS NAVTEX system overview
For simplicity, power is shown diagrammatically throughout;
fuses, circuit breakers, alternative supplies, etc are omitted.
SMARTFIND GMDSS NAVTEX Minimum System
SMARTFIND GMDSS NAVTEX Expanded System
Page 26
Hole size
to fit #10 screw:
3.5mm
Trunnion mounting the display
The standard bulkhead mounting U-Bracket can be used to mount the SMARTFIND
GMDSS NAVTEX above or below a horizontal (or near horizontal) surface.
Drilling drawing (mm)
Select hole size to suit method of fixing mountings –
clear or tapped holes.
Rear view of trunnion bracket assembly
Ensure that rubber washers are fitted between
the trunnion bracket and the plastic enclosure.
Tilt the display to the correct viewing angle.
Tighten the two thumbwheels.
Mounted dimensions:
Height: 150 mm
Width: 270 mm
Depth: 120 mm (over connectors)

Page 27
Flush mounting the display
If the SMARTFIND GMDSS NAVTEX is to
be mounted through a flat panel, use the
flush mounting kit provided.
A cutting template is supplied with the
flush mounting kit. This template carries
full fitting instructions.
Warning: Do not mount the SMARTFIND
GMDSS NAVTEX in a position where sea
spray can reach it, or where it may be
exposed to direct sunlight
Page 28
Electrical connections
This manual is concerned only with the installation of the SMARTFIND GMDSS
NAVTEX and does not cover the installation of peripheral equipment connected to the
SMARTFIND GMDSS NAVTEX such as printers, navigational systems or source of
NMEA data in detail. For proper installation and connection of peripheral equipment
refer to the installation manuals for these products.
The table below shows the connections that must be made to the SMARTFIND
GMDSS NAVTEX for it to function correctly.
Connection Must connect Optional
Ship’s earth connection 
12V or 24 V DC power supply 
NAVTEX antenna 
Alarm Relay 
NMEA or IBS UTC (time) reference See Note 1 See Note 1
Integrated Bridge/Navigation System 
External printer 
Note 1: Connecting a UTC (time) reference (e.g. a GPS receiver) is highly
recommended.
Ship’s earth connection
The earth terminal on the rear of the SMARTFIND GMDSS NAVTEX display must be
connected to ship’s ground by the earth cable supplied. The earth connection should
be kept as short as possible.
12V or 24 V DC power connection
A connection must be made to a 12 or 24 V DC supply via a circuit breaker capable of
supplying at least 2 amps. Connection should be to the ship’s radio battery and be in
accordance with GMDSS requirements.
 Connections should be made using the 2 m power cable provided
 Use cable ties to restrain the wiring, and so prevent it becoming weakened
by vibration. The connecting cables should be restrained by securing them to
Safety Warning
To ensure the best possible protection of the NAVTEX from
static electricity or nearby lighting strikes, the pre-fitted green
grounding wire (connected to the safety earth spade) must be
connected to a nearby (hull) electrical grounding point.

Page 29
the rear of the SMARTFIND GMDSS NAVTEX bracket, or to adjacent
metalwork
 The screen of the cable should be connected to ship’s earth if possible. The
screen of the cable should not be connected to ship’s battery –ve
Safety Warning
The SMARTFIND GMDSS NAVTEX has been designed and manufactured
to be completely safe when used in accordance with the instructions
given in this manual. To ensure that the complete installation is safe, it
is essential that a fuse or circuit breaker is installed in the power supply
cable as described in the Installation section of this manual.
Isolation between the power supply connections and any other connection to the
SMARTFIND GMDSS NAVTEX is 1 kV minimum.
The DC power source should comply with IMO guidelines for the class of vessel
concerned. National authorities and classification societies may have their own power
supply requirements; these should also be considered.
Signal cable connections
As shown in the table above, the SMARTFIND GMDSS NAVTEX may be connected
to different types of peripheral units including IBS & INS serial ports and printers.
The signal connections are all connected via a serial RS422 type interface; data rates
are selectable at 4800, 38400 or 115200 baud.
In some cases, particularly in retrofit installations, it may not be possible to connect
the SMARTFIND GMDSS NAVTEX directly to the required source/destination for
serial data, because some equipment does not provide the IEC 61162-2 (NMEA)
sentences required by the SMARTFIND GMDSS NAVTEX unit. In such cases a
protocol converter is required between the sensor and the SMARTFIND GMDSS
NAVTEX. Converters are available from different manufacturers, either as direct
protocol converters or frequently as repeater instruments for the sensor.
IEC 61162-1 alarm message example
The alarm number and text are output as part of a standard ALR sentence format, for
example:
$CRALR,<time>,004,A,A,NAVTEX: Meteorological warning*<checksum>
Page 30
1
5
6
11
15
10
Signal line termination
RS422 signal lines may need termination resistors at the far end of the serial cable
connected to the SMARTFIND GMDSS NAVTEX, depending on the length of
connecting cable and the rate of data transmission. Both COM 1 & 2 in the
SMARTFIND GMDSS NAVTEX have inbuilt 100Ω termination resistors for both Tx
and Rx.
Whether termination is required depends on many factors, particularly the length of
the signal cable and the environment in which the equipment is operating. The
principle is shown in the sketch:
There is only one talker per twisted pair; there can be several listeners. The intention
is that terminations must be provided by the devices at the ends of the line, regardless
of whether they are listeners or the talker, and that no other device should provide a
termination.
Since the SMARTFIND GMDSS NAVTEX contains internal termination, it MUST be at
the end of the line and NOT in the middle.
It is good practice to use screened cables in all ship cable installations. Take care to
connect the cable screen to ship’s ground at one end only of the cable, as connecting
at both ends may cause ground loops and interference to the signals. The cable
screen should not be connected to any part of the SMARTFIND GMDSS NAVTEX.
Connecting to COM port serial interface
The display connection cable is supplied ready for use, and needs only to be plugged
into the appropriate connector on the SMARTFIND GMDSS
NAVTEX.
Display cable: Six twisted pairs, screened, PVC sheathed.
For lengths to 200 meters, use 0.22 mm2 (7/32); Belden
8106 or equivalent.
Ground cable
screen at
NAVTEX ONLY
Terminating
resistor
Listener
(may need
termination)
Talker
(NAVTEX)

Page 31
1
5
6
9
The connections to the15-pin socket on the SMARTFIND GMDSS NAVTEX are given
below. Note that the cable screen should not be connected to any part of the
SMARTFIND GMDSS NAVTEX.
Power, Alarm & COM port (2m cable supplied)
Pin
Number
Connection
SMARTFIND
GMDSS
NAVTEX
Cable Colour Notes
1 IBS_TXA O/P WHITE/BLUE O/P to COM 1 or 2
2
3 +V
(12/24 V DC nominal) I/P RED/BLUE Ship’s supply +ve
4 -V (0V) I/P BLUE/RED Ship’s supply -ve
5
6 IBS_TXB O/P BLUE/WHITE O/P to COM 1 or 2
7
8 AUX_NC O/P ORANGE/WHITE
Alarm Relay NC
9 AUX_NO O/P WHITE/BROWN
Alarm Relay NO
10 AUX_COM O/P WHITE/GREY Alarm Relay COM
11
12 IBS_RXB I/P GREEN/WHITE
I/P from COM 1 or 2
13 IBS_RXA I/P WHITE/GREEN
I/P from COM 1 or 2
14
15
Connecting to the NMEA 0183 interface
If a connection to NMEA 0183 compatible equipment is
required then a suitable cable has to be purchased or
manufactured.
Recommended NMEA 0183 cable: Two twisted pairs,
screened, PVC sheathed. For lengths to 200 meters, use
0.22 mm2 (7/32); Belden 8102 or equivalent.
The connections to the D-Sub 9-pin socket on the SMARTFIND GMDSS NAVTEX are
given below. Note that the cable screen should not be connected to any part of the
SMARTFIND GMDSS NAVTEX.
COM 2
Pin Number Connection Notes
1
2 SER_TXB O/P to NMEA 0183 (printer)
3
4 SER_RXB I/P from NMEA 0183
5
6
7 SER_TXA O/P to NMEA 0183 (printer)
8 SER_RXA I/P from NMEA 0183
9
Page 32
Alarm relay
The SMARTFIND GMDSS NAVTEX provides a relay connection which can be
selected as normally closed or normally open contacts.
The alarm relay function is configurable from within the setup pages and can be set
(for example) to switch (change state) on receipt of a Search and Rescue
message or for a system fault.
The red LED on the front panel of the SMARTFIND GMDSS NAVTEX mirrors the
function of the alarm relay.
Red LED function
LED OFF Alarm relay NC contact closed
LED ON Alarm relay NO contact closed
Recommended Remote Klaxon alarm unit (loud bridge repeater alarm) Orolia Ltd part
40-187.
Recommended cable for connection of alarm relay:
One twisted pair, shielded, PVC sheathed. The required cable dimension is
dependent on the current necessary to activate the alarm indicator.
Built in alarm relay ratings:
Alarm relay absolute maximum ratings
Maximum switching current in
contacts (inductive load) 1.0 Amp
Maximum switching current in
contacts (resistive load) 3.0 Amp
Maximum switching voltage 120 V AC or 24 V DC
External connections
SMARTFIND
GMDSS NAVTEX
N/C
Com
N/O

Page 33
Rear Panel Connections
 The auxiliary alarm contact is capable of switching up to 24 V DC at up to 1A
(inductive load). The contacts are not connected to any internal voltages.
 The power supply input is isolated from the case and antenna. It must remain
within the range 10.8 – 31.2 V DC (12/24 V DC nominal) at all times.
Connecting a Printer
The recommended external printer option is the Seiko DPU-414; the default printer
parameters are set correctly for this model. The printer should be connected to COM
2 of the SMARTFIND GMDSS NAVTEX (the 9-way D-type socket at the rear):
DPU-414 pin 3 (RxD) to SMARTFIND GMDSS NAVTEX pin 7 (TxA)
DPU-414 pin 5 (Gnd) to SMARTFIND GMDSS NAVTEX pin 2 (TxB)
TNC RF connector
1/8” Spade terminal – ground pin
9-way D-type – COM 2
15-way D-type – power and COM 1 and alarm relay
Page 34
After connecting the printer, set the 'Printer output' parameter to COM 2 on the
Setup mode: Serial options page and ensure that the ‘NRX output’ and 'Alarm
output' parameters are set to either 'IBS' or 'None'. Set the ‘COM 2 port speed’ to
4800.
The printer is powered by the mains adaptor supplied and must be configured for
correct operation. The standard default settings for the printer should be used, except
for the following:
SW-1 Set for serial interface (not parallel)
SW-2 Set for English (not Japanese)
SW-3 Set for XON/XOFF control (not H/W BUSY)
SW-3 Set for 4800bps (not 75bps)
Refer to the DPU-414 manual for details of how to set these parameters.
The compass safe distance for the printer is 1.0 m.
The printer should be secured to prevent it moving during operation. The use of
adhesive foam pads is recommended.
ANTENNA INSTALLATION
Selecting a suitable antenna
The SMARTFIND GMDSS NAVTEX receives transmissions on three frequencies. 518
kHz transmissions are in International English; 490 kHz and 4209.5 kHz
transmissions may be in a local language.
To receive on all frequencies the SMARTFIND GMDSS NAVTEX must be used with a
wide frequency (400 kHz to 5 MHz) antenna that covers 518 kHz, 490 kHz and
4209.5 kHz.
If you have purchased the SMARTFIND GMDSS NAVTEX receiver without an
antenna then a suitable active NAVTEX antenna should be used. Orolia Ltd
recommends the 905-05 as described in the following section.
If an alternative antenna type is used it must be a low impedance 50 ohm
antenna or an antenna with a 50 ohm matching network. A mismatched or high
impedance whip or wire antenna should not be used as the operational range of
NAVTEX reception may be greatly reduced; it is also important that the antenna is
capable of reception over the frequency range specified above.
Wire or long whip antennas must be fitted with a 50 ohm matching transformer.
Important, disable the SMARTFIND GMDSS NAVTEX antenna power setting – refer
to Setup – Receiver mode for details. If in any doubt a qualified GMDSS installer
should be consulted.

Page 35
Installation of the tri-channel NAVTEX antenna
Metal, rigging or other antennas must not be located in the 'NO GO cone' surrounding
the upper part.
Use the mounting bracket supplied; an alternative mounting kit may be purchased if
the mounting arrangement is unsuitable for your installation.
Attach the clamping brackets to the antenna mounting adapter and use the clamping
arrangement to fix to a suitable vertical tube.
Important
NAVTEX antennas must be mounted clear of obstructions and at least
0.5 metres away from other antennas.
Where practical avoid locating the NAVTEX antenna close to MF / HF
transmitting antennas or VHF / AIS antennas.
Ensure that antennas cannot be snagged by mooring warps or running
rigging or engulfed by green water.
Antennas should always be mounted vertically in an elevated position.
SMARTFIND GMDSS NAVTEX Minimum System
Page 36
Thread the PL259 connector end of the coax cable through the antenna mounting
adapter and secure the connector to the antenna 1" threaded adapter.
Slide the rubber boot over the PL259 connector; if desired, it may be filled with
silicone grease for a better weatherproof seal.
Screw the antenna down into the antenna mounting adapter.
Ensure that the mounting adapter is connected to ground. If necessary, connect a
grounding wire, 2.5 mm2 minimum, to a suitable ground point.
Typical installation of
active antenna

Page 37
Installation of the antenna cable
Start routing the antenna cable at the antenna end.
Where the cable passes through bulkheads or decks, waterproof deck glands should
be installed. Securely fasten the cable against vibration using plastic cable tie wraps.
Complete routing of the antenna cable at the SMARTFIND GMDSS NAVTEX TNC
connector.
Fitting the TNC connector
A TNC connector is supplied as part of the SMARTFIND GMDSS NAVTEX Receiver
Kit.
 Place the rubber boot, gland nut, washer and rubber seal onto cable.
Remove the outer insulation for a distance of 8mm.
 Slide the cable braid sleeve over the screen braid, fold the braid back and
trim off extra braid.
 Strip 2.5mm of the inner insulation to
expose the centre conductor.
 Solder the pin onto the centre conductor.
 Assemble the connector and tighten
the gland nut. Push the rubber boot
securely over the gland nut.
Extending the antenna coax cable
If required, the coaxial cable may be extended with 50 ohm coaxial cable and
connectors. The maximum cable length should not exceed 100 m. Ensure that any
cable joints are well secured and waterproofed using self-amalgamating (rubber) tape.
Cable should be RG-58 / RG-67 / RG-213 / RG-214 grade or better; connectors
should be suitable RF types (TNC, BNC, etc).
Testing the tri-channel active antenna installation
By default the SMARTFIND GMDSS NAVTEX provides a regulated 12 V DC (nom)
100 mA output to provide power for an active antenna such as the one supplied as
part of a SMARTFIND GMDSS NAVTEX System.
Ru
Rubber boot
Page 38
If you are using an alternative active antenna please check that it is compatible with
this power output. If it is not, then an external power supply interface will be required.
Your antenna supplier should be able to provide this.
Switch on the SMARTFIND GMDSS NAVTEX by applying power (12 V DC or 24 V
DC) via a circuit breaker or fuse.
There will be a few seconds delay whilst the software loads the contents of the
NAVTEX message store during which time the front panel red LED will blink.
The LCD display backlight will come on and the SMARTFIND GMDSS NAVTEX start-
up screen will be shown.
If the antenna fault icon appears along the top of the display, switch off immediately
and check for a short circuit at the antenna, the TNC connector or any other RF
connections in-between. If the fault persists then please follow the trouble shooting
guide in this manual.
Passive antenna installation
The SMARTFIND GMDSS NAVTEX regulated 12 V DC 100mA output should be
disabled for passive antenna installations or for installations using a matching
transformer.
NOTE: This should be done the first time that power is applied to the
SMARTFIND GMDSS NAVTEX BEFORE the antenna is connected.
Switch on the SMARTFIND GMDSS NAVTEX by applying power (12 V DC or 24 V
DC) via a circuit breaker or fuse.
There will be a few seconds delay whilst the software loads the contents of the
NAVTEX message store during which time the front panel red LED will blink.
The LCD display backlight will come on and the SMARTFIND GMDSS NAVTEX start-
up screen will be shown.
If the antenna fault icon appears along the top of the display, switch off immediately
and check for a short circuit at the antenna, the TNC connector or any other RF
connections in-between. If the fault persists then please follow the trouble shooting
guide in this manual.
WARNING
Take care not to apply power to the antenna TNC connector
from an external supply

Page 39
OPTIONS
SMARTFIND GMDSS NAVTEX ancillary items:
Model Description Code
ANA2 Active
NAVTEX Antenna
Commercial grade 518 – 490 kHz + 4209.5 kHz, SO239
socket, white glass fibre construction with 1 inch nut fitting 93-063A
Stand-off Mounting
Bracket A
Pole mount stand-off bracket for NAVTEX Antenna, 1 inch
bolt mount fitting (for 93-063A). 93-064A
Stand-off Mounting
Bracket B
Pole or Wall mount stand-off bracket for NAVTEX Antenna,
1 inch bolt mount fitting (for 93-063A). 93-065A
Deck Mounting
Bracket C
Deck mount for NAVTEX antenna, 1inch bolt mount fitting
(for 93-063A). 93-066A
Antenna Cable Kit 20 m antenna cable kit (for 93-063A). 93-067A
ANA1 Active
NAVTEX Antenna
Light duty, 1m stainless steel wideband active whip antenna
complete with 20 m attached cable and fixing plastic bracket
93-062A
Klaxon alarm unit Remote Klaxon alarm unit (loud bridge repeater alarm) 40-187
Seiko DPU-414 Remote thermal roll printer (sold directly by Seiko agents) N/A
EXTERNAL RECEIVER
The SMARTFIND GMDSS NAVTEX has the capability to receive from an external
receiver (not supplied) on an additional NAVTEX frequency should such an additional
frequency be mandated by the IMO in the future.
NAVTEX messages from the external receiver appear on the View EXTERNAL
RECEIVER page.
The external NAVTEX data must be presented as a stream of NMEA NRX sentences
as defined in Annex C of the IEC 61097-6 Ed.2 (2005) specification.
The external receiver may be another SMARTFIND GMDSS NAVTEX; in such a
case, a single antenna may serve several displays. For more information, contact
your dealer or the Orolia Ltd Customer Service team.
MAINTENANCE GUIDE
General Points to Check
 Periodically make sure that the antenna connector is well sealed and that there
isn’t sign of corrosion around the PL259 connector
 Make sure connections to the back of the SMARTFIND GMDSS NAVTEX
display are secure
Page 40
Cleaning Instructions
 Periodically clean the LCD front window with a soft lint-free cloth (such as
those supplied by opticians to clean spectacles)
 Do not used cleaning solvents on any part of the SMARTFIND GMDSS
NAVTEX
CAUTION: Avoid using chemical solvents to clean the system as some solvents
can damage the case material.
NOTE: The SMARTFIND GMDSS NAVTEX contains no user serviceable parts.
Contact your Service Agent for repair advice or contact the Orolia Ltd Customer
Service team.
TROUBLESHOOTING GUIDE
General Points to Check
 Make sure the antenna is mounted vertically and is clear of obstructions
 Make sure the vessel is operating within the coverage area of a NAVTEX
transmitter
 When the NAVTEX station(s) selected are transmitting, icons for 490, 518 and
4209.5 kHz show whenever a NAVTEX signal is received
 Ensure that the required NAVTEX station and message categories have not
been deselected in the SMARTFIND GMDSS NAVTEX setup menu
Antenna fault icon appears at the top of the display: active antenna
1 Turn off the SMARTFIND GMDSS NAVTEX
2 Disconnect the active antenna and check that there is not a
short across the antenna’s TNC connector
3 Turn on the SMARTFIND GMDSS NAVTEX, apply a 120 ohm
5 W resistor across the TNC connector. If there is 12 V DC
across the TNC then either the antenna or coax cable is faulty
4 If there is not 12 V DC across the TNC connector then check
that
Antenna power : Enabled is selected in the setup
screens
5 If these instructions do not work then please contact your
service agent
Antenna fault icon appears at the top of the display: passive antenna
1 Turn off the SMARTFIND GMDSS NAVTEX
2 Disconnect the passive antenna and check that there is not a
short across the antenna TNC connector
