MDT Technologies BE-TA5502.01 User manual

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
1
12/2011

Technical Manual
MDT Push Buttons/
Push Buttons Plus

BE-TA5502.01
BE-TA5504.01
BE-TA5506.01
BE-TA5508.01
BE-TA55P2.01
BE-TA55P4.01
BE-TA55P6.01
BE-TA55P8.01

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
2
1Content

1Content.................................................................................................................................................2
2Overview.............................................................................................................................................4
2.1Overviewdevices...........................................................................................................................4
2.2Exemplarycircuitdiagrams..........................................................................................................5
2.2Usage&areasofuse.....................................................................................................................6
2.4Structure&Handling.....................................................................................................................6
2.5Functions.......................................................................................................................................7
2.5.1Overviewofthefunctions......................................................................................................8
2.6.SettingsattheETS‐Software........................................................................................................9
2.7.Startingup....................................................................................................................................9
3Communicationobjects....................................................................................................................10
3.1Communicationobjectsperchannel.........................................................................................10
3.2Communicationobjectslogic......................................................................................................11
3.3CommunicationobjectsLED........................................................................................................12
3.4Defaultsettingsofthecommunicationobjects.......................................................................13
4ReferenceETS‐Parameter..................................................................................................................14
4.1GeneralSettings..........................................................................................................................14
4.2Configuration...............................................................................................................................16
4.3Identicalparameter.....................................................................................................................17
4.3.1Blockingobject.....................................................................................................................17
4.4ParameterChannelsgrouped......................................................................................................17
4.4.1Dimming...............................................................................................................................18
4.4.2Shutter..................................................................................................................................20
4.4.3Switch...................................................................................................................................21
4.5Parameterschannelsunique.......................................................................................................22
4.5.1Switch...................................................................................................................................22
4.5.2Scene....................................................................................................................................32
4.5.3Switchshort/long.................................................................................................................34
4.5.4OnebuttonDimming............................................................................................................37
4.5.5One‐buttonShutter..............................................................................................................41
4.6.Logic(onlyattheplusvariant)...................................................................................................42
4.6.1Logicobjecttypeswitch.......................................................................................................44
4.6.1Logicobjecttypescene........................................................................................................46

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
3

4.7LEDlights(onlyattheplusvariant).............................................................................................47
4.7.1LEDsperbutton....................................................................................................................48
4.7.2OrientationLED/light............................................................................................................51
4.7.3BlockingobjectforLEDs.......................................................................................................52
4.7.4LEDpriority...........................................................................................................................53
5Index...................................................................................................................................................55
5.1Registerofillustrations................................................................................................................55
5.2Listoftables.................................................................................................................................56
6Attachment.........................................................................................................................................57
6.1Statutoryrequirements...............................................................................................................57
6.2Routinedisposal..........................................................................................................................57
6.3Assemblage..................................................................................................................................57
6.44‐BitDimcommand.....................................................................................................................58
6.5Datasheet....................................................................................................................................59



Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
4
2Overview

2.1Overviewdevices

Themanualreferstothefollowingdevices,whichareinourassortmentofpushbuttons.Actuallywe
canofferyouthefollowingpushbuttons(OrderCoderespectivelyprintedinboldtype):
BE‐TA5502.01pushbutton2‐fold
BE‐TA5504.01pushbutton4‐fold
BE‐TA5506.01pushbutton6‐fold
BE‐TA5508.01pushbutton8‐fold
BE‐TA55P2.01pushbutton2‐fold,Plus
o2LEDstatusdisplays,4Logicblocks
BE‐TA55P4.01pushbutton4‐fold,Plus
o4LEDstatusdisplays,4Logicblocks
BE‐TA55P6.01pushbutton6‐fold,Plus
o6LEDstatusdisplays,4Logicblocks
BE‐TA55P8.01pushbutton8‐fold,Plus
o8LEDstatusdisplays,4Logicblocks



Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
5

2.2Exemplarycircuitdiagrams


Illustration1:ExemplarycircuitdiagramBE‐TA5508.01
Designwith8pushbuttons

Illustration2:ExemplarycircuitdiagramBE‐TA550P8.01
Plus‐designwith8pushbuttons

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
6

2.2Usage&areasofuse

Thepushbuttoncontainsofalmostallofthefunctionsofthebinaryinput.Itisdesignedforflush
mounting.Byapushingabuttonthepushbuttoncancallparameterizedfunctionslikedimmingor
callwholescenes.
Theplusvariantcontainsadditionalofupto8bicoloredLEDsfortherespectivebuttonsanda
bicoloredorientationLEDanda4logicblocks.TheLEDScanbeparameterizedindividually.

2.4Structure&Handling

Thepushbuttoncontains,dependingonthedesign,of2to8buttons,whichcanbeparameterized
individually.AdditionalLEDsexistsattheplusvariant.Thebuscanbeconnectedatthebackofthe
pushbuttons.Furthermoreallpushbuttonscontainsofthestandardelementsprogrammingbutton
andprogrammingLEDatthesideofthepushbuttons.
TheIllustrationshowsan8‐foldpushbutton,attheleftanormaloneandattherighttheplusvariant:

Illustration3:OverviewhardwaremodulePushButton(left:BE‐TA5508.01;right:BE‐TA55P8.01)



Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
7

Thepushbuttonscontainsofaninvisiblecoverplate,whichisincludedatthedeliveryofthepush
buttons.Thiscoverplateisfortheprotectionofthelabeling.Whenthelabelingwasinserted,the
coverplatecanbeinstalled.Thecoverplatehastwolugsateveryside,whichmustengageinthe
intendedexecutions.Fortheinstallationofthecoverplate,onesideisinsertedintotheexecution.
Nowyoumustcurvethecoverplateabit,sothesecondlugfitsintotheexecution.Thecoverplate
shouldbeinstalledwiththeplainsideup.
Thereare2opportunitiesforthelabelingofthepushbuttons.Whenthepushbuttonisnottobe
labeled,agreyinsertplateisincluded,whichcanbeinsertedbehindtheinvisiblecoverplate.Ifyou
wanttolabelthepushbutton,youwillfindafreepatterninthedownloadsectionatourhomepage
www.mdtautomation.de.Thiscopypatterncanbeadaptedtoyourparameterizationandinserted
behindtheclearcoverplatewithoutthegreyinsertplate.
Fordismantlingthecoverplate,onebuttonispushed.Nowyoucanliftthecoverplatebestwitha
pointyobject.Sothecoverplatejumpsoutofitsexecutionandcanberemoved.

2.5Functions

Thefunctionalityisidenticalforeverychannel.Thedevicecontainsof2,4,6or8buttonsbasedon
thehardwaredesign.
Thedesignationofthechannelsisalwaysinaconsecutivealphabeticorder.
Therearethreepossiblefunctionalitiesforeachchannel:

Disabled
Nofunctionissettothechannel,sothischanneldoesnotcontainofanycommunicationobjects.

Channelsgrouped
Ifyouselectapairofchannelas“channelsgrouped”,youwillbeabletoparameterizethepairof
channelsasdimming‐function,shutter‐functionorswitching‐function.

Channelsunique
Ifyouselectapairofchannelsas“channelsunique”,youwillbeabletoparameterizeeachchannel
foritselfasswitch,counter,scene,switchshort/long,onebuttondimmingoronebuttonshutter.

Attheplusvariant,thereareadditional4logicfunctions(and/or)containingofuptotwoadditional
inputobjects.FurthermoretheplusvariantcontainsofonebicoloredLEDperchannel,whichare
individualparameterizeable,andonebicoloredoperatingLED.


Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
8

2.5.1Overviewofthefunctions
GeneralsettingsDebouncetime10‐120ms,selectableinsteps
Timeforkeystrokelong0,1‐30s,selectableinsteps
Limitationoftelegramsmax.numberoftelegramsper10s,canbe
parameterizedfreely
ChannelsgroupedDimmingfunctionbrighter/darkerfunctioncanbeassignedtothe
channelsfreely
Shutterfunctionup/downfunctioncanbeassignedtothe
channelsfreely
Switchingfunctionoff/ontelegramscanbeassignedtothe
channelsfreely
Channelsunique

Switchingfunctionswitchingfunction
togglefunction
statusfunction
timefunctions
oswitchon/offdelay
edgeevaluation
forcedsettings
sendingofbyte‐values
Scenefunctionmemoryfunction
selectionofdifferentscenes
Switchshort/longOn‐/Off‐/togglefunction
short/longindependentparameterize
able
Onebuttondimmingstepsofdimming
telegramrepetition
Onebuttonshuttershutterfunctionwithonlyonebutton
Logicfunctions
(onlyattheplus
variant)
AND‐functionswitchingfunction
scenefunction
inverting
OR‐functionswitchingfunction
scenefunction
inverting
Configurationof
LEDs
(onlyattheplus
variant)
Status‐LEDsconnectionstointernalobjectspossible
connectionstoexternalobjects
possible
reactiontopushingabuttonpossible
LEDdisplaybehaviorparameterizeable
luminescentbehaviorparameterize
able
LEDpriorityparameterizeable(from
hardwareversion1.1)
OperatingLEDon‐/offswitchable
controllingwithext.objectspossible
BlockingfunctionallLEDslockablebytheblockingobject
Chart1:Functionaloverviewpushbuttons

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
9

2.6.SettingsattheETS‐Software
Selectionattheproductdatabase:

Manufacturer:MDTTechnologies
Productfamily:Pushbuttons
Producttype:Pushbuttons/Pushbuttonsplus
MediumType:TwistedPair(TP)
Productname:addictedtotheusedtype,e.g.:BE‐TA55P8.01Pushbutton8‐fold,plusvariant
Ordernumber:addictedtotheusedtype,e.g.:BE‐TA55P8.01


Theavailableparametersdependtothechosenproducttype.Theadditionalfunctionsfortheplus
variantarenotshownatthenormalpushbuttons.

2.7.Startingup

Afterwiringtheallocationofthephysicaladdressandtheparameterizationofeverychannelfollow:
(1) Connecttheinterfacewiththebus,e.g.MDTUSBinterface
(2) setbuspowerup
(3) Presstheprogrammingbuttonatthedevice(redprogrammingLEDlights)
(4) LoadingofthephysicaladdressoutoftheETS‐Softwarebyusingtheinterface(redLEDgoes
out,aswellthisprocesswascompletedsuccessful)
(5) Loadingoftheapplication,withrequestedparameterization
(6) Switchthepowersupplyon
(7) Ifthedeviceisenabledyoucantesttherequestedfunctions(alsopossiblebyusingtheETS‐
Software)


Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
10

3Communicationobjects

3.1Communicationobjectsperchannel

Thecommunicationobjectsappearforeverychannelindependenceoftherespective
parameterization.10numbers(0‐9,10‐19,…)forcommunicationobjectsareautomaticallyassigned
foreverypairofchannels.Thenumerationisconsecutive,sothechannelpairA/Bcanonlyhavethe
numbersfrom0to9,thesameiftheyparameterizedasgroupedchannelsoruniquechannels.With
everyfollowingchannelpairthenumbersoftheobjectsincreaseby10,evenifachannelpairis
disabled.Ifyouchooseachannelpairasunique,thechannel,whichisfirstinthealphabet,will
becomethefirst5numbersandtheotheronewillbecomethefollowingfivenumbers(e.g.channel
A‐‐>0‐4andchannelB‐‐>5‐9).Thenumerationofthechannelsisalwaysthesame,evenifsome
channelsaredisabled.
Attheplusvariant,thereareadditionalobjectsfortheLEDsandthelogicblocks.Thecommunication
objectsforthelogicfollowontheobjectsforthechannels.Thereareupto12objectsforthelogic
function,so12numbersarereservedforthelogicfunction,e.g.thenumbersfrom40to51atan8‐
foldpushbutton.ThecommunicationobjectsfortheLEDsstartconsequentlywiththefirstnumbers
afterthelogicblocks.Accordingtotheparameterization,onecommunicationobjectperLEDcanbe
shown.Sothereare9objectsattheplusvariantofan8‐foldpushbuttonandoneblockingobject.
Thefollow
Thefollowingillustrationshowsthecommunicationobjectsforthechannels.ChannelA/Bisselected
as“channelsgrouped”andparameterizedasadimmingfunction.ThechannelsC/Dareselectedas
“channelsunique”thuseverychannelcanbecomeanindividualfunction.ChannelCisparameterized
asswitching‐functionandchannelDisparameterizedasscene‐function.ThechannelsE/Farealso
selectedasuniquechannels.ChannelEisparameterizedasshutterandchannelFasswitchwiththe
subfunction“sendstatus”.ThechannelsGandHareselectedasgroupedwithashutterfunction:

Illustration4:Communicationobjectsperchannel

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
11

Ifachannelpairisselectedasdisabled,noobjectswillbeshown.Sotherearenoopportunitiesfor
programmingthischannel.
Thesearetheavailableobjectsforeachchannel:
Nr.FunctionUsageDatatype 
0SwitchedgecontrolDPT1.001Out,Read
0Sendforcedsettingforcecontrol/switchDPT2.001Out,Read
0Shuttersdown/updrivingofshuttersDPT1.008Out,Read
0Dimmingon/offtogglingofthedimminglightsDPT1.001Out,Read
0Switchon/offtwobuttonswitchingDPT1.001Out,Read
0SendvaluesendstheparameterizedvalueDPT5.001Out,Read
0push‐buttonshortsendsactionforshortkeystrokeDPT1.001Out,Read
1ValuefortoggleedgecontrolwithtogglefunctionDPT1.001In,Write
1Stop/Blindsopen/closedrivingoftheblinds/stopping
movementoftheshutters
DPT1.009Out,Read
1DimmingdimmingDPT3.007Out,Read
2ScenescenecontrolDPT18.001Out,Read
0push‐buttonlongsendsactionforlongkeystrokeDPT1.001Ѐut,Read
4BlockingobjectblockstherelatedchannelDPT1.001In,Write
+5nextchannel  
Chart2:communicationobjectsperchannel

3.2Communicationobjectslogic
onlyattheplusvariant

Therearecommunicationobjectsforthelogicfunctionateverypushbuttonadditionaltothe
communicationobjectsperchannel.Theseobjectscanbeparameterizedandshownindependent
fromtheparameterizationofthechannels.Thelogicobjectshavethenumbersfrom80ata16‐fold
pushbuttonandthenumbersfrom40atan8‐foldpushbutton.Thefirstlogicblockgetsassigned
thefirstthreenumbers,soatan8‐foldpushbuttonfrom40to42.Everyfollowingblockincreases
thenumbersby3.
Theaddressingcanbemadebyusingthecommunicationobjectsforthelogicanalogoustothe
addressingbythechannels.
Thefollowingcommunicationobjectsforthelogiccanbeshown:

Illustration5:communicationobjectslogic

Ifalogicblockisdisabled,nocommunicationobjectswillbeshown.Thereforenoaddressingis
possible.Everypushbuttoncontainsof4logicblocksforwhichthefollowingobjectscanbeshown:
Nr.FunctionUsageDatatype 
40/80Logicinput1ALogicinputDPT1.001In,Write
41/81Logicinput1BLogicinputDPT1.001In,Write
42/82Logicoutput1LogicoutputDPT1.001Out,Read
42/82Logicoutput1sceneLogicoutputsceneDPT18.001Out,Read
+3nextlogicblock  
Chart3:communicationobjectslogic

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
12

3.3CommunicationobjectsLED
onlyattheplusvariant

TheavailableLEDscanbecontrolledbydifferentmethods.Accordingtothemethod,one
communicationobjectcanbeshownforeveryLED,whichafterwardscanbeconnectedtothegroup
addressesinanyway.Sothereareupto9communicationobjectsavailableatthe8‐foldpushbutton.
ThereisadditionaloneblockingobjectfortheLEDsandtwoobjectsforthepriorityoftheLEDs.
Thefollowingillustrationshowsthecommunicationobjects,whichcanbeshown:

Illustration6:CommunicationobjectsLEDs


Thefollowingcommunicationobjectsareavailable:
Nr.FunctionUsageDatatype 
22/32/
42/52
LED1switchLEDDPT1.001In,Write,Out
Read
+1nextLED 
30/40/
50/60
LEDorientationlightswitchLEDDPT1.001In,Write,Out,
Read
31/41/
51/61
LEDblockingobjectblockallLEDsDPT1.001In,Write,Out,
Read
32/42/
52/62
LEDpriority1*switchpriority1DPT1.001In,Write,Out,
Read
33/43/
53/63
LEDpriority2*switchpriority1DPT1.001In,Write,Out,
Read
Chart4:CommunicationobjectsLEDs

*=fromhardwareversion1.1

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
13

3.4Defaultsettingsofthecommunicationobjects

Thefollowingchartshowsthedefaultsettingsforthecommunicationobjects:
Defaultsettin
g
s
Nr.ButtonFunction Length PriorityCRW T U
0Button1Switch 1Bit LowXXX
0Button1 Shutter 1Bit LowXXX
0Button1Sendvalue 1Byte LowXXX
0Button1Dimmingon/off 1Bit LowXXX
0Button1push‐buttonshort 1Bit LowXXX
0Button1Sendforcedsetting 2Bit LowXXX
0Buttons1/2Switchon/off 1Bit LowXXX
0Buttons1/2Dimmingon/off 1Bit LowXXX
0Buttons1/2Shutterdown/up 1Bit LowXXX
1Button1Valuefortoggle 1Bit LowXXX
1Button1Stop/Blindsopen/close 1Bit LowXXX
1Button1Dimming 4Bit LowXXX
1Buttons1/2Dimming 4Bit LowXXX
1Buttons1/2Stop/Blindsopen/close 1Bit LowXXX
2Button1Scene 1Byte LowXXX
2Button1Valuefortoggle 1Bit LowX X X X
2Button1Push‐buttonlong 1Bit LowXXX
4Button1Blockingobject 1Bit LowX X X
10/20/30/40Logicinput1ALogicinput1A 1Bit LowX X X
11/21/31/41Logicinput1BLogicinput1B 1Bit LowX X X
12/22/32/42Logicoutput1Logicoutput1 1Bit LowXXX
12/22/32/42Logicoutput1sceneLogicoutput1scene 1Byte LowXXX
22/32/42/52LED1*LEDswitch 1Bit LowXXX X X
30/40/50/60LEDorientation
light*LEDswitch1BitLowXXX XX
31/41/51/61LEDblockingobject*blockallLEDs 1Bit LowXXX X X
32/42/52/62LEDpriority1**switchpriority1 1Bit LowX X X X
33/43/53/63LEDpriority2**switchpriority1 1Bit LowX X X X
Chart5:Communicationobjects–defaultsettings

Youcanseethedefaultvaluesforthecommunicationobjectsfromtheupperchart.Accordingto
requirementsthepriorityoftheparticularcommunicationobjectsaswellastheflagscanbe
adjustedbytheuser.Theflagsallocatesthefunctionoftheobjectsintheprogrammingthereby
standsCforcommunication,RforRead,Wforwrite,TfortransmitandUforupdate.
*=onlyattheplusvariant
**=fromhardwareversion1.1

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
14

4ReferenceETS‐Parameter

4.1GeneralSettings

Thefollowingparametersexistonceandaffectallchannels:

Illustration7:Generalsettings

Thefollowingchartshowsthedynamicrangeforthegeneralsettings:
ETS‐textDynamicrange
[defaultvalue]
comment
Timeforkeystrokelong0,1‐30sec
[0.8sec]
releasesthetimewhentheETS
recognizesalongkeystroke
LimitationoftelegramsInactive
Active
activates/deactivatesthelimitationof
telegrams
maxquantityin10seconds1‐255
[15]
maxnumberoftelegramsper10
seconds(appearsonlyifthelimitation
oftelegramsisactivated)
BehavioratbuspowerupNoreadvaluefortoggle
Readvaluefortoggle
activatesthereadingofthevaluefor
toggleatbuspowerup
Chart6:Generalsettings

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
15

1. Allpushbuttonshaveafixeddebouncingtime,whichcannotbechangedbytheuser.The
debouncetimeisadjustedin‐planttothepushbuttons.

1. Theparameter“Timeforkeystrokelong”allocatesastaticvaluetothepushbuttonfrom
whenalongkeystrokeisrecognized.Thisparameterisimportantforfunctions,whichhave
differentfunctionsforalongandashortkeystroke.

2. Thelimitationoftelegramscanachievethatthebusgetsnotoverloaded.Anoverloading
ofthebus‐systemcancauselongwaitingperiods,e.g.atpushingabutton.Ifthelimitation
oftelegramsisactivatedandmoretelegramsthanallowedaresend,thetelegramsabove
thelimitationwillbesendatthenexttimeinterval.Thereforeanoverloadofthebuscan
beprevented.

3. Theparameter“Behavioratbuspowerup”definesthebehaviorofthepushbuttonata
buspowerreturn.Thesetting“Readvaluefortoggle”effectsthatallcommunication
objects“valuefortoggle”areread.Sothepushbuttonknowsthecurrentstatusofthe
objects.Ifyouchoosethesetting“noreadvaluefortoggle”,thepushbuttonwillnotknow
thecurrentstatusoftheactor.Sothepushbuttonassumesanunconfirmedvalueforthe
objects“valuefortoggle”andsendsalwaysa“0”‐signalatthenextoperation.Onlynow
thepushbuttonknowsthestatusoftheactorandcansendtherightvalues.Butifyou
choosethereadofthesevaluesatabuspowerup,thepushbuttonwillsendimmediately
therightvaluefortoggling.


Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
16

4.2Configuration

Settingofthefunctionalityofthechannels:

Illustration8:Usageofthebuttons


ETS‐textDynamicrange
[defaultvalue]
comment
FunctionButtonA/B–[O/P]disabled
Channelsgrouped
Channelsunique
Operatingmodeofthe
channels
Chart7:Parameterchannel‐configuration

Thereare3differentoperatingmodesforeverybutton(havealookatchart7).Thefollowigoptions
toparameterizethechannelsaredependenttothechoosenoperatingmode.Ifyoudisablethe
channel,therewillbenooptionstoparameterizethischannel.


Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
17

4.3Identicalparameter

4.3.1Blockingobject

Aswellforgroupedchannelsasforuniquechannelstheblockingobjectcanbeactivated.Atthe
uniquechannelsoneblockingobjectforeverychannelcanbeactivated.Forgroupedchannels,you
canactivateoneblockingobjectforbothchannels.Thecommunicationobjectforachannelappears
assoonasitisactivatedforachannel.Sothereareupto8blockingobjectsparameterizeableata8‐
foldpushbutton.Thecorrespondingchanneloftheblockingobjectisblockedbysendingalogical1.
Ablockedchannelisnotcontrollableaslongasitisblocked.Bysendingalogical0,thechannelcan
beunblockedagain.
NumberNameLength Usage
4Blockingobject1Bitblockstherelatedchannelbysendingalogical1
Chart8:Communicationobjectblockingobject

4.4ParameterChannelsgrouped

Thechartshowsthesettingoptionsforgroupedchannels:
ETS‐textDynamicrange
[defaultvalue]
comment
ButtonA/BDimming
Shutter
Switch
Operatingmodeofthechannel
DimmingfunctionA/BBrighter/Darker
Darker/Brighter
Defineswhichchannelshould
dimupandwhichshoulddim
down
ShutterfunctionA/BUp/Down
Down/Up
Defineswhichchannelshould
drivetheshutteradownand
whichup
SwitchfunctionA/BOn/Off
Off/On
Defineswhichchannelshould
switchoffandwhichon
BlockingObjectInactive
Active
Theblockingobjectcanbe
displayedforeverypairof
channels
Chart9:ParameterChannelsgrouped

Bychoosingchannelsasgrouped,twochannelsbecomeonecommonfunction.Thegrouped
functioniscalleddualsurface,likedualsurfacedimming,anddualsurfaceshutter.Incontrasttothe
singlesurfacefunctions,oneactioncanbeperformedindependentformtheotherone.Oneinput
performsalwaysonefunction.Theassignmentforthebuttonscanbemadeindividually,soitis
possibletoconfigurewhichbuttonshouldforexampledrivetheshuttersupandwhichdown.

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
18

4.4.1Dimming

Thedualsurfacedimmingfunction(channelsgrouped)isforcontrollingdimmingactuatorsbystart‐
stopdimmingcommands.
Thefollowingparametersarevisible,whenapairofchannelsischosenasdimming‐function:

Illustration9:Parameterdualsurfacedimming

NumberNameLength Usage
0Dimmingon/off1BitSwitchingfunctionofthedimmingprocess;
actionforashortkeystroke
1Dimming4BitDimmingfunction;actionforalongkeystroke
Chart10:Communicationobjectsdualsurfacedimming

Whenapairofchannelsisparameterizedasdimmingfunction,twoobjectsareshown.Oneobject
reactstoashortkeystroke,theswitchingobject“Dimmingon/off”,andtheotherobjectreactstoa
longkeystroke,thedimmingobject“dimming”.
Itispossibletoparameterizethisfunctionasbrighter/darkerorasdarker/brighter.Thefirstfunction
belongsalwaystothefirstbutton.Ifyouswitchthisparameter,thefunctionwillbeswitched
automatically.
Bychoosingthedimmingfunction(channelA/B)asbrighter/darker,thefunctionreactsinthisway:
AshortkeystrokeatbuttonAswitchesthelightson.Thelightsareswitchedoffbyashortkeystroke
atbuttonB.Alongkeystrokedimsthelightsstepbystepuntilreleasingthelongkeystroke.Thelights
aredimmedbrighteratbuttonAanddarkeratbuttonB.Thepushbuttonstartsalwayswiththelast
brightnesslevel,beforeswitchingoff.
Thestepsizeissetfixedto100%atthedualsurfacedimming.Itisastart‐stopdimming.thatmeans
thelightsaredimmedaslongasyouholdthebutton.Afterreleasingthebuttonastopvalueissent,
whichstopsthedimmingprocess.Soyoucandimthelightswithonlyonekeystrokefrom0%to
100%orfrom100%to0%,bypushingthebuttonlongenough.

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
19

Thechartshowsthecorrelationsbetweenthedimming‐andtheswitching‐object:
Chart11:Dimmingfunction

Thefollowingdiagramshowsthedualsurfacedimmingfunction:



FunctionBrighter/DarkerFunctionDarker/Brighter
ButtonButtonAButtonBButtonAButtonB
DimmingfunctionBrighterDarkerDarkerBrighter
SwitchingfunctionOnOffOffOn

Technical Manual Taster BE-TA55
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
20

4.4.2Shutter

Thedualsurfaceshutter‐functiontriggersshutteractuators,whichcandriveshutterandblinds.
Thefollowingparametersareshown,whenapairofchannelisadjustedasshutterfunction:

Illustration10:dualsurfaceshutterfunction

NumberNameLength Usage
0ShutterDown/Up1BitDrivingfunctionfortheshutters,actionfora
longkeystroke
1Stop/BlindsOpen/Close1BitStop/Adjustmentoftheblinds,actionfora
shortkeystroke
Chart12:Communicationobjectsdualsurfaceshutterfunction

Ifyouchooseapairofchannelsasshutterfunction,twocommunicationobjectswillappearforthis
pairofchannel.Ontheonehandthestop/blindadjustmentobjectcalled“Stop/BlindsOpen/Close”,
whichrespondstoashortkeystrokeandontheotherhandthedrivingobjectcalled“Shutter
Down/Up”,whichrespondstoalongkeystroke.
Thedrivingobjectisformovingtheshuttersupanddown.Thestop‐/blindadjustmentobjectisfor
theadjustmentoftheblindsandadditionalitstopsarunningmovementoftheshutter.
Everyshutteractuatorcontrolswitha0‐signaltheup‐movementandwitha1‐signalthedown
movement.Sothepushbuttonsendsthesesignalstothecorrespondingdrivingcommands.

TheChartshowsthecorrelationsbetweentheStop‐/Blindadjustmentobjectandthedrivingobject
fortheindividualchannels:
Chart13:shutterfunction

FunctionDown/UpFunctionUp/Down
ButtonButtonAButtonBButtonAButtonB
Stop‐/Blind
adjustmentobject
DownUpUpDown
DrivingobjectStop/closeblindsStop/openblindsStop/openblindsStop/closeblinds
