MDV MDV-D71T1/N1-B User manual

High static pressure duct unit MCAC-VTSM-2011-03
112 Features
High static pressure duct unit
1. Feature..........................................................................113
2. Specifications ..............................................................115
3. Dimension ....................................................................118
4. Service Space...............................................................124
5. Piping Diagram ............................................................125
6. Wiring Diagram ............................................................126
7. Fan Performance .........................................................129
8. Capacity Tables............................................................131
9. Electric Characteristics...............................................139
10. Noise Levels...............................................................140
11. Accessories................................................................142
Библиотека СОК 

MCAC-VTSM-2011-03 High static pressure duct unit
Features 113
1. Feature
1.1 High static pressure allows flexible duct design
1.1.1 External static pressure of Indoor Unit can be up to 196 Pa(71~160 model) (220Pa for 20kW and up),
which allows extensive duct work for flexible applications. so the cool air can be delivered to every indoor
corner even in a super-high ceiling.
1.1.2 The max. distance of air supply is about 14m, the height of air supply is about 6.5m.
1.1.3 With 420mm (71~160 model) thickness body, not occupied much ceiling space which is 450mm
only.
1.2 Wide capacity range
—The capacity ranges from 7.1KW to 28.0KW, totally nine models.
1.3 Four speed fan motor(Medium Hi speed as an option) * (for
71~160 model)
1.4 Two external static pressure settings for added flexibility
just exchange the wiring connection of „MH‟and „Me‟. P2 and P3 as
the right side diagram. *(for 71~160 model)
1.5 Convenient installation
1.5.1 The EXV is fixed inside the indoor unit ((for 71~160 model), no

High static pressure duct unit MCAC-VTSM-2011-03
114 Features
need extra connection.
1.5.2 Standard filter with aluminum frame, which is removable downward from bottom.
1.5.3.Suction chamber is included as standard equipment
1.5.4 Flange for air in/outlet duct connection is standard.
1.5.5Optional drain pump * (for 71~160 model)
Drain pump is equipped as optional accessory with 750 mm lift.
1.5.6 Easy to access the motor and do the maintenance. Possible to replace the motor without
removing the whole unit.
1.6 Flexible control and convenient for maintenance
1.6.1 Standard Wired remote controller KJR-12B (FOLLOW ME), and wireless remote controller R05 is
as an option.
1.6.2 The display board is connected with the E-box in factory, which makes trouble-shooting easier by
LED display.
1.6.4 Standard functional port such as Remote On/Off Dry contact.

MCAC-VTSM-2011-03 High static pressure duct unit
Specifications 115
2. Specifications
Model
MDV-D71T1/N1-B
MDV-D80T1/N1-B
MDV-D90T1/N1-B
Power supply
V- Ph-Hz
220-240V~, 1Ph, 50Hz
Cooling
Capacity
kW
7.1
8
9
Input
W
263
263
423
Rated current
A
1.1
1.1
1.8
Heating
Capacity
kW
8
9
10
Input
W
263
263
423
Rated current
A
1.1
1.1
1.8
Max. input consumption
W
269
269
437
Max. current
A
1.23
1.23
1.8
Indoor
fan motor
Model
YDK100-4X-2
YDK100-4X-2
YDK160-4C
Type
AC Motor
Brand
YongAn
YongAn
WELLING
Input
W
247
247
391
Capacitor
μF
12
12
10
Speed (hi/mid/lo)
r/min
975/923//847
975/923//847
1282/1213/1035
Indoor
coil
Number of rows
2
2
3
Tube pitch(a)* row pitch(b)
mm
25.4×22
25.4×22
25.4×22
Fin spacing
mm
1.5
1.5
1.6
Fin type
Hydrophilic aluminum
Tube outside diameter and
type
mm
Ф9.52
inner groove tube
length * height * width
mm
700*356×44
700*356×44
700*356×66
Number of circuits
3
3
3
Indoor air flow (H/M/L)
m3/h
1440/1359/1236
1446/1346/1221
1936/1821/1511
Indoor external static pressure (Hi)
Pa
30~ 196
30~ 196
30~ 196
Indoor noise level (Hi/Mid/Lo)
dB(A)
48/46/44.5
48/46/44.5
52/49/47
Indoor
unit
Dimension (W×H×D)
mm
952*420*690
952*420*690
952*420*690
Packing (W×H×D)
mm
1102*450*768
1102*450*768
1102*450*768
Net/Gross weight
kg
45/50
45/50
46.5/52.4
Refrigerant type
R410A
Throttle
Type
EXV
Model
BD20FKS, (Winding: DZF20XQ-1000-XHP-6)
Design pressure (Hi/Lo)
MPa
4.4/2.6
Refrigerant piping
Liquid / Gas
mm
Ф9.53/ Ф15.9
Ф9.53/ Ф15.9
Ф9.53/ Ф15.9
Connecting wiring
Power wiring
mm2
3*2.5(L≤20m); 3*3.5(L≤50m)
Signal wiring
mm2
3*0.75
Drainage water pipe diameter
Ф32 (ID Ф25, OU Ф32)
Controller
Wired controller KJR-10B/DP(T)-E(6 meters connection wire)
Operation temp
℃
Cooling：17～32；Heating:10～28
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temp. : 27°CDB, 19°CWB, outdoor
temp.:35°CDB,equivalent ref. Piping: 8m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temp.: 20°CDB, outdoor temp.:
7°CDB,6°CWB,equivalent ref. Piping: 8m(horizontal)

High static pressure duct unit MCAC-VTSM-2011-03
116 Specifications
Model
MDV-D112T1/N1-B
MDV-D140T1/N1-B
MDV-D160T1/N1-B
Power supply
V- Ph-Hz
220-240V~, 1Ph, 50Hz
Cooling
Capacity
kW
11.2
14
16
Input
W
524
627
832
Rated current
A
2.3
2.7
3.6
Heating
Capacity
kW
12.5
16
18
Input
W
524
627
832
Rated current
A
2.3
2.7
3.6
Max. input consumption
W
528
660
891
Max. current
A
2.3
2.85
4.77
Indoor
fan motor
Model
YSK200-4F-1
YSK300-4C-1
YSK400-4C-2
Type
AC MOTOR
Brand
WELLING
YongAn
YongAn
Input
W
490
588
798
Capacitor
μF
15
12
15
Speed (hi/mid/lo)
r/min
1000/930/774
956/853/697
1087/953/836
Indoor
coil
Number of rows
3
4
4
Tube pitch(a)* row
pitch(b)
mm
25.4×22
25.4×22
25.4×22
Fin spacing
mm
1.6
1.6
1.6
Fin type
Hydrophilic aluminum
Tube outside diameter
and type
mm
Ф9.52
inner groove tube
length * height * width
mm
700*356×66
996*355.6×88
996*355.6×88
Number of circuits
7
7
7
Indoor air flow (H/M/L)
m3/h
2117/1950/1544
2988/2598/2229
3678/3046/2767
Indoor external static pressure (Hi)
Pa
30~ 196
30~ 196
30~ 196
Indoor noise level (Hi/Mid/Lo)
dB(A)
52/49/47
53/50/48
54/52/50
Indoor
unit
Dimension (W×H×D)
mm
952*420*690
1300*420*690
1300*420*690
Packing (W×H×D)
mm
1102*450*768
1430*450*768
1430*450*768
Net/Gross weight
kg
50.6/56
70/77.5
70/77.5
Refrigerant type
R410A
Throttle
Type
EXV
Model
BD20FKS, (Winding: DZF20XQ-1000-XHP-6)
Design pressure
MPa
4.4/2.6
Refrigerant piping
Liquid / Gas
mm
Ф9.53/ Ф15.9
Ф9.53/ Ф15.9
Ф9.53/ Ф15.9
Connecting wiring
Power wiring
mm2
3*2.5(L≤20m); 3*3.5(L≤50m)
Signal wiring
mm2
3*0.75
Drainage water pipe diameter
Ф32 (ID Ф25, OU Ф32)
Controller
Wired controller KJR-12B/DP(T)-E(6 meters connection wire)
Operation temp
℃
Cooling：17～32；Heating:10～28
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temp. : 27°CDB, 19°CWB, outdoor
temp.:35°CDB,equivalent ref. Piping: 8m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temp.: 20°CDB, outdoor temp.:
7°CDB,6°CWB,equivalent ref. Piping: 8m(horizontal)

MCAC-VTSM-2011-03 High static pressure duct unit
Specifications 117
Model
MDV-D200T1/N1-B
MDV-D250T1/N1-B
MDV-D280T1/N1-B
Power supply
V- Ph-Hz
220-240V~, 1Ph, 50Hz
Cooling
Capacity
kW
20.0
25.0
28.0
Input
W
1516
1516
1516
Rated current
A
6.6
6.6
6.6
Heating
Capacity
kW
22.5
26.0
31.5
Input
W
1516
1516
1516
Rated current
A
6.6
6.6
6.6
Max. input consumption
W
1978
1978
1978
Max. current
A
8.6
8.6
8.6
Indoor fan
motor
Model
YDK550-4X (×2)
YDK550-4X (×2)
YDK550-4X (×2)
Type
AC Motor
Brand
YongAn
Input
W
900/820/630(×2)
900/820/630(×2)
900/820/630(×2)
Capacitor
μF
12(×2)
12(×2)
15(×2)
Speed (hi/mid/lo)
r/min
1300/1100/900(×2)
1300/1100/900(×2)
1300/1100/900(×2)
Indoor
coil
Number of rows
4
4
4
Tube pitch(a)* row
pitch(b)
mm
25.4×22
25.4×22
25.4×22
Fin spacing
mm
1.8
1.8
1.8
Fin type
Hydrophilic aluminum
Tube outside diameter
and type
mm
Ф9.52
inner groove tube
length * height * width
mm
1125×512×88
1125×512×88
1125×512×88
Number of circuits
20
20
20
Indoor air flow (H/M/L)
m3/h
4180/3820/3200
4180/3820/3200
4400/3940/3300
Indoor external static pressure (Hi)
Pa
50~250Pa
50~250Pa
50~250Pa
Indoor noise level (Hi/Mid/Lo)
dB(A)
59/55/52
59/55/52
59/55/52
Indoor
unit
Dimension (W×H×D)
mm
1443×470×810
1443×470×810
1443×470×810
Packing (W×H×D)
mm
1509×570×964
1509×570×964
1509×570×964
Net/Gross weight
kg
115/129
122/128
122/128
Refrigerant type
R410A
Throttle
Type
EXV (2 sets throttle boxes each unit)
Model
BD24FKS(L) (Winding: PXR-6-L400-XHP6R/AMP6BL-P)
Design pressure
MPa
4.4/2.6
Refrigerant piping
Liquid / Gas
mm
Ф9.53/ Ф15.9 *2
Ф9.53/ Ф15.9 *2
Ф9.53/ Ф15.9 *2
Connecting wiring
Power wiring
mm2
3*2.5(L≤20m); 3*3.5(L≤50m)
Signal wiring
mm2
3*0.75
Drainage water pipe diameter
Ф32 (ID Ф25, OU Ф32)
Controller
Wired controller KJR-12B/DP(T)-E(6 meters connection wire)
Operation temp
℃
Cooling：17～32；Heating:10～28
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temp. : 27°CDB, 19°CWB, outdoor
temp.:35°CDB,equivalent ref. Piping: 8m(horizontal)
2. Nominal heating capacities are based on the following conditions: return air temp.: 20°CDB, outdoor temp.:
7°CDB,6°CWB,equivalent ref. Piping: 8m(horizontal)

High static pressure duct unit MCAC-VTSM-2011-03
118 Dimensions
3. Dimension
MDV-D71T1/N1-B MDV-D80T1/N1-B MDV-D90T1/N1-B MDV-D112T1/N1-B
Front view, top view and rear view:
72265
642
420
85
856
214
86
800
44253155
65
PLASTICCOVER
ELECTRICALCONTROLBOX
4-12*25OBLONGSUSPENTIONBOLTHOLES AIRINTAKE
AIROUTLETDUCTFLANGE 4-Φ5HOLESFORAIR
INTAKEDUCTCONNECTION
AIROUTLET
339
690
952

MCAC-VTSM-2011-03 High static pressure duct unit
Dimensions 119
Side view:
Left side
75
61
43
189123
REFRIGERANT-PIPEFLANED
CONNECTIONΦ16(5/8)
REFRIGERANT-PIPEFLANED
CONNECTIONΦ9.52(3/8)
SAFETYDRAINCONNECTINGPIPE
CONNECTINGPOINTOF
DRAINPIPE
Right side
189123
26
255 33

High static pressure duct unit MCAC-VTSM-2011-03
120 Dimensions
MDV-D140T1/N1-B MDV-D160T1/N1-B
Front view, top view and rear view:

MCAC-VTSM-2011-03 High static pressure duct unit
Dimensions 121
Side view:
Left side
Right side

High static pressure duct unit MCAC-VTSM-2011-03
122 Dimensions
MDV-D200T1/N1-B MDV-D250T1/N1-B MDV-D280T1/N1-B
Front view, top view and rear view:
1121 75
343
96
60
4-Φ10 hanging screw
(configure on spot)
Air intake
Air outlet
Refrigerant-pipe flared
connectionΦ16(5/8)
Refrigerant-pipe flared
connectionΦ9.52(3/8)
Air outlet
duct flange
4-12*25 oblong
suspention
bolt holes
Electrical
parts box
Entrances and exits
for communication
lines of indoor and outdoor
Air intake
duct flange
378
55
810
66
50
936
1275
1443
200
Side view:

MCAC-VTSM-2011-03 High static pressure duct unit
Dimensions 123
Key points about the 200, 250, 280 model installation:
There‟re two sets of EXV boxes, as well two groups of pipes (Gas/Liquid), it‟s necessary to connect the two
gas pipes together with the attached branch header BY101N1, as well the liquid pipes.
The branch header (1 set) already includes 1 gas and 1 liquid branch joint. Please kindly check the
accessory and follow the instructions while install the indoor units and piping.
Low-pressurepipe
Hi-pressurepipe
Electricthrottlepart
Liquid branch pipe Φ9.5
Φ9.5 Φ15.9
Φ15.9
Gas branch pipe
≤10m
Φ25.4
Φ12.7

High static pressure duct unit MCAC-VTSM-2011-03
124 Service Space
4. Service Space
Ensure the needed spaces for installation and maintenance.
The ceiling is horizontal, and its structure can endure the weight of the indoor unit.
The outlet and the inlet are not impeded, and the influence of external air is the least.
The air flow can reach throughout the room.
The connecting pipe and drainpipe could be extracted out easily.
There is no direct radiation from heaters.
Below is the recommended duct installation method:
Air outlet Air inlet
Canvas tie-in Canvas tie-in
Air dust filter
checkingorifice
Isolation booth
Isolation booth
Keep min. 600*600 space for checking & maintenance:
Maintenance space
Maintenance space
checking port
600mm* 600mm
500mm or up
600mm or up
checking orifice
Confirm the minimum
drain tilt is 1/100 or more

MCAC-VTSM-2011-03 High static pressure duct unit
Piping circuit 125
5. Piping Diagram
MDV-D71T1/N1-B ，MDV-D80T1/N1-B ，MDV-D90T1/N1-B ，MDV-D112T1/N1-B ，MDV-D140T1/N1-B ，
MDV-D160T1/N1-B，
flare nut
flare nut
T2B
gas side
motor
heat exchanger
fan
EXV liquid side
T2
T1
MDV-D200T1/N1-B，MDV-D250T1/N1-B，MDV-D280T1/N1-B，
flare nut
flare nut
motor
heat exchanger
EXV
liquid side
flare nut
gas side
flare nut
liquid side
motor
fan
T2B
T2B
T2
T2
T1
T1
EXV

High static pressure duct unit MCAC-VTSM-2011-03
126 Wiring diagram
6. Wiring Diagram
MDV-D71T1/N1-B，MDV-D80T1/N1-B，MDV-D90T1/N1-B，

MCAC-VTSM-2011-03 High static pressure duct unit
Wiring diagram 127
MDV-D112T1/N1-B, MDV-D140T1/N1-B, MDV-D160T1/N1-B,

High static pressure duct unit MCAC-VTSM-2011-03
128 Wiring diagram
MDV-D200T1/N1-B, MDV-D250T1/N1-B, MDV-D280T1/N1-B,

MCAC-VTSM-2011-03 High static pressure duct unit
Fan performance 129
7. Fan Performance
How to Read the Diagram
The vertical axis is the External Static Pressure (Pa)while the horizontal axis represents the Air Flow (CMH).
The characteristic curve for the “Hi,” “Med, ” and “Lo ” fan speed control, The nameplate values are shown
based on the “Hi ” air flow.
Therefore in the case of 112T1 Type, the air flow is 1544 CMH , while the External Static Pressure is 90Pa at
“Lo ” position. And 2117 CMH @ 90Pa, at„Hi„position.
MDV-D71(80)T1/N1-B MDV-D90T1/N1-B
MDV-D112T1/N1-B MDV-D140T1/N1-B

High static pressure duct unit MCAC-VTSM-2011-03
130 Fan performance
MDV-D160T1/N1-B MDV-D200(250)T1/N1-B
MDV-D280T1/N1-B
If the external static pressure is too great (due to long extension of duct, for example), the air flow volume
may drop too low at each air outlet.
So there‟s a limit air flow volume line for each speed, which is the min. airflow of this duct unit. At this flow
volume, the fan achieve the max. ESP, and indoor evaporator may protect by low temp.
As well, there‟s a limit airflow volume, which is the max. Value at each speed. It request the unit to connect
duct for air-inlet and outlet, to prevent damage from the high temp. of motor/evaporator.

MCAC-VTSM-2011-03 High static pressure duct unit
Capacity table 131
8. Capacity Tables
8.1 Cooling TC: total capacity SC: sensible capacity
WB: wet-bulb temperature DB:dry-bulb temperature
Indoor
Unit size
(kW)
Outdoor
temperature
(℃DB)
Indoor temperature (℃WB/DB)
14/20
16/23
18/26
19/27
20/28
22/30
24/32
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
7.1
10.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
12.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
14.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
16.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
18.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
20.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
21.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.6
1.7
1.5
1.4
23.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.5
1.6
1.5
1.4
25.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.5
1.6
1.5
1.4
27.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.5
1.6
1.5
1.4
29.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.4
1.5
1.5
1.4
31.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.4
1.5
1.5
1.4
33.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.4
1.5
1.5
1.4
35.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.3
1.5
1.5
1.4
37.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.3
1.5
1.5
1.4
39.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.2
1.6
2.3
1.5
1.5
1.4
42.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.2
1.6
2.3
1.5
1.5
1.4
44.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.2
1.6
2.3
1.5
1.5
1.4
46.0
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.2
1.6
2.3
1.5
1.5
1.4
8.0
10.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
12.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
14.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
16.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
18.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
20.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
21.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.2
1.9
1.7
23.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.3
2.1
1.9
1.7
25.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.2
2.1
1.9
1.7
27.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.2
2.1
1.9
1.7
29.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.1
2.0
1.9
1.7
31.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.1
2.0
1.9
1.7
33.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.1
2.0
1.9
1.7
35.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.0
1.9
1.7
37.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.0
1.9
1.7
39.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.1
1.9
1.7
42.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.1
1.9
1.7
44.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.1
1.9
1.7
46.0
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
2.9
2.0
3.0
2.1
1.9
1.7
9.0
10.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
12.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
14.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
16.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
18.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
20.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
21.0
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.3
2.6
2.5
2.1
