Meco YF-128 User manual

User Manual
E-mail: [email protected]
Facebook: @mecodirect
Website: http://www.meco-ele.com/
Handheld Steam IRON
YF-128

Handle 90-degree rotation
Hanging, flat and dry ironing available
Intelligent digital display with adjustable temperature
Three-stage steam on-demand regulation
APO (Automatic Power Off) within 30 min when not in operation
Please keep this User Manual for future references .
Please read this User Manual carefully before using the steam iron .

6
1
12
2
34
5
7
8
9
10
11
14
17
13
16
15
English English
Precautions when it is used for the first time
◆ The water tank may have some water stains left after testing the steam iron, which
does not mean that you have bought a second-hand product.
◆ The garment steamer generates steam only at 180-200 degrees.
◆ It's normal to have a small amount of water droplets or steam and a small amount
of unpleasant odor when you just start to use the garment steamer.
◆ Clothes cannot be used before fully cleaned and dried; your clothes may discolor if
used with dirt and detergent residues.
◆ Keep buttons, collars, zippers, badges, etc. away from direct contact with the steamer.
◆ Do not use the ironing table or rack where there is no countertop available.
◆ When steam is ejected, there may be white particles, indicating mineral substances in
water, which is normal.
◆ If there are white particles left on your clothes, pat gently and the particles will fall off.
 Ⅰ. Precautions
Product ParametersⅡ. :
1. Water filler cover
2. 90-degree spin button
3. Steam adjuster button
4. Power switch (temperature adjuster) button
5. Handle cap
6. Power cord sheath
7. Handle lower cover
8. Steam switch
9. Decorative cover
10. Water tank
11. Heat shield
12. Heating panel
13. Measuring glass
14. Flat ironing plate
15. Brush
16. Main steamer base
17. Travel bag
◆ Product Name: Handheld Steam Electric Garment Steamer
◆ Product Model: YF-128
◆ Rated Voltage: 110V~220V
◆ Rated Frequency: 50Hz
◆ Rated Power: 1400W
Steam quantity: first gear◆
Precautions for subsequent use:
1. Unplug the power supply and then install/disassemble the brush or ironing plate after
the garment steamer has been cooled completely;
2. The power supply will be cut off within 30 minutes of inactivity;
3. Use steam 30mm/2 inches away from garments; otherwise, uneven marks are left if
the steam is used too close.
(Note) If your clothes have an unpleasant odor or some evident creases left , please
set the temperature higher.
Ⅲ. Product Structure (Schematic)
-1- -2-

English English
Ⅳ. Brush Assembly/Disassembly
Assembly:
a. Select a brush or ironing plate as required.
b. First insert the flat ironing plate or brush button into the groove in the front of the
garment steamer body (as illustrated).
Disassembly: Push the flat ironing plate or brush against the handle until it has been
pushed out.
Open the water tank cover and point the measuring cup at the water inlet to fill with water
The water level should not exceed the maximum capacity of the water tank. Cover the
water tank once full and then dry the tank surface. Never add water to the water tank
from the tap directly.
See the figure below:
Ⅴ. Filling the water tank
Ⅵ. Uses of Electric Garment Steamer Functions
- Instructions to Ironing Use
1. When the product is connected with the power supply, the indicator will flash for one
second and then will go out.
2. Startup/Shutdown: Press the switch button for 5sec to start up or shut down the
equipment.
3. Temperature Switching: This product has seven choices of temperature: 80/100/120/
140/160/180/200℃ (176/212/248/284/320/356/392°F), which can be switched on by
pressing the switch button shortly after the equipment is started.
4. Temperature Indicator: During preheating, the temperature indicator will be flashing
continuously and you can put the iron on its base for heating. Moreover, the indicator
light will remain on steadily when the ironing board has reached the set temperature
value. Once it is solidly lighted, you can begin to steam your clothes.
5.When your iron is not in use, you can place it on its base. To add water to the water
tank, please place your iron vertically on its base. If tilted, the water may leak from the
cover edge when the water level is too high.
After use, please press the power switch for 5 seconds to turn off the steam iron or
unplug its power supply. Pour out the water remaining in the water tank and store the
electric iron properly until it has completely cooled down.
Disassemble
Assembl
-3- -4-

English English
- Instructions to Steaming Use
1. The ironing plate supports 90-degree rotation and can be adjusted by pressing the
spin button. See the figure below for details.
2. Install its anti-scalding board or brush.
3. Connect the power supply and press the power switch for 5 seconds to start your
steamer. Adjust the temperature to 180/200 degrees Celsius (356/392 Fahrenheit),
when the temperature indicator stops flashing, you can press the steam button to start
steaming. (Steaming function is available only at 180/200℃ (356/392°F).)
4.There are three types of steam flows adjustable by clicking the button for steam flow
to adjust it as needed. Then, press the steam switch and you can begin steaming.
Operation Methods:
When steaming, straighten the clothes to be steamed with one hand, hold the garment
steamer with the other hand, let the steam outlet close to your clothes and move the
garment steamer up and down repeatedly, especially for thicker clothes.
5. When the steamer is not in use, it can be rested on its base. To fill the water tank,
please place your steamer vertically on its base. If tilted, the water may drip from the
cover edge when the water level is too high.
After use, please press the power switch for 5 seconds to turn off the garment steamer
or unplug its power supply. Pour out the water remaining in the water tank and store the
electric steamer properly until it has completely cooled down.
Note: In order to avoid damages to your clothes
and ironing plate, please do not allow
the sprinkler to remain immobile atop the
same place for more than 30 seconds..
For a garment steamer, after long-term use of tap water, scale will accumulate in the
steam chamber. To reduce scale formation , you can use filtered water, mineral water or
distilled water. As recommended, you should remove the water scale at least twice a
year as follows:
1. For maintenance, unplug the power supply, let it cooled completely and then add
vinegar diluted with water into the water tank (according to the proportion - white
vinegar: water = 1:2);
2. Connect the power supply, turn on the steam switch after the garment steamer has
been heated enough, let it jet steam for about 5 minutes continuously and then turn off
the steam switch;
3. Pour out the vinegar water remaining in the tank. Rinse the tank with clean water until
there is no smell of vinegar. 1 hour later, you can fill it with clean water for reuse.

1. When cleaning the garment steamer brush/electric steamer, please make sure that it
has cooled completely. Clean it with a wet cloth. If necessary, use a neutral detergent.
Never use any strong detergent.
2. If a paste or other residue forms on the baseplate, it can be easily wiped clean with a
wet cloth. Do not use metal sheets to clean it to avoid scratching the smooth surface.
Also, avoid placing the electric steamer on any rough surface. If you steam synthetic
fabric at high temperature, it may not only damage the fabric, but also stain the baseplate
with fabric residues. In this case, it is best to place an old cloth over your clothes before
ironing.
3. Store this product on a dry horizontal surface. When not in use, disconnect its power
supply, drain the water in the water tank and assure no water drops are left on or in the
iron.
Ⅶ. Water Scale Removal
Ⅷ. Storage and Maintenance of Hand-held Garment
Steamer
Press the
button down
The body rotates
leftwards for 90 degrees
-5- -6-

English English
Ⅷ. Instructions to Temperature Settings
Refer to the following table contents for type of clothing:
◆
◆ If there is no ironing label attached, please strictly follow the temperature applicable
to all kinds of fibers. For blended clothing, please use a lower temperature.
◆ For silk, wool and chemical fibers, etc., which are not very heat-resistant, please place
a cloth over your clothes or test in a place on the garment not easily visible to make sure
the steamer can be used to iron that garment without damaging it.
◆ Please remember never keep your steamer immobile on your clothes for long; otherwise,
your clothes may be seriously damaged. Use continuous motion constantly!
Never steam vinylon.
Ⅸ. Troubleshooting
If a fault, as you think, occurs, you can read the following questions and answers to see
whether they are helpful or you can contact MECO support.
Please do not disassemble the body or repair the garment steamer on your own.
FAQ Please check as follows
Not hot enough
The water pump
does not work
No or insufficient
steam emitted
There is a smell
of burning cloth
White powder occurs
when steam is ejected
The water tank is
leaking
◆ Please check whether the product has started working
(Press 5 seconds to start it).
◆ Please check whether the power supply is connected
or the plug is used correctly.
◆ Please check whether the temperature has been set
available to steam ironing. Steaming function is
available only at 180/200℃ (356/392°F).
◆ Please adjust the steam temperature to 180 or 200℃
(356 or 392°F).
◆ Check whether the steam outlet is blocked by anything,
and if so use a toothpick or other hard object to remove
foreign matters (if any).
◆ Check whether there is sufficient water in the water
tank; if not enough, please add more water.
◆ Check whether there is rubbish left in the water tank.
Please remove the rubbish (if any) and refill it with tap
water.
◆ Check whether you have the correct temperature
setting for the type of clothing (can refer to the label
where the temperature stated for best use of the
steamer).
◆ This is a normal mineral substance in water. In case it
sticks to your clothes, tap it gently and you can wipe it
off.
◆ Check whether the water level exceed the maximum
capacity of the water tank. or the steam iron is tilted.
Temperature setting Ironing instructions Fabric ironing label
200℃
( 392℉ )
120℃/140℃
（248/284℉ )
80℃/100℃
（176/212℉ )
160℃/180℃
（320/356℉ )
Suitable for garment steamer ironing
and dry ironing of special high-
temperature fabrics.
Cotton cloth, linen and flocks
Steam ironing is not applicable to silk,
wool, nylon and rayon
Steam ironing is not applicable to
chemical or propylene fibers.
