Meco 5024 Quick setup guide

P/N 03.5774.02
20110511

-NOTICE-
MECO CORPORATION STRIVES TO BE A QUALITY SUPPLIER OF CONSUMER PRODUCTS. IF WE OMITTED ANY PARTS NEEDED
FOR ASSEMBLY, OR YOU NEED TROUBLESHOOTING INFORMATION, PLEASE CONTACT US USING OUR TOLL FREE NUMBER
OR VISIT OUR WEBSITE, WITH MANUAL AND GRILL MODEL NUMBER AVAILABLE FOR REFERENCE.
THANK YOU FOR PURCHASING A MECO CORPORATION PRODUCT.
IT IS IMPORTANT TO REGISTER YOUR GRILL AT OUR WEBSITE AND RETAIN YOUR RECEIPT.
1-(800)-251-7558 (U.S. and Canada)
8 am - 5 pm E. S. T. Mon.-Fri.
1-(423)-639-1171 (Telephone)
1-(423)-639-2570 (Fax)
www.aussiegrills.com
CONSUMER SERVICE DEPARTMENT
MECO CORPORATION
1500 INDUSTRIAL ROAD
GREENEVILLE, TN 37745 USA
MODEL 5024/5025
ASSEMBLY INSTRUCTIONS
TOOLS NEEDED: Phillips screwdriver, 3/8” open-end wrench
or pliers.
Step 1. Take all parts out of the box and lay them on a
smooth, clean surface. For helpful hints on how to assemble
your smoker, read the next few pages before you start.
NOTE: The parts you need depend upon which model
smoker you have. Look on the carton UPC LABEL and
match the model number to the one shown on the Parts
List. The parts under your model are the ones you need.
Do not throw away packaging until you have finished
assembly.
Step 2. Turn Body Assembly (1) upside down.
Put Bolt (3) through lower hole of Body, through bottom
hole of Leg (4-5). Attach Lock Nut (6). Put Bolt (3)
through hole in Body through top hole Leg. Attach Lock
Nut (6), tighten Bolts and Nuts. Repeat for other Bolts,
Lock Nuts, and Legs to the Body.
Stand Body Assembly on the Legs.
----------------------- -------------- ---- ---- ---- ----
