OWNERS MANUAL
SERENA & SOFIA RISER RECLINER
ARMCHAIRS

SERENA & SOFIA RISER RECLINER ARMCHAIRS
Serena:- Button Back, Standard Back & Waterfall Back
Sofia, Button Back
Introduction
The Serena is supplied with single or double motors . The single motor chair is available in a range of 3 different
coloured fabrics (mocha, cinnamon, oatmeal) and a wine coloured vinyl. The dual motor chair is available in a
range of 3 different fabrics (mocha, cinnamon, oatmeal). The sofia is available with a single motor and 3
different fabrics (mocha, cinnamon, oatmeal).
The battery back up system on the Serena/Sofia enables the chair to be raised and lowered at least 3 times, in
the event of a power failure.
The Serena/Sofia are E marked and are flame retardant in accordance with BS 7176 : 2007
-
Medium
Dual Motor hair
(shown right)
MOD
ELS AVAILABLE
Model No.
Description
Motor
Style/Back
Colour
920B1C5 SEREN - fabric SINGLE BUTTON CINN MON
920B2C5 SEREN - fabric SINGLE BUTTON MOCH
920B3C5 SEREN - fabric SINGLE BUTTON O TME L
920S1C5 SEREN - fabric SINGLE ST ND RD CINN MON
920S2C5 SEREN - fabric SINGLE ST ND RD MOCH
920S3C5 SEREN - fabric SINGLE ST ND RD O TME L
920W1C5 SEREN - fabric SINGLE W TERF LL CINN MON
920W2C5 SEREN - fabric SINGLE W TERF LL MOCH
920W3C5 SEREN - fabric SINGLE W TERF LL O TME L
920W4C5 SEREN - vinyl SINGLE W TERF LL WINE
922B1C5 SOFI - fabric SINGLE BUTTON CINN MON
922B2C5 SOFI - fabric SINGLE BUTTON MOCH
922B3C5 SOFI - fabric SINGLE BUTTON O TME L
923W1C5 SEREN - fabric DU L W TERF LL CINN MON
923W2C5 SEREN - fabric DU L W TERF LL MOCH
923W3C5 SEREN - fabric DU L W TERF LL O TME L

SERENA & SOFIA RISER RECLINER ARMCHAIRS
On receipt of your Riser Recliner Armchair, you will be in possession of the following parts:- Seat
Base, Backrest, Transformer, Handset, Head and Arm overs & Batteries.
Assembly Instructions
1. Working at the back of the chair, untie cable ties and connect lead to the Transformer (fig 1).
2. Remove cover and connect batteries to Transformer (fig 2). Batteries can be found in side pocket of
chair.
3. Plug into mains (fig 3). Your Days Healthcare Lift & Recline hair operates on standard household
electric.
4. Remove handset from side pocket.
5. Before fitting backrest, recline the chair via the handset .
6. lip backrest onto base, ensuring both receivers lock into the brackets (fig 4).
Operation
To allow for sufficient room for the backrest to recline, the chair must be placed at least 46cm (18”) at the rear from
a wall or surrounding furniture. Your Lift-Recline hair is operated by a hand control located on the right hand side
of the chair.
The handset for the single motor chair has 2 buttons (fig 5). One will lower and recline the backrest and the other
will raise and incline the seat. The chair will only move when the selected button is continuously pressed. To stop in
any position, simply release the button. To recline the chair, press the “down” button and hold, until the backrest is
in the required position. To raise the chair, press the “up” button and hold until the seat is in the raised position. The
handset for the dual motor chair has 5 buttons.
Note:- If Riser Recliner does not operate, check thoroughly that the above assembly
instructions have been administered.
?
(f i g 5 )

SERENA & SOFIA RISER RECLINER ARMCHAIRS
Caution
When raising the chair seat, always keep your feet In contact with the ground. Do not operate the chair unless you are
certain there are no children or pets anywhere near or at the rear of the chair. Do not allow any liquids to come in
contact with the hand control and any spilt drinks or fluids on the seat are to be immediately removed to avoid
possible contact with the electrics underneath. Remove power supply immediately.
Battery Back-Up Supply
In the event of a mains power supply failure, your chair will automatically be operated from the battery supply system.
The batteries should be fitted to the transformer. They will not be connected at time of shipping from Days
Healthcare. Please ensure that the batteries are connected to the transformer, before use and that they remain
connected. Replacement batteries can be sourced from your local shop or supermarket and we advise you to replace
them every two years or immediately after use to ensure adequate supply of power in the event of a mains supply
failure.
Maintenance and Cleanin
Your chair does not require any routine or regular service. In the event of a fault, please contact your Supplier or local
Days Healthcare Agent. The motor and folding mechanism requires no cleaning. The upholstery can be cleaned with
light sponging of warm soapy water or domestic upholstery cleaner. Do not use bleach base cleaners to avoid
discolouration.
Warranty
The Days Healthcare range of Lift-Recline hairs are warranted for two years from date of purchase against faulty
workmanship or materials on the frame, mechanics and electric controls. Note - Wear and tear on the upholstery is not
covered. Please contact your Supplier/Dealer should a fault occur. The warranty does not extend to the consequential
costs resulting from fault clearance, in particular freight and travel costs, loss of earnings, expenses etc. The
manufacturer will not accept responsibility for any damages or injury caused by misuse or non-observance of the
instructions set out above.
Disposin of the Riser Recliner Armchair
The hair consists of metal and plastic components, electronic components, electrical cables and batteries. Disposal of
the individual materials must be carried out in accordance with environmental and disposal regulations in the relevant
country, and may only take place after the riser recliner chair has been dismantled. To dismantle the chair and to
separate and dispose of the materials, you would be advised to hand it over to your specialist dealer. Batteries may not
be disposed of in domestic waste, and must be disposed of according to national regulations.
Specification
Serena
-
single motor
Serena
-
double motor
Sofia
Max User Weight 160 Kg (25 st) 160 Kg (25 st) 115 Kg (18 st)
Overall Width 95cm (37 1/2”) 96.5cm (38”) 78cm (30 3/4”)
Overall Depth Upright 90cm (35 1/2”) 78.75cm (31”) 84cm (33”)
Overall Depth Reclined 172cm (67 3/4”) 185cm (73”) 155cm (61”)
Overall Height 120cm (47 1/4”) 109cm (43”) 101cm (40”)
Seat Width 53cm (20 3/4”) 53.25cm (21”) 45cm (17 3/4”)
Seat Depth 50cm (19 3/4”) 46cm (18”) 48cm (19”)
Seat Height 47cm (18 1/2”) 49.5cm (19 1/2”) 46cm (18”)
