Medion Navigation Unit User manual

Contents:
Safety and Maintenance .....................................................1
Safety Instructions............................................................. 1
Data Security.................................................................. 2
Operating Environment..................................................... 2
Repair............................................................................ 2
Ambient temperature ....................................................... 3
Electromagnetic Compatibility ........................................... 3
Connection ..................................................................... 4
Battery Operation ............................................................ 5
Maintenance...................................................................... 6
Care of the Display............................................................. 6
Transport ....................................................................... 7
Notes on these Operating Instructions .................................. 8
Quality........................................................................... 8
Service .......................................................................... 8
Supplied Items .................................................................. 9
Views ...............................................................................10
Front Components ........................................................... 10
Model A........................................................................ 10
Model B........................................................................ 10
Back Components ............................................................ 12
Model A........................................................................ 12
Model B........................................................................ 12
Bottom Components......................................................... 13
Model A........................................................................ 13
Model B........................................................................ 13
Left Components ............................................................. 14
Model A Model B...................................................... 14
Right components ............................................................ 15
Model A Model B...................................................... 15

ii
Initial Set-up....................................................................16
I. Charging the battery ..................................................... 16
AC Adapter ................................................................... 17
Car Adapter .................................................................. 17
II. Switching on the navigation system ............................... 18
III. Installing the Navigation software ................................. 19
Operating .........................................................................20
Switching on/off the divice ................................................ 20
Working with Memory Cards .............................................. 21
Inserting Memory Cards ................................................. 21
Removing Memory Cards ................................................ 21
Accessing Memory Cards ................................................ 22
Data exchange via card reader ........................................ 22
Synchronisation with the PC .............................................. 23
I. Installing Microsoft®ActiveSync®.................................. 23
II. Connecting with the PC .............................................. 24
III. Working with Microsoft®ActiveSync®.......................... 24
Resetting the navigation system ........................................ 25
Soft Reset .................................................................... 25
Hard Reset ................................................................... 25
Navigation........................................................................26
Safety Instructions for Navigation ...................................... 26
Tips for Navigation......................................................... 26
Notes for Use in a Vehicle ............................................... 27
Additional Notes for Use on a Bicycle or a Motorcycle .............. 27
Aerial Orientation............................................................. 28
Model A........................................................................ 28
Model B........................................................................ 28
I. Mounting the car holder ................................................. 29
II. Fixing the suction plate................................................. 31
III. Attach Navigation System............................................ 31
IV. Connecting the car adapter .......................................... 32
V. Starting the navigation software..................................... 33

iii
MP3-Player.......................................................................34
Main Screen Overview ...................................................... 34
Play list ........................................................................ 36
FAQ ..................................................................................37
Customer Service .............................................................38
First-Aid in the Event of Malfunction ................................... 38
General guidance........................................................... 38
Check Connections and Cables ........................................ 38
Faults and Possible Causes ................................................ 39
Additional Support ........................................................... 40
Appendix ..........................................................................41
GPS (Global Positioning System) ........................................ 41
External GPS antenna .................................................... 42
TMC (Traffic Message Channel) .......................................... 43
Installing the External TMC Receiver................................. 44
Additional card material .................................................... 45
Transfer of card material to a memory card ....................... 45
Attachment to a Bicycle .................................................... 47
Warranty ........................................................................ 48
Liability limitations......................................................... 49
Copying this manual ...................................................... 49
Index ...............................................................................51

iv
Device
At the end of its life, the appliance must not be disposed of in household rubbish. Enquire
about the options for environmentally-friendly disposal
Batteries
Do not dispose of used batteries in the household rubbish! They must be deposited at a collec-
tion point for used batteries.
Copyright © 2005, All rights reserved. Microsoft®, MS-DOS®, and Windows are registered
trademarks of Microsoft Corporation in the U.S. and other countries. Pentium®is a registered
trademark of Intel Corporation. The names of actual companies and products mentioned
herein may be the trademarks of their respective owners. Information in this document is
subject to change without notice

SAFETY AND MAINTENANCE
1
S
SA
AF FE ET TY Y A AN ND D M
MA
AI IN NT TE EN NA AN NC CE E
SAFETY INSTRUCTIONS
Please read this section carefully and follow all the instructions
given. This will help ensure reliable operation and extend the ser-
vice life for your appliance.
Keep the packaging and the user instructions for future reference
or inquiries at a later date. If you pass the article on to another
person, you must pass on these instructions.
•Never open up the housing of the appliance or the power
adapter. These contain no user-serviceable parts. If the
housing is opened there is a danger to life from electric
shock.
•Do not place any objects on the appliance and do not exert
any pressure on the display. Otherwise there is a danger
that the screen will break.
•To avoid damage, do not touch the screen with sharp ob-
jects. Use only the stylus provided (if also supplied) or an-
other blunt implement. The device can also be operated
with a finger in many cases.
•There is a risk of injury if the display breaks. If this should
occur, use protective gloves to pack the broken parts and
contact customer support to arrange for disposal. Then
wash your hands with soap, since there is a possibility that
chemicals may have escaped.
•Never allow children to play with electrical equipment
unsupervised. Children may not always correctly recognize
possible danger.

ENGLISH
2
Remove the power adapter from the outlet, switch the appliance
off immediately, or do not actually switch it on, and contact Cus-
tomer Service...
... if the power adapter or the attached plug become scorched or
damaged.
... if the housing of the appliance or the Power Pack becomes
damaged or fluids leak into it. Components must be checked
by Customer Service in order to avoid damage!
DATA SECURITY
•Every time you update your data make backup copies on
an external storage medium. The supplier does not assume
liability for data loss or damage to data storage units, and
no claims can be accepted for damages resulting from the
loss of data or for consequential damages.
OPERATING ENVIRONMENT
Failure to follow these instructions may lead to damage to your ap-
pliance. The guarantee will be excluded in such cases.
•Keep your navigation System and all connected devices
away from moisture and avoid dust, heat and direct sun-
light, especially in the car.
•Make sure you protect your appliance from getting wet,
e.g. from rain and hail, at all times. Please pay attention
that moisture can even build up in a protective pouch be-
cause of condensation.
•Avoid heavy vibrations and shaking, such as can arise, for
example, in the case of transverse field intrusions.
•Avoid the device from releasing itself from its holder, for
example when braking. Install the device as vertically as
possible.
REPAIR
•Please contact our Service Center if you encounter techni-
cal problems with your appliance.
•In the event repair becomes necessary, please use only our
authorized Service Partners. You will find the address on
the back of your guarantee card.

SAFETY AND MAINTENANCE
3
AMBIENT TEMPERATURE
•The appliance is most reliably operated at an ambient tem-
perature of between 41°F and 104°F (5°C and 40°C) and
at a relative humidity of between 10% and 90% (non-
condensing).
•In the powered down state the appliance can be stored at
between 32°F and 140°F (0°C and 60°C).
•Store the appliance in a safe location to avoid high tem-
peratures (e.g. when parking or from direct sunlight).
ELECTROMAGNETIC COMPATIBILITY
•When connecting additional or other components the “Elec-
tromagnetic Compatibility Directive” (EMC) must be ad-
hered to. Please also note that only screened cable (maxi-
mum 10ft) should be used with this appliance.
•For optimal performance, maintain a distance of at least 10
ft. from sources of high-frequency and magnetic interfer-
ence (televisions, loudspeaker systems, mobile telephones
and so on. This will help avoid malfunctions and loss of da-
ta.
•Electronic devices emit electromagnetic waves during op-
eration.
These emissions are harmless, but can interfere with other
devices operated in close proximity.
While our devices are tested and optimized for electromag-
netic compliance in our laboratories, interference during
operation may still occur in the device itself and with other
devices in its proximity.
Should such interference occur, try to eliminate it by ad-
justing the positions of and the distances between the de-
vices.
Before driving a car, please ensure that the electronic sys-
tems of the car are working properly.

ENGLISH
4
CONNECTION
When connecting your appliance be sure to correctly observe the
following instructions:
POWER THROUGH CAR ADAPTER
•The car adapter should only be connected to the lighter so-
cket of a car (car battery = DC 12V , no trucks!). If you
are in any doubt about the power source in your car, con-
tact your car manufacturer.
POWER SUPPLY
•The outlet must be in the vicinity of the appliance and must
be easily accessible.
•Only use the mains adapter on grounded sockets at
100 – 240 V~ AC, 50/60 Hz. If you are unsure about the
power supply to the place of use, ask the relevant energy
supplier.
•Use only the power adapter provided with your appliance.
•For additional safety, we recommend the use of a surge
protector in order to protect your appliance from damage
from spikes or lighting strikes on the power network.
CABLING
•Arrange cables so that no-one can tread on them or trip
over them.
•Do not place any items on the cable.

SAFETY AND MAINTENANCE
5
BATTERY OPERATION
Your appliance is operated with a removable battery. In order to pro-
long the life and efficiency of your battery and to ensure safe opera-
tion, follow the instructions below:
Caution! Danger of explosion if rechargeable batter-
ies are not changed properly. Only replace with the
same type of battery or a similar type recommended
by the manufacturer. Never open the rechargeable
battery. Do not throw the rechargeable battery into
fire. Dispose of the used batteries following the
manufacturer's instructions.
•Batteries cannot withstand heat. Avoid the appliance and the
integrated battery becoming overheated. Failure to comply
with this instruction may lead to damage to and even explo-
sion of the battery.
•Use only the original power pack to charge the battery or the
car adapter from the optional navigation kit.
•The batteries are special category waste. When dis-
posing of the appliance ensure that this is done correctly.
Contact Customer Service for more details.
!

ENGLISH
6
MAINTENANCE
Warning: There are no user-serviceable or clean-
able parts inside the housing of the appliance.
You can prolong the life of the appliance by taking the following
simple steps:
•Always remove the power plug and all connecting ca-
bles before cleaning.
•Clean the appliance only with a damp, lint-free cloth.
•Do not use solvents, caustic or gaseous cleaners .
•The device and its packaging are recyclable.
CARE OF THE DISPLAY
•Avoid scratching the display surface as this is easily dam-
aged. It is strongly recommended to use a display protec-
tion mylar to avoid scratches. Please ask your nearest
dealer for this accessory.
The foil on the display at delivery is purely for protection
during transportation!
•Ensure that no traces of water remain on the screen. Wa-
ter can cause irreversible discoloration.
•Use only a soft, lint-free cloth to clean the screen.
•Do not expose the screen to either strong sunlight or ul-
traviolet radiation.
!

SAFETY AND MAINTENANCE
7
TRANSPORT
If you wish to transport the appliance follow the instructions below:
•Following transport of the appliance wait until the unit has
acclimatized before using it.
•In the case of wide fluctuations in temperature or humidity
condensation or moisture may form inside the appliance
and this can cause an electrical short-circuit.
•In order to protect the appliance from dirt, knocks and
scratching, use either the protective case.
•Before travelling ensure that you are aware of the power
and communications provision at your destination. Before
travelling obtain any power or communications adapters
(modem, LAN, etc.) that may be needed.
•When shipping your appliance use only the original pack-
aging and advise the carrier accordingly.
•When passing through the hand luggage control at air-
ports, it is recommended that you pass the appliance and
all magnetic storage media (external hard drives) through
the X-ray system (the machine on which you place your
bags). Avoid the magnetic detector (the structure through
which you yourself pass) or the magnetic wand (the hand
device that the security staff use), since this may corrupt
your data.

ENGLISH
8
NOTES ON THESE OPERATING INSTRUCTIONS
We have structured these Operating Instructions for the installa-
tion so that you will be able to look up the necessary subject-
related information by means of the Contents List at any time.
Note: You will find comprehensive Operating Instruc-
tions for navigation on the relevant CDs and at the
online help of the device.
Read the section "Frequently Asked Questions" to obtain answers
to questions that are often addressed to our customer service.
The purpose of this manual is to help you with installing your
appliance using instruction, that are easy to understand.
QUALITY
In selecting the components we have aimed for a high level of
functionality, simple handling, safety and reliability. A well-
balanced hardware and software design allows us to offer you a
technologically advanced navigation system that will give great
satisfaction in both work and leisure use.
SERVICE
Our individual customer care is there to support you when you
have questions or problems. Please get in touch – we look forward
to helping you. This manual contains a special section on Cus-
tomer Service starting on page 38.

SAFETY AND MAINTENANCE
9
SUPPLIED ITEMS
Please check the integrity and completeness of the supplied items
and, in the case this is not complete, forward us any possible
claims within 14 days from the purchase date. The purchase pa-
ckage includes:
•Navigation system
•AC adaptor (Phihong PSC05R-050)
•Support CD
•CDs with navigation software
•Car holder
•Power cable for 12V cigarette lighter
•Instruction manual and warranty card
•USB-cable
Optional
•Bicycle fixture
•Protective case / storage pocket
•Pre-installed memory card MMC/SD
•External GPS antenna
•External TMC receiver

ENGLISH
10
V
VI
IE EW WS S
FRONT COMPONENTS
MODEL A
MODEL B
n
p
q
r
o

VIEWS
11
Ref Component Description
nBattery Charge
Indicator
The loading display will shine orange during
the charging process. It will shine green
when the accumulator is completely
charged.
oTouch Screen Displays the output of your appliance. Tap
the screen with the stylus to select menu
commands or enter information.
On/Off Button
Button Settings*
Button Back
Button Options / Destination
Button to zoom out
pHardware
buttons
Button to zoom in
Moves up, down, left or right by pushing the
corresponding area of the pad.
qNavigationpad
Press the centre button to confirm your selec-
tion.
r
Loudspeaker Plays back music, language statements and
warnings.
*The key will only be operational after installation of the
navigation software.

ENGLISH
12
BACK COMPONENTS
MODEL A
MODEL B
Ref Component Description
nStylus Take the pen out of its compartment in or-
der to use it, and replace it after use. The
pointer pen is required for operating the
touch screen.
oMain switch/
Battery button
Separates the device from the battery
completely (also Hard Reset).
pGPS antenna The GPS antenna (fold-out in the case of
Model A) will receive the signals of GPS sat-
ellites.
qExternal
aerial connec-
tion
Connection for an optional second aerial.
n
o
q
p

VIEWS
13
BOTTOM COMPONENTS
MODEL A
MODEL B
Ref Component Description
nMini-USB-
Connector
Connection for connecting to a PC
by means of the ActiveSync®Cable
(for data matching).
oPower supply Connection to external power supply.
* The optional TMC receiver will be connected through the mini-
USB connection in the case of models with the possibility of TMC
upgrading (see Page 43). Your device can be upgraded by TMC if
the device specification (on the back of your navigation system)
shows a T(e.g. PNA220T).
no
no

ENGLISH
14
LEFT COMPONENTS
MODEL A MODEL B
Ref Component Description
nSD/MMC Slot Accepts an optional SD (Secure Digital) or
MMC (MultiMediaCard) card for removable
storage.
oReset Button Restarts your appliance. (Soft-Reset), see
page 25.
*The Reset Button can be located to the left
or also on the top of the device in the case
of Model A, according to the design.
n
o*

VIEWS
15
RIGHT COMPONENTS
MODEL A MODEL B
Ref Component Description
nVolume control Adjusts the volume of your device. Turn
the wheel upwards to increase the volume
and downwards to reduce it.
oEarphones Connects to a pair of stereo earphones
(3,5 mm).
n
o

ENGLISH
16
I
IN
NI IT TI IA AL L S
SE
ET T-
-U
UP P
The following guides you step by step through the initial set up of
the navigation system.
Firstly, remove the foil for protecting the device during transpor-
tation from the display.
I. CHARGING THE BATTERY
Attention: It can be necessary to recharge the bat-
tery for some time initially before it is possible to run
through the initial installation, according to the state
of charging of the battery installed.
You have different possibilities to charge the battery of your navi-
gation system:
•By means of the car adapter
•With the help of the AC adapter
Please pay attention to the following notes when handling the
battery:
•The charging status display lights orange until the naviga-
tion system is charged. Do not interrupt the charging
process before the battery is fully charged. This may take a
few hours.
The navigation system is fully charged if the charging display
lights green.
•Note: You can use the navigation system during the charg-
ing process, but the power supply must not be interrupted
during initial set-up.
•Leave the mains adapter connected to the navigation sys-
tem for around 24 hours, so that the backup battery also
charges-up fully.
•You can leave the main adapter connected, and this is very
handy for continuous operation. However, the mains
adapter also requires power even when it is not charging
up the battery of the navigation system.
•The battery will also be charging if the main switch is at
the OFF position.
!
