Medion Navigation UnitNavigation Unit User manual

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
Notes on these Operating Instructions
The operating instructions and installation guidelines have been organized so that subject-
related information can be easily found using the contents list.
Note
Comprehensive Operating Instructions for navigation can be found on the
DVD supplied, as well as online at www.medion.co.uk .
The section "Frequently Asked Questions" contains answers to questions that are fre-
quently addressed to our customer service department.
Document Your Navigation Unit
It is important to record the details of your Navigation Unit and the purchase thereof. In
the event you require warranty support you may be asked for this information. The serial
number can be found on the back of the device:
Serial Number ....................................................................................
Password ....................................................................................
Information note ....................................................................................
SuperPIN ....................................................................................
UUID ....................................................................................
Date of Purchase ....................................................................................
Place of Purchase ....................................................................................
Please record the serial number into any appropriate guarantee documents.
You will enter your own password and information note using the Security Function.
The SuperPIN and the UUID will be provided following the activation of the Security Func-
tion.
See Page 17.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-ii-
Quality
The components used have been selected to provide a product that has a high level of
functionality and is user friendly, safe and reliable. A well-balanced hardware and software
design allows us to offer you a technologically advanced navigation system, which is both
practical and enjoyable to use.
Service
Our customer care is there to provide support and assistance whenever you have ques-
tions or are experiencing problems.
This manual contains a section specific to Customer Service starting on page 41.
Copyright © 2008, version 30/10/2008. All rights reserved. Microsoft®, MS-DOS®, and Windows are
registered trademarks of Microsoft Corporation in the U.S. and other countries. Pentium®is a regis-
tered trademark of Intel Corporation. The names of actual companies and products mentioned herein
may be the trademarks of their respective owners. Information in this document is subject to change
without notice.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
- iii -
Contents
Safety and Maintenance ..................................................................................1
Safety Instructions ......................................................................................................... 1
Data Security................................................................................................................. 1
Operating Environment................................................................................................. 2
Repair............................................................................................................................ 2
Ambient temperature .................................................................................................... 2
Electromagnetic Compatibility ...................................................................................... 3
Connection ................................................................................................................... 3
Power supply through Car Adapter............................................................................ 3
Cabling .........................................................................................................................3
Information about the Regulatory Compliance according to R&TTE .............................. 4
Battery Operation.......................................................................................................... 4
Cleaning and Maintenance............................................................................................ 4
Care of the Display ........................................................................................................ 5
Recycling and Disposal.................................................................................................. 5
Transport ...................................................................................................................... 6
Supplied Items .............................................................................................................. 7
Views ...............................................................................................................8
Front Components ........................................................................................................ 8
Back Components ......................................................................................................... 9
Bottom Components................................................................................................... 10
Top Components ........................................................................................................ 10
Right Components ...................................................................................................... 11
Left Components......................................................................................................... 12
Initial Set up ..................................................................................................13
I. Charging the Battery ................................................................................................ 13
II. Power Supply .......................................................................................................... 14
Car Adapter.............................................................................................................. 14
Alternative possibility of charging the battery........................................................... 14
III. Switching on the Device ......................................................................................... 15
IV. Installing the Navigation Software .......................................................................... 16
General Operating Instructions .....................................................................17
Switching on/off the device......................................................................................... 17

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-iv-
Security .........................................................................................................19
Storing the password and the information note .......................................................... 19
Making settings........................................................................................................... 20
SuperPIN and UUID..................................................................................................... 21
Fingerprint Sensor ....................................................................................................... 22
Benefits of this technology ....................................................................................... 22
Storing a fingerprint .................................................................................................... 22
Making subsequent settings........................................................................................ 24
Password Request ....................................................................................................... 25
Resetting the Navigation System ................................................................................. 26
Soft Reset .................................................................................................................... 26
1. Possibility ............................................................................................................. 26
2. Possibility ............................................................................................................. 26
Switching the Device off Completely / Hard Reset ....................................................... 27
Navigation .....................................................................................................28
Safety Instructions for Navigation ................................................................................ 28
General Instructions ................................................................................................. 28
Notes for Use in a Vehicle ......................................................................................... 29
Aerial Orientation ........................................................................................................ 29
I. Mounting the Car Holder ......................................................................................... 30
II. Attaching the Navigation System ............................................................................. 31
III. Connecting the Car Adapter ................................................................................... 32
IV. Starting the Navigation Software ............................................................................ 33
Integrated FM Transmitter ............................................................................34
Starting the FM Transmitter......................................................................................... 34
Overview of the main screen ....................................................................................... 34
Description of the Interfaces ........................................................................................ 35
Selecting the frequency............................................................................................ 35
Speech commands .........................................................................................37
Handsfree Facility by means of Bluetooth ........................................................42
Starting the Bluetooth Application............................................................................... 42
Overview of the Main Screen ................................................................................... 43
Pairing the Navigation Device and the Mobile Phone ............................................... 44
Accepting incoming calls ......................................................................................... 45
Making Calls ............................................................................................................ 45
During a Call............................................................................................................ 46

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-v-
MP3 Player ....................................................................................................47
Main Screen Overview................................................................................................. 47
Select a Title and Move it into the List of Favourites.................................................. 49
List of Favourites ...................................................................................................... 50
List of the established bookmarks ................................................................................ 50
Picture Viewer ...............................................................................................51
Operating the Picture Viewer....................................................................................... 51
Main Screen ................................................................................................................ 51
Full Image View........................................................................................................ 52
Travel Guide ..................................................................................................54
Alarm Clock (waking function) .....................................................................55
Overview of the main screen ....................................................................................... 55
Description of the Interfaces ........................................................................................ 56
Setting the System Time........................................................................................... 57
Selecting an Alarm Signal......................................................................................... 58
Setting the Volume .................................................................................................. 58
Snooze Function ...................................................................................................... 59
Ending the Alarm Clock Application ......................................................................... 59
Sudoku ..........................................................................................................60
Main Screen ................................................................................................................ 60
Description of the switch fields.................................................................................... 60
FAQ ................................................................................................................62
Customer Service ...........................................................................................63
Faults and Possible Causes .......................................................................................... 63
Additional Support...................................................................................................... 63
Appendix .......................................................................................................64
Special CleanUp Function............................................................................................ 64
Synchronisation with the PC........................................................................................ 66
I. Installing Microsoft®ActiveSync®............................................................................ 66
II. Connecting with the PC ....................................................................................... 67
Alternative possibility of charging the battery........................................................... 67
III. Working with Microsoft®ActiveSync®.................................................................... 68
GPS (Global Positioning System) ................................................................................. 69
TMC (Traffic Message Channel)................................................................................... 70
Connecting an additional TMC Dipole Aerial............................................................ 71
Working with Memory Cards....................................................................................... 72
Inserting Memory Cards........................................................................................... 72
Removing Memory Cards......................................................................................... 72

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-vi-
Accessing Memory Cards ......................................................................................... 72
Data Exchange via Card Reader ................................................................................ 73
Additional Card Material.............................................................................................. 73
Transfer of card material to a memory card .............................................................. 73
Alternate method of installing Navigation Software (using a Memory Card) ........... 74
Transferring Installation Files and Map Material to the Internal Memory .................. 74
Specifications ................................................................................................75
Index .............................................................................................................76

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-1-
Safety and Maintenance
Safety Instructions
Please read this section carefully and follow all the instructions provided. This will help
ensure reliable operation and prolong the life for your appliance.
Keep the packaging and the user instructions for future reference or inquiries at a later
date. If you pass the article on to another person, you should pass on these instructions.
•Never allow children to play with electrical equipment unsupervised.
•Keep the packing materials, such as plastic bags away from children as there is a
danger of suffocation.
•Never open up the housing of the appliance or the power adapter. These contain
no user-serviceable parts. If the housing is opened there is a danger of electric
shock.
•Do not place any objects on the appliance and do not exert any pressure on the dis-
play. Otherwise there is a danger that the screen will break.
•To avoid damage, do not touch the screen with sharp objects. We recommend us-
ing only the stylus provided or finger when using the touch-screen functionality of
the product.
•There is a risk of injury if the display breaks. If this should occur, use protective
gloves to pack the broken parts and contact customer support to arrange for dis-
posal. Then wash your hands with soap, since there is a possibility that chemicals
may have escaped.
Remove the power adapter from the outlet, switch the appliance off immediately, or do
not switch it on, and contact Customer Service.
•If the housing of the appliance or the power pack becomes damaged or liquid may
have leaked into it the components must be checked by Customer Service in order
to avoid damage!
Data Security
•Every time your data is updated or modified backup copies should be made on an
external storage medium. The supplier assumes NO liability for data loss or damage
to data storage units, and no claims can be accepted for damages resulting from
the loss of data or for consequential damages.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-2-
Operating Environment
Failure to follow these instructions may lead to your appliance being damaged. In cases
where products are damaged as a result of misuse of neglect the associated guarantee will
be considered void.
•Keep your navigation System and all connected devices away from moisture and
avoid exposure to dust, heat and direct sunlight, especially in the car.
•Make sure you prevent your appliance from getting wet, e.g. from rain and hail, at
all times. Please note that moisture can even build up inside a protective pouch as a
result of condensation.
•Avoid heavy vibrations and shaking.
•Please note the device should be installed vertically, this will ensure that the device
remains secured within its holder.
Repair
•Please contact our Service Centre if you encounter technical problems with your
appliance.
•In the event a repair becomes necessary, please use Medion authorized Service
Partners. The address can be found on the back of your guarantee card or online at
www.medion.co.uk
Ambient temperature
•The appliance will operate effectively at an ambient temperature of between +32°F
and +95°F (0° C and 35° C) and at a relative humidity of between 10% and 90%
(non-condensing).
•In the powered down state the appliance can be stored at between -4°F and
+140°F (-20°C and +60°C).
•Store the appliance in a safe location, away from high temperatures (e.g. when
parking or from direct sunlight).

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-3-
Electromagnetic Compatibility
•When connecting additional or other components the “Electromagnetic Compati-
bility Directive” (EMC) must be adhered to. Please note that only screened cable
(maximum 10ft) should be used with this appliance.
•For optimal performance, maintain a distance of at least 10 ft. from sources of high-
frequency and magnetic interference (televisions, loudspeaker systems, mobile tele-
phones etc. This will help to avoid malfunctions and loss of data.
•Electronic devices emit electromagnetic waves during operation.
These emissions are harmless, but can interfere with other devices operated in close
proximity.
While our devices are tested and optimized for electromagnetic compliance in our
laboratories, interference during operation may still occur in the device itself and
with other devices in its proximity.
Should such interference occur, try to eliminate it by adjusting the positions of and
the distances between the devices.
Before driving, please ensure that the electronic systems of the car are working
properly.
Connection
When connecting your appliance it is important to observe the following instructions:
Power supply through Car Adapter
•The car adapter should only be connected to the lighter socket of a car
(car battery = DC 12V , truck battery = DC 24V !). If you are in any doubt about
the power source in your car, please contact your car manufacturer.
Cabling
•Arrange cables so that they do not cause unnecessary obstruction or risk entan-
glement or snaring. E.g. ensure that the cables cannot be trod on, or tripped over.
•Do not place any items on the cable.
•The device and its packaging are recyclable.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-4-
Information about the Regulatory Compliance according
to R&TTE
The company declares that this device is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. Complete declarations of conformity
are available under www.medion.com/conformity.
Battery Operation
Your appliance is powered by an integrated battery, Li-Ion. In order to prolong the life and
efficiency of your battery and ensure safe operation, follow the instructions below:
•Batteries cannot withstand excessive heat. Take care to avoid overheating of appli-
ance and the integrated battery. Failure to comply with this instruction may lead to
damage to or, even explosion of the battery.
•Only use the car adapter to charge the battery from the navigation kit.
•The batteries are special category waste. When disposing of the appliance en-
sure that this is done correctly. Contact Customer Service for more details.
Cleaning and Maintenance
Warning
There are no user-serviceable or parts which require cleaning inside the
housing of the appliance.
You can prolong the life of the appliance by taking the following simple steps:
•Always remove the power plug and all connecting cables before cleaning.
•Clean the appliance only with a damp, lint-free cloth.
•Do not use solvents, caustic or gaseous cleaners.
•The device and its packaging are recyclable.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-5-
Care of the Display
•Avoid scratching the display surface as this may be easily damaged. We recom-
mended using a display protection film (mylar) to prevent scratching to the screen.
Please contact your nearest dealer for this accessory.
The foil on the display at delivery is purely for protection during transportation!
•Ensure that no traces of water remain on the screen. Water can cause irreversible
discoloration.
•Use only a soft, lint-free cloth to clean the screen.
•Do not expose the screen to strong sunlight or ultraviolet radiation.
Recycling and Disposal
•The device and its packaging are recyclable.
Device
At the end of its life, the appliance must not be disposed of in household rubbish. Consult
your local waste disposal company to enquire about environmentally-friendly options for
disposal.
Packaging
To avoid damage during transport, the appliance is supplied in protective packaging. The
majority of packaging is manufactured from materials which can be disposed of in an
environmentally friendly manner and be recycled professionally.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-6-
Transport
When transporting the appliance please follow the instructions below:
•In the event of large fluctuations in temperature or humidity, condensation or
moisture may form inside the appliance. This can cause an electrical short-circuit.
•After transporting the appliance wait until the unit has acclimatised and adjusted to
surrounding conditions (e.g. room temperature and humidity) prior to use.
•In order to protect the appliance from dirt, knocks and scratching, please use an
appropriate protective case.
•Before travelling ensure that you are aware of the power and communications pro-
visions at your destination. Before travelling obtain any power or communications
adapters that may be required for the operation of your device.
•When shipping your appliance we recommend using the original packaging. If the
original packaging isn’t available please contact customer service for advice.
•When passing through baggage control at airports, it is recommended that you
pass the appliance and all magnetic storage media (external hard drives) through
the X-ray system (the machine on which your bags are placed). Avoid the magnetic
detector (the structure through which you yourself pass) or the magnetic wand
(the hand device that the security staff use), since this may corrupt your data.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-7-
Supplied Items
Please check the condition of items supplied and check for missing items using the list
below. If you find your package to be incomplete, please forward us all claims for missing
items within 14 days from the date of purchase.
The package should include the following:
•Navigation system
•Power cable for cigarette lighter
•USB cable
•TMC dipole antenna
•Car holder
•DVD with navigation software, digital maps, ActiveSync®, data for rapidly resetting
the contents of the memory card/internal memory
•Instruction manual and warranty card

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-8-
Views
Front Components
Ref Component Description
nTouch Screen Displays the output of your appliance. Tap on the
screen with the stylus (found in the holder, see page
31) to select menu commands or enter data.
oBattery charge
indicator
The LED will flash orange during the charging process.
It will shine constant green when the accumulator is
fully charged.
pBluetooth indicator This LED will blink at different speeds, according to the
connection status, if Bluetooth has been activated.
qMicrophone
n
q
op

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-9-
Back Components
Ref Component Description
nStylus Take the stylus out of it's compartment in order to
use it, and replace it after use. The stylus is required
for operating the touch screen.
oLoudspeaker Provides audible language statements and warn-
ings.
GPS
aerial
no

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-10-
Bottom Components
Ref Component Description
nExtension
socket
For the expansion for future components.
oMini-USB-
Connector
Connection for connecting to a PC by means of a USB
cable (for data transfer) as well as connection to exter-
nal power supply.
pTMC connection You also have the possibility to connect a TMC dipole
antenna here.
qHeadphone
connection
Connection for a pair of stereo headphones (3.5 mm).
Using this appliance at full or
high volumes for extended
periods of time may cause
damage to the hearing of the
listener.
Top Components
Ref Component Description
nOn/Off button Turn the device on or off by pressing and holding the
On/Off button. You will switch to the stand-by mode
or reactivate the device by quickly pressing the button
(> ½ sec.).
oFingerprint sensor See page 22
n o p q
no

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-11-
Right Components
Ref Component Description
nSD/MMC Slot Accepts an optional SD (Secure Digital) or MMC
(MultiMediaCard) card for removable storage.
n

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-12-
Left Components
Ref Component Description
nVolume control /
Activation of the
voice entry
(optional)
You can control the volume of your device as follows:
You can increase the volume by turning the wheel
upwards (+). You can reduce the volume by turning
the wheel downwards (-).
Press the wheel briefly to activate speech input
(optional).
oMain switch /
Battery switch
Switches the device completely off (Hard Reset).
pReset opening Restarts your appliance (Reset, see page 26).
n
o
p

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-13-
Initial Set up
The following is a step by step guide to assist in the initial Set-up of the navigation system.
Start by removing the protective plastic sheet from the display.
I. Charging the Battery
The battery of your navigation system can be charged in the following ways:
•Using the supplied car adapter,
•using a suitable USB cable or
•by using a mains adapter (purchased as an optional extra).
Attention!
It may be necessary to initially charge the battery for a considerable period
of time prior to commencing and running through the initial installation,
this is dependent on the level of charge held at the time by the internal
battery.
Please observe the following notes:
•The charging status display LED will flash orange until the navigation system is
charged. If possible, do not interrupt the charging process until the
battery is fully charged. This may take a few hours. The charging status LED will
shine constant green if the battery has a high level of charge. Leave the device
charging for 20 further minutes, to ensure the battery is charged-up fully.
•The navigation system can be used during the charging process, but the power
supply must not be interrupted during initial set-up.
•Leave the external power supply connected to the navigation system for around
24 hours, so that the backup battery also charges-up fully.
•The external power supply can remain connected; this is recommended for con-
tinuous operation.
•Even after a power source has been connected to the device it may take several
minutes until the device is once again ready to operate again, this occurs if the
charging state of the battery is exceptionally low. The battery will continue to be
charged if the power supply is connected and the device is switched off.

UK/ N. IRELAND HELPLINE 0871 37 61 020
REP. IRELAND HELPLINE 1-800-992508
-14-
II. Power Supply
Car Adapter
(similar picture)
1. Plug the jack (n) of the connection cable into the corresponding receptor at the
bottom of your navigation system.
2. Insert the power adapter (o) into the cigar lighter socket ensuring, that it will not
lose contact while driving. This could cause a malfunction.
Alternative possibility of charging the battery
The battery will charge as soon as you connect your navigation device to a switched-on PC
or notebook by means of a USB cable.
Please pay attention to the fact that both USB plugs of the USB cable supplied with the
device must be connected to your PC or laptop to guarantee a sufficient supply of electric-
ity.
No additional software or updates are required for your PC to perform this function. Do
not interrupt the charging process if possible during the initial charge.
Note
The brightness will be adjusted downwards, if necessary, if a USB connec-
tion is being set up when the device is switched on.
It is recommended to set the device to the stand-by mode, in order to
shorten the charging time by USB.
n
o
